Dome Camera

User Manual

www.hikvision.com

Thank you for purchasing our product. If there

are any questions, or requests, please do not

hesitate to contact the dealer.

This manual applies to

Type Model

IDS-2CE5582P(N), DS-2CE55C2P(N)

DS-2CE5582P(N)-IRP, DS-2CE55C2P(N)-IRP

DS-2CE5582P(N)-IR,DS-2CE55C2P(N)-IR

DS-2CE5682P(N)-IT3, DS-2CE56C2P(N)-IT3

III

IV DS-2CE5582P(N)-VFIR3

This manual may contain several technical

incorrect places or printing errors, and the

content is subject to change without notice.

The updates will be added to the new version of

this manual. We will readily improve or update

the products or procedures described in the

manual.

DISCLAIMER STATEMENT

Underwriters Laboratories Inc. (”UL” has not)

tested the performance or reliability of the

security or signaling aspects of this product.

Regulatory Information

FCC Information

FCC compliance: This equipment has been

tested and found to comply with the limits for a

digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide

reasonable protection against harmful

interference when the equipment is operated in

a commercial environment. This equipment

generates, uses, and can radiate radio

frequency energy and, if not installed and used

in accordance with the instruction manual, may

cause harmful interference to radio

communications. Operation of this equipment in

a residential area is likely to cause harmful

interference in which case the user will be

required to correct the interference at his own

expense.

UL Certification does not

performance or reliability of the

signaling aspects of this product UL MAKES NO

REPRESENTATIONS, WARRANTIES OR

CERTIFICATIONS WHATSOEVER REGARDING

THE PERFORMANCE OR RELIABILITY OF ANY

SECURITY OR SIGNALING RELATED FUNCTIONS

OF THIS PRODUCT.

cover the

security or

0100001030115

FCC Conditions

This device complies with part 15 of the FCC

Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful

interference.

2. This device must accept any interference

received, including interference that may

cause undesired operation.

EU Conformity Statement

This product and - if applicable -

the supplied accessories too are

marked with "CE" and comply

upo n the pu rcha se of eq uival ent new equipment,

or di spos e of it at designat ed col lection po ints.

For mor e info rma tion see:

www.recyclethis.info.

2006/66/EC (battery directive):

This product contains a battery

that cannot be disposed of as

unsorted municipal waste in the

European Union.

See the product documentation for specific

battery information. The battery is marked with

this symbol, which may include lettering to

indicate cadmium (Cd), lead (Pb), or mercury (Hg).

For proper recycling, return the battery to your

supplier or to a designated collection point. For

more information see:

www.recyclethis.info.

This series of camera adopts new generation

sensor with high sensitivity and advanced circuit

design technology It features high resolution.

low image distortion and low noise etc which.

makes it suitable for surveillance system and

image processing system.

●High-performance sensor and high resolution

bring high-quality image

●IR LED enables day night surveillance

●Day/night auto switch

●ATW brings high color rendition

●Auto electronic shutter control to adapt to the

different surveillance environments

●Auto gain control, adaptive brightness

●High SNR brings high-quality image

●Ingress protection: IP66

Type camera doesn’t support day night autoⅠ

switch and IP .

DS-2CE5582P N IRP and DS- CE55C P N IRP

don’t support IP66.

, ,

Notes:

( )- 2 2 ( )-

1 Introduction

1.1 Product Features

1.2 Overview

2 Installation

Before you start:

●Please make sure that the device in the package

is in good condition and all the assembly parts

are included.

●Please make sure that all the related equipment

is power-off during the installation.

●Check the specification of the products for the

. installation environment

●Check whether the power supply is matched

with your AC outlet to avoid damage.

●If the product d oes not function properly, please

contact your dealer or the nearest ser vice

center. Do not disassemble the camera for

repair or maintenance by yourself.

●Please make sure that the wall or the ceiling is

strong enough to withstand 3 times the weight

of the camera.

UD.6L0201D0172A01

therefore with the applicable harmonized

European standards listed under the Low Voltage

Directive 2006/95/EC, the EMC Directive 2004/

108/EC.

UL has only tested for fire, shock or casualty

hazards as outlined in Ul’s Standard(s) for Safety,

UL60950-1.

2002/96/EC (WEEE directive):

Products marked with this symbol

cannot be disposed of as unsorted

municip al was te in th e European

Uni on. For pr oper recyc ling , return

thi s product to your local su ppli er

Power

Cable

Power

Cable

Power Cable

Zoom Focus &

Video Cable

Video

Cable

Power Cable

Mounting

Base

Lock

Screw

Enclosure Camera

TYPE

Enclosure

Trim Ring

Mounting

Base

Video

Cable

Enclosure

Trim Ring

Mounting

Base

Video

Cable

Camera

TYPE

III

Camera

Adjustable Screw

Black Liner

Lower

Dome

TYPE

Camera

1.Hold the mounting base, and rotate the lower

dome counterclockwise to disassemble the

lower dome and the black liner.

2.Drill the screw holes and the cable hole the

ceiling according to the supplied drill template.

83.5

2- 4.5∅

Steps:

Figure 2-1 The Disassembling

2.1 Ceiling Mounting for Type I

Camera

3.Route the cables to the cable hole and

the corresponding power cable and video cable.

4.Secure the mounting base to the ceiling with

the self tapping screws.

connect

6.Fit the black liner back to the camera.

7.Install the lower dome back to the camera and

rotate it clockwise to get it secured.

Figure 2-2 The Securing & 3-axis Adjustment

5.Adjust the Lens

1).Loosen the tilting lock screws besides the

lens.

2).Adjust the camera from the pan angle

( degrees); tilt angle (0~90 degrees),

and rotate the lens(0~355 degrees) to get the

optimum angle.

3).Tighten the tilting lock screws.

0~355

108

Screw Hole

∅86

108

∅72

Steps:

1.Drill the screw holes and the cable hole

according to the drill template.

Figure 2-5 Drill Template of Type CameraⅢ

2.Secure the mounting base to the ceiling with

.the screws

Figure 2-6 Secure the Mounting Base

3.Route the cables to the cable hole and

the corresponding power cable and

video cable.

4.Secure the camera to the mounting base.

5.Install the enclosure and the trim ring to

camera.

connect

Figure 2-7 Secure the Components

Camera

Figure 2-4 Drill Template of Type CameraⅡ

110

Hole

Ceiling Mounting

Hole

110

∅102

∅5

∅20

83.5

2.2 Ceiling Mounting for Type II/ III

Screw Hole

Template

3- 4.5∅

∅110

3939

22.5

6.Adjust the surveillance angle according to the

figure below.

7.Rotate the trim ring clockwise to secure the

camera.

Figure 2-10 The Lock Screw

Figure 2-8 Lens Adjustment

2.3 Ceiling Mounting for Type IV

Camera

Figure 2-9 The Drill Template

2.Loosen the lock screw to disassemble the

camera from the mounting base.

3.Secure the mounting base to the ceiling.

Steps:

1.Drill the screws holes and the cable hole on the

ceiling according to the supplied drill template.

360°

0-75°

P 0°an 360° -

Rotation 0° 360°-

Tilt 0° °-75

4.Route the cables to the cable hole and connect

the corresponding cables.

5.Secure the camera to the mounting base by

tightening the lock screw.

6.Adjust the camera according to the figure

below to get an optimum angle.

Figure 2-11 Lens Adjustment

7.Use the screwdriver to adjust the ZOOM screw

and the FOCUS screw until you get the

optimum image.

Figure 2-12 Zoom and Focus Adjustment

2.4 Power Supply

Figure 2-13 The Power Cable & the Video Cable

Note:

Please make sure that the power adapter is

compatible with the camera, and the standard

power supply is 12V DC Please refer to the.

technical specification for more information.

Figure 2-3 Complete the Installation

Produkt Specifikationer

Mærke:	Hikvision
Kategori:	Overvågningskamera
Model:	DS-2CE5582P-IR
Kode for international beskyttelse (IP):	IP66
Type:	CCTV sikkerhedskamera
Højde:	69.8 mm
Vægt:	260 g
Produktfarve:	Hvid
Wi-Fi:	Ingen
Formfaktor:	Kuppel
Relativ luftfugtighed ved drift (H-H):	0 - 90 %
Format til analogt signal:	PAL
Ethernet LAN:	Ingen
Driftstemperatur (T-T):	-40 - 60 °C
Maksimal opløsning:	720 x 480 pixel
Forbindelsesteknologi:	Ledningsført
Strømforbrug (maks.):	5 W
Diameter:	89.5 mm
Understøttet placering:	Udendørs
Sensortype:	DIS
Optisk zoom:	- x
Fokusindstilling:	1.2
Hældningsvinkelområde:	0 - 75 °
Sammensat videoudgang:	1
Strøm over Ethernet (PoE):	Ingen
Dag/nat funktion:	Ja
Minimumsbelysning:	0.1 Lux
Panoreringsområde:	0 - 360 °
Rotationsvinkel:	360 °
Optisk sensorstørrelse:	1/3 "
Fast brændvidde:	2.8 mm
Nattesyn:	Ja
LED type:	IR
DC udgangsspænding:	+12V
Kameraets lukkerhastighed:	1/25 - 1/15000 sek./side
Signal/støjforhold:	52 dB
Nattesyn, afstand:	20 m
Antal TV-linier:	600
PAL opløsninger:	720 x 480 pixel
