HA354

Load break switch 3P 250A

Technical characteristics

Architecture

Type of order Long thumb-grip

Number of poles 3 P

Type of pole 3 P

Type of case Fixed built-in

Functions

Reversing switch No

Controls and indicators

Motor drive integrated No

Main electrical features

Rated operational voltage Ue 380 / 415 V

Voltage

Rated insulation voltage 800 V

Rated impulse withstand voltage 8000 V

Electric current

Rated operational current in AC21category

B 250 A

Acceptable current rating with AC22

category A 250 A

Cut off current 4.3 kA

Rated current 250 A

Short-circuit current with gI-gG fuses 50 kA

Rated short-time withstand current 1s 9 kA

Thermal rated current outside of housings 250 A

Rated operational current in AC21 category

A 250 A

Acceptable current rating with AC22

category B 250 A

Rated operational current in AC23 category

A 200 A

Acceptable current rating with AC23

category B 200 A

Conventional thermal current under

enclosure at 40°C 250 A

Dimensions

Depth of installed product 130 mm

Height of installed product 160 mm

Subject to technical modifications

Width of installed product 180 mm

Power

Nominal power under 440/500, 50Hz 90 kW

Total power loss under IN 17.4 W

Power loss per pole at In 5.8 W

Contact rating with 400 V in AC1 164 kW

Cover, door

Interlockable Yes

Installation, mounting

Fixation type Back plate monting

Connection

Connection cross-sect. flexible conductor 120mm²

Connection cross-sect. rigid cable 150mm²

Type of connection Terminal

Equipment

Number of auxiliary contacts as normally

closed contact 0

Number of auxiliary contacts as normally

open contact 0

Number of auxiliary contacts as change-

over contact 0

Width available for insulation connection 185

Motor drive optional No

Standards

Standard text IEC 60947-3

European directive WEEE concerned

Safety

Protection index IP IP00

Use conditions

Operating temperature -20…70 °C

Identification

meta_keyword

Switch disconnector;Load disconnecting switch;Main

switch;Switch;Disconnector

Subject to technical modifications
