Owner’s Manual
Havis Docking Station
For Panasonic Toughbook H2
www.havis.com
1-800-524-9900
DS-PAN-601
DS-PAN-602
DS-PAN-603
DS-PAN-600 Series
DS-PAN-601
DS-PAN-602
DS-PAN-603
Before Beginning (Original Instructions)
2
• NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE
AIRBAG DEPLOYMENT ZONE.
• DO NOT USE COMPUTER WHILE DRIVING.
• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
Havis is pleased to provide this Owner’s Manual to aid in the proper
installation and use of the DS-PAN-600 Series Docking Station for
the Panasonic Toughbook H2.
For questions regarding the set-up of your DS-PAN-600 Series Docking Station,
please contact Havis at 1-800-524-9900 or visit www.havis.com for additional
product support and information.
This Owner’s Manual applies to the following Part Numbers:
• FOR DOCKING STATION MODELS EQUIPPED WITH AN INTEGRATED POWER SUPPLY
(DS-PAN-602) REFER TO THE SUPPLIED LIND POWER SUPPLY REFERENCE GUIDE.
Optional Accessories
EC DECLARATION OF CONFORMITY in accordance with EN 45014
Manufacturers Name: Havis, Inc.
Manufacturers Address: 47801 Anchor Court, Plymouth Twp, MI 48170 USA
Declares under our sole responsibility that the product:
Product name: Havis Docking Station For Panasonic Toughbook H2
Model: DS-PAN-60X, where ‘X’ may be any alphanumeric character and which describes product options.
May be followed by any alphanumeric characters which describe product options.
Product Options: This declaration covers all options of the above product which bear the CE Marking.
Is in conformity with the following standards or other normative documents:
EMC Directive 2004/108/EC: EN 55022:2010, Class B, Information technology equipment -
Radio disturbance characteristics - Limits and methods of measurement
EN 55024:2010, Information technology equipment - Immunity characteristics -
Limits and methods of measurement
Directive 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
Supplementary Information:
The product herewith complies with the requirements of the EMC Directive 2004/108/EC. This product requires the
use of the provided e-Marked automotive power supply when used within vehicles.
Plymouth twp, MI, USA August 1, 2012 Bruce Jonik, Director of Engineering , Havis, Inc.
FCC 47CFR, Part 15 compliance: This is an FCC Class B device. Any changes or modications
to the model DS-PAN-60X not expressly approved by Havis, Inc. could void
the user's authority to operate this equipment.
www.havis.com • 1-800-524-9900
Table of Contents
3
Specications
Parts Included
Port Replication Capability
Installation
Cable Management
Operation - Docking
Operation - Undocking
3
4
5
6
7
9
10
Specications
Power Supply Input 15.6V DC-In
Dimensions 11.3” ( 28.7 cm) W x 4.0” ( 10.1 cm ) D x 11.8” ( 30.0 cm ) H
Weight 4.6 lbs ( 2.1 kg )
Operating Environment -20° C to 60° C ( -4° F to 140°F )
Storage Environment -40° C to 85° C ( -40° F to 185° F )
• Do not place metal objects or containers of liquid on top of the Docking Station
• If a malfunction occurs, immediately unplug the Power Supply and remove the laptop
• Use only the specied Power Supply (Part # LPS-102) with this Docking Station
• Do not store the Docking Station where water, moisture, steam, dust, etc. are present
• Do not connect cables into ports other than what they are specied for
• Do not leave the Docking Station in a high temperature environment (greater than 85°C, 185°F)
for a long period of time
Precautions
4
Docking Station
Parts Included
Barrel Lock
Bumpers
Docking Connector
Latch Handle
Mounting Bracket
(shown assembled)
Hardware Kit
Mounting Bracket
This Hardware Kit includes:
1. Zip Ties (6)
2. Keys (2)
3. 1/4”-20 x 5/8” long
Button Head Screws (4)
4. 1/2”-20 X 3/8” Long
Pan Head Screws (5)
5. Int. Zip Ties (2)
Tools required for installation:
• 5/32” Hex Drive • #3 Phillips
(For 1/4”-20 Button Head Screws) (For 1/2”-20 Pan Head Screws)
Operation - Docking
4 5
www.havis.com • 1-800-524-9900 5
Port Replication Capability
USB 2.0
(x3)
Strain Relief
Bracket
VGAPower Input
Ethernet
(RJ45) Serial
Installation and Cable Management
1) Remove the Mounting Bracket from the packaging. Install the
Mounting Bracket to the Motion Device using (3) 1/4“-20 x 5/8” long
screws (Hardware Kit Item 3). Torque screws to 80 in-lbs (9.0Nm) ± 10%.
NOTE: Numerous hole patterns present in Mounting Bracket will accomodate Havis Motion
Devices as well as most competitors’
1/4”-20 Screws
Mounting Bracket
Typical Motion Device Example
(not included)
NOTE: We recommend applying a drop of medium strength (blue)
thread locking adhesive to the threads of all fasteners.
6
Installation (continued)Installation and Cable Management (continued)
2) Connect all needed peripheral cables to the Docking Station and bundle them
to the Strain Relief Bracket using the provided Zip Ties (Hardware Kit Item 1).
3) Feed the cables through the center opening in the Mounting Bracket.
Strain Relief
NOTE: If you are mounting the optional Power Supply (Part # LPS-102)
or Side Exiting USB Cable (Part # DS-DA-311),
please refer to page 11 before continuing to Step 3.
