Side 1/2

Dimensions / Capacity

Interior Storage Capacity (CF)

Interior Storage Capacity (CF) (AHAM)

Overall Width x Depth (including 1” bumper)

Height (including 6” casters)

Depth with Cutting Board Installed

Door Opening Width x Height

Depth with Drawer Fully Open

(including 1” bumper)

Depth with Door Open at 90° (including 1” bumper)

Pan Capacity (# of 1/6 size x 4” deep) Max. Pan Depth 6”

Adjustable Shelves / Shelf Dimensions (WxD)

Crated Weight

Crated Width x Depth x Height

Features

• Cabinet, doors, and drawers are insulated with 2” CFC

free, foamed in place polyurethane

• Front breathing air flow design

• Innovative air distribution system distributes air evenly

to maintain product temperature

• Drawer slides are constructed of 16 gauge stainless

steel with acetal rollers

• Drawer frames are formed of 14 gauge stainless steel

and securely fastened in the cabinet

• CRMR48-18MD2: Drawers will accommodate (1) 1/2

and (1) 1/3 size pans 6” deep (pans by others)

• CRMR60-24MD2: Drawers will accommodate (1) full

size pan 6” deep (pans by others)

• Provided with a full complement of polycarbonate

plastic 1/6th size pans, 4” deep and adapter bars

• Rails will also accept 6” deep pans for 50% more

pan volume

• Full length, 10” deep, 1/2” thick white polyethylene

cutting board is standard

• One epoxy coated shelf per door section is standard

• Extruded aluminum flush mount drawer handle

• Magnetic door gasket is easily removable for cleaning

• Enamel coated evaporator coil

• Standard with 6” stem casters (two with brakes)

• Three year parts and labor warranty

• Five year compressor warranty

• 8 ft. cord and plug

Note: Made to order. Allow 4-6 weeks.

Electrical / Refrigeration

Voltage

HACR Breaker

Electrical Connection

(NEMA)

Voltage Range

Ambient Temp. Range

Control Setpoint Range

Amperage

Energy Consumption

(kWh/day) @NSF

Heat Rejection (BTU/Hr.) @NSF

Approx. Nominal Compres. BTU/HR (HP)

Refrigerant / Charge Amount (oz)

2.25” Casters

4” Casters

Stainless steel lift off covers

Additional Epoxy Shelves

Composite cutting board (48”-HS-5267, 60”-HS-5268)

Options

Hoshizaki reserves the right to change specifications without notice.

Commercial Series Mega Top Refrigerator

with Two Drawers and One Door

Item #:

Project:

Qty:

AIA#:

618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com

Valid in United States, Canada, Puerto

Rico and U.S. Territories. Contact

factory for warranty in other countries.

Warranty

3 Year - parts and Labor on

entire machine.

5 Year - Parts on Compressor

W x D x H

48” x 30” x 44.25”*

*with 6” casters

Printed in the U.S.A.

13.66 ft

11.95 ft

48” x 31”

44.25”

37.3”

19.5” x 23”

50.25”

52.5”

(1) / 21.25” x 16”

242 lbs.

52.5” x 34” x 45.75”

115/60/1

15.0 Amps

5-15P

104-126

45° to 100°F

32° to 52°F

2.6

4.0

567

1029(1/6HP)

R-134a (6.5 oz)

CRMR48-18MD2 CRMR60-24MD2

Stainless steel back

Overshelves

Drawer divider bars

Rail adapter bars

Two Section

CRMR48-18MD2

CRMR60-24MD2

11/03/17

Item # 13415

Engineered to maintain NSF-7

temperatures in 100°F ambient.

(Certified to NSF-7 temperatures in

86°F ambient.)

Stainless steel exterior front, sides

and top

Stainless steel interior sides and back

with stainless steel interior floor

17.6 ft

16.6 ft

60” x 31”

44.25”

37.3”

25.5” x 23”

50.25”

58.5”

(1) / 27.25” x 16”

335 lbs.

64.5” x 34” x 45.75”

115/60/1

15.0 Amps

5-15P

104-126

45° to 100°F

32° to 52°F

6.0

3.9

556

2607(1/3HP)

R-134a (8.8 oz)

CRMR60-24MD2

W x D x H

60” x 30” x 44.25”*

*with 6” casters

Two Section

CRMR48-18MD2 CRMR60-24MD2

Front breathing refrigeration system allows unit to be built into any enclosure with zero side or rear clearance. The high efficiency refrigeration system is self-contained with an

enamel coated evaporator for extended life. Condensate removal is accomplished with an energy efficient non-electric evaporation system. A capillary tube controls the flow

of environmentally friendly R-134A refrigerant through the evaporator. Refrigeration system utilizes a heated defrost to eliminate any ice on the evaporator coil. An innovative

air distribution system distributes air evenly around the pans. Engineered to maintain NSF-7 temperatures in 100°F ambient. (Certified to NSF-7 temperatures in 86°F ambient.)

Preparation tables are supplied with a full complement of N.S.F. approved plastic 1/6 size pans, 4” deep and stainless steel adapter bars. Units will also accommodate 6” deep

pans. Pans are located 1.5” below the top to keep food product within easy reach. 115 volt units are equipped with an eight foot cord and NEMA rated plug (20.0 amps or less).

SIDE VIEW

FRONT VIEW

618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com

Printed in the U.S.A.

PLAN VIEW

CRMR48-18MD2

30”

51.5”

1”

(18) - 1/6 Size

Pan Capacity

48” x 10” x 1/2”

Think Cutting Board

1”

51”

48”

CRMR48-18MD2

37.3”

7.75”

16.75”

40”

44.25”

8.25”

36”

6”

49.25”

30”

57.5”

1”

(24) - 1/6 Size

Pan Capacity

60” x 10” x 1/2”

Think Cutting Board

49.25”

The exterior cabinet top, front, and sides, are constructed of high quality stainless steel. Cabinet is provided with a stainless steel top enclosure and an easily removable

stainless steel insulated lift-up cover. The exterior back and bottom are constructed of coated steel. The cabinet interior back and sides are stainless steel with an ABS ceiling

and stainless steel floor. Cabinet walls and drawers are insulated with 2” of environmentally friendly, CFC free, foamed in place polyurethane. 6” polyolefin, stem casters (two

with brakes) are standard. Preparation tables are supplied with a full length, 10” deep x 1/2” thick N.S.F. approved white polyethylene cutting board.

Drawer fronts are constructed of high grade stainless steel inside with stainless steel interior liners and are insulated with R-134a CFC free foamed in place polyurethane.

CRMR48-18MD2 drawers will accommodate (1) 1/2 & (1) 1/3 size pans, 6” deep (pans by others). CRMR60-24MD2 drawers will accommodate (1) full size pan per drawer, 6”

deep (pans by others). Drawer frames are formed of 14-gauge stainless steel and securely fastened in the cabinet. The drawer slides are constructed of heavy duty 16-gauge

stainless steel and durable acetal rollers with stainless steel ball bearings to prevent metal to metal contact. The drawer slides have a dynamic load capacity of 175 lbs. and have

been life tested (fully loaded) three hundred thousand openings and closings without showing significant wear.

Doors are constructed of high grade stainless steel exterior with an ABS interior liner. Hoshizaki’s exclusive “stepped” design protects the gasket while product is removed

from the cabinet. Spring assisted self-closing doors are equipped with a stay open feature past 90 degrees. Field reversible door hinging is standard.

Doors & drawers are provided with a one piece, extruded aluminum, flush mount handle. Snap-in magnetic door gaskets are durable and easily removed for cleaning.

CRMR60-24MD2

55”

6”

CRMR60-24MD2

Commercial Series Mega Top Refrigerator

with Two Drawers and One Door

CRMR48-18MD2

CRMR60-24MD2

11/03/17

Item # 13415

60”

1.5”
