Hager Ltd. Hortonwood 50, Hortonwood, Telford, TF1 7FT / 01952 675 675 1

Cat ref.

Steel Enclosure

Cat ref.

GRP Enclosure

4 1 IP65 Triple Pole Ways 25A TP&N Board - H800 x W600 x D300mm JK104BD JK104BF

6 Triple Pole Ways 125A IP65 TP&N Board - H800 x W600 x D300mm JK106BD JK106BF

8 Triple Pole Ways 125A IP65 TP&N Board - H800 x W600 x D300mm JK108BD JK108BF

12 Triple Pole Ways 125A IP65 TP&N Board - H1250 x W850 x D300mm JK112BD JK112BF

JK116BD JK116BF

Invicta 3 25A1

IP65 T &N Distribution P

Boards

A range of Type B TPN Distribution boards

Installed within an IP65 Enclosure, available in either

Steel (mild steel powder coated) or Glass Reinforced

Plastic (GRP).

Conforming the BS EN 61439-3. A wide range f incoming options create a versatile o

solution. urge rotection options ensure efficient integration in to the With S p to

buildings electrical upply model. s

Description

16 Triple Pole Ways 125A IP65 TP&N Board - H1250 x W850 x D300mm

Incomer Kits for 125A Boards

Description

Max Cable Capacity

Solid Cat ref.

3 Pole 100A Switch Disconnector Incomer Kit (Fits within distribution board) 50mm² JK11003S

4 Pole 100A Switch Disconnector Incomer Kit (Fits within distribution board) 50mm² JK11004S

3 Pole 125A Switch Disconnector Incomer Kit (Fits within distribution board) 50mm² JK11253S

4 Pole 125A Switch Disconnector Incomer Kit (Fits within distribution board) 50mm² JK11254S

125A Direct Connection Kit (Fits within distribution board) 50mm² JK11254D

4 Pole 63A 30mA RCCB Incomer Kit (Fits within distribution board) 25mm² JK10634RH

4 Pole 100A 30mA RCCB Incomer Kit (Fits within distribution board) 50mm² JK11004RH

4 Pole 100A 300mA RCCB Incomer Kit (Fits within distribution board) 50mm² JK11004RL

4 Pole 100A 300mA Time Delayed RCCB Incomer Kit (Fits within distribution board) 50mm² JK11004RLD

4 Pole 100A 100mA RCCB Incomer Kit (Fits within distribution board) 50mm² JK11004RM

4 Pole 100A 100mA Time Delayed RCCB Incomer Kit (Fits within distribution board) 50mm² JK11004RMD

Surge Protection Kits

Description Cat ref.

Type 1 & 2 Surge protection Kit JK101SPD

Type 2 Surge protection Kit JK102SPD

Hager Ltd. Hortonwood 50, Hortonwood, Telford, TF1 7FT / 01952 675 675 2

Technical Characteristics

Standards Designed, manufactured and tested to

BS EN 61439-3

Busbar Current Rating 125A

Busbar Type Fully shrouded copper

Busbar Rating 25kA Conditional

Incoming 125A 3 or 4 Pole Switch Disconnector

Direct Connection

RCCB Incomers

Outgoing Ways 4 6 8 2 16, , , 1 , Triple pole outgoing ways

Outgoing Protection Type B MCB (6A to 63A, 1P & 3P)

Type C, D MCB, (0.5A to 63A, 1P & 3P)

1Mod and 2Mod RCBO

Voltage Rating in AC 230 / 415V

IP Protection IP65

Enclosure Body Type Steel or Glass Reinforced Plastic GRP

Enclosure Paint Type Powder Coat Grey White BS4800 00A01

Terminal Connection Capacity

Incoming Earth Terminal M8 stud

Incoming Neutral Terminal 50mm² cage or M6 stud

Outgoing Earth Terminals 16mm²

Outgoing Neutral Terminals 16mm²

Enclosure Earth Stud M8

Devices

MCB 10kA 0.5A to 63A NBN*** NCN*** NDN***

RCBO 10kA 6A to 45A ADB*** ADC*** ADA1** ACB*** ACC***

MCB 10kA / 15kA 80A to 125A HMC*** HMD***

Invicta 3 TP&N Distribution Board125A IP65
