WELCOME
PREPARATION
Before beginning the assembly of this product,
ensure all parts are present. Compare all parts with
the package contents list and hardware contents list.
If any part is missing or damaged, do not attempt to
assemble the product.
After opening the top of the carton, remove the
mounting hardware package from the foam inserts,
then remove the motor from the packaging and place it
on a soft surface, such as a carpet, to avoid damage to
the nish.
Estimated Assembly Time: Approximately 120 minutes
Tools Required for Assembly (not included): Electrical
Tape, Phillips Screwdriver, Pliers, Safety Glasses, Step
Ladder, and Wire Strippers
Helpful Tools (not included): AC Tester Light, Tape
Measure, Wiring Handbook, and Wire Cutters
CARE AND MAINTENANCE
At least twice each year, lower the canopy to check the
downrod assembly, and then tighten all screws on the
fan. Clean the motor housing with only a soft brush or
lint-free cloth to avoid scratching the nish. Clean the
blades with a lint-free cloth.
Important: Shut off the main power supply before you
begin any maintenance tasks. Do not use water or a
damp cloth to clean the ceiling fan.
FAN WEIGHT
The net weight of this fan is: 15.97 lbs. (7,24 kg).
TABLE OF CONTENTS
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . .2
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Mounting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Mounting Bracket Installation . . . . . . . . . . . . . . . . . . .6
Standard or Angle Mounting Instructions . . . . . . . . . .7
Closemount Instructions. . . . . . . . . . . . . . . . . . . . . .10
Wiring....................................11
Canopy Installation. . . . . . . . . . . . . . . . . . . . . . . . . .12
Blade Installation . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Light Kit Installation . . . . . . . . . . . . . . . . . . . . . . . . .14
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . .16
Replacement Parts List . . . . . . . . . . . . . . . . . . . . . .17
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Limited Lifetime Warranty. . . . . . . . . . . . . . . . . . . . .19
