Please read this operation manual before using the air conditioner.

Keep this operation manual for future reference.

SPLIT TYPE ROOM AIR CONDITIONER

OPERATION MANUAL

0010518786

Contents

2-4

6.7

CAUTIONS

PARTS AND FUNCTIONS

OPERATION

MAINTENANCE

TROUBLE SHOOTING

HSU-09HEK03

HSU-09LEK03

HSU-12HEK03

HSU-12LEK03

HSU-09LEK13

HSU-12LEK13

HSU-07LEK03

HSU-07HEK03

HSU-18LEK13

HSU-24LEK13

HSU-12LEK13-M

HSU-18HEK03

HSU-24HEK03

HSU-18LK2S3

HSU-12LEK03-Y3

HSU-24LK2S3

HSU-18LEK03-Y3

HSU-24LEK03-Y2

HSU-09CK2S3

HSU-09LEK03-Y3

HSU-12CK2S3

HSU-09CK2W3

HSU-09CK6B3

HSU-12CK2W3

HSU-12CK6B3

HSU-18LK2W3

HSU-18LK6B3

SAS-09HEK3

SAS-12HEK3

SAS-18HEK3

SAS-24HEK3

HSU-12LEK03-Y5

HSU-09LEK03-Y5

HSU-12LH03

HSU-09LH03

HSU-18LEK03-Y5

HSU-18LH03

HSU-24LEK03-Y5

HSU-24LH03

HSU-12HH03

HSU-09HH03

HSU-18HH03

HSU-24HH03

HSU-12HEG03

HSU-09HEG03

HSU-18HEG03

HSU-24HEG03

HSU-12LEK03-Y6

HSU-18LEK03-Y6

HSU-12LEK03-Y2

HSU-24LEK03-Y3

HSU-09LEK03-Y2

HSU-18LEK03-Y2

YKS-18HEK03

YKS-24HEK03

HSU-18LEK03

HSU-24LEK03-Y6

HSU-12LEK03-Y4

HSU-18LEK03-Y4

HSU-24LEK03-Y4

HSU-09LEK03-Y4

HSU-09LEK03-Y6

HSU-18LK2W3

HSU-18LK6B2

HSU-24LK2S2

HSU-12CK6B2

HSU-24LEK03

HSU-18LEK03EK1

HSU-26HEK03

Inlet grille

Inlet

Air Purifying Filter (inside)

Outlet

Horizontal flap

Parts and Functions

Actual inlet grille may vary from the one shown in the

manual according to the product purchased

adjust up and down air flow Don't adjust it manually

adjust left and right air flow

Vertical blade

Remote controller

If the unit which you purchased has healthy function,follow it.If not,please ignore.

NOTE:

Cooling only unit do not have displays and functions related with heating

(inside)

Power indicator

Timer mode indicator

Operation mode indicator

(Lights up when unit starts.)

(Lights up whenTimer operation is selected.)

(lights up when the compressor is on.)

Remote signal receiver

(A beeping sound is generated when a signal

from remote controller isreceived.)

Ambient temp display

When receiving the remote control signal, display the set

temperature and in the rest time the room temperature is

displayed and this room temperature is only for reference.

Anion generator

Outdoor Unit

Indoor Unit

OUTLET

INLET

CONNECTING PIPING AND ELECTRICAL WIRING

DRAIN HOSE

Remove the battery cover;

Load the batteries as

illustrated. 2 R-03 batteries,

resetting key(cylinder);

Be sure that the loading

is in line with the" + "/"-";

Load the battery,then put on the cover again.

The distance between the signal transmission head and the

receiver hole should be within 7m without any obstacle as well.

When electronic-started type fluorescent lamp or change-over

so the distance to the indoor unit should be shorter.

wireless telephone is installed in the type fluorescent lamp or

room, the receiver is apt to be disturbed in receivingthe signals,

Note:

Full display or unclear display during operation indicates the

ries have been used up.Please change batteries.

If the remote controller can't run normally during operation,

reload several minutes later.

batte

remove the batteries and

Remove the batteries in case unit won't be in usage for a long period.

If there are any display after taking-out, just need to press reset key

Hint:

Loading of the battery

please

Clock set

Press CLOCK button, "AM" or "PM" flashes.

Press or to set correct time. Each press

change quickly.

After time setting is confirmed,press SET,

"AM "and "PM" stop flashing,while clock starts working.

or decrease 1min. If the

button is kept pressed,time will

will increase

TIMER

CLOCK

SET SLEEP

FAN

DRY

COOL

AUTO

1. Mode display

2. SWING display

3. FAN SPEED display

4. SLEEP display

5. LOCK display

6. SIGNAL SENDING

7. TIMER OFF display

8. TIMER ON display

9. CLOCK display

10. TEMP display

11. POWER ON/OFF

Used for unit start and stop.

12. MODE

Used to select AUTO run, COOL,

DRY HEAT and FAN operation.,

13. FAN

Used to select fan speed LO,

14. HOUR

Used to set clock and timer setting.

15. SWING

Used to set auto fan direction.

16. SLEEP

Used to select sleep mode.

17. LOCK

Used to lock buttons and LCD display.

18. TEMP.SETTING

Used to select your desired temp.

LO MED HIAUTO

HEAT

ON/OFF

FAN

MODE

SWING

TIMER

CLOCK

SET SLEEP

LOCK RESET

19. SET /

Used to confirm timer and clock

settings.

20. TIMER

Used to select TIMER ON,

TIMER OFF,TIMER ON-OFF

21. CLOCK Used to set correct time

22. RESET

Used to reset the controller back

LIGHT

HEALTH

23. HEALTH

Used to operate the healthy function

MED, HI, AUTO

to normal condition.

and LCD display.(This function is

unacailable on some models.)
