SPLIT TYPE ROOM AIR CONDITIONER

OPERATION MANUAL

●

Please read this operation manual before using the air

conditioner. Keep this operation manual for future reference.

0010595326

CAUTIONS

PART

S AND FUNCTIONS

OPER

ATION

MAINTENANCE

TROUBLE SHOOTING

HSU-12ANTIRUSTCOOL(INV)(TH)

HSU-12CLEANCOOL(INV)(TC)

HSU-12ENERGYCOOL(INV)(TR)

HSU-18ANTIRUSTCOOL(INV)(TH)

HSU-18CLEANCOOL(INV)(TC)

HSU-18ENERGYCOOL(INV)(TR)

HSU-18UVCOOL(SMART)(INV)(PB)

HSU-24ANTIRUSTCOOL(INV)(TH)

HSU-24CLEANCOOL(INV)(TC)

HSU-24ENERGYCOOL(INV)(TR)

HSU-10TSV13(DC)-SC

HSU-10TSP13(DC)-SC

HSU-12TSV13(DC)-SC

HSU-12TSP13(DC)-SC

HSU-18TSV13(DC)-SC

HSU-24TSV13(DC)-SC

HSU-10VTH21/10VTK21

HSU-13VTH21/13VTK21

HSU-19VTH21/19VTK21

HSU- 25VTH21

HSU-10VQA22/10VQC22

HSU-13VQA22/13VQC22

HSU-19VQA22/19VQC22

HSU-25VQA22/25VQC22

HSU-10VXA21

HSU-13VXA21

HSU-10XSV32

HSU-13XSV32

HSU-10VQB22

HSU-13VQB22

HSU-19VQB22

HSU-10PSV32

HSU-13PSV32

HSU-19PSV32

HSU-25PSV32

HSU-10QSV32

HSU-13QSV32

HSU-19QSV32

HSU-25QSV32

Remote controller

Parts and Functions

Indoor Unit

Outdoor Unit

●

OUTLET

INLET

CONNECTING PIPING

AND ELECTRICAL

WIRING DRAIN HOSE

Display board

Actual inlet grille and Display board may vary from the one

shown in the

manual according to the product purchased

(adjust left and

Vertical blade

right air flow)

Air Purifying Filter

Inlet

(inside)

Emergency

Switch

Horizontal flap

Don't adjust it manually

Inlet grille

Outlet

Anion generator

(

inside,

only applicable for certain

Display board

Signal receiver

emp.display

Operation mode indicator

1. Mode display

Operation mode

FAN

COOL DRY

Remote controller

2.Signal sending

3.display SWING

4.display FAN SPEED display

LO MED HI

AUTO

circulated

5. LOCK display

6.TIMER OFF display

7.TIMER ON display

8.TEMP display Additional

functions display

Operation mode

Remote controller

QUIET TURBOSLEEP HEALTH

Loading of the battery

Remove the battery cover;

Load the batteries as illustrated.

2 R-03 batteries, resetting key

(cylinder);

is in line with th

e" + "/"-";

Load the battery,then put on the cover again.

The distance between the signal transmission head and the rece-

iver hole should be within 7m without any obstacle as well.

Note:

When electronic-started type fluorescent lamp or change-

over

type fluorescent lamp or

wireless telephone is installed in the

room, the recei

ver is apt to be disturbed in receiving

the signals,

so the distance to the indoor unit should be shorter.

Full display or unclear display during operation indicates the

batte

ries have been used up

Please change batteries.

If the remote controller can't run normally during operation, please

remove the batteries and

reload several minutes later.

(adjust up and down air flow

SLEEP

TIME

SWING

EXTRA

FUNCTION

LOCK

LIGHT

R E S E T

MODE

SLEEP

I FEEL

HEALTH

TIMER

SELF

CLEAN

HEALTH

AIRFLOW

1. Mode display

Operation mode

FAN

COOL DRY

Remote controller

LO MED HI

AUTO

circulated

Operation mode

Remote controller

QUIET TURBOSLEEP HEALTH

Be sure that the loading

9.TURBO/QUIET button

10.SELF CLEAN button

11.COOL button

12.SWING LEFT/RIGHT button

(only applicable for certain models)

13.FAN SPEED button

14.HEALTH button/DRY button

(Refer to the actual remote control layout

for specific functions)

15.SLEEP button

16.LOCK button

17.LIGHT button

18.POWER ON/OFF button

19.DRY button/ECO button

(Refer to the actual remote control layout

for specific functions)

20.TEMP button

21.SWING UP/DOWN button

22.TIME OFF/ON button

23.EXTRA FUNCTION button

Function :FAN---Healthy airflow position1---

Healthy airflow position2

Function :FAN --- Health

24.CONFIRM/CANCEL button

Function :Setting and cancel to the timer

and other additional functions.

25.RESET button

When the remote controller appears

abnormal,use a sharp pointed article to

press this button to reset the remote.

9.TURBO/QUIET button

10.SELF CLEAN button

11.MODE button

12.SWING UP/DOWN button

13.FAN SPEED button

14.I FEEL button

15.SLEEP button

16.LOCK button

17.LIGHT button

18.POWER ON/OFF button

19.ECO button

20.TEMP button

21.SWING LEFT/RIGHT button

(only applicable for certain models)

22.HEALTH AIR FLOW button

23.CONFIRM/CANCEL button

Function :Setting and cancel to the

timer and other additional functions.

24.TIMER button

25.HEALTH button

26.RESET button

When the remote controller appears

abnormal,use a sharp pointed

article to press this button to reset

the remote.

5. LOCK display

6.TIMER OFF display

7.TIMER ON display

8.TEMP display Additional

functions display

2.Signal sending

3.display SWING

4.display FAN SPEED display

CONFIRM

CANCEL

TURBO/QUIET

LOCK

LIGHT

R E S E T

TIME

OFF

CONFIRM

CANCEL

COOL

SELF

CLEAN

TURBO/QUIET

（

DRY/ECO）

(HEALTH/DRY)

Type 1

Type 2
