ASSEMBLY INSTRUCTION

Item#: 5805- -99 Bench 90019

** Please make sure you have all parts indicated below prior to assembly.

This unit is heavy and can best be assembled with the help of two or more people

Diagram 3 Diagram 4

Diagram 1

Diagram 2

2/2

Assembly Steps:

1. Put seat frame (K) upside down on a soft surface to prevent it from being scratched. Attach

center leg frame(H) to seat frame (K) by using bolts (A), lock washers (B) and at washers (C),

tighten with allen wrench (D) in clockwise direction. Do not over tighten (See Diagram 1).

2. Screw full threaded rod (E) to metal stretcher (J) in clockwise direction.Then a gn one end in li

of full threaded rod (E) to the pre-drilled hole center leg frame and through it .Screw full on

threaded rod into another metal stretcher in clockwise direction(See Diagram 2 ).

3. Attach two side leg frames ( I ) to seat frame (K), aligh holes on two side leg frames to the

pre-drilled holes on seat frame (N need to tighten them) ake sure all three leg frames are o . M

on the same level , place two ends of metal stretcher (J) into two side leg frames, align two

ends of metal stretcher to the pre-drilled holes on two side leg frames (See Diagram 3).

Then tighten two side leg frames by using bolts (A), lock washers (B) and at washers (C),

tighten with allen wrench (D) in clockwise direction (See Diagram 3).

4. Insert 2 allen bolts (F) into two ends of metal stretcher , screw it with spanner at one end of

metal stretcher meanwhile lock it at another end of metal stretcher.(Need two people to do ,

this step on boh ends at the same time).

5. Tighten all bolts.

6. Turn bench upright.

Cleaning Instruction: Clean nished parts with a damp cloth using a mild dishwashing liquid and water solution.

Polish the nish with soft cloth and an industry recognized furniture polish.
