Side 1/4
www.hager.com
Safety instructions
Electrical equipment must only be installed and assembled by a qualied
electrician in accordance with the relevant installation standards, regulations,
directives and safety and accident prevention directives of the country.
Failure to comply with these installation instructions may result in damage to
the device, re or other hazards.
Function
dimmable electronic transformers (marked with L, C) with halogen lamps.
Recommendation: Use Osram transformator ET-PARROT 105/220…240 I.
Correct use
- For the ush-mounted installation in standard wall boxes
(recommended wall box depth ≥ 35 mm).
- Only suitable for use in indoor areas with no drip and no spray water.
Product characteristics
- Dimming principle: phase cut-on
- Change-over switch in combination with change-over switch possible.
- Short-circuit proof and overload proof
Technical data
Rated voltage: 230 V~
Frequency: 50/60 Hz
230 V incandescent and halogen lamps: 40 ... 500 W
Electronic transformers (marked with L,C): 40 ... 250 W
Conductor cross-section of screw terminals: max. 3 x 1.5 mm²
Distance of xing holes: 60.3 mm
Operating temperature: -5 ... +45 °C
Relative humidity (without condensation): 5 ... 95 % (at 25 °C)
Standards: BS EN 60669-2-1, IEC 60669-2-1
Mixed operation of 230 V incandescent and halogen lamps as well as electronic
transformers (marked with L,C until smallest maximum load possible.
40-500W Single dimmer
Hager Dream
Installation and operating
instructions
2
Operating the device
The switch-on brightness level depends on the position of the dimmer.
Information for electricians
Installation and electrical connection
DANGER!
Touching live parts can result in an electric shock.
An electric shock can lead to death.
Disconnect the connecting cables before working on the device and
cover all live parts in the area!
ç
Preparing the device for installation
Notches
Cover
1
Carefully loosen the cover on the notches with a at-blade screwdriver (1).
Remove the cover.
