Side 1/7

Touch/Glass sensor 1gang comfort with bus coupling unit

Order No. : 7514 1x xx

Touch/Glass sensor 2gang comfort with bus coupling unit

Order No. : 7514 2x xx

Touch/Glass sensor 3gang comfort with bus coupling unit

Order No. : 7514 3x xx

Touch/Glass sensor 4gang comfort with bus coupling unit

Order No. : 7514 4x xx

Operation- and

Assembly Instructions

1 Safety instructions

Electrical equipment may only be installed and fitted by electrically skilled persons.

Failure to observe the instructions may cause damage to the device and result in fire and

other hazards.

Do not operate the device with sharp or pointed objects. The touch-sensitive surface

could be damaged.

Do not use sharp objects for cleaning. Do not use acids or organic solvents.

These instructions are an integral part of the product, and must remain with the end

customer.

2 Device components

Figure 1

(1) User interface

(2) Sensor buttons for operating functions

(3) Status LED

(4) Operation LED

Seite 1/7

Touch/Glass sensor comfort

32585401

97-09937-000 16.09.2013

KNX

3 Function

System information

This device is a product of the KNX system and complies with the KNX directives. Detailed

technical knowledge obtained in KNX training courses is a prerequisite to proper

understanding.

The function of this device depends upon the software. Detailed information on loadable

software and attainable functionality as well as the software itself can be obtained from the

manufacturer´s product database.

Planning, installation and commissioning of the device are carried out with the aid of KNX-

certified software. Full functionality with KNX commissioning software version ETS3.0d

onwards.

An updated version of the product database, technical descriptions and conversion programs

and other auxiliary programs are available on our Internet website.

Intended use

- Operation of loads, e.g. light on/off, dimming, blinds up/down, brightness values,

temperatures, calling up and saving light scenes, etc.

- Touch sensor: Installation in double flush-mounted appliance box according to DIN 49073

- Glass sensor: Installation in double installation socket for glass sensor (see chapter 6.3.

Accessories)

Product characteristics

- The pushbutton functions switching, dimming, controlling blinds, value transmitter, calling

up moods, etc.

- Operation through touching the sensor buttons

- LED to display status or actuation

- Integrated room temperature sensor for operation as controller extension

- Integrated bus coupling unit

4 Operation

The operation of functions or electrical consumers can be set individual for each device. Two

operating modes are used:

- Single button operation:

Switching on or off or dimming brighter/darker, e.g. of lighting, takes place alternately when

the same sensor button is pressed repeatedly.

- Two button operation:

Two sensor buttons next to each other form a function pair. Pressing the left button,

for example, switches or dims lighting on or brighter, pressing the right one switches it off

or makes it darker.

Operating a function or load

Consumers such as lighting, blinds, etc. are operated using the sensor buttons (2) and such

operation depends on the programming of the device.

o Press a sensor button.

The stored function is executed.

i The actuation pulse is relative to the length of touch. Depending on the function, short and

long actuations may trigger different actions, e.g. switching/dimming.

Cleaning the device

The device can be blocked for 60 s to prevent unintentional actions from being executed when

the glass is being cleaned.

o Recalling cleaning function by external telegram, e.g. from central

All the functions on the device are blocked for 60 s.

All the status LEDs of the sensor buttons flash.

i Cleaning with a lightly moistened, lint-free cloth, possibly with a mild glass cleaner. Do not

use sharp objects or abrasive cleaning agents, e.g. scouring powder.

Seite 2/7 16.09.2013

32585401

97-09937-000

KNX

Touch/Glass sensor comfort

Produkt Specifikationer

Mærke:	Hager
Kategori:	Ikke kategoriseret
Model:	75142850
Kode for international beskyttelse (IP):	IP20
Bredde:	81 mm
Dybde:	23 mm
Højde:	152 mm
Produktfarve:	Hvid
Driftstemperatur (T-T):	-5 - 45 °C
Husmateriale:	Glas
Antal produkter inkluderet:	1 stk
