EZ2250i/EZ2350i BARCODE PRINTER

USER MANUAL

User Manual

Version

Issue Date

P/N

: EZ2250i series

: Rev. E

: 2013.11.28

: 920-014611-00

Contents

EZ2250i/EZ2350i USER MANUAL

CONTENTS

Contents

. BOX CONTENT ............................................................................

1.1 Box Content ...............................................................................................................

1.2 Getting to Know Your Printer ..................................................................................

. PRINTER SETUP .............................................................................

2-1. Loading the label roll ...................................................................................................

2-2. Loading the ribbon.......................................................................................................

2-3. Connecting the printer to the host computer ..........................................................

2.4 Installing Printer Driver and GoLabel with Super Wizard CD ................................

. PRINTER SETTING AND CONTROL ............................................. 1

3-1. Operation Panel ......................................................................................................... 14

3-2. LCD Interface Introduction ....................................................................................... 15

3-3 LAN Setting ................................................................................................................... 20

3-4 LCD Password .............................................................................................................. 22

3-5. LCD Interface Function .............................................................................................. 24

3-6. Label Calibration and Self Test ................................................................................. 28

3-7. Dump mode ................................................................................................................ 30

3-8. Error Alerts .................................................................................................................... 31

3-9. USB Host ....................................................................................................................... 33

. NETSETTING FOR ETHERNET ....................................................... 3

4-1. Installing the NetSetting software ............................................................................. 35

4-2. The Interface of NetSetting ....................................................................................... 36

. ACCESSORIES ........................................................................... 4

5-1. Internal rewinder ......................................................................................................... 43

5-2. Installing the rewinder guide ..................................................................................... 45

5-3. Label dispenser ........................................................................................................... 46

5-4. Installing the cutter ..................................................................................................... 48

5-5. Installing the Parallel adapter ................................................................................... 50

. MAINTENANCE AND ADJUSTMENT .......................................... 5

6-1. Installing / removing the print head module .......................................................... 52

6-2. Adjusting the print line ............................................................................................... 53

6-3. Adjusting the ribbon tension ..................................................................................... 54

6-4. Cleaning the thermal print head ............................................................................. 55

6-5. Adjusting the balance and print head tension ...................................................... 56

6-6. Ribbon shield settings ................................................................................................. 57

6-7. Cutter settings ............................................................................................................. 58

6-8. Troubleshooting .......................................................................................................... 59

PPENDIX

Produkt Specifikationer

Mærke:	Godex
Kategori:	Etiketprinter
Model:	EZ2350i
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	274 mm
Dybde:	512 mm
Højde:	291 mm
Vægt:	15000 g
Produktfarve:	Sort
Wi-Fi:	Ingen
USB-port:	Ja
Opbevaringstemperatur (T-T):	-20 - 50 °C
Relativ luftfugtighed ved drift (H-H):	30 - 85 %
Relativ luftfugtighed ved opbevaring (H-H):	10 - 90 %
Antal USB 2.0-porte:	1
Ethernet LAN:	Ja
Driftstemperatur (T-T):	5 - 40 °C
Udskrivningsteknologi:	Direkte termisk/termisk overførsel
Maksimal opløsning:	300 x 300 dpi
Skærm:	LCD
Intern hukommelse:	16 MB
Forbindelsesteknologi:	Ledningsført
Certificering:	CE (EMC), FCC Class A, CB, cUL, CCC
Understøttede Windows-operativsystemer:	Windows 2000, Windows 7 Home Basic, Windows 8, Windows Vista Home Basic, Windows XP Home
Farve:	Ingen
Flashhukommelse:	8 MB
Indbygget processer:	32 Bit RISC CPU
Understøttede operativsystemer til servere:	Windows Server 2003, Windows Server 2008
Udskrivningshastighed:	127 mm/sek.
RS-232-porte:	1
Maksimal udskrivningsbredde:	104 mm
Maksimal rullediameter:	203.2 mm
Kernediameter:	76.2 mm
Medietykkelse:	0.06 - 0.25 mm
Maksimal udskrivningshøjde:	1143 mm
Indbyggede stregkoder:	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, MaxiCode, Micro QR Code, PDF417, POSTNET, QR Code
Båndbredde:	110 mm
Båndlængde:	450 m
Understøttede Windows kodesider:	1250, 1251, 1252, 1253, 1254, 1255,1257
