Design may vary by model number.
numéro de modèle.
El diseño puede variar conforme al
número de modelo
This user manual is to be only used for
electronic control 15,000 BTU, 18,000
BTU and 24,000 BTU - Some models
may have an additional letter after the
model number.
Ce guide d'utilisation doit être
utilis tement avec les modèles éstric
à commande électronique de
15,000BTU, 18 000 BTU et 24 000 BTU
- Sur certains modèles, le numéro de
modèle peut être suivi d'une lettre.
Este manual del usuario sólo se debe
utilizar para el control electrónico
15,000 BTU, 18,000 BTU y 24,000 BTU –
Algunos modelos pueden tener
unaletraadicional después
delnúme ode modelr o.
HWR15XCR
HWR18VCR
HWR24VCR
HWE15XCR
HWE18VCR
HWE24VCR
User & Care Guide
Guide d'utilisation et d'entretien
Guía de uso y cuidado
Room Air Conditioner
Climatiseur individuel
Aire acondicionado
de uso doméstico
0010559978
ENGLISH
TABLE OF CONTENTS
PRODUCT REGISTRATION
Thank you for purchasing our Haier
product. This easy-to-use manual will guide
you in getting the best use of your product.
Remember to record the model and serial
numbers. They are on a label on the side of
your unit.
Model number
Serial number
Date of purchase
Staple your receipt to your manual. You will need it to obtain warranty service.
SAFETY INFORMATION ............................................................................................................. 2
Important Safety Precautions ................................................................................................ 2-3
Operational Safety & Warnings ..................................................................................................4
INSTALLATION REQUIREMENTS .............................................................................................5
Tools and Parts ............................................................................................................................5
Location Requirements ..............................................................................................................6
Electrical Requirements .......................................................................................................7-10
HOW TO INSTALL ....................................................................................................................11
Unpacking the Air Conditioner .................................................................................................11
Preparing the Air Conditioner ............................................................................................11-13
Preparing the Window ..............................................................................................................14
Completing the Installation ................................................................................................15-16
USING YOUR AIR CONDITIONER ...........................................................................................17
Starting the Air Conditioner ...............................................................................................17-21
Using the Remote Control ........................................................................................................22
Changing the Air Direction .......................................................................................................22
CARING FOR YOUR AIR CONDITIONER ................................................................................23
Cleaning the Air Filter ...............................................................................................................23
Cleaning the Front Panel ..........................................................................................................24
Customer Service .....................................................................................................................24
Normal Sounds of an Air Conditioner ......................................................................................25
TROUBLESHOOTING ..............................................................................................................26
LIMITED WARRANTY ...............................................................................................................27
SAFETY INFORMATION PAGE 3
ENGLISH
8. This air conditioner contains R410a refrigerant and requires certified
technicians to use the proper equipment, tools and safety standards that
are approved for this refrigerant. Use only equipment for R410a certified
refrigerant. In addition, under federal law, all refrigerant must be properly
removed from the air conditioner prior to its disposal.
For responsible disposal of the product, please contact your local
municipality for additional recycling options in your area.
READ AND FOLLOW THE
SAFETY INSTRUCTIONS CAREFULLY.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY PRECAUTIONS
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the
State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the
State of California to cause birth defects or other reproductive harm.
ENGLISH
INSTALLATION REQUIREMENTS PAGE 7
ELECTRICAL REQUIREMENTS
1. DO NOT cut or remove the grounding prong on the attached power supply cord. Doing so may
cause sparks or fire, and voids all warranties. For safety purposes the air conditioner must be
properly grounded.
2. To avoid a fire hazard or possible electric shock, DO NOT use an adapter plug, extension cord,
surge protectors, or multi-outlet adapters with the air conditioner.
3. The power supply cord is equipped with a 3-prong plug which mates with the grounded 3-prong
wall outlet to minimize the possibility of electrical shock from this air conditioner.
4. The power supply cord includes a leakage current detection interrupter device (LCDI). A
RESET and TEST button are on the plug case. The device should be tested on a periodic
basis by pressing the TEST button and then the RESET button while it is plugged into the wall
outlet. If the TEST button does not trip or the RESET will not stay engaged, do not use the air
conditioner and contact a qualified service technician.
5. Have the wall outlet and circuit inspected by a qualified electrician to ensure that the wall outlet
is properly grounded.
6. If there is a 2-prong wall outlet present and not a 3-prong wall outlet, it is the responsibility of
the user to have it replaced with a properly grounded 3-prong outlet.
7. The air conditioner should always be plugged into a dedicated electrical outlet which has a
voltage rating that matches the serial label on the side of the air conditioner.
8. The electrical ratings for your air conditioner are listed on the Model/Serial Number label. The
Model/Serial Number label is located on the side of the air conditioner cabinet.
9. Specific electrical requirements are listed in the chart below. Follow the requirements for the
type of plug on the power supply cord.
ELECTRICAL SAFETY and WARNINGS
WARNING
ENGLISH
PAGE 8 INSTALLATION REQUIREMENTS
ELECTRICAL REQUIREMENTS cont.
POWER SUPPLY CORD (See Fig.2)
Wiring Requirements
For model HWE15XCR, HWR15XCR
• 115-volt (103.5 minimum to 126.5 maximum)
• 15-amp time-delay grounded fuse or circuit breaker
• Use on single outlet circuit only.
For model HWE18VCR, HWR18VCR
• 230/208 volt (187 min. to 253 max.)
• 15-amp time-delay fuse or circuit breaker
• Use on single outlet circuit only.
For model HWE24VCR, HWR24VCR
• 230/208 volt (187 minimum to 253 maximum)
• 20-amp time-delay grounded fuse or circuit breaker
• Use on single outlet circuit only.
REQUIRED GROUNDING METHOD (See Fig.2)
This air conditioner must be grounded. This air conditioner is equipped with a power
supply cord that has a 3 prong grounding plug. The power supply cord must be plugged
into a mating, grounded 3 prong outlet, and grounded in accordance with all local codes and
ordinances. If a mating outlet is not available, it is the customer’s responsibility to contact a
qualified electrician and ensure that a properly grounded 3 prong
outlet is installed.
POWER SUPPLY CORD (See Fig.3)
NOTE: Your air conditioner's plug may er slightly in appearance diff
from the one shown.
A. Reset button
B. Test button
This room air conditioner is equipped with an a leakage current detection interrupter (LCDI)
power supply cord required by UL. This power supply cord contains a current detection device.
If the power supply cord is crushed, this device will detect current leakage and power will be
disconnected from the air conditioner. If this power supply cord is damaged, it cannot be
repaired and must be replaced with a cord from the product manufacturer. If the power supply
cord is damaged call Haier Customer Service: 1-877-337-3639.
RESET
TEST
A
B
Fig. 3
Fig. 2
HWE15XCR
HWR15XCR
HWE18VCR
HWR18VCR
HWE24VCR
HWR24VCR
115V
15 Amp
230V
15 Amp
230V
20 Amp
ENGLISH
CLEANING THE AIR FILTER
USING YOUR AIR CONDITIONER PAGE 23
The air filter is removable for easy cleaning. A clean air filter helps remove dust, lint, and particles
from the air for optimal cooling and operating efficiency. The Filter Reset light will turn on to
notify you that the air filter must be cleaned. The light goes on after the air conditioner has been
operating for 240 hours.
1. Turn off the air conditioner and unplug the power supply cord from the outlet.
2. Remove the air filter by opening the front panel and removing the air filter. (See Fig.21)
3. Use a vacuum cleaner with the hose attachment to clean the air filter. If the air filter is very
dirty, wash it in warm water with a mild detergent. Do not wash the air filter in a dishwasher or
clothes washer, or use any chemical cleaners. Do not use a clothes dryer or microwave oven to
dry it. Air-dry the air filter completely before placing it back in the unit.
4. Place the air filter back in the air conditioner.
5. Close the front panel.
6. Plug the power supply cord into the outlet, turn on the air conditioner and press the filter reset
button to turn off the indicator light.
NOTE: Do not operate the air conditioner without the filter in place.
Fig. 21
