Side 1/35
GI3, GI6
INSTRUCTIONS FOR USE
Induction hob
We thank you for your trust and the purchase of our appliance.
This detailed instruction manual is supplied to make the use of this product easier. The
instructions should allow you to learn about your new appliance as quickly as possible.
Make sure you have received an undamaged appliance. If you do find transport damage,
please contact the seller from which you purchased the appliance, or the regional
warehouse from which it was supplied. The telephone number can be found on the
invoice or on the delivery note.
Instructions for use are also available at our website:
www.gorenje.com / < http://www.gorenje.com />
INFORMATION!
Information, advice, tip, or recommendation
WARNING!
Warning general danger–
Contents
41. Safety precautions ..........................................................................................................
62. Other important safety warnings ...................................................................................
62.1 Before connecting the appliance ....................................................................................
73. Induction hob installation ...............................................................................................
103.1 Flush-mount installation into the worktop .......................................................................
133.2 Fitting the foam gasket ....................................................................................................
134. Connecting the induction hob to the power mains ......................................................
134.1 Power cord ......................................................................................................................
144.2 Connecting the appliance ...............................................................................................
175. Appliance description .....................................................................................................
175.1 Before first use ................................................................................................................
186. Operating the cooking hob .............................................................................................
186.1 Control unit ......................................................................................................................
196.2 Powering on the induction cooking hob .........................................................................
196.3 Switching on the cooking zones .....................................................................................
196.4 Bridged cooking zone .....................................................................................................
206.5 Automatic rapid heating ..................................................................................................
216.6 Power Boost ....................................................................................................................
226.7 Child lock / lock ...............................................................................................................
226.8 Time functions .................................................................................................................
246.9 Residual heat indicator ....................................................................................................
246.10 Maximum cooking time ...................................................................................................
246.11 Overheat protection ........................................................................................................
246.12 Automatic switch off ........................................................................................................
256.13 Switching off the cooking zone .......................................................................................
256.14 Switching off the entire cooking hob ..............................................................................
267. User settings ....................................................................................................................
288. Tips and hints ..................................................................................................................
288.1 Cooking hob (conventional or glass ceramic) .................................................................
288.2 Induction cooking zone operating principle ....................................................................
298.3 Induction cookware .........................................................................................................
308.4 Energy saving tips ...........................................................................................................
319. Cleaning and maintenance .............................................................................................
3210. Problems and errors .......................................................................................................
3310.1 Noises during induction cooking .....................................................................................
3311. Technical data .................................................................................................................
3412. Disposal ............................................................................................................................
3
1. Safety precautions
IMPORTANT SAFETY PRECAUTIONS CAREFULLY READ–
THE INSTRUCTIONS AND SAVE THEM FOR FUTURE
REFERENCE.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
WARNING: The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching heating
elements.
Children less than 8 years of age shall be kept away unless
continuously supervised.
Do not use steam cleaners or high-pressure cleaners to clean
the appliance, as this may result in an electric shock.
The appliance is not intended to be controlled by external timers
or separate remote controll system.
Means for disconnection must be incorporated in the fixed
wiring in accordance with the wiring rules.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or. similarly qualified persons
in order to avoid a hazard (only for appliances supplied with
connection cord).
4
WARNING: If the surface is cracked, switch off the appliance
to avoid the possibility of electric shock. Switch off all cooking
zones using their respective controls and remove the fuse or
trip the main circuit breaker so that the appliance is fully isolated
from the power mains.
WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in fire. NEVER try to extinguish a fire
with water, but switch off the appliance and then cover flame
e.g. with a lid or a fire proof blanket.
WARNING: Danger of fire: do not store items on the cooking
surfaces.
CAUTION: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
CAUTION: This appliance is for cooking purposes only. It must
not be used for other purposes, for example room heating.
WARNING: Use only hob guards designed by the manufacturer
of the cooking appliance or indicated by the manufacturer of
the appliance in the instructions for use as suitable or hob
guards incorporated in the appliance. The use of inappropriate
guards can cause accidents.
Metalic objects such as knives, forks, spoons and lids should
not be placed on the hob surface since they can get hot.
After use, switch off the hob element by its control and do not
rely on the pan detector.
Appliance must be connected to fixed wiring which has
incorporated means of disconnection. Fixed wiring must be
made in accordance with the wiring rules.
5
3. Induction hob installation
30 cm
60 cm
80 cm
INFORMATION!
Installation of the appliance into a kitchen worktop and its connection to the power mains may
only be performed by an adequately qualifi ed technician.
7
Installation procedure
•Suitably protect the edges of the cut aperture.
•Connect the induction cooking hob to the mains power supply (see instructions for the connection
of the induction cooking hob to mains power supply).
•Place the induction hob into the cut aperture.
•Veneer or other fi nish of the piece of kitchen furniture into which the hob is to be built in should
be treated with heat resistant glue (100 °C); otherwise, the worktop fi nish may be discolored or
deformed.
•Use of solid wood corner trims on worktops behind the induction cooking hob is only allowed if
the clearance between the trim and the hob is no smaller than indicated on the installation plans.
INFORMATION!
The worktop has to be completely level.
•The induction hob is suitable for installation
into a worktop above a kitchen cabinet with
a minimum width of 600 mm.
•Any kitchen cabinetry suspended above the
induction hob should be high enough not to
disturb the work process.
•The vertical distance between the induction
hob and the kitchen hood must be at least
the distance specified in the instructions for
installation of the kitchen hood and no less
than 500 mm.
•The distance between the edge of the induc-
tion hob and the adjacent kitchen cabinet
should be no less than 40 mm.
•Minimum clearance between the induction
hob and the rear wall is indicated in the install-
ation diagram.
8
Lower cabinet with a drawer
•There must be an opening with a height of
no less than 140 mm along the entire width
of the cabinet in the cabinet rear wall. In ad-
dition, there should be an opening of at least
4 mm in the front side, along the entire width
of the cabinet.
•A horizontal partition panel should be in-
stalled underneath the induction hob along
its entire length. There should be at least
10 mm of clearance between the lower end
of the hob and the partition panel.
•Adequate ventilation should be allowed from
the rear side.
•If there is a drawer under the kitchen cabinet,
do not store aluminium foil or flammable
substances or liquids (such as sprays) in this
drawer. Keep such substances away from
the cooking hob. Danger of explosion!
Lower cabinet with an oven
•Installing an oven under the induction hob is
possible for oven models with a cooling fan.
•Before installing the oven, the kitchen cabinet
rear wall has to be removed in the area of the
opening for installation.
•In addition, there should be an opening of at
least 4 mm on the front side, along the entire
width of the cabinet.
•If other appliances are installed under the in-
duction cooking hob we cannot guarantee
their correct operation.
INFORMATION!
Normal operation of the induction cooking hob electronic components requires sufficient air
circulation.
9
3.1 Flush-mount installation into the worktop
30 cm
60 cm
80 cm
Appliances without faceted edges or decorative frames, are suitable for flush mounting.
Installation procedure
•The appliance may only be installed into a temperature- and water-resistant countertop, such as
a countertop made of natural stone (marble, granite) or solid wood (the edges along the cut-out
have to be sealed).
10
•When installing into a countertop made of ceramics, wood, or glass, a wooden sub-frame should
be used. The frame is not supplied with the appliance. The appliance may only be installed into
a countertop made of other materials after you have consulted the countertop manufacturer and
obtained his express approval.
•Internal dimension of the basic unit should be at least equal to the internal cut-out for the appliance.
This will allow simple removal of the appliance from the countertop.
•Attach sealing tape along the perimeter of the bottom of the glass panel.
1. First, feed the power cord through the cut-out.
2. Place the appliance over the centre of the cut-
out.
3. Connect the appliance to the power mains.
4. Test appliance operation.
5. Seal the slot between the appliance and the
countertop using a silicone sealant. The silicone
sealant used to seal the appliance has to be
temperature-resistant (to at least 160 °C).
6. Smooth out the silicone sealant using a suit-
able tool. Do not switch on the appliance until
the silicone sealant has dried completely.
1. Silicone sealant
2. Sealing tape
Stone countertop
WARNING!
Pay particular attention to built-in dimensions with (natural) stone countertops. When choosing
the silicone sealant, observe the countertop material and consult the countertop manufacturer.
Use of inappropriate silicone sealants can result in permanent discolouration of some parts.
1. Countertop
2. Appliance
3. Slot
Given the margin of error (tolerance) for the glass ceramic plate of the appliance, and the cutout in
the countertop, the slot is adjustable (min.2 mm).
11
Ceramic, wooden, or glass countertop
1. Countertop
2. Appliance
3. Slot
4. Wooden frame, thickness
16 mm.
Given the margin of error (tolerance) for the glass ceramic plate of the appliance, and the cut-out
in the countertop, the slot is adjustable (min. 2mm).
Install the wooden frame 5 mm below the upper edge of the countertop (see figure).
Observe the radii of glass edges (R10, R2) when making the cut-out.
CUT-OUTGLASS
Removing the built-in appliance
Disconnect the induction hob from the power mains. Use a suitable tool to remove the silicone gasket
from the perimeter. Remove the induction hobby pressing from the lower side upwards.
WARNING!
Do not attempt to remove the appliance from the upper side of countertop.
WARNING!
The service department shall only be responsible for repair and servicing of the induction hob.
Consult your specialized kitchen equipment dealer regarding the re-installation of the flush-mount
induction hob.
WARNING!
If the oven is installed under a flush-mounted induction hob, then the worktop thickness should
be at least 45 mm.
12
3.2 Fitting the foam gasket
Before installing the induction hob into a kitchen worktop, attach the foam gasket supplied with the
appliance to the bottom side of the hob. Some appliances come with the gasket already fitted!
1. Remove the protective film from the gasket.
2. Attach it to the bottom side of the glass surface, 2 3 mm away from the edge, along the entire–
perimeter of the glass panel.
3. The gasket may not overlap in the corners.
4. When fitting the gasket, make sure it is not damaged by or in contact with any sharp objects.
WARNING!
Do not install the appliance without the gasket!
4. Connecting the induction hob to the power
mains
•Power mains protection must conform to the relevant regulations.
•Before connecting the appliance, make sure the voltage specified on the rating plate conforms to
the voltage of the power mains.
•There should be a switching device in the electrical installation that can disconnect all poles of
the appliance from the power mains, with a minimum clearance of 3 mm between the contacts
when open. Suitable devices include fuses, protective switches etc.
•The connection should be adjusted to the current and fuses.
•After installation, the parts carrying electrical current and insulated parts shall be protected against
contact.
WARNING!
The appliance may only be connected by an authorised expert. False connection can destroy
parts of the appliance. In such case, there is no right to warranty! Disconnect the appliance from
the power mains before any repair or maintenance operation.
4.1 Power cord
(appliance without a power cord)
* Ferrules are not supplied.
13
INFORMATION!
We recommend using electric wire ferrules (end terminals).
•The following may be used for connection: PVC insulated connection cables type H05V2V2-F with
yellow-and-green protective conductor, or other equivalent or superior cables.
•Exterior cable diameter should be at least 8.0 mm.
•Run the power cord through a cord strain relief (clamp) which
4.2 Connecting the appliance
Connecting a 60-cm, 80-cm appliance
1. Open the cover of the connection terminal box.
2. Connect the wires according to your type of appliance. The jumpers are provided on the connection
terminal.
3. Run the power cord through a cord strain relief (clamp) that protects the cable from being pulled
out.
Connection diagram
Single phase connection (32 A)
• – –Single-phase connection (1 1N, 220 240 V~ /50 60 Hz):
- Voltage between line and neutral conductor is 220 240 V~. Install–
a jumper between terminals 1 and 2, and between terminals 4 and
5.
- The circuit should be fitted with a fuse of at least 32 A. Power cord
core cross-sectional area should be at least 4 mm².
2-phase connection (16A)
• – –2 phases, 1 neutral conductor (2 1N, 380 415 V~ /50 60 Hz):
- Voltage between the line and neutral conductor is 220 240 V~.;–
voltage between lines is 380 415 V~. Install a jumper between the–
terminals 4 and 5. The circuit should be fitted with at least two
fuses of at least 16 A each. Power cord core cross-sectional area
should be at least 1.5 mm².
• – –2 phases, 2 neutral conductors (2 2N, 220 240 V 2 2N ~ /50 60Hz):
Voltage between phases and neutral conductor is 220-240 V~.-
- The circuit should be fitted with at least two fuses of at least 16 A
each. Power cord core cross-sectional area should be at least
1.5 mm².
only for NL!
14
Connecting the power cord to the power mains
(appliance with a power cord)
•The cooking hob has to be hard-wired directly to the power mains.
•Devices for disconnecting from the power mains have to comply with the relevant regulations.
•Do not extend the power cord and do not lead it over sharp edges.
•If the appliance is installed above an oven, make sure the power cord is never in contact with the
oven's hot parts.
Two-phase connection
Single-phase connec-
tion
L, L1 = brown
L2 = black
N, N1 = grey
= yellow and green
Two-phase connectionSingle-phase connection
If your electric mains have 2 line
conductors and 2 neutral con-
ductors, connect the appliance
as shown in Diagram C.
If your electric mains have 2 line
conductors and 1 neutral con-
ductor, connect the appliance
as shown in Diagram B.
Connect the hob as shown in
Diagram A. If your power mains
do not allow a 32 A fuse, the ap-
pliance power should be de-
creased or limited accordingly. only for NL!
Connecting a 30-cm appliance
1. Open the cover of the connection terminal box.
2. Connect the wires according to your type of appliance.
3. Run the power cord through a cord strain relief (clamp) that protects the cable from being pulled
out.
15
Connecting the power cord to the power mains
(appliance with a power cord)
Connection diagram
L = brown
N = blue
= yellow and green
Single-phase connection
Connect the appliance as shown in Diagram A. If your power mains
do not allow a 16 A fuse, the appliance power should be decreased
or limited accordingly.
See chapter User Settings.
The circuit should be fitted with
a fuse of at least 16 A. Appli-
ances with a width of 30 centi-
metres (two cooking zones)
only allow single-phase connec-
tion. The cross-sectional area
of the power cord core should
be at least 1.5 mm²!
16
5. Appliance description
INFORMATION!
Appliance functions and equipment depend on the model.
1. Induction cooking zone ø 230 mm
2. Induction cooking zone ø 180 mm
3. Induction cooking zone ø 145 mm
4. Cooking hob control module
5.1 Before first use
Clean the cooking surface using a damp cloth and some mild washing-up liquid.
During initial use, the characteristic "new appliance smell" may appear; it will gradually disappear.
17
6. Operating the cooking hob
6.1 Control unit
Touch the relevant key to switch the hob on or off.Hob on/off key
Locks/unlocks the cooking hob controlsLock/child lock
Powers on the selected cooking zone or increases operating
power:
Power increase key
•touch to switch on the selected cooking zone to power
level 9
•touch once (tap) to increase the power level by one
level
•long-press to set or increase the power level faster
Power off the selected cooking zone or decrease operating
power:
Power decrease key
•touch to switch on the selected cooking zone to power
level 4
•touch once (tap) to decrease the power level by one
level
•long-press to set or decrease the power level faster
•long-press or press multiple times to switch off the se-
lected cooking zone
Indicates the current power level setting for the cooking
zone
Power level display
Setting the timer:Time functions
•countdown timer (minute minder) for the entire cooking
hob; does not power off the cooking zone
•shut-off timer for respective cooking zones; when the
time expires, the cooking zone is powered off
Indicates the selected cooking zoneTimer function indicator
18
6.2 Powering on the induction cooking hob
1. Touch to power on the induction hob.
2. Place the cookware onto the selected cooking zone.
3. appears on all cooking zone displays; a short beep is emitted.
INFORMATION!
If no cooking zone is switched on in 10 seconds, the induction hob will power off.
6.3 Switching on the cooking zones
1. Touch the key for the selected cooking zone. The selected display unit will flash.
2. Use the or key to set the power level for the selected cooking zone.
3. The cooking zone remains activated.
4. If the hob does not recognize any pan on the selected cooking zone, the symbol appears. If
you do not place a pan on the selected cooking zone within 2 minutes, the cooking zone will auto-
matically switch off.
INFORMATION!
During operation, power level for the selected cooking zone can he adjusted using
the or key.
6.4 Bridged cooking zone
(depending on the model)
•Some models allow combining two cooking zones on the left-hand side into a single large
connected cooking zone. Thus, a large oval pan or a griddle can be placed on the combined
cooking field. The pan has to be large enough to cover the centres of the upper and lower cooking
zone.
•Maximum pan size: 40 x 25 cm. For even heat distribution, we recommend using a heavy-bottom
baking dish or pan. During cooking, the dish or pan will heat up. Be careful to prevent burns.
•When placing the baking dish on the hob, make sure it does not cover the control module.
19
Table continued from last page
3. Press the key and hold it for approximately 3 seconds until you hear a short beep.
and will flash alternately on the display.
4. Press or to set the final power level for the automatic rapid heating function. Five seconds
after you have selected the power level, the function is confirmed with a short beep. If you set the
final power level to or the function is disabled.
5. and selected power level will alternate on the power level display.
6. When the automatic rapid heating time expires, the cooking zone automatically switches to the
selected level which will then be continuously displayed.
7. To switch off the automatic rapid heating function, simultaneously press and or if you de-
crease or increase the power level on the selected cooking zone. Then, you can set the new power
level.
Automatic rapid heating table
87654321Power level
1951204302601801207040Automatic rapid heating time (sec)
6.6 Power Boost
(depending on the model)
For rapid cooking, power boost can be activated on the cooking zones. This will allow you to rapidly
heat large amounts of food using extra power. The power boost is active for no more than 10 minutes;
then, the power level is automatically decreased to 9. If the cooking hob is not too hot, the power
boost can be reactivated for 10 minutes after it is switched off. To avoid overheating, the electronic
control function may automatically switch off the Power Boost earlier and decrease the power level
to 9.
1. Power on the induction hob.
2. Place the cookware on the selected cooking zone.
3. Set the power level to , then press the key.
4. will appear on the display. The function is activated.
5. Press to deactivate the function. Power boost will be deactivated, and operating power will
return to level .
6. Press multiple times to decrease power to the desired level.
21
6.7 Child lock / lock
Induction hob controls can be locked to prevent the hob from being powered on inadvertently.
INFORMATION!
The cooking hob has to be switched off or in the standby mode.
1. Touch the key and hold it for 3 seconds. will appear on the cooking zone power level
displays.
2. will appear on the timer function display.
3. The induction hob is locked.
4. After 5 seconds, the induction cooking hob will automatically switch off to standby mode.
5. Touch the key and hold it for 3 seconds. The hob is now unlocked.
INFORMATION!
Note: If the child lock/lock function is activated in the user settings mode (see chapter User
Settings Mode, Parameter ), then the hob will be automatically locked every time it is switched
off.
INFORMATION!
Activate the lock function before cleaning to prevent the induction hob from being inadvertently
switched on.
6.8 Time functions
This function allows two operating modes:
1. countdown timerThe (minute minder) applies to the entire induction hob. With this function, the
hob only beeps when the set time expires.
22
Table continued from last page
2. Program timer applies to the selected cooking zone. A separate timer can be set for each
cooking zone. When the set time expires, the cooking zone is automatically switched off.
1 Countdown timer
The countdown timer (minute minder) operates independently, and it is not related to the operation
of any cooking zone. When the countdown timer is set, it will continue to count down the time even
if you power off the induction cooking hob. The minute minder can only be switched off when the
induction cooking hob is on.
1. Touch the key to activate the timer. will appear on the timer display.
2. Touch the or key to set the time in the range from 1 to 99 minutes. Touch the key to
display the preset time of 90 minutes.
3. When the set time expires, the alarm is sounded.
4. Press any key to acknowledge and turn off the alarm.
5. The countdown timer (minute minder) remains active even when the cooking hob is switched off.
6. During the last minute of countdown, remaining time will be displayed in seconds.
2 Program timer
The program timer can be used to set the operating time for the cooking zones on which a power
level has already been set.
INFORMATION!
The switch-off program timer can be set independently for all cooking zones.
The program timer may only be set for an active cooking zone.
1. Touch the key to activate the timer. will appear on the timer display.
2. Touch the key again and will start flashing, indicating one or more of the selected
cooking zones.
3. Touch the or key to set the time in the range from 1 to 99 minutes. The countdown begins.
4. After the set time has expired, acoustic signal will be activated, and the cooking zone will be
switched off. The value will flash on the display.
5. Switch of the alarm by touching any key; alternatively, it will switch off automatically after a certain
period of time.
6. To delete the set time, select timer display by pressing . The set time will ap-
pear, and will flash. Touch the key multiple times to set the value to , or simultan-
eously press and to immediately reset/delete the set time.
23
INFORMATION!
Remaining cooking time can be changed at any time during cooking.
6.9 Residual heat indicator
The induction hob is also fitted with a residual heat display, . The cooking zone is not heated
directly, but only indirectly by the heat radiated back by the pan. As long as the sign is lit up after
the hob has been switched off, there is residual heat in the cooking zone, which can be used to keep
the food warm or for defrosting. When the sign disappears, the cooking zone may still be hot.
WARNING!
Be careful as there is danger of burns!
6.10 Maximum cooking time
For safety reasons, the cooking time for each cooking zone on the induction hob is restricted to a
maximum duration.
Maximum cooking time depends on the most recently set power level. If the power level is not changed
for a long time, the cooking zone will be switched off automatically after the maximum cooking duration
is reached (see table below).
P*987654321Cooking power
level
1,51,522446688Maximum operat-
ing time (h)
* After 10 minutes, the power level automatically decreases to 9; after 1.5 hours, the cooking zone is
switched off.
6.11 Overheat protection
The induction hob is fitted with a cooling fan that cools the electronic components during cooking.
The fan may operate for a while even after the end of the cooking process.
The hob is also fitted with an overheating protector that protects the electronics from damage. The
protector operates at several levels. When the cooking zone temperature gets very high, the cooking
power is automatically reduced. If this does not suffice, the cooking zone power continues to decrease,
or the safety mechanism switches off the cooking zone completely. When the induction hob cools
down, its total power is available again.
6.12 Automatic switch off
If the keys are activated for too long during cooking (e.g., due to spilt liquid or an object placed over
the sensor keys), all cooking zones will be switched off automatically after 10 seconds.
24
1. will flash on the display unit.
2. Remove the object or wipe the spilt liquid from the sensor keys within 5 seconds to retain the
power level settings. If you do not remove the object or wipe the spilt liquid in 10 seconds, the in-
duction hob will be powered off automatically.
6.13 Switching off the cooking zone
To switch off a cooking zone, press the key to set the value to . To quickly switch off a cooking
zone, simultaneously press and hold the or key. You will hear a short beep, and will appear
on the display unit.
INFORMATION!
If the power level of all cooking zones is set to , the cooking hob will switch off automatically
after 10 seconds.
6.14 Switching off the entire cooking hob
The hob can be switched off at any time by pressing .
25
7. User settings
Setting the acoustic signal, automatic features, and lock parameters
You can adjust the volume of the acoustic signal, duration of acoustic alarm, total maximum appliance
power, and automatic lock settings on the appliance.
Uo: Acoustic signal and alarm volume (loudness)
So: Acoustic alarm duration
Lo: Automatic lock
Po: Total maximum power
1. To activate the parameter settings menu, press and hold the key for 3 seconds while the
appliance is switched off.
2. The first parameter will appear on the timer display, indicating the volume (loudness) of
acoustic signals.
3. Press the timer setting keys or to adjust the setting.
4. The parameters are also set for the lower left cooking zone.
5. The currently set parameter value will appear on the left-hand side cooking zone power level
displays. The value can be adjusted by pressing the or key for the cooking zone.
6. All parameters can be confirmed and stored by pressing and holding the key for 2 seconds.
7. A short beep will be emitted.
8. If you do not wish to store the new parameter settings, close the user settings mode by pressing
the key; alternatively, the user settings mode will close automatically after 2 minutes.
Acoustic signal and alarm volume (loudness) "Uo"
The following values can be set:
0on the display = off (does not apply to alarm and error acoustic signal)
1on the display = minimum volume
2on the display = medium volume
3on the display = maximum volume (default)
A short acoustic signal will be sounded upon every change, with the newly set
volume.
26
8. Tips and hints
8.1 Cooking hob (conventional or glass ceramic)
•The hob is resistant to temperature changes.
•Using the cooking hob surface as a storage area may result in scratches or other damage to it.
•Do not use the glass ceramic hob if it is cracked or broken. If a sharp object falls on the hob, the
hob may break. The consequences of such occurrence may be visible immediately or only after
a while.
•If any visible crack appears in the hob, immediately cut off the power supply to the appliance.
•Make sure the cooking zone and the cookware bottom is clean and dry. This will allow better
conduction of heat and prevent any damage to the heating surface.
•Do not place empty cookware on the cooking zone, as this may result in damage.
WARNING!
If sugar or food with high sugar content is spilled over a hot class ceramic hob, immediately wipe
the hob or remove the sugar with a scraper, even if the cooking zone is still hot. This will prevent
any damage to the class ceramic surface.
Do not use detergents and other cleaners to clean a hot glass ceramic hob as this could damage
the surface.
8.2 Induction cooking zone operating principle
Cooking on an induction hob differs from cooking on traditional appliances. Induction hob uses
magnetic field for generating heat and cooking. This means that not all types of cookware can be
used on an induction hob.
The cooking hob is fitted with highly efficient induction cooking zones.
The heat is generated directly in the bottom of the pan where it is needed
the most. This avoids any losses through the glass ceramic surface. Power
consumption is considerably lower than in conventional cooking zones
with radiation heaters.
The glass ceramic cooking zone is not heated directly, but only indirectly
with the heat radiated back by the pan. After the cooking zone is switched
off, this residual heat is indicated by .
In induction cooking zones, heating is made possible by the induction
coil installed under the glass ceramic surface. The coil induces a magnetic
field which generates eddy currents in the bottom of a ferromagnetic pan,
which in turn heats the pan.
The induction will work correctly if you use suitable cookware.
28
Produkt Specifikationer
| Mærke: | Gorenje |
| Kategori: | Ovn |
| Model: | GI6421SYB |
Har du brug for hjælp?
Hvis du har brug for hjælp til Gorenje GI6421SYB stil et spørgsmål nedenfor, og andre brugere vil svare dig
Ovn Gorenje Manualer
12 Januar 2025
12 Januar 2025
12 Januar 2025
12 Januar 2025
12 Januar 2025
12 Januar 2025
11 Januar 2025
11 Januar 2025
11 Januar 2025
9 Januar 2025
Ovn Manualer
- Ovn Godrej
- Ovn Liebherr
- Ovn ARC
- Ovn Vedette
- Ovn Pit Boss
- Ovn BEKO
- Ovn Flama
- Ovn Neff
- Ovn Instant
- Ovn Glem Gas
- Ovn Efbe-Schott
- Ovn Casselin
- Ovn KB Elements
- Ovn Gram
- Ovn Nutrichef
Nyeste Ovn Manualer
2 Juni 2025
2 Juni 2025
2 Juni 2025
1 Juni 2025
1 Juni 2025
1 Juni 2025
1 Juni 2025
1 Juni 2025
1 Juni 2025
1 Juni 2025
