Side 1/2
Pitch detection accuracy: ±0.01 Cent
Pot Resistance (EXP out): 10k Ohms
Input Impedance: 1M Ohms 10k Ohms/
Output Impedance: 1k Ohms
Current Consumption: Max 70mA
Dimensions: 81mm (W) x 162mm (D) x 61mm (H)
Weight: 606g
Specifications
Scan the QR code for manuals in other languages.
感谢您购买 ，Hotone产品
请扫描上⽅⼆维码获取其他语⾔说明书。
※ In the interest of product improvement, the specifications and/or
the content of products (including but not limited to appearances,
packaging design, manual content, accessories, size, parameters
and display screen), are subject to change without prior notice.
Please check with local supplier for exact offers. Specifications and
features (including but not limited to appearances, colors and size)
may vary by model owing to environmental factors, and all images
are illustrative.
Buffer Setting & USB Interface
1. Remove two screws from the compartment with a phillips screwdriver.
2. Remove the compartment cover.
You can choose whether to enable the buffer circuit
by using the two-position switch shown in the figure.
USB interface: used to connect to the computer for
firmware update.
※ Follow the software instruction to update the firmware.
ONOFF
Buffer
12
1
2
3 4
5
6
7
8
9
10
11
7. Footswitch:
Switch pedal working mode: volume (VOL) control or
expression (EXP) control.
8. EXP/VOL:
Used to cooperate with the pedal to indicate the
current pedal working mode.
9. HI/LOW:
Used to switch the input impedance, HI can be used for
high-impedance instrument input such as electric guitar
and bass, and the LOW can be used for low-impedance
input such as stompbox.
10. EXP OUT:
1/4” TRS jack, for connecting to
another device with EXP control IN jack.
11. OUTPUT:
1/4"mono audio jack, for connecting to other gears.
12. Screen:
Built-in high-definition LCD display, used to display
interfaces such as tuner and pedal travel indicator.
1. INPUT:
1/4” mono audio jack, for connecting your
instrument or other gear.
2. DISPLAY:
T+S—Tuner is only displayed when pedal is in the
heel-down position, otherwise the screen will be blank.
T—Tuner always shows regardless of the pedal state.
T+P—Tuner is only displayed when pedal is in the
heel-down position, otherwise pedal's (physical)
travel value would be displayed in real-time.
3. TUNER MODE:
Used to select the tuning mode. And the tuner pitch
detection accuracy is ±0.01 Cent.
4. PITCH:
Used to adjust the tuner reference frequency.
5. DC IN:
Plug in 9V DC adapter (center negative).
6. Switch Compartment:
You can choose whether to turn the buffer on through the
buffer switch in the switch compartment, and the
USB interface for firmware upgrade can be found in this
switch compartment.
