PROLINE G2 MOduLaR ENcLOsuRE sOLutIONs Frames and Frame accessories

nVent.com/HOFFMANSUBJECT TO CHANGE WITHOUT NOTICEMOduLaR ENcLOsuRE sOLutIONs1 Spec-01187 G

FRaMEs

aPPLIcatION

The ProLine G2 frame is the foundational design element that

protects the components inside this modular enclosure. The

frame was designed to withstand heavier load requirements and

to maintain a solid square structure - a solid foundation for the

electrical enclosure.

FEatuREs

•

Superior performance under load: 12 gauge (2.5 mm) roll-formed

steelframewithweldedcorners,hybridframeprole

•

Wide range of standard options: 114 frame sizes; EMC protected

and disconnect options, custom sizes on request

•

Easy to assemble and use: 25 mm hole pattern on horizontal

and vertical frame members, wide door opening, removable rear

centerpost for frames greater than 1200 mm wide

sPEcIFIcatIONs

• Welded corners with steel corner blocks

• 12 gauge (2.5 mm), roll-formed steel frame sections

• Hybridframeprole

• Flangetroughcollarondoorandsideopeningsdeectdustand

debris away from the enclosure interior

• Integral frame channels support the full weight of the mounting

subpanel

• Frames greater than 1200 mm wide have a removable rear

centerpost, and cross-members in the center top and center

bottom; no front center post facilitates component installation

• Accommodates 25-mm DIN standard; rectangular frame holes

designed for BV-M6 fastener or metric cage nut fasteners; round

frame holes accommodate M5 self-tapping screws and allow

numerous grounding locations using M5 thread-forming screws

• Uniform internal frame width to simplify component installation;

universal frame member used for both horizontal and vertical

frame sections to simplify component installation

• Simple means for joining frames to create multiple-bay

enclosures

• Provisions for mounting subpanel, rack mounting and grid/rail

system mounting

• Longer lead times required for EMC items

FINIsH

• Polyester powder paint; RAL 7035 textured light gray standard

• Custom colors available

• EMC-protected frames: plated (not painted) to provide corrosion

resistance while maintaining a metal-to-metal contact with the

metalbergasketusedinProLineG2EMCIndustrialPackages

LOad RatING

• 3500 lb (1587kg), safety factor 1.5; frame size: 2000x600x800

mm (load ratings vary by frame size)

accEssORIEs

• Solid Doors (Single or Overlapping Double)

• Solid Top

• Gland Plate

• Side Cover

• Frame Joining Kits

• Grid Strap Network (Rail System)

• Lifting Eyes

• Fastener Packages

• Full Subpanel (Rear or Side)

• Partial Subpanel and Side-Mount Panel

• Panel Support Bracket

• 19-Inch Rack Angles

• Center Upright

Bulletin: P40

Standard Product 

Catalog Number AxBxC mm AxBxC in. H x W x D (mm) Maximum Subpanel Size (mm) Maximum Subpanel Size (in.) Maximum Rack Mount Units Description

P2F664 599 x 599 x 394 23.59 x 23.57 x 15.52 600 x 600 x 400 506x528 19.9x20.8 8 Painted

P2F666 599 x 599 x 594 23.59 x 23.57 x 23.39 600 x 600 x 600 506x528 19.9x20.8 8 Painted

P2F688 599 x 799 x 794 23.59 x 31.45 x 31.26 600 x 800 x 800 506x728 19.9x28.7 8 Painted

P2F864 799 x 599 x 394 31.46 x 23.57 x 15.52 800 x 600 x 400 706x528 27.8x20.8 13 Painted

P2F866 799 x 599 x 594 31.46 x 23.57 x 23.39 800 x 600 x 600 706x528 27.8x20.8 13 Painted

P2F888 799 x 799 x 794 31.46 x 31.45 x 31.26 800 x 800 x 800 706x728 27.8x28.7 13 Painted

P2F1064 999 x 599 x 394 39.34 x 23.57 x 15.52 1000 x 600 x 400 906x528 35.7x20.8 18 Painted

P2F1065 999 x 599 x 494 39.34 x 23.57 x 19.45 1000 x 600 x 500 906x528 35.7x20.8 18 Painted

P2F1066 999 x 599 x 594 39.34 x 23.57 x 23.39 1000 x 600 x 600 906x528 35.7x20.8 18 Painted

P2F1085 999 x 799 x 494 39.34 x 31.45 x 19.45 1000 x 800 x 500 906x728 35.7x28.7 18 Painted

P2F1086 999 x 799 x 594 39.34 x 31.45 x 23.39 1000 x 800 x 600 906x728 35.7x28.7 18 Painted

P2F1088 999 x 799 x 794 39.34 x 31.45 x 31.26 1000 x 800 x 800 906x728 35.7x28.7 18 Painted

P2F10125 999 x 1199 x 494 39.34 x 47.20 x 19.45 1000 x 1200 x 500 906x1128 35.7x44.4 18 Painted

P2F1264 1199 x 599 x 394 47.21 x 23.57 x 15.52 1200 x 600 x 400 1106x528 43.5x20.8 23 Painted

P2F1265 1199 x 599 x 494 47.21 x 23.57 x 19.45 1200 x 600 x 500 1106x528 43.5x20.8 23 Painted

P2F1266 1199 x 599 x 594 47.21 x 23.57 x 23.39 1200 x 600 x 600 1106x528 43.5x20.8 23 Painted

P2F1285 1199 x 799 x 494 47.21 x 31.45 x 19.45 1200 x 800 x 500 1106x728 43.5x28.7 23 Painted

P2F1286 1199 x 799 x 594 47.21 x 31.45 x 23.39 1200 x 800 x 600 1106x728 43.5x28.7 23 Painted

P2F1288 1199 x 799 x 794 47.21 x 31.45 x 31.26 1200 x 800 x 800 1106x728 43.5x28.7 23 Painted

P2F12125 1199 x 1199 x 494 47.21 x 47.20 x 19.45 1200 x 1200 x 500 1106x1128 43.5x44.4 23 Painted

P2F1465 1399 x 599 x 494 55.09 x 23.57 x 19.45 1400 x 600 x 500 1306x528 51.4x20.8 28 Painted

P2F1466 1399 x 599 x 594 55.09 x 23.57 x 23.39 1400 x 600 x 600 1306x528 51.4x20.8 28 Painted

P2F1466HF 1399 x 599 x 594 55.09 x 23.57 x 23.39 1400 x 600 x 600 1306x528 51.4x20.8 28 EMC

PROLINE G2 MOduLaR ENcLOsuRE sOLutIONs Frames and Frame accessories

PH 763.422.2211nVent.com/HOFFMAN MOduLaR ENcLOsuRE sOLutIONs 2

Spec-01187 G

Catalog Number AxBxC mm AxBxC in. H x W x D (mm) Maximum Subpanel Size (mm) Maximum Subpanel Size (in.) Maximum Rack Mount Units Description

P2F1485 1399 x 799 x 494 55.09 x 31.45 x 19.45 1400 x 800 x 500 1306x728 51.4x28.7 28 Painted

P2F1486 1399 x 799 x 594 55.09 x 31.45 x 23.39 1400 x 800 x 600 1306x728 51.4x28.7 28 Painted

P2F1488 1399 x 799 x 794 55.09 x 31.45 x 31.26 1400 x 800 x 800 1306x728 51.4x28.7 28 Painted

P2F14125 1399 x 1199 x 494 55.09 x 47.20 x 19.45 1400 x 1200 x 500 1306x1128 51.4x44.4 28 Painted

P2F1664 1599 x 599 x 394 62.96 x 23.57 x 15.52 1600 x 600 x 400 1506x528 59.3x20.8 33 Painted

P2F1665 1599 x 599 x 494 62.96 x 23.57 x 19.45 1600 x 600 x 500 1506x528 59.3x20.8 33 Painted

P2F1666 1599 x 599 x 594 62.96 x 23.57 x 23.39 1600 x 600 x 600 1506x528 59.3x20.8 33 Painted

P2F1668 1599 x 599 x 794 62.96 x 23.57 x 31.26 1600 x 600 x 800 1506x528 59.3x20.8 33 Painted

P2F1684 1599 x 799 x 394 62.96 x 31.45 x 15.52 1600 x 800 x 400 1506x728 59.3x28.7 33 Painted

P2F1685 1599 x 799 x 494 62.96 x 31.45 x 19.45 1600 x 800 x 500 1506x728 59.3x28.7 33 Painted

P2F1686 1599 x 799 x 594 62.96 x 31.45 x 23.39 1600 x 800 x 600 1506x728 59.3x28.7 33 Painted

P2F1688 1599 x 799 x 794 62.96 x 31.45 x 31.26 1600 x 800 x 800 1506x728 59.3x28.7 33 Painted

P2F16104 1599 x 999 x 394 62.96 x 39.32 x 15.52 1600 x 1000 x 400 1506x928 59.3x36.5 33 Painted

P2F16106 1599 x 999 x 494 62.96 x 39.32 x 19.45 1600 x 1000 x 600 1506x928 59.3x36.5 33 Painted

P2F16124 1599 x 1199 x 394 62.96 x 47.20 x 15.52 1600 x 1200 x 400 1506x1128 59.3x44.4 33 Painted

P2F16125 1599 x 1199 x 494 62.96 x 47.20 x 19.45 1600 x 1200 x 500 1506x1128 59.3x44.4 33 Painted

P2F16126 1599 x 1199 x 594 62.96 x 47.20 x 23.39 1600 x 1200 x 600 1506x1128 59.3x44.4 33 Painted

P2F16128 1599 x 1199 x 794 62.96 x 47.20 x 31.26 1600 x 1200 x 800 1506x1128 59.3x44.4 33 Painted

P2F16164 1599 x 1599 x 394 62.96 x 62.94 x 15.52 1600 x 1600 x 400 1506x1528 59.3x60.2 33 Painted

P2F16165 1599 x 1599 x 494 62.96 x 62.94 x 19.45 1600 x 1600 x 500 1506x1528 59.3x60.2 33 Painted

P2F16166 1599 x 1599 x 594 62.96 x 62.94 x 23.39 1600 x 1600 x 600 1506x1528 59.3x60.2 33 Painted

P2F16168 1599 x 1599 x 794 62.96 x 62.94 x 31.26 1600 x 1600 x 800 1506x1528 59.3x60.2 33 Painted

P2F1845 1799 x 399 x 494 70.83 x 15.70 x 19.45 1800 x 400 x 500 1706x328 67.2x12.9 38 Painted

P2F1846 1799 x 399 x 594 70.83 x 15.70 x 23.39 1800 x 400 x 600 1706x328 67.2x12.9 38 Painted

P2F1864 1799 x 599 x 394 70.83 x 23.57 x 15.52 1800 x 600 x 400 1706x528 67.2x20.8 38 Painted

P2F1865 1799 x 599 x 494 70.83 x 23.57 x 19.45 1800 x 600 x 500 1706x528 67.2x20.8 38 Painted

P2F1866 1799 x 599 x 594 70.83 x 23.57 x 23.39 1800 x 600 x 600 1706x528 67.2x20.8 38 Painted

P2F1866HF 1799 x 599 x 594 70.83 x 23.57 x 23.39 1800 x 600 x 600 1706x528 67.2x20.8 38 EMC

P2F1884 1799 x 799 x 394 70.83 x 31.45 x 15.52 1800 x 800 x 400 1706x728 67.2x28.7 38 Painted

P2F1885 1799 x 799 x 494 70.83 x 31.45 x 19.45 1800 x 800 x 500 1706x728 67.2x28.7 38 Painted

P2F1886 1799 x 799 x 594 70.83 x 31.45 x 23.39 1800 x 800 x 600 1706x728 67.2x28.7 38 Painted

P2F1888 1799 x 799 x 794 70.83 x 31.45 x 31.26 1800 x 800 x 800 1706x728 67.2x28.7 38 Painted

P2F18104 1799 x 999 x 394 70.83 x 39.32 x 15.52 1800 x 1000 x 400 1706x928 67.2x36.5 38 Painted

P2F18105 1799 x 999 x 494 70.83 x 39.32 x 19.45 1800 x 1000 x 500 1706x928 67.2x36.5 38 Painted

P2F18106 1799 x 999 x 594 70.83 x 39.32 x 23.39 1800 x 1000 x 600 1706x928 67.2x36.5 38 Painted

P2F18106HF 1799 x 999 x 594 70.83 x 39.32 x 23.39 1800 x 1000 x 600 1706x928 67.2x36.5 38 EMC

P2F18124 1799 x 1199 x 394 70.83 x 47.20 x 15.52 1800 x 1200 x 400 1706x1128 67.2x44.4 38 Painted

P2F18125 1799 x 1199 x 494 70.83 x 47.20 x 19.45 1800 x 1200 x 500 1706x1128 67.2x44.4 38 Painted

P2F18126 1799 x 1199 x 594 70.83 x 47.20 x 23.39 1800 x 1200 x 600 1706x1128 67.2x44.4 38 Painted

P2F18128 1799 x 1199 x 794 70.83 x 47.20 x 31.26 1800 x 1200 x 800 1706x1128 67.2x44.4 38 Painted

P2F18164 1799 x 1599 x 394 70.83 x 62.94 x 15.52 1800 x 1600 x 400 1706x1528 67.2x60.2 38 Painted

P2F18165 1799 x 1599 x 494 70.83 x 62.94 x 19.45 1800 x 1600 x 500 1706x1528 67.2x60.2 38 Painted

P2F18166 1799 x 1599 x 594 70.83 x 62.94 x 23.39 1800 x 1600 x 600 1706x1528 67.2x60.2 38 Painted

P2F18168 1799 x 1599 x 794 70.83 x 62.94 x 31.26 1800 x 1600 x 800 1706x1528 67.2x60.2 38 Painted

P2F18185 1799 x 1799 x 494 70.83 x 70.82 x 19.45 1800 x 1800 x 500 1706x1728 67.2x68.0 38 Painted

P2F18186 1799 x 1799 x 594 70.83 x 70.82 x 23.39 1800 x 1800 x 600 1706x1728 67.2x68.0 38 Painted

P2F18188 1799 x 1799 x 794 70.83 x 70.82 x 31.26 1800 x 1800 x 800 1706x1728 67.2x68.0 38 Painted

P2F2045 1999 x 399 x 494 78.71 x 15.70 x 19.45 2000 x 400 x 500 1906x328 75.0x12.9 42 Painted

P2F2046 1999 x 399 x 594 78.71 x 15.70 x 23.39 2000 x 400 x 600 1906x328 75.0x12.9 42 Painted

P2F2064 1999 x 599 x 394 78.71 x 23.57 x 15.52 2000 x 600 x 400 1906x528 75.0x20.8 42 Painted

P2F2065 1999 x 599 x 494 78.71 x 23.57 x 19.45 2000 x 600 x 500 1906x528 75.0x20.8 42 Painted

P2F2066 1999 x 599 x 594 78.71 x 23.57 x 23.39 2000 x 600 x 600 1906x528 75.0x20.8 42 Painted

P2F2066HF 1999 x 599 x 594 78.71 x 23.57 x 23.39 2000 x 600 x 600 1906x528 75.0x20.8 42 EMC

P2F2084 1999 x 799 x 394 78.71 x 31.45 x 15.52 2000 x 800 x 400 1906x728 75.0x28.7 42 Painted

P2F2085 1999 x 799 x 494 78.71 x 31.45 x 19.45 2000 x 800 x 500 1906x728 75.0x28.7 42 Painted

P2F2086 1999 x 799 x 594 78.71 x 31.45 x 23.39 2000 x 800 x 600 1906x728 75.0x28.7 42 Painted

P2F2086HF 1999 x 799 x 594 78.71 x 31.45 x 23.39 2000 x 800 x 600 1906x728 75.0x28.7 42 EMC

P2F20810 1999 x 799 x 994 78.71 x 31.45 x 39.14 2000 x 800 x 1000 1906x728 75.0x28.7 42 Painted

P2F20104 1999 x 999 x 394 78.71 x 39.32 x 15.52 2000 x 1000 x 400 1906x928 75.0x36.5 42 Painted

P2F20105 1999 x 999 x 494 78.71 x 39.32 x 19.45 2000 x 1000 x 500 1906x928 75.0x36.5 42 Painted

P2F20106 1999 x 999 x 594 78.71 x 39.32 x 23.39 2000 x 1000 x 600 1906x928 75.0x36.5 42 Painted

P2F20108 1999 x 999 x 794 78.71 x 39.32 x 31.26 2000 x 1000 x 800 1906x928 75.0x36.5 42 Painted

P2F20124 1999 x 1199 x 394 78.71 x 47.20 x 15.52 2000 x 1200 x 400 1906x1128 75.0x44.4 42 Painted

P2F20125 1999 x 1199 x 494 78.71 x 47.20 x 19.45 2000 x 1200 x 500 1906x1128 75.0x44.4 42 Painted

P2F20126 1999 x 1199 x 594 78.71 x 47.20 x 23.39 2000 x 1200 x 600 1906x1128 75.0x44.4 42 Painted

P2F20128 1999 x 1199 x 794 78.71 x 47.20 x 31.26 2000 x 1200 x 800 1906x1128 75.0x44.4 42 Painted

P2F20165 1999 x 1599 x 494 78.71 x 62.94 x 19.45 2000 x 1600 x 500 1906x1528 75.0x60.2 42 Painted

P2F20166 1999 x 1599 x 594 78.71 x 62.94 x 23.39 2000 x 1600 x 600 1906x1528 75.0x60.2 42 Painted

P2F20168 1999 x 1599 x 794 78.71 x 62.94 x 31.26 2000 x 1600 x 800 1906x1528 75.0x60.2 42 Painted

P2F20185 1999 x 1799 x 494 78.71 x 70.82 x 19.45 2000 x 1800 x 500 1906x1728 75.0x68.0 42 Painted

P2F20186 1999 x 1799 x 594 78.71 x 70.82 x 23.39 2000 x 1800 x 600 1906x1728 75.0x68.0 42 Painted

P2F20188 1999 x 1799 x 794 78.71 x 70.82 x 31.26 2000 x 1800 x 800 1906x1728 75.0x68.0 42 Painted

P2F2265 2199 x 599 x 494 86.58 x 23.57 x 19.45 2200 x 600 x 500 2106x528 82.9x20.8 47 Painted

P2F2266 2199 x 599 x 594 86.58 x 23.57 x 23.39 2200 x 600 x 600 2106x528 82.9x20.8 47 Painted

P2F2285 2199 x 799 x 494 86.58 x 31.45 x 19.45 2200 x 800 x 500 2106x728 82.9x28.7 47 Painted

P2F2266HF 2199 x 599 x 594 86.58 x 23.57 x 23.39 2200 x 800 x 500 2106x728 82.9x28.7 47 EMC

P2F2286 2199 x 799 x 594 86.58 x 31.45 x 23.39 2200 x 800 x 600 2106x728 82.9x28.7 47 Painted

P2F2286HF 2199 x 799 x 594 86.58 x 31.45 x 23.39 2200 x 800 x 600 2106x728 82.9x28.7 47 EMC

P2F2288 2199 x 799 x 794 86.58 x 31.45 x 31.26 2200x800x800 2106x728 82.9x28.7 47 Painted

P2F22810 2199 x 799 x 994 86.58 x 31.45 x 39.14 2200 x 800 x 1000 2106x728 82.9x28.7 47 Painted

P2F22105 2199 x 999 x 494 86.58 x 39.32 x 19.45 2200 x 1000 x 500 2106x928 82.9x36.5 47 Painted

P2F22106 2199 x 999 x 594 86.58 x 39.32 x 23.39 2200 x 1000 x 600 2106x928 82.9x36.5 47 Painted

P2F22108 2199 x 999 x 794 86.58 x 39.32 x 31.26 2200 x 1000 x 800 2106x928 82.9x36.5 47 Painted

P2F22125 2199 x 1199 x 494 86.58 x 47.20 x 19.45 2200 x 1200 x 500 2106x1128 82.9x44.4 47 Painted

P2F22126 2199 x 1199 x 594 86.58 x 47.20 x 23.39 2200 x 1200 x 600 2106x1128 82.9x44.4 47 Painted

P2F22128 2199 x 1199 x 794 86.58 x 47.20 x 31.26 2200 x 1200 x 800 2106x1128 82.9x44.4 47 Painted

P2F22165 2199 x 1599 x 494 86.58 x 62.94 x 19.45 2200 x 1600 x 500 2106x1528 82.9x60.2 47 Painted
