THERMAL
NETWORK CAMERA
User Manual
TNO-4030T/TNO-4040T/TNO-4041T
TNO-4050T/TNO-4051T
TNO-4030TR/TNO-4040TR/TNO-4041TR
Copyright
©2018 Hanwha Techwin Co., Ltd. All rights reserved.
Trademark
Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their
respective company.
Restriction
Copyright of this document is reserved. Under no circumstances, this document shall be reproduced, distributed or changed, partially or wholly, without
formal authorization.
Disclaimer
Hanwha Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be
provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Hanwha Techwin reserves the
right to change the contents of this document without prior notice.
Design and specications are subject to change without prior notice.
The initial administrator ID is “admin” and the password should be set when logging in for the rst time.
Please change your password every three months to safely protect personal information and to prevent the damage of the information
theft.
Please, take note that it’s a user’s responsibility for the security and any other problems caused by mismanaging a password.
Thermal Network Camera
User Manual
English _3
●●overview
important Safety inStructionS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth.
(Do not use a detergent or cosmetic products that contain alcohol, solvents or surfactants or oil constituents
as they may deform or cause damage to the product.)
7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11. Only use attachments/ accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lighting storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15. This product is intended to be supplied by a Listed Power Supply Unit marked “Class 2” or “LPS” and rated
from 24 Vac (50/60 Hz) min.0.91 A or 12 Vdc, min.0.83 A.
16. If you use excessive force when installing the product, the camera may be damaged and malfunction.
If you forcibly install the product using non-compliant tools, the product may be damaged.
17. Do not install the product in a place where chemical substances or oil mist exists or may be generated. As
edible oils such as soybean oil may damage or warp the product, do not install the product in the kitchen or
near the kitchen table.
This may cause damage to the product.
18. When installing the product, be careful not to allow the surface of the product to be stained with chemical
substance.
Some chemical solvents such as cleaner or adhesives may cause serious damage to the product’s surface.
19. If you install/disassemble the product in a manner that has not been recommended, the production functions/
performance may not be guaranteed.
Install the product by referring to “Installation & connection” in the user manual.
20. Installing or using the product in water can cause serious damage to the product.
warninG
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE
VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT.
Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
To prevent injury, this apparatus must be securely attached to the Wall/ceiling in accordance
with the installation instructions.
caution
caution
riSK of eLectric SHocK.
Do not open
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
eXpLanation of GrapHicaL SymBoLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in
the literature accompanying the product.
overview
overview
4_ overview
Class construction
An apparatus with CLASS construction shall be connected to a MAINS socket outlet with a
protective earthing connection.
Battery
Batteries(battery pack or batteries installed) shall not be exposed to excessive heat such as
sunshine, fire or the like.
Disconnection Device
Disconnect the main plug from the apparatus, if it’s defected. And please call a repair man in
your location.
When used outside of the U.S., it may be used HAR code with fittings of an approved
agency is employed.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
ATTENTION
IL Y A RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACÉE PAR UNE BATTERIE DE
TYPE INCORRECT.
METTRE AU REBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS.
These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock do not perform any servicing other than that contained in
the operating instructions unless you are qualified to do so.
The CVBS out terminal of the product is provided for easier installation, and is not
recommended for monitoring purposes.
Please use the input power with just one camera and other devices must not be connected.
The ITE is to be connected only to PoE networks without routing to the outside plant.
The wired LAN hub providing power over the Ethernet (PoE) in accordance with IEEE
802-3af shall be a UL Listed device with the output evaluated as a Limited Power Source
as defined in UL60950-1.
Unit is intended for installation in a Network Environment 0 as defined in IEC TR 62102.
As such, associated Ethernet wiring shall be limited to inside the building.
Please read the following recommended safety precautions carefully.
Do not place this apparatus on an uneven surface.
Do not install on a surface where it is exposed to direct sunlight, near heating equipment or
heavy cold area.
Do not place this apparatus near conductive material.
Do not attempt to service this apparatus yourself.
Do not place a glass of water on the product.
Do not install near any magnetic sources.
Do not block any ventilation openings.
Do not place heavy items on the product.
Please wear protective gloves when installing/removing the camera.
The high temperature of the product surface may cause a burn.
User’s Manual is a guidance book for how to use the products.
The meaning of the symbols are shown below.
Reference : In case of providing information for helping of product’s usages
Notice : If there’s any possibility to occur any damages for the goods and human caused by
not following the instruction
Please read this manual for the safety before using of goods and keep it in the safe place.
English _5
●●overview
contentS
overview
3
3 Important Safety Instructions
6 Recommended PC Specifications
6 Recommended Micro SD/SDHC/SDXC
Memory Card Specifications
6 NAS recommended specs
7 What’s Included (TNO-4030T/4040T/4050T
/4030TR/4040TR)
8
What’s Included (TNO-4041T/4051T/4041TR)
9
At a Glance (TNO-4030T/4040T/4050T/4030TR
/4040TR)
9 At a Glance (TNO-4041T/4051T/4041TR)
installation & connection
10
10 Installation (TNO-4030T/4040T/4050T/
4030TR/4040TR)
11 Installation (TNO-4041T/4051T/4041TR)
13 Inserting/Removing a Micro SD Memory
Card
14 Memory Card Information (Not Included)
14 Connecting with other Device
network connection and
setup
18
18 Connecting the Camera Directly to Local
Area Networking
18 Connecting the Camera Directly to a DHCP
Based DSL/Cable Modem
19 Connecting the Camera Directly to a
PPPoE Modem
19 Connecting the Camera to a Broadband
Router with the PPPoE/Cable Modem
20 Buttons used in IP Installer
20 Static IP Setup
22 Dynamic IP Setup
22 Port Range Forward (Port Mapping) Setup
23 Connecting to the Camera from a Shared
Local PC
23 Connecting to the Camera from a Remote
PC via the Internet
web viewer
24
24 Connecting to the Camera
24 Password setting
24 Login
24 Camera Web Viewer Setup
appendix
25
25 Specification
29 Product Overview
30 Troubleshooting
31 Open Source Announcement
overview
6_ overview
recommenDeD pc SpecificationS
•CPU : Intel(R) Core(TM) i7 3.4 GHz or higher
•RAM : 8G or higher
•Supported OS : MS Windows, Mac OS X
•Recommended browser: Google Chrome
Supported browsers: MS Explorer, MS Edge, Mozilla Firefox (Window 64bit only), Apple Safari (Mac OSX only)
※ Please see the appendix for detailed information on verified OS and browsers.
recommenDeD micro SD/SDHc/SDXc memory carD
SpecificationS
•Recommended capacity : 16GB to 256GB (MLC type)
•The following types of memory cards from the following manufacturers are recommended for this camera.
- Manufacturer : SanDisk, Transcend
- Product family : High endurance
naS recommenDeD SpecS
•Recommended capacity : 200GB or higher is recommended.
•Simultaneous access : One unit of NAS can accept a maximum of sixteen camera accesses.
•For this camera, you are recommended to use a NAS with the following manufacturer’s specs.
Recommended products Available sizes
QNAP NAS A maximum of 16 cameras can access simultaneously.
Synology NAS A maximum of 16 cameras can access simultaneously.
J
`If you use NAS equipment for purposes other than video saving, the number of accessible cameras may be reduced.
English _7
●●overview
wHat’S incLuDeD (tno-4030t/4040t/4050t/4030tr/4040tr)
Please check if your camera and accessories are all included in the product package.
(As for each sales country, accessories are not the same.)
Appearance DescriptionItem Name Quantity
Camera
1
Instruction book,
Installer S/W CD
1
Quick Guide
(Optional)
1
Warranty card
(Optional)
1
Cable for the testing monitor
1
Used to test the camera connection to a portable
display device
Template
1
Product installation guide
Power Terminal Block
1
Plugged in the power plug
Audio/alarm Terminal Block
1
Plugged in the audio/alarm plug
CAUTION: Be w a re o f t he Rated Vol ta g e an d P o l ar it y
of th e p owe r co nn e c t io n.
Power Cable
1
Used to plug into the power port
Appearance DescriptionItem Name Quantity
L Wrench
1
Used to control the direction of the camera
Audio/alarm cable
1
Used to connect with the audio and alarm port
Tapping Screw
4
Used for installation on the wall or ceiling
Sunshield
1
It protects the camera from the direct sunlight.
Sunshield Hold
1
It fixes the sunshield with the camera.
CONDUIT
BASE WALL MOUNT
1
The adapter that should be adjusted in order to hang
the camera on the wall
Cable bush
1
Used to connect the LAN cable with a diameter of
Ø7~8.5.
overview
8_ overview
wHat’S incLuDeD (tno-4041t/4051t/4041tr)
Please check if your camera and accessories are all included in the product package.
(As for each sales country, accessories are not the same.)
Appearance DescriptionItem Name Quantity
Camera
1
Instruction book,
Installer S/W CD
1
Quick Guide
(Optional)
1
Warranty card
(Optional)
1
Cable for the testing monitor
1
Used to test the camera connection to a portable
display device
Power Terminal Block
1
Plugged in the power plug
Audio/alarm Terminal Block
1
Plugged in the audio/alarm plug
CAUTION: Be w a re o f t he Rated Vol ta g e an d P o l ar it yof th e p owe r co nn e c t io n.
Power Cable
1
Used to plug into the power port
Star-Shape wrench
1
Used to fasten the PT bracket to the main body
Appearance DescriptionItem Name Quantity
Audio/alarm cable
1
Used to connect with the audio and alarm port
Sunshield
1
It protects the camera from the direct sunlight.
Sunshield Hold
1
It fixes the sunshield with the camera.
Waterproof stopper
1
Used to block a hole from which the cable does not
come out
Waterproof adapter
1
Cable range: Ø2mm(minimum) ~ Ø6mm(maximum)
Used for connecting cables (Ex: Power cable)
※ Provided cable glands from the camera will be
applicable to Ø4.5mm(minimum) ~ Ø10mm(maximum)
cable
English _9
●●OVERVIEW
AT A GLANCE (TNO-4030T/4040T/4050T/4030TR/4040TR)
Appearance & Components
Item Description
a
Network Port Used to connect the PoE or Ethernet cable for network connection.
b
Power Port Used to plug the power cable.
c
Audio and alarm cable port Port to connect audio and alarm cables.
d
Sunshield Hold It fixes the sunshield with the camera.
e
Sunshield It protects the camera from the direct sunlight.
f
Test Monitor Out Output port for test monitoring the video output. Use the test monitor cable to connect to a
mobile display and check the test video.
g
Reset Button
The button restores all camera settings to the factory default.
Press and hold for about 5 seconds to reboot the system.
J
If you reset the camera, the network settings will be adjusted so that DHCP can be
enabled. If there is no DHCP server in the network, you must run the IP Installer
program to change the basic network settings such as IP address, Subnet mask,
Gateway, etc., before you can connect to the network.
h
MICRO USB port
Port to connect the Wi-Fi dongle.
You can check the installation video through the applications installed in the smartphone.
Refer to “Connect to WiFi dongle” on page 15.
`WiFi dongle and OTG adapter are sold separately.
i
Micro SD card slot This is a slot in which you can insert a Micro SD card.
AT A GLANCE (TNO-4041T/4051T/4041TR)
Appearance & Components
Item Description
a
Audio and alarm cable port Port to connect audio and alarm cables.
b
Test Monitor Out Output port for test monitoring the video output. Use the test monitor cable to connect to a
mobile display and check the test video.
c
Power Port Used to plug the power cable.
d
Network Port Used to connect the PoE or Ethernet cable for network connection.
e
Micro SD card slot This is a slot in which you can insert a Micro SD card.
f
Reset Button
The button restores all camera settings to the factory default.
Press and hold for about 5 seconds to reboot the system.
J
If you reset the camera, the network settings will be adjusted so that DHCP can be
enabled. If there is no DHCP server in the network, you must run the IP Installer
program to change the basic network settings such as IP address, Subnet mask,
Gateway, etc., before you can connect to the network.
12 34 567 8
1:LI NE I N
2:G N D
3:AU DI O O U T R
4:AU DI O O U T L
5:G N D
6:AL ARM I N
7:AL ARM OU T
8:AL ARM O UT 2
d e
f g
b ca
hi
ba c d
ef
installation & connection
10_ installation & connection
installation & connection
INSTALLATION (TNO-4030T/4040T/4050T/4030TR/4040TR)
J
`This camera is waterproof and in compliance with the IP66 spec, but the jack connected to the external cable is not. You are
recommended to install this product below the edge of eaves to prevent the cable from being externally exposed.
Precautions before installation
Ensure you read out the following instructions before installing the camera:
• It must be installed on the area (ceiling or wall) that can withstand 5 times the weight of the camera
including the installation bracket.
• Stuck-in or peeled-off cables can cause damage to the product or a fire.
• For safety purposes, keep anyone else away from the installation site.
And put aside personal belongings from the site, just in case.
• Do not use the sunshield hole for any purpose other than for connecting the sunshield.
• If you use excessive force when installing the product, the camera may be damaged and malfunction.
If you forcibly install the product using non-compliant tools, the product may be damaged.
Installation
1. Use the four tapping screws provided to secure the base wall
mount.
2. Hang the safety cable up on a hook that looks like an arrow in the
Bottom cover.
3. Connect the appropriate cables with camera terminals.
4. After placing the bottom cover on the base wall mount, use the L
wrench provided to connect and secure the three screws.
5. After placing the camera on the bottom cover, use the L wrench
provided to connect the three screws on the top cover.
6. Adjust the camera direction using the L wrench provided.
J
`When you adjust the camera position using a bracket, please loosen the
bracket screw, adjust the camera, and tighten it. If you attempt to adjust it
forcibly while the screw is tight, it may result in a scratch or other problems.
Connecting waterproof power cable and LAN cable
1. Pick off the extruded part of the rubber cover on the bottom side of
the bottom cover as shown in the figure below.
J
`Use an appropriate cable bush for the LAN cable to be connected.
-Basic camera : Use the cable with a diameter of Ø5~6.5.
-Components provided : Use the cable with a diameter of Ø7~8.5.
2. Insert the power cable into the small hole made by removing the
projected part of the rubber plug in step 1 above.
3. Connect the power cable with the power terminal block.
CONDUIT
CAUTION : Be ware o f the
Rated Vo ltage and P olari ty
of the power conne ction .
123 45 67 8
1:LIN E IN
2:GND
3:AUD IO OU T R
4:AUD IO OU T L
5:GND6:ALA RM IN
7:ALA RM O UT8:ALA RM OU T2
English _11
●●INSTALLATION & CONNECTION
Outdoor installation
When you install it outside of the building, please waterproof it with waterproof butyl rubber tape (can be
purchased in stores) so that water does not leak from the gap of the cable connected to the outside.
1. Connect to cables, such as I/O and audio.
2. Wrap the black cable jacket (Area A) and the cable connection
area with waterproof (butyl rubber) tape so that more than half of
the butyl rubber tape is overlapped.
J
`If the cable jacket is not waterproofed properly, then it can directly cause
leakage. Make sure to protect the cable with a dense layer of taping.
`Waterproof butyl tape is made of butyl rubber that can be stretched to
twice its normal length.
INSTALLATION (TNO-4041T/4051T/4041TR)
J
`This camera is waterproof and in compliance with the IP66 spec, but the jack connected to the external cable is not. You are
recommended to install this product below the edge of eaves to prevent the cable from being externally exposed.
Precautions before installation
Ensure you read out the following instructions before installing the camera:
•It must be installed on the area (ceiling or wall) that can withstand 5 times the weight of the camera
including the installation bracket.
•Stuck-in or peeled-off cables can cause damage to the product or a fire.
•For safety purposes, keep anyone else away from the installation site.
And put aside personal belongings from the site, just in case.
•Do not use the sunshield hole for any purpose other than for connecting the sunshield.
•If you use excessive force when installing the product, the camera may be damaged and malfunction.
If you forcibly install the product using non-compliant tools, the product may be damaged.
4. Insert the LAN cable into the large hole made by removing the
projected part of the rubber plug in step 1 above.
5. Remove the sheath with a cable cutter, and align the cables.
6. Connect the LAN cable with a LAN connector, and insert it into the
LAN tool.
7. Connect the finished cable to the Ethernet port.
Connecting the alarm and audio cable
1. Remove the rubber cover on the bottom side of the bottom cover
as shown in the figure below.
2. Insert the alarm/audio cable through the hole created by removing
the rubber cap in No. 1, and connect the cable to the alarm
terminal.
3. Align the cable so that it should not be damaged or jammed
when installing the camera.
4. Put the rubber cap located on the alarm/audio cable in the hole.
CAUTION : Be war e o f the
Rated Vo ltage a nd P olar it y
of the power conne ction.
123 45 678
1:LINE I N
2:GND3:AUDI O O UT R
4:AUDI O O UT L5:GND
6:ALAR M IN
7:ALAR M OU T
8:ALAR M OUT 2
CAUTION : Be wa re o f the
Rated Vo lta ge a nd P olari ty
of the power conne ction .
123 45 67 8
1:LIN E IN2:G ND
3:AUD IO OU T R4:AUD IO OU T L
5:GND
6:ALA RM IN7:ALA RM O UT
8:ALA RM OU T2
Ca erm a
Ca erm a
Ca erm a
S temys
S temys
S temys
AA
Produkt Specifikationer
| Mærke: | Hanwha |
| Kategori: | Overvågningskamera |
| Model: | TNO-4041TR |
Har du brug for hjælp?
Hvis du har brug for hjælp til Hanwha TNO-4041TR stil et spørgsmål nedenfor, og andre brugere vil svare dig
Overvågningskamera Hanwha Manualer
24 September 2024
24 September 2024
24 September 2024
1 September 2024
31 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
Overvågningskamera Manualer
- Overvågningskamera Lindy
- Overvågningskamera IDIS
- Overvågningskamera IPX
- Overvågningskamera SPC
- Overvågningskamera Summer Infant
- Overvågningskamera Moog
- Overvågningskamera Belkin
- Overvågningskamera Yale
- Overvågningskamera VideoComm
- Overvågningskamera Dorr
- Overvågningskamera GVI Security
- Overvågningskamera Nest
- Overvågningskamera Tecno
- Overvågningskamera Ganz
- Overvågningskamera AVerMedia
Nyeste Overvågningskamera Manualer
9 Juni 2025
8 Juni 2025
8 Juni 2025
8 Juni 2025
7 Juni 2025
7 Juni 2025
7 Juni 2025
7 Juni 2025
7 Juni 2025
7 Juni 2025
