Side 1/13

Glass sensor 2gang with room thermostat

Order No. : 7564 2x xx

Glass sensor 3gang with room thermostat

Order No. : 7564 3x xx

Operation- and

Assembly Instructions

1 Safety instructions

Electrical equipment may only be installed and fitted by electrically skilled persons.

Serious injuries, fire or property damage possible. Please read and follow manual fully.

Do not use any sharp objects, acids or organic solvents for cleaning. Device can be

damaged.

Do not operate the device with sharp or pointed objects. The touch-sensitive surface

could be damaged.

These instructions are an integral part of the product, and must remain with the end

customer.

2 Device components

Figure 1

(1) Sensor buttons / , /– OK + ¨

(2) Sensor buttons for operating functions

(3) Status LED

(4) Operation LED

3 Function

System information

This device is a product of the KNX system and complies with the KNX directives. Detailed

technical knowledge obtained in KNX training courses is a prerequisite to proper

understanding.

The function of this device depends upon the software. Detailed information on loadable

software and attainable functionality as well as the software itself can be obtained from the

manufacturer´s product database. Planning, installation and commissioning of the device are

carried out with the aid of KNX-certified software. The latest versions of product database and

the technical descriptions are available on our website.

Seite 1/13

Touch/Glass sensor 2gang / 3gang with room thermostat

32586901

97-09635-000 13.09.2013

KNX

Intended use

- Operation of loads, e.g. light on/off, dimming, blinds up/down, brightness values,

temperatures, calling up and saving light scenes, etc.

- Touch sensor: Installation in double flush-mounted appliance box according to DIN 49073

- Glass sensor: Glass sensor TS: Installation in double installation socket for glass sensor

(see chapter 6.3. Accessories)

Product characteristics

- The pushbutton functions switching, dimming, controlling blinds, value transmitter, calling

up moods, etc.

- Operation through touching the sensor buttons

- LED to display status or actuation

- Integrated room temperature sensor

- Room temperature control with setpoint value specification

- Display of room and setpoint temperature

- Display of external temperature; in conjunction with external KNX temperature sensor

- Display of day and time, in conjunction with KNX time encoder

- Temperature limitation for floor heating; in conjunction with external temperature sensor

- Integrated bus coupling unit

4 Operation

The operation of functions or electrical consumers can be set individual for each device. Two

operating modes are used:

- Single button operation:

Switching on or off or dimming brighter/darker, e.g. of lighting, takes place alternately when

the same sensor button is pressed repeatedly.

- Two button operation:

Two sensor buttons next to each other form a function pair. Pressing the left button,

for example, switches or dims lighting on or brighter, pressing the right one switches it off

or makes it darker.

Operating a function or load

Consumers such as lighting, blinds, etc. are operated using the sensor buttons (2) and such

operation depends on the programming of the device.

o Press a sensor button.

The stored function is executed.

i The actuation pulse is relative to the length of touch. Depending on the function, short and

long actuations may trigger different actions, e.g. switching/dimming.

Operating modes and display icons

The device compares the current room temperature with the setpoint temperature and controls

heating or cooling devices according to the current demand. The setpoint temperature depends

on the current operating mode and can be changed by the user, depending on the

programming. The operating modes and the current controller status are shown in the display.

Seite 2/13 13.09.2013

32586901

97-09635-000

KNX

Touch/Glass sensor 2gang / 3gang with room thermostat
