English (GB) Installation and operating instructions
Original installation and operating instructions
These installation and operating instructions
describe Grundfos cranes for AMD, AMG, AFG, SRP,
SMD, SMG, SFG and SRG mixers and flowmakers.
Sections 1-5 give the information necessary to be
able to unpack, install and operate the product in a
Sections 6-9 give important information about the
product, as well as information on service and
These installation and operating instructions are
intended for professional installers.
1.2 Symbols used in this document
1.2.1 Warnings against hazards involving risk of
The text accompanying the three hazard symbols
DANGER, WARNING and CAUTION is structured in
1.2.2 Other important notes
1.2 Symbols used in this document
2.1 General safety instructions
2.2 Safe working practice
4. Installing the product
4.1 Mounting the crane foot
4.3 Mounting of the lifting wire in the drum
5. Handling and storing the product
5.2 Relocating the product
7.1 Maintaining the product
8.4 Dimensions and weights
9. Disposing of the product
Read this document before installing the
product. Installation and operation must
comply with local regulations and accepted
Indicates a hazardous situation which, if
not avoided, will result in death or serious
Indicates a hazardous situation which, if
not avoided, could result in death or
Indicates a hazardous situation which, if
not avoided, could result in minor or
moderate personal injury.
Consequence of ignoring the warning.
- Action to avoid the hazard.
A blue or grey circle with a white graphical
symbol indicates that an action must be
A red or grey circle with a diagonal bar,
possibly with a black graphical symbol,
indicates that an action must not be taken
If these instructions are not observed, it
may result in malfunction or damage to the
Tips and advice that make the work easier.
