Side 1/32
Refrigerator
User Manual
GKN5686VW
58 9998 1000 / EN/ AA/ 10/07/2023 09:21
7282946307
EN / 2
Please read this manual first!
Dear Customer
Please read this manual before using the product.
Thank you for choosing this Grundig product. We would like you to achieve the optimal effi-
ciency from this high quality product which has been manufactured with state of the art
technology. To do this, carefully read this manual and any other documentation provided
before using the product and keep it as a reference.
Heed all information and warnings in the user manual. This way, you will protect yourself
and your product against the dangers that may occur.
Keep the user manual. Include this manual with the unit if you hand it over to someone
else.
The following symbols are used in the user manual:
Hazard that may result in death or injury.
Important information or useful tips on operation.
Read the user manual.
Combustible material, warning against fire hazard.
NOTICE A hazard that may cause material damage to the product or its surroundings
The model information as stored in the product data
base can be reached by entering following website and
searching for your model identifier (*) found on energy
label.
https://eprel.ec.europa.eu/
EN / 3
1 Safety Instructions........................ 4
1.1 Intention of Use ............................. 4
1.2 Safety of Children, Vulnerable
Persons and Pets ..........................
4
1.3 Electrical Safety............................. 5
1.4 Handling Safety ............................. 6
1.5 Installation Safety.......................... 6
1.6 Operational Safety......................... 8
1.7 Food Storage Safety...................... 10
1.8 Maintenance and Cleaning Safety 11
1.9 Disposal of the Old Product.......... 12
2 Environmental Instructions.......... 12
2.1 Compliance with the WEEE Dir-
ective and Disposing of the
Waste Product...............................
12
3 Your Refrigerator .......................... 13
4 Installation ..................................... 13
4.1 Right Place For Installation........... 13
4.2 Electrical Connection .................... 14
4.3 Attaching the Plastic Wedges ...... 14
4.4 Adjusting the Legs......................... 15
4.5 Hot Surface Warning ..................... 15
5 Preparation.................................... 15
5.1 What To Do For Energy Saving ..... 15
5.2 First Use......................................... 16
5.3 Climate Class and Definitions ...... 16
6 Operating the Product.................. 16
7 Use of Your Appliance.................. 17
7.1 Control Panel of the Product ........ 17
7.2 Storing Food in the Cooler Com-
partment.........................................
18
7.3 Humidity Controlled Crisper ......... 20
7.4 Reversing the Door Opening Side. 20
7.5 Door Open Alert ............................. 20
7.6 Foldable Wine Rack....................... 21
7.7 Replacing the Illumination Lamp.. 21
7.8 AeroFresh....................................... 21
8 Maintenance and Cleaning .......... 21
9 Troubleshooting............................ 22
EN / 4
1 Safety Instructions
• This section includes the
safety instructions necessary
to prevent the risk of personal
injury or material damage.
• Our company shall not be held
responsible for damages that
may occur if these instructions
are not observed.
Always have installation and repair
operations performed by manufac-
turer, authorized service or a per-
son who will be described by im-
porter company.
Use original spare parts and ac-
cessories only.
Do not repair or replace any com-
ponent of the product unless it is
clearly specified in the user
manual.
Do not perform any modifications
on the product.
1.1 Intention of Use
• This product is not suitable for
commercial use and should
not be used for a purpose
other than its intended use.
• This product is intended for
operating interiors, such as
households or similar.
For example;
In the staff kitchens of the
stores, offices and other work-
ing environments,
In farm houses,
In the units of hotels, motels or
other resting facilities that are
used by the customers,
In hostels, or similar environ-
ments,
In catering services and similar
non-retail applications.
• This product shall not be used
in open or enclosed external
environments such as vessels,
camper vans, balconies or ter-
races. Exposing the product to
rain, snow, sunlight and wind
may cause risk of fire.
1.2 Safety of Children,
Vulnerable Persons
and Pets
• This product may be used by
children aged 8 years and
older and persons with under-
developed physical, sensory or
mental capabilities or lack of
experience and knowledge if
they are being supervised or
have been given instruction
concerning use of the appli-
ance in a safe way and the
hazards involved.
EN / 5
• Children between 3 and 8
years are allowed to put and
take out food into/from the
cooler product.
• Electrical products are danger-
ous for children and pets. Chil-
dren and pets must not play
with, climb on, or enter the
product.
• Cleaning and user mainten-
ance should not be performed
by children unless there is
someone overseeing them.
• Keep the packaging materials
away from children. Risk of in-
jury and suffocation.
Before disposing of old products
that shall not be used any more:
1. Unplug the power cord from
the mains socket.
2. Cut the power cable and re-
move it from the appliance
together with the plug.
3. Do not remove the racks and
drawers from the product to
prevent children from getting
inside the appliance.
4. Remove the doors.
5. Store the product so that it
shall not be tipped over.
6. Do not allow children to play
with the scrapped product.
• Do not dispose of the product
by throwing it into fire. Risk of
explosion.
• If there is a lock available on
the product’s door, keep the
key out of children's reach.
1.3 Electrical Safety
• The product shall not be
plugged into the outlet during
installation, maintenance,
cleaning, repair, and transport-
ation operations.
• If the power cable is damaged,
it shall only be replaced by au-
thorized service to avoid any
risks that may occur.
• Do not tuck the power cable
under the product or to the
rear of the product. Do not put
heavy items on the power
cable. The power cable should
not be bent, crushed, and
come into contact with any
heat source.
• Do not use an extension cord,
multi-plug or adaptor to oper-
ate your product.
• Portable multi-plugs or port-
able power supplies may over-
heat and cause fire. Thus, do
not have a multi-plug, portable
power sources behind or in the
vicinity of the product.
• Do not plug the product’s
power cord in a loose or dam-
aged power outlet. These
types of connections may
overheat and cause fire.
EN / 6
• The plug shall be easily ac-
cessible. If this is not possible,
a mechanism that meets the
electrical legislation and that
disconnects all terminals from
the mains (fuse, switch, main
switch, etc.) shall be available
on the electrical installation.
• Do not touch the plug with wet
hands.
• When unplugging the appli-
ance, don’t hold the power
cord, but the plug.
1.4 Handling Safety
• Make sure to unplug the appli-
ance before carrying the
product.
• This product is heavy, do not
handle it by yourself. Injuries
may occur if the product falls
on you. Do not bump into
places or drop the product
while transporting it.
• Always close the doors and do
not hold the product by its
doors while transporting it.
• Be careful not to damage the
cooling system and the pipes
while handling the product. Do
not operate the product if the
pipes are damaged, and con-
tact an authorized service.
1.5 Installation Safety
• Contact the Authorized Service
for the product's installation.
To prepare the product for use,
see the information in the user
manual and make sure the
electric and water utilities are
as required. If not, call a quali-
fied electrician and plumber to
arrange the utilities as neces-
sary. Failure to do so may res-
ult in electric shock, fire, prob-
lems with the product, or in-
jury.
• The product is designed for
use in areas 2000 metres be-
low sea level.
• Check for any damage on the
product before installing it. Do
not have the product installed
if it is damaged.
• Always use personal protective
equipment (gloves, etc.) during
product installation, mainten-
ance and repair. Risk of Injury!
• Place the product on a clean,
level and hard surface and bal-
ance it with the adjustable legs
(by rotating the front feet to
the right or left). Otherwise, the
refrigerator may tip over and
cause injuries.
• The product shall be installed
in a dry and ventilated environ-
ment. Do not keep carpets,
EN / 8
• Place the power cable and
hoses (if any) of the product
so that they shall not cause a
risk of tripping over.
• Penetration of humidity and li-
quid to live parts or to the
power cord may cause short
circuit. Thus, do not use the
product in humid environ-
ments or in areas where water
may splash (e.g. garage, laun-
dry room, etc.) If the refriger-
ator is wet by water, unplug it
and contact an authorized ser-
vice.
• Do not ever connect your refri-
gerator to power saving
devices. These systems are
harmful for the product.
• There is a risk of contact with
electrical parts when removing
the electronic board cover and
the compressor rear cover (if
fitted). Do not remove the elec-
tronic board cover and the
compressor rear cover (if fit-
ted). There is a risk of electro-
cution!
1.6 Operational Safety
• Do not ever use chemical
solvents on the product. These
materials contain an explosion
risk.
• In case of a failure of the
product, unplug it and do not
operate until it is repaired by
the authorized service. There
is a risk of electric shock!
• Do not place a source of flame
(e.g. candles, cigarettes, etc.)
on the product or in the vicinity
of it.
• Do not get on the product. Risk
of falling and injury!
• Do not cause damage to the
pipes of the cooling system us-
ing sharp and piercing tools.
The refrigerant that sprays out
in case of puncturing the gas
pipes, pipe extensions or upper
surface coatings may cause ir-
ritation of skin and injury to the
eyes.
• Do not place and operate elec-
trical appliances inside the re-
frigerator/freezer unless it is
advised by the manufacturer.
• Do not jam any parts of your
hands or your body to the mov-
ing parts inside the product. Be
careful to prevent jamming of
your fingers between the refri-
gerator and its door. Be careful
while opening or closing the
door if there are children
around.
EN / 9
• Do not put ice cream, ice
cubes or frozen food to your
mouth as soon as you take
them out of the freezer. Risk of
frostbite!
• Do not touch the inner walls,
metal parts of the freezer or
food kept inside the freezer
with wet hands. Risk of frost-
bite!
• Do not place soda cans or
cans and bottles that contain
fluids that may be frozen to the
freezer compartment. Cans or
bottles may explode. Risk of
injury and material damage!
• Do not use or place materials
sensitive against temperature
such as flammable sprays,
flammable objects, dry ice or
other chemical agents in the
vicinity of the refrigerator. Risk
of fire and explosion!
• Do not store explosive materi-
als such as aerosol cans with
flammable materials inside the
product.
• Do not place cans containing
fluids over the product an open
state. Splashing of water on an
electrical part may cause an
electric shock or a fire.
• This product is not intended
for storage and cooling of
medicines, blood plasma,
laboratory preparations or sim-
ilar materials and products
that are subject to the Medical
Products Directive.
• If the product is used against
its intended purpose, it may
cause damage to or deteriora-
tion of the products kept in-
side.
• If your refrigerator is equipped
with blue light, do not look at
this light with optical devices.
Do not stare directly at UV LED
light for a long time. Ultraviolet
rays may cause eye strain.
• Do not fill the product with
more contents than its capa-
city. Injuries or damages may
occur if the contents of the re-
frigerator fall when the door is
opened. Similar problems may
also occur when an object is
placed over the product.
• Ensure that you have removed
any ice or water that may have
fallen to the floor to prevent in-
juries.
• Change the locations of the
racks/bottle racks on the door
of your refrigerator only when
the racks are empty. Danger of
injury!
• Do not place objects that may
fall/tip over on the product.
These objects may fall while
opening or closing the door
and cause injuries and/or ma-
terial damages.
EN / 11
Thus, it does not drip on or
come into contact with other
foods.
• Two-star freezer compart-
ments are used for storing pre-
filled foods, making and stor-
ing ice and ice cream.
• One, two and three-star com-
partments are not appropriate
for freezing fresh food.
• If the cooling product has been
left empty for a long time, turn
off the product, defrost, clean,
and dry the product in order to
protect the housing of the
product.
1.8 Maintenance and
Cleaning Safety
• Unplug the refrigerator before
cleaning it or starting to per-
form maintenance.
• Do not pull by the door handle
if you shall move the product
for cleaning purposes. Handle
may cause injuries if it is
pulled too hard.
• Do not put your hands etc. un-
der the refrigerator. Jamming
may occur or any sharp edge
may cause personal injuries.
• Do not clean the product by
spraying or pouring water on
the product and inside the
product. Risk of electric shock
and fire.
• When cleaning the product, do
not use sharp and abrasive
tools or household cleaning
agents, detergent, gas, gasol-
ine, thinner, alcohol, varnish,
and similar substances. Use
only cleaning and maintenance
agents that are not harmful for
food inside the product.
• Do not ever use steam or
steamed cleaning materials for
cleaning the product and thaw-
ing the ice inside it. Steam con-
tacts the live areas in your re-
frigerator and causes short cir-
cuit or electric shock.
• Do not use any mechanical
tools or any other tools than
the recommendations of the
manufacturer to speed up the
defrost operation.
• Take care to keep water away
from the ventilation holes,
electronic circuits or lighting of
the product.
• Use a clean, dry cloth to wipe
the dust or foreign material on
the tips of the plugs. Do not
use a wet or damp piece of
cloth to clean the plug. Other-
wise, risk of fire or electric
shock may occur.
EN / 12
1.9 Disposal of the Old
Product
When disposing of your old
product follow the instructions
below:
• To prevent children from acci-
dentally locking themselves
into the product, if there is
door lock, make it deactivated.
• Splash of coolant is harmful to
the eyes. Do not damage any
part of the cooling system
while disposing of the product.
• It may be fatal if the com-
pressor oil is swallowed or if it
penetrates the respiratory
tract.
• Cooling system of your
product includes R600a gas as
specified in the type label. This
gas is flammable. Do not dis-
pose of the product by throw-
ing it into fire. Risk of explo-
sion!
2 Environmental Instructions
2.1 Compliance with the WEEE Dir-
ective and Disposing of the
Waste Product
This product complies with EU
WEEE Directive (2012/19/EU).
This product bears a classifica-
tion symbol for waste electrical
and electronic equipment
(WEEE).
This symbol indicates that this product
shall not be disposed with other household
wastes at the end of its service life. Used
device must be returned to offical collec-
tion point for recycling of electrical and
electronic devices. To find these collection
systems please contact to your local au-
thorities or retailer where the product was
puchased. Each household performs im-
portant role in recovering and recycling of
old appliance. Appropriate disposal of used
appliance helps prevent potential negative
consequences for the environment and hu-
man health.
Compliance with RoHS Directive
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging
materials together with the do-
mestic or other wastes. Take them
to the packaging material collection
points designated by the local au-
thorities.
EN / 13
3 Your Refrigerator
1
2
3
4
5
6
7
8
9
10
11
12
1 * Adjustable Door Shelves 2 * Egg Holders
3 * Bottle Shelf 4 * Adjustable Front Legs
5 * Freezer Compartment 6 * Ice Container
7 * Cold Storage Drawer 8 * Crisper
9 * Adjustable Shelves 10 * Foldable Wine Bin
11 * Fan 12 * Illumination Lamp
*Optional: Figures in this user manual are
schematic and may not exactly match your
product. If your product does not comprise
the relevant parts, the information pertains
to other models.
4 Installation
Read the “Safety Instructions” sec-
tion first!
4.1 Right Place For Installation
Contact the Authorized Service for the
product's installation. To prepare the
product for installation, see the information
in the user manual and make sure the elec-
tric and water utilities are as required. If
not, call an electrician and plumber to ar-
range the utilities as necessary.
EN / 14
WARNING:
The manufacturer assumes no re-
sponsibility for any damages
caused by the work carried out by
unauthorized persons.
WARNING:
The product’s power cable must be
unplugged during installation. Fail-
ure to do so may result in death or
serious injuries!
WARNING:
If the door span is too narrow for
the product to pass, remove the
door and turn the product side-
ways; if this does not work, contact
the authorized service.
• Place the product on a flat surface to
avoid vibration.
• Place the product at least 30 cm away
from the heater, stove and similar
sources of heat and at least 5 cm away
from electric ovens.
• Do not expose the product to direct sun-
light or keep it in damp environments.
• Your product requires adequate air circu-
lation to function efficiently. If the
product will be placed in an alcove, re-
member to leave at least 5 cm clearance
between the product and the ceiling, rear
wall and the side walls.
• Check if the rear wall clearance protec-
tion component is present at its location
(if provided with the product).
• If the component is not available, or if it
is lost or fallen, position the product so
that at least 5 cm clearance shall be left
between the rear surface of the product
and the wall of the room. The clearance
at the rear is important for efficient oper-
ation of the product.
4.2 Electrical Connection
Do not use extension or multi sock-
ets in power connection.
Damaged power cable must be re-
placed by Authorized Service.
When placing two coolers in adja-
cent position, leave at least 4 cm
distance between the two units.
• Our firm will not assume responsibility
for any damages due to usage without
earthing and power connection in compli-
ance with national regulations.
• The power cable plug must be easily ac-
cessible after installation.
• Do not use multi-group plug with or
without extension cable between the wall
socket and the refrigerator.
4.3 Attaching the Plastic Wedges
Use the plastic wedges provided with the
product to maintain sufficient space for air
circulation between the product and the
wall.
1. To attach the wedges, remove the
screws on the product and use the
screws provided with the wedges.
2. Attach 2 plastic wedges on the ventila-
tion cover as shown in the figure.
EN / 15
4.4 Adjusting the Legs
If the product is not in balanced position,
adjust the front adjustable legs by rotating
them to right or left.
4.5 Hot Surface Warning
The side walls of your product are equipped
with cooler pipes to enhance the cooling
system. High pressure fluid may flow
through these surfaces, and cause hot sur-
faces on the side walls. This is normal and
it does not require servicing. Be careful
when you contact these areas.
5 Preparation
Read the “Safety Instructions” sec-
tion first!
5.1 What To Do For Energy Saving
Connecting the product to elec-
tronic energy-saving systems is
harmful, as it may damage the
product.
• This refrigerating appliance is not inten-
ded to be used as a built in appliance.
• Do not keep the refrigerator doors open
for long periods.
• Do not place hot food or beverages into
the refrigerator.
• Do not overfill the refrigerator; blocking
the internal air flow will reduce cooling
capacity.
• Since hot and humid air will not directly
penetrate into your product when the
doors are not opened, your product will
optimize itself in conditions sufficient to
protect your food. Under these circum-
stances, functions and components such
as compressor, fan, heater, defrost, light-
ing, display and so on will operate ac-
cording to the needs by consuming min-
imum energy.
• In case that multiple options are present,
glass shelves must be placed so that the
air outlets at the rear wall are not blocked
and preferably, in a way that air outlets
remain below the glass shelf. This com-
bination may help improving air distribu-
tion and energy efficiency.
• Using the below drawer when storing is
strongly recommended.
• Depending on the product’s features; de-
frosting frozen foods in the cooler com-
partment will ensure energy saving and
preserve food quality.
• In order to load the maximum quantity of
food into the freezer compartment of
your refrigerator, the upper drawers may
be taken out and the food should be
placed onto the wire/glass shelves.
• Make sure the foods are not in contact
with the cooler compartment temperat-
ure sensor described below.
• If they are in contact with the sensor, en-
ergy consumption of the appliance might
increase
EN / 16
• Food shall be stored using the drawers in
the cooler compartment in order to en-
sure energy saving and protect food in
better conditions.
• Food packages shall not be in direct con-
tact with the temperature sensor located
in the freezer compartment.
5.2 First Use
Before using your refrigerator, make sure
the necessary preparations are made in line
with the instructions in "Safety and Environ-
mental Instructions" and "Installation" sec-
tions.
• Keep the product running without placing
any food inside for 6 hours and do not
open the door, unless absolutely neces-
sary.
• The temperature change caused by open-
ing and closing of the door while using
the product may normally lead to con-
densation on door/body shelves and
glassware placed in the product.
A sound will be heard when the
compressor is engaged. It is nor-
mal for the product to make noise
even if the compressor is not run-
ning, as fluid and gas may be com-
pressed in the cooling system.
It is normal for the front edges of
the refrigerator to be warm. These
areas are designed to warm up in
order to prevent condensation.
For some models, indicator panel
turns off automatically 1 minute
after the door closes. It will be re-
activated when the door is opened
or any button is pressed.
5.3 Climate Class and Definitions
Please refer to the Climate Class on the rat-
ing plate of your device. One of the follow-
ing information is applicable to your device
according to the Climate Class.
• Long Term Temperate Climate: ThisSN:
cooling device is designed for use at am-
bient temperatures between 10 °C and 32
°C.
• Temperate Climate: This coolingN:
device is designed for use at ambient
temperatures between 16°C and 32 °C.
• Subtropical Climate: This coolingST:
device is designed for use at ambient
temperatures between 16°C and 38°C.
• Tropical Climate: This cooling deviceT:
is designed for use at ambient temperat-
ures between 16°C and 43°C.
6 Operating the Product
Read the “Safety Instructions” sec-
tion first!
• Do not use any mechanical tools or any
other tools than the recommendations of
the manufacturer to speed up the defrost
operation.
• Do not use parts of your refrigerator such
as the door or drawers as a support or a
step. This may cause the product to trip
over or its components to be damaged.
• The product shall be used for storing
food only.
• Turn off the water valve if you will be
away from home (e.g. at vacation) and
you will not be using the Icematic or the
water dispenser for a long period of time.
Otherwise, water leaks may occur.
Unplugging the Product
• If you are not going to use the product for
a long time, unplug the product from the
socket.
• Remove the food to prevent odours,
• Wait for the ice to melt, clean the interior
and let it dry, leave the doors open to
avoid damaging the inner body plastics.
EN / 18
6. Cooler Compartment Off (Vacation)
Function Key
To activate the holiday function, press the
button for 3 sec. The holiday mode is activ-
ated and the holiday icon ( ) lights up. All
icons on the cooler compartment temperat-
ure indicator turn off and the cooler com-
partment does not perform active cooling.
When this function is activated, you are ad-
vised against storing food in the refrigerat-
ing compartment. The other compartments
continue to cool according to their set tem-
perature. Press the key for 3 seconds again
to cancel this function.
7.2 Storing Food in the Cooler Compartment
Storing Food in the Cooler Compart-
ment
• Compartment temperatures rise promin-
ently if compartment door is opened and
closed frequently and kept open for a
long time, this can reduce the life span of
the food and cause the food to spoil.
• In order not to cause odour and taste
changes, the food should be stored in the
closed containers.
• Do not store too much food in your refri-
gerator. To achieve a better and homo-
geneous cooling, place the food separ-
ately in a way that cold air can wander
through them.
• Provide air flow by leaving a space
between the food and internal wall. If you
lean the food against the rear wall, the
food may freeze.
• Bring cooked hot meals to the room tem-
perature before placing them in the refri-
gerator. Then, you can place the tepid
meal in the lower shelves of your refriger-
ator. Do not place the tepid meals close
to the foods which may easily spoil.
• Defrost your frozen food in the fresh food
compartment. Thereby, you can cool
fresh food compartment by using frozen
food and save energy.
• Storing unripe tropical fruits (mango,
melon varieties, papaya, banana, pine-
apple) in the refrigerator may speed up
the ripening process. This is not recom-
mended because it will cause shorter
storage time.
• You should store onions, garlics, gingers
and other root vegetables in dark and
cold room conditions, not in the refriger-
ator.
• If you notice that a food has spoiled in
the refrigerator, throw away that food and
clean the accessories which have come
into contact with it.
• In order to cool the meals like soups and
stews, which are cooked in the large
pots, quickly, you can put them in the re-
frigerator by separating them into their
own shallow containers.
• Do not place unpackaged food close to
eggs.
• Keep the fruits and vegetables separately
and store each variety together (for ex-
ample; apples with apples, carrots with
carrots).
• Take green vegetables out of the plastic
bag and place them in the refrigerator
after wrapping them in a paper towel or
drying cloth. If you wash this type of food
before placing them in the refrigerator, re-
member to dry them.
• You can both create a damp environment
and provide an air flow by keeping fruits
and vegetables, which are prone to dry-
ing, in the perforated or unsealed plastic
bags.
• Except the cases where extreme circum-
stances are available in the environment,
if your product (on the recommended set
values table) is set to the specified set
values, the food keep their freshness for
a longer time both in the fresh product
compartment and freezer compartment.
EN / 21
door open alert is sounded gradually. First,
an audible warning starts to sound. After 4
minutes, if the door is still not closed, a
visual warning (lighting flash) is activated.
The door open alert will be delayed for a
certain period of time (between 60 s and
120 s) when any key on the product screen,
if any, is pressed. Then the process will
start again. When the device door is closed,
the door open alert will be cancelled.
7.6 Foldable Wine Rack
It allows the user to store wine bottles if ne-
cessary. To use the rack section, grasp the
plastic part and gently pull it down. You can
now use the foldable wine rack.
It is recommended to store a max-
imum of 2 wine bottles on the fold-
able wine rack.
To group the wine rack, first remove the
glass shelf from the refrigerator. Place it on
the glass shelf by pushing the plastic part
through the front and back grooves as
shown in the picture. The product will be
ready to use with the foldable wine rack.
To remove the foldable wine rack, first re-
move the glass shelf from the refrigerator.
Then grab the plastic part and pull it in any
direction. You can now use the product
without a foldable wine rack when needed.
7.7 Replacing the Illumination Lamp
Call the Authorized Service when the Bulb/
LED used for lighting in your refrigerator
will be replaced.
Lamp(s) used in this appliance cannot be
used for house lighting. Intended use of
this lamp is to help the user place food into
the refrigerator / freezer safely and com-
fortably.
7.8 AeroFresh
It is an air distribution system that provides
homogeneous temperature distribution.
With the air circulation, the homogeneous
temperature distribution is ensured in the
fresh food storage compartment, and the
temperature fluctuations are kept at low
levels. No direct air blowing over the food is
realized and this helps to reduce moisture
loss. It preserves the freshness of the food
stored in the fresh food compartment of
the refrigerator. In this way, your food is
stored at more stable temperatures and the
contact with air is reduced. The drying and
shrinking of foods by losing moisture is
prevented and freshness is provided for a
longer time.
8 Maintenance and Cleaning
WARNING:
Read the “Safety Instructions” sec-
tion first.
WARNING:
Unplug the refrigerator before
cleaning it.
• Do not use sharp or abrasive tools to
clean the product. Do not use materials
such as household cleaning agents,
soap, detergents, gas, gasoline, thinner,
alcohol, wax, etc.
• The dust shall be removed from the vent-
ilation grill on the rear of the product at
least once a year (without opening the
cover). Clean the product with a dry cloth.
• Take care to keep water away from the
lamp's cover and other electrical parts.
EN / 22
• Clean the door with a damp cloth. Re-
move all contents to remove the door
and body racks. Remove the door racks
by lifting them upwards. Clean and dry
the shelves, then attach back in place by
sliding from above.
• Do not use chlorinated water or cleaning
products on the exterior surface and
chromecoated parts of the product.
Chlorine will cause rust on such metallic
surfaces.
• Do not use sharp and abrasive tools,
soap, house cleaning materials, deter-
gents, gas, gasoline, varnish and similar
substances to prevent deformation of the
plastic part and removal of prints on the
part. Use warm water and a soft cloth for
cleaning, and then dry it.
• On the products without a No-Frost fea-
ture, water droplets and icing up to a
thickness of a finger may occur on the
rear wall of the freezer compartment. Do
not clean, and never apply oils or similar
materials.
• Use a mildly dampened micro-fibre cloth
to clean the external surface of the
product. Sponges and other types of
cleaning clothes may cause scratches.
• To clean all removable components dur-
ing the cleaning of the interior surface of
the product, wash these components
with a mild solution consisting of soap,
water and carbonate. Wash and dry thor-
oughly. Prevent contact of water with illu-
mination components and the control
panel.
CAUTION:
Do not use vinegar, rubbing alcohol
or other alcohol based cleaning
agents on any interior surface.
Stainless Steel External Surfaces
Use a non-abrasive stainless steel cleaning
agent and apply it with a soft lint-free cloth.
To polish, gently wipe the surface with a mi-
cro-fibre cloth dampened with water and
use dry polishing chamois. Always follow
the veins of the stainless steel.
Preventing Odours
The product is manufactured free of any
odorous materials. However, keeping the
food in inappropriate sections and im-
proper cleaning of internal surfaces may
lead to odours.
• To avoid this, clean the inside with car-
bonated water every 15 days.
• Keep the foods in sealed holders, as mi-
cro-organisms arising from foods kept in
unsealed containers will cause bad
odour.
• Do not keep expired and spoilt foods in
the refrigerator.
Protecting Plastic Surfaces
Oil spilled on plastic surfaces may damage
the surface and must be cleaned immedi-
ately with warm water.
9 Troubleshooting
Check this list before contacting the ser-
vice. Doing so will save you time and
money. This list includes frequent com-
plaints that are not related to faulty work-
manship or materials. Certain features
mentioned herein may not apply to your
product.
The refrigerator is not working.
• The power plug is not fully settled. >>>
Plug it in to settle completely into the
socket.
• The fuse connected to the socket power-
ing the product or the main fuse is blown.
>>> Check the fuse.
EN / 24
The food items kept in cooler compart-
ment drawers are frozen.
• The cooler compartment temperature is
set to a very low degree. >>> Set the
cooler compartment temperature to a
higher degree and check again.
The temperature in the cooler or the
freezer is too high.
• The cooler compartment temperature is
set to a very high degree. >>> Temperat-
ure setting of the cooler compartment
has an effect on the temperature in the
freezer compartment. Wait until the tem-
perature of relevant parts reach the suffi-
cient level by changing the temperature
of cooler or freezer compartments.
• The doors were opened frequently or
kept open for long periods. >>> Do not
open the doors too frequently.
• The door may be ajar. >>> Fully close the
door.
• The product may have been recently
plugged in or a new food item is placed
inside. >>> This is normal. The product
will take longer to reach the set temperat-
ure when recently plugged in or a new
food item is placed inside.
• Large quantities of hot food may have
been recently placed into the product.
>>> Do not place hot food into the
product.
Shaking or noise.
• The surface is not flat or durable >>> If
the product is shaking when moved
slowly, adjust the stands to balance the
product. Also make sure the ground is
sufficiently durable to bear the product.
• Any items placed on the product may
cause noise. >>> Remove any items
placed on the product.
• The product is making noise of liquid
flowing, spraying etc.
• The product's operating principles in-
volve liquid and gas flows. >>> This is
normal and not a malfunction.
There is sound of wind blowing coming
from the product.
• The product uses a fan for the cooling
process. This is normal and not a mal-
function.
There is condensation on the product's
internal walls.
• Hot or humid weather will increase icing
and condensation. This is normal and not
a malfunction.
• The doors were opened frequently or
kept open for long periods. >>> Do not
open the doors too frequently; if open,
close the door.
• The door may be ajar. >>> Fully close the
door.
There is condensation on the product's
exterior or between the doors.
• The ambient weather may be humid, this
is quite normal in humid weather. >>>
The condensation will dissipate when the
humidity is reduced.
The interior smells bad.
• The product is not cleaned regularly. >>>
Clean the interior regularly using sponge,
warm water and carbonated water.
• Certain holders and packaging materials
may cause odour. >>> Use holders and
packaging materials without free of
odour.
• The foods were placed in unsealed hold-
ers. >>> Keep the foods in sealed hold-
ers. Microorganisms may spread out of
unsealed food items and cause bad
odour.
• Remove any expired or spoilt foods from
the product.
The door is not closing.
• Food packages may be blocking the
door. >>> Relocate any items blocking
the doors.
• The product is not standing in full upright
position on the ground. >>> Adjust the
stands to balance the product.
• The surface is not flat or durable >>>
Make sure the surface is flat and suffi-
ciently durable to bear the product.
Produkt Specifikationer
| Mærke: | Grundig |
| Kategori: | Fryser |
| Model: | GKN5686V |
Har du brug for hjælp?
Hvis du har brug for hjælp til Grundig GKN5686V stil et spørgsmål nedenfor, og andre brugere vil svare dig
Fryser Grundig Manualer
16 December 2024
12 December 2024
18 Oktober 2024
7 Oktober 2024
2 September 2024
27 August 2024
27 August 2024
27 August 2024
27 August 2024
27 August 2024
Fryser Manualer
- Fryser Comfee
- Fryser Whynter
- Fryser Wilfa
- Fryser Bauknecht
- Fryser Dometic
- Fryser Finlux
- Fryser White Knight
- Fryser Titanium
- Fryser PowerXL
- Fryser Commercial Cool
- Fryser Baumatic
- Fryser Veripart
- Fryser Gorenje
- Fryser Bluesky
- Fryser PKM
Nyeste Fryser Manualer
4 Juni 2025
4 Juni 2025
3 Juni 2025
3 Juni 2025
3 Juni 2025
2 Juni 2025
2 Juni 2025
2 Juni 2025
2 Juni 2025
1 Juni 2025
