Side 1/4

www.hager.com

Safety instructions

Electrical equipment must only be installed and assembled by a qualied

electrician in accordance with the relevant installation standards, regulations,

directives and safety and accident prevention directives of the country.

Failure to comply with these installation instructions may result in damage to

the device, re or other hazards.

Function

Multiple frames for 2gang to 5gang combinations of ush-mounted devices.

The frames are suitable for vertical as well as for horizontal installation.

Correct use

- For ush-mounted installation with standard connectable wall boxes.

- Only suitable for use in indoor areas with no drip and no spray water.

Technical data

For horizontal installation:

Dimensions (Width x Height)

- 2gang: 170.2 x 86 mm

- 3gang: 256.3 x 86 mm

- 4gang: 342.3 x 86 mm

- 5gang: 428.3 x 86 mm

For vertical installation:

Dimensions (Width x Height)

- 2gang: 86 x 170.2 mm

- 3gang: 86 x 256.3 mm

- 4gang: 86 x 342.3 mm

- 5gang: 86 x 428.3 mm

Multi-gang frames

2gang / 3gang / 4gang / 5gang

Hager Dream

Installation manual

Information for electricians

Installation and electrical connection

Preparing the devices for installation

Remove cover at every single device to be combined (see installation manual of the

respective device).

Connecting the devices for multiple combinations

(for example with "3gang frame (horizontal)")

For tting of the devices the multi-gang frame has two diagonally arranged snap mecha-

nisms (1). On the outside corners of the supporting plate the devices have corresponding

xing holes for snapping onto multi-gang frame.

Fixing holes

Snap

mechanisms

Click

Depending on the application position the multi-gang frame horizontally or vertically.

Example here: horizontal (1).

Snap the devices one after the other in the desired order on the multi-gang frame (1).
