Side 1/2

Performance

• XGA resolution (1024 x 768)

• 80" (2m) image from only 50cm*

• 3500 ANSI Lumens (Normal Mode)

• Full connectivity including HDMI

• Perfect Fit – adjust all four corners and

sides of the image individually to achieve a

square image

• Input Source Naming

• My Button

• Table top mount facility

• 16W speaker

• Anti theft features including:

– PIN-Lock

– MyScreen Lock

– Transition Detector

– Security bar

Cost of ownership

• Extended Hybrid Filter life: 4000hr

cleaning cycle

•

Extended lamp life: 4000hrs (Eco Mode)

• Virtually maintenance free

• Easy set up and installation - New on

screen installation guide

• Power Saving Mode (ImageCare™)

• Wall mount included in the box

Advanced Network Features

• Full connectivity including 1 x RJ-45

• Optional wireless networking†

• Conﬁgure and control projector via

network with a web browser

• Projector management via SNMP

• Content via LAN

• AMX Device Discovery

• Messenger

• Cloning function

• PJ Link™

• Network Bridge

• iOS Connectivity

Environment

• The extended Hybrid Filter life means

reduced electronic waste and reduced

maintenance visits, resulting in an overall

reduction in carbon footprint

• ImageCare™ - The combination of Eco

and Saver Modes conserve energy

Hitachi have formulated an “Environmental

Vision” to contribute towards building a

sustainable society through business and

product development.

Our goal is to develop life-enhancing

technology that will contribute to and realise

a truly sustainable society for current and

future generations.

CP-A352WNM

ULTIMATE SHORT THROW XGA LCD PROJECTOR

The light weight and compact CP-A352WNM Ultimate Short Throw projector offers the highest quality images

with a compelling design and low cost of ownership. With the bundled wall mount and optional table top kit you

can project onto any existing whiteboard, wall or table top. Easy to install and ﬂexible to use with optional wireless

networking making the CP-A352WNM the ideal solution for any education or corporate environment.

www.hitachi.com.au/dps

*From centre of mirror to screen.

†Wireless is optional on this model (USB wireless adapter sold separately).

CP-A352WNM

Technical Speciﬁcations

Digital Presentation Solutions, Hitachi Australia Pty Ltd,

123 Epping Road, North Ryde NSW 2113

Toll Free: 1800 HITACHI Fax: +61 2 9888 4188

www.hitachi.com.au/dps

*The stated lamp and ﬁlter life refers to the average life expected in ideal operating conditions with usage in accordance with the manual.

The majority of, but not all lamps and ﬁlters should achieve this ﬁgure. **Where a lamp fails within warranty and a replacement lamp is taken,

the warranty for the replacement lamp will be a maximum of 6 months (dependent on warranty hours stated). HDMI, the HDMI logo and High-

Deﬁnition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. AMX and the AMX logo, and Device Discovery

are all registered trademarks of AMX. The speciﬁcation above and photography is for reference only and may be subject to change.

Wall mount

Table mount (optional)

4 x 3V

OPTICAL

LCD panel 0.63" (1.6cm) P-Si TFT p2-x3

Resolution XGA (1024 x 768)

Light output (brightness) 3500 ANSI Lumens (Normal Mode)/2400 ANSI Lumens (Eco Mode)

Colour light output (colour brightness)

3500 ANSI Lumens (Normal Mode)/2400 ANSI Lumens (Eco Mode)

Contrast ratio 4000:1

Lens Free shaped lens and motorised free shaped mirror

Lamp Wattage 250 W

Lamp life 2500 Hours (Normal Mode)/4000 Hours (Eco Mode)*

Focus distance 0.4m~0.7m (from mirror top to screen plane)

Distance to width ratio (:1) 0.3:1 (ﬁxed)

Diagonal display size 60~100" (152~254cm)

Number of colours 8 Bit/colour, 16.7M colours

Keystone Fixed, 6.1:-1 upward shift, Normal at 71.1° projection angle

COMPATIBILITY

Computer compatibility IBM Compatible VGA, SVGA, XGA, WXGA WXGA+, SXGA, ,

SXGA+, UXGA (compressed), MAC 16"

Composite/S-Video NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43

Component Video 525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60),

1125p(1080p@50/60), 750p(720p@50/60)

HDMI 525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60),

750p(720p@50/60), 1125p(1080p@50/60)

Plug & Play DDC2B

FEATURES

Speakers 16W x 1 Mono

Basic functions Freeze, Magnifying, Blank, Auto adjustment, Mirror reverse

image, Up-side down image, Auto signal search

Picture adjustments Digital Zoom x 1.35, Equalising Digital Gamma Correction,

2-3 pull down for NTSC, Progressive Scan, Noise reduction,

Aspect selection 4:3/16:9/16:10/14:9/Native - dependant on

source, Equalising colour temperature adjustment, Perfect Fit

Digital keystone Horizontal ±5°, Vertical ±5°

Advanced features Drawing function (optional wireless tablet TB-1 required), My Screen,

My Memory, My Button by remote control, My Source, My Text, Picture

mode (8 modes), Source naming (English), Resolution setting, Template,

Saving mode Audio pass through, Cloning Audio sound mixing, , ,

Audio out (standby) and monitor out/selectable source with menu,

Eco Mode (Normal, Eco, Intelligent Eco, Saver), Filter timer/selectable

interval time, PC-less Presentation (JPEG, PNG, BMP, GIF, AVI, MOV),

Stand-by Audio, On screen installation guide, iOS Connectivity

Outward Easy Lamp replace from Top, Rear intake air ﬁlter

Power on & off Direct on, Auto off Auto eco mode ,

Security systems PIN Security Lock, Myscreen Password Lock Transition Detector, ,

My Text Password Lock, Key Lock (key pad, remote control),

Kensington slot, Security bar, Lens door lock

Network Conﬁgure and control projector via web browser, Failure and warning

alerts via e-mail, Scheduling, My Image (still image transfer display),

Displaying text data transferred via the network, Command Control

via network, Crestron RoomView® (not accessible through wireless

adapter) AMX Device Discovery, Projector management via SNMP, ,

PJ Link™, Network Bridge, Network Presentation (PC still picture

transfer), MAC address on side, USB Display

OSD languages options 33, including: English, French, German, Spanish, Italian, Norwegian,

Dutch, Japanese, Portuguese, Swedish, Russian, Finnish, Polish,

Turkey, Arabic, Czech, Danish, Hungarian, Romanian, Slovenian,

Croatian, Greek, Lithuanian, Estonian, Latvian

CONNECTIONS

Digital input 1 x HDMI (HDCP compatible)

Computer input 2 x 15-pin Mini D-sub

Monitor output 1 x 15-pin Mini D-sub

Video input 1 x RCA Jack (for composite), 1 x S-Video Jack,

2 x Component D-sub (shared with analogue computer in 1/2)

Audio input 2 x Stereo Mini Jack, 1 x pair RCA (L/R), 1 x Microphone Jack

Audio output 1 x pair RCA (L/R)

Control 1 x 9-pin D-sub for RS232 control

USB 2 x USB type A, 1 x USB type B

Wired network 1 x RJ-45

Wireless network Option, IEEE801.11b/g/n ready (optional wireless adapter required)

POWER

Power supply AC100-120V/220-240V, auto switching

Power consumption/standby 350W (AC220-240V)/<0.35W

PHYSICAL

Dimensions (W x H x D)

345 x 85 x 303mm (excluding feet and extrusions when mirror is closed)

Weight 3.8Kg

Noise level 37dB (Normal Mode)/30dB (Eco Mode)

Ambient temperature Operating 0°C~40°C, Storage -20°C~60°C

Air ﬁlter Hybrid

MISCELLANEOUS

Lamp indicator light, power light, ceiling mount image, rear projection image, serial number label on side,

Tabletop use (optional stand is required)

CERTIFICATION

UL60950-1/ cUL, FCC Part15 subpart B class B, CE Marking: EN61000-3-2, EN61000-3-3,

EN55022(class B), EN55024(EMC directive), EN60950-1 (Low voltage directive), WEEE/RoHS,/ErP(lot6)

compliant, c-tick class B (Australia/New Zealand), GOST-R (Russia)

ACCESSORIES SUPPLIED

Remote control with batteries, RGB cable, power cord, cable cover, security label, user manual (detail &

concise), application CD, wall mount (HAS-K250), adapter cover

OPTIONAL ACCESSORIES

Replacement lamp DT01411

Table top stand TT-251

USB wireless adapter USB-WL-11N

WARRANTY

Projector warranty 3 Years

Lamp warranty 6 Months**

2 x USB Type A

USB Type B HDMI

RJ-45 (LAN)

Computer In 2

Computer In 1

Security Bar

Monitor Out

Audio In 1/2

Kensington Slot

Audio In 3

Audio Out

S-Video

Composite Video

Microphone

Control

(RS-232C)

Throw distance (from the top of the lens)

Screen size H x V a1 a2 b1 b2

(diagonal) (m) (m) (m) (m) (m) (m)

60" (1.5m)

70" (1.8m)

80" (2.0m)

90" (2.3m)

100" (2.5m)

1.2

1.4

1.6

1.8

2.0

0.9

1.1

1.2

1.4

1.5

0.096

0.161

0.225

0.289

0.353

0.373

0.437

0.501

0.566

0.630

0.281

0.317

0.352

0.387

0.423

1.196

1.384

1.571

1.759

1.947

Produkt Specifikationer

Mærke:	Hitachi
Kategori:	videoprojektorer
Model:	CP-A352WNM
Vekselstrømsindgangsspænding:	220 - 240 V
Bredde:	345 mm
Dybde:	303 mm
Højde:	85 mm
Vægt:	3800 g
Produktfarve:	Hvid
Format til analogt signal:	NTSC,NTSC 4.43,PAL,PAL M,PAL N,SECAM
Strømforbrug (typisk):	350 W
Driftstemperatur (T-T):	0 - 40 °C
Fjernbetjening inkluderet:	Ingen
Pæreeffekt:	250 W
Lampens levetid:	2500 t
Fokus:	0.4 - 0.7
Projektor lysstyrke:	3500 ANSI lumens
Projektør, opløsning:	XGA (1024x768) pixel
