FIRST EDITION 07-2016

Dimensions

Unit : mm (inch)

Key Features

• Up to 32CH, Max. 12megapixel camera supported

• 256Mbps network camera recording

• Support 4K video out on HDMI monitor

• Support Dual monitor video out

• Support H.265, H.264, MJPEG compression

• WiseStream support

• Max. 8 internal HDDs (48TB), e-SATA / iSCSI storage support

• ARB & Failover (N+1) support

XRN-2010

DISPLAY

Video

Inputs Up to 32CH

Resolution CIF ~ 12MP

Protocols Samsung, ONVIF

Live

Local Display 1x HDMI, 1x VGA dual monitor

Multi Screen Display

[Local monitor] 1 / 2V / 3V / 4 / 9 / 16 / 25 / 36 / Sequence,

[Web] 1 / 4 / 9 / 16 / 25 / 36 / Sequence

Performance

[Local monitor] 12MP (30fps), 8.3MP (120fps), 1080p (480fps),

720P (960fps), D1 (960fps)

PERFORMANCE

Operating System

Embedded Linux

Recording

Compression H.265, H.264, MJPEG, WiseStream (H.265, H.264)

Recording Bandwidth Max. 256Mbps

Resolution CIF ~ 12MP

Mode Normal, Schedule (Continuous / Event), Event (Pre / Post)

Event Trigger Alarm input, Video loss, Camera event (Sensor, MD, Video analytics)

Event Action E-mail, PTZ preset, Alarm out, Buzzer, Monitor out

Search &

Playback

Playback Bandwidth 32Mbps (16CH simultaneously)

Performance Max. 4 users (Local 1, Remote 3)

Mode Date & Time (Calendar) / Event log list / Text search

Simultaneous Playback

Max. 16CH (Local monitor, CMS)

Resolution CIF ~ 12MP

Fish-eye Dewarping WEB / CMS

Playback Control Fast/Slow Forward/Backward, Move one step up/down

Storage

Built-in / Internal HDD

0TB ~ 6TB / 8 (Max. 48TB)

External

iSCSI storage (Max. 384TB), Promise VessRaid R2600

Backup

File Backup (Via Web) BU/Exe (GUI), JPG/AVI (Network)

Function Multi channel (Up to 16CH) play, Date-time/title display

Sensor Input / Output 8 / 4 (NO/NC selectable)

Audio

Input 32CH (Network)

Compression G.711, G.726, AAC (16/48KHz)

Audio Communication

2-way

NETWORK

Interface RJ-45, Gigabit ethernet x 2

Protocol Support

TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server,

Client), PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP,

ONVIF (Profile-S), SUNAPI (Server, Client)

DDNS iPOLiS DDNS

Transmission Bandwidth 512Mbps (iSCSI off ), 256Mbps (iSCSI on)

Max. Remote Users Search 3 / Live unicast 10 / Live multicast 20

IP IPv4 / IPv6

Security IP address filtering, User access log, 802.1x authentication, Encryption

Language

English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch,

Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian,

Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai

OS Window 7, 8, 10, Mac OS X (10.8 or above)

Web Browser MS IE, Google Chrome, Mac Safari, Firefox

Viewer

Software

Type SSM, Webviewer, SmartViewer, iPOLiS mobile viewer

CMS Support SDK / CGI (SUNAPI)

FUNCTIONS

Camera Setup

Setup Items

IP address, Add profile edit, Bitrate, Compression, GOP, Quality,

Camera MD setup, Camera video setup (Simple focus, Brightness/

Contrast, Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter, SSDR, DIS),

Fisheye dewarping mode, Hallway view setup, Camera webpage

PTZ Control / Preset Via GUI, Webviewer, SPC-2000 / 255 presets

Smart Phone

OS Android, iOS

Protocol Support RTP, RTSP, HTTP, CGI (SUNAPI)

Control Live (16CH) : Multi-profile support, Playback (1CH)

Max. Remote Users Search 3 / Live unicast 10

Redundancy Failover / ARB N + 1 / Yes

System Control Mouse, Web, SPC-2000 (Controller)

INDICATOR / INTERFACE

Front Indicator

LED (Status indicator) : 6ea

HDD action 1, Alarm 1, Power 1, Record 1, Backup 1, Network1

Connections

HDMI

Main : 1ea (Both support Live / PB / Setup)

Support up to 4K (3840 x 2160, Single monitor mode)

VGA Sub : 1ea (Support live screen up to 16 div. mode)

Audio Out 1ea (RCA, Line)

Ethernet RJ-45 2ea (LAN/WAN, 1Gbps)

Alarm

In 8ea (Terminal block), Alarm reset 1ea

Out 4ea (Terminal block) - Relay out1(NO/NC/COM) - Relay out 2 ~ 4 (NO/COM)

USB 2ea (Front 1, Rear 1)

Storage 1 e-SATA

Serial / Reset RS-232C / Switch 1ea

Power Cord 1ea AC Inlet

SYSTEM

Log Log List Max. 20,000 (System log, Event log each)

GENERAL

Electrical

Input Voltage / Current

100 ~ 240V AC ±10%, 50/60Hz / 4 ~ 1.5A

Power Consumption Max. 99W (338BTU, 6TB HDD x 8ea)

Environmental

Operating Temperature

+0°C ~ +40°C (+32°F ~ +104°F)

Operating Humidity 20% ~ 85% RH

Mechanical

Color / Material Black / Metal

Dimensions (WxHxD) 440.0 x 88.0 x 384.8mm (17.32" x 3.46" x 15.15") (2U)

Weight 4.86Kg (10.71 lb) (without HDD)

* The lastest product information / sepecication can be found at http://security.hanwhatechwin.com

32CH Network Video Recorder

XRN-2010

384.8 (15.15")

391.8 (15.43")

440.0 (17.32")

95.9 (3.78")

88.0 (3.46")

440.0 (17.32")

384.8 (15.15")

391.8 (15.43")

95.9 (3.78")

88.0 (3.46")
