Side 1/32

Instructions for

Installation and Use

Build-in Electric

double oven

Contents

Introduction, 2

Safety Information, 3

The main parts of your Double Oven, 4

The Cooking Systems in your Double Oven, 5

Temperature Conversion Chart, 6

Controls, 7

The electronic programmer, 8

Grill Pan and Handle, 9

Operation when using the Top Oven for Grilling, 10

Guide to Grilling, 11

Using the Top Oven as a Convection Oven, 12

Operation when using the Top Oven as a

Convection Oven, 13

Oven Temperature Charts - Baking, 14

Oven Temperature Chart - Meat, 15

Using the Main Oven for Fan Cooking, 16

Using the Main Oven for Other Functions, 17-18

Care and Cleaning, 19-21

Installation, 22-24

If something goes wrong..., 25-26

Disposal of the appliance, 26

Hotpoint Service Cover, 27

Guarantee Information, 30

Service Information, 31

English, 2

GBGB

DY46K/2

DY46W/2

DY46X/2

BD42SS/2

BD32B/2

BD32K/2

BD32P/2

DH53DH53DH53DH53DH53

Safety Information

When used properly your appliance is completely

safe but as with any electrical product there are

certain precautions that must be observed.

PLEASE READ THE PRECAUTIONS BELOW

BEFORE USING YOUR APPLIANCE.

Always

•Always make sure you remove all packaging and

literature from inside the oven and grill

compartments before switching on for the first

time.

•Always make sure you understand the controls

prior to using the appliance.

•Always keep children away from the appliance

when in use as the surfaces will get extremely hot

during and after cooking.

•Always make sure all controls are turned off when

you have finished cooking and when not in use.

•Always stand back when opening an oven door to

allow any build up of steam or heat to disperse.

•Always use dry, good quality oven gloves when

removing items from the oven/grill.

•Always take care to avoid heat/steam burns when

operating the controls.

•Always turn off the electricity supply at the wall

switch before cleaning and allow the appliance to

cool.

•Always make sure the shelves are in the correct

position before switching on the oven.

•Always keep the oven and grill doors closed when

the appliance is not in use.

•Always take care when removing utensils from the

top oven when the main oven is in use as the

contents may be hot.

•Always keep the appliance clean as a build up of

grease or fat from cooking can cause a fire.

•Always follow the basic principles of food handling

and hygiene to prevent the possibility of bacterial

growth.

•Always keep ventilation slots clear of obstructions.

•Always refer servicing to a qualified appliance

service engineer.

•During use the oven becomes hot. Care should be

taken to avoid touching heating elements inside

the oven.

SAFETY ADVICE

IN THE EVENT OF A CHIP PAN OR ANY OTHER

PAN FIRE:

1. TURN OFF THE COOKER APPLIANCE AT THE

WALL SWITCH.

2. COVER THE PAN WITH A FIRE BLANKET OR

DAMP CLOTH, this will smother the flames and

extinguish the fire.

3. LEAVE THE PAN TO COOL FOR AT LEAST 60

MINUTES BEFORE MOVING IT. Injuries are often

caused by picking up a hot pan and rushing

outside with it. NEVER USE A FIRE

EXTINGUISHER TO PUT OUT A PAN FIRE as the

force of the extinguisher is likely to tip the pan

over. Never use water to extinguish oil or fat

fires.

Never

•Never leave children unsupervised where a

cooking appliance is installed as all cooking

surfaces will be hot during and after use.

•Never allow anyone to sit or stand on any part of

the appliance.

•Never store items above the appliance that

children may attempt to reach.

•Never remove the oven shelves whilst the oven is

hot.

•Never heat up unopened food containers as

pressure can build up causing the container to

burst.

•Never store chemicals, food stuffs or pressurised

containers in or on the appliance, or in cabinets

immediately above or next to the appliance.

•Never operate the grill with the door closed as this

will cause the appliance to overheat.

•Never use the appliance as a room heater.

•Never use the grill to warm plates.

•Never dry any items on the oven doors.

•Never install the appliance next to curtains or other

soft furnishings.

•Never allow children to play with the appliance

controls.

•Never use 'steam cleaners'.

Children should be supervised to ensure that they

do not play with the appliance.

! The appliance should not be operated by people

(including children) with reduced physical, sensory

or mental capacities, by inexperienced individuals or

by anyone who is not familiar with the product.

These individuals should, at the very least, be

supervised by someone who assumes responsibility

for their safety or receive preliminary instructions

relating to the operation of the appliance.

! The appliance must be used by adults only for

the preparation of food, in accordance with the

instructions outlined in this booklet. Any other

use of the appliance (e.g. for heating the room)

constitutes improper use and is dangerous. The

manufacturer may not be held liable for any

damage resulting from improper, incorrect and

unreasonable use of the appliance.

The main parts of your

Double Oven

Top Oven

Temperature Control

Main Oven

Temperature Selector

Grill Control

Timer

Stay Clean Side Liner

Stay Clean Back Panel

Oven Fan

Meat Pan

(NOT ALL MODELS)

Grill Pan &

Food Support

Oven Light

Oven Shelf

Oven Light

Grill/Top Oven Element

Top Oven Door

2 Oven Shelves

Main Oven Door

Door Handle

Inner Door Glass

MAIN OVEN PILOT LIGHT

TOP OVEN

PILOT LIGHT

GRILL

PILOT

LIGHT

Model & Serial Number

WARNING: DO NOT TOUCH THE GLASS DOORS WHEN THE OVEN IS IN USE AS

THESE AREAS CAN BECOME HOT

NEVER line the shelves, floor or sides of the oven or grill with aluminium foil as

overheating and damage may result.

The Cooking Systems

in your Double Oven

Your new oven is equipped with three different

cooking systems:

1. Conventional Heating (Top Oven) - with upper

and lower heat. This system is particularly suitable for

roasting and baking on one shelf only.

2. Grilling (Top Oven) - Has a full width, fully

controllable grill. The grill also has an economy setting

which enables you to use just the left section. NOTE:

The oven door should be open when grilling. (See page

"Operation when using the Top Oven for Grilling".)

3. Fan Cooking (Lower Oven) - the fan oven

operates by constantly blowing heated air from an

element wrapped around the fan into the oven. This

gives improved efficiency and, in general, enables the

use of lower temperatures for cooking. It also means

that there is less need to be particular about shelf

positions and that you can bake at more than one level

simultaneously (Batch Baking).

It should be noted that at the end of a cooking period there may be a momentary puff of steam when the oven

door is opened. This will disperse in a few seconds and is a perfectly normal characteristic of an oven with a

good door seal.

Temperature Conversion Chart

The chart below gives details of comparisons of oven settings for gas conventional ovens and fan oven in

degrees °F and °C



 

  

½ 250 120 100

1 275 140 120

2 300 150 130

3 325 160 140

4 350 180 160

5 375 190 170

6 400 200 180

7 425 220 200

8 450 230 210

9 475 240 220

Controls

A B C

Grill

Setting

Control

Top Oven

Temperature

Control

Timer Main Oven Temperature

And Function Control

MAIN OVEN PILOT LIGHT

TOP OVEN

PILOT LIGHT

GRILL

PILOT

LIGHT



     



Selects the heat at which the grill will cook the food.

 

!"#$%&'()*#)+

 ,./ 0&1#2+

' 334

Selects the cooking temperature (Degrees

Centigrade) when using the top oven as a

conventional oven.

345

  

6

- This is used to decrease the amount of time

required to defrost food items.

%6

- Switches on the Main Oven Interior Light Only

34

&, 7 +8

- When cooking select the required

cooking temperature.

Cooling Fan

A gentle flow of air will be blown below the control

panel when the grill control is used and after a short

period of time when the ovens are used.

Note: Whenever the appliance has been used, the

cooling fan may run on or restart itself after all the

controls have been turned off. This indicates that the

appliance is still warm.

Oven Interior Lights

The oven lights are operated when their respective

oven control is used.

(N.B. Not all models have a top oven interior light).

The main oven has a light only position.

Slow Cooking

The main oven has a "Slow Cook Setting" this can be

used for slow cooking, keeping food warm and

warming plates for a short period.

Note: It is advisable to check that all oven controls

have been switched off when you have finished

using the appliance.

The electronic programmer

DISPLAY

SET TIME

button

END OF

COOKING icon

CLOCK icon

DURATION

icon

TIMER icon

DECREASE TIME

button

INCREASE TIME

button

•• ••

! The Top Oven and Main Oven can be controlled by

the automatic timer. When the timer control has been

set for one oven, it is possible to use the other oven

only during the same automatic cooking programme.

! NEVER operate the grill when the ovens are set to

cook automatically because the oven cavity can

become warm and this may cause bacterial growth

in food.

Setting the clock

! The clock may be set when the oven is switched off

or when it is switched on, provided that the end time of

a cooking cycle has not been programmed previously.

After the appliance has been connected to the mains,

or after a blackout, the icon and the four numerical

digits on the DISPLAY will begin to flash.

1. Press the button several times until the icon

and the four digits on the display begin to flash.

2. Use the “+” and “-” buttons to adjust the time; if you

press and hold either button, the display will scroll

through the values more quickly, making it quicker and

easier to set the desired value.

3. Wait for 10 seconds or press the button again to

finalise the setting.

Setting the minute minder

! This function does not interrupt cooking and does not

affect the oven; it is simply used to activate the buzzer

when the set amount of time has elapsed.

1. Press the button several times until the icon

and the three digits on the display begin to flash.

2. Use the “+” and “-” buttons to set the desired time;

if you press and hold either button, the display will

scroll through the values more quickly, making it

quicker and easier to set the value.

3. Wait for 10 seconds or press the button again to

finalise the setting.

The display will then show the time as it counts down.

When this period of time has elapsed the buzzer will

be activated.

Programming cooking

! A cooking mode must be selected before

programming can take place.

Programming the cooking duration

1. Press the button several times until the icon

and the three digits on the DISPLAY begin to flash.

2. Use the “+” and “-” buttons to set the desired

duration; if you press and hold either button, the

display will scroll through the values more quickly,

making it quicker and easier to set the value.

3. Wait for 10 seconds or press the button again to

finalise the setting.

4. When the set time has elapsed, the text END

appears on the DISPLAY, the oven will stop cooking

and a buzzer sounds. Press any button to stop the

buzzer and turn all control knobs to 0 position.

• For example: it is 9:00 a.m. and a time of 1 hour

and 15 minutes is programmed. The programme

will stop automatically at 10:15 a.m.

Setting the end time for a cooking mode

! A cooking duration must be set before the cooking

end time can be scheduled.

1. Follow steps 1 to 3 to set the duration as detailed

above.

2. Next, press the button until the icon and the

four digits on the DISPLAY begin to flash.

3. use the “+” and “-” buttons to adjust the cooking

end time; if you press and hold either button, the

display will scroll through the values more quickly,

making it quicker and easier to set the desired value.

4. Wait for 10 seconds or press the button again to

finalise the setting.

5. When the set time has elapsed, the text END

appears on the DISPLAY, the oven will stop cooking

and a buzzer sounds.Press any button to stop it.

Programming has been set when the and buttons

are illuminated. The DISPLAY shows the cooking end

time and the cooking duration alternately.

• For example: It is 9:00 a.m. and a duration of 1

hour has been programmed. 12:30 is scheduled as

the end time. The programme will start

automatically at 11:30 a.m.

Cancelling a programme

To cancel a programme:

• press the button until the icon corresponding to

the setting you wish to cancel and the digits on the

display are no longer flashing. Press the “-” button

until the digits 00:00 appear on the display.

• Press and hold the “+” and “-” buttons; this will

cancel all the settings selected previously,

including timer settings.

Grill Pan and Handle

Using the grill pan kit

The grill pan handle is detachable from the pan to

facilitate cleaning and storage. Fix the pan handle

securely before use:

1. Fit the handle to the grill pan so that the external

‘hooks’ embrace the edge of the pan (fig. 1)

2. Make sure that the middle part of the handle fits

exactly the protruding support of the pan (fig .2)

and holds the pan from the bottom.

The food must be placed on the rack in the grill pan.

Position the grill pan on top of the oven rack. The

best results are achieved by placing the oven rack

on the uppermost shelves. Pouring a little water into

the grill pan will make the collection of grease

particles more efficient and prevent the formation of

smoke.

1 2

Grill Pan, Food Support and Anti-Splash Tray

GRILL PAN FOOD SUPPOR

Top Oven Shelf Positioning for Grilling

ENSURE SHELVES ARE

FITTED CORRECT WAY UP.

DO NOT PLACE FOOD/UTENSILS

DIRECTLY ON THE OVEN FLOOR

NOTE:

--- Preheat the grill if indicated on grill chart.Preheat the grill if indicated on grill chart.

Preheat the grill if indicated on grill chart.Preheat the grill if indicated on grill chart.Preheat the grill if indicated on grill chart.

- The grill pan must be placed on the correctThe grill pan must be placed on the correct

The grill pan must be placed on the correctThe grill pan must be placed on the correct

The grill pan must be placed on the correct

shelf and positioned centrally under the grillshelf and positioned centrally under the grill

shelf and positioned centrally under the grill

element.element.element.element.element.

----- Leave the control at 4 or MAX (dependingLeave the control at 4 or MAX (dependingLeave the control at 4 or MAX (dependingLeave the control at 4 or MAX (dependingLeave the control at 4 or MAX (depending

on Model) for toast, and for fast cooking ofon Model) for toast, and for fast cooking ofon Model) for toast, and for fast cooking ofon Model) for toast, and for fast cooking ofon Model) for toast, and for fast cooking of

foods.foods.foods.foods.foods.

--- For thicker foods requiring longer cooking,For thicker foods requiring longer cooking,

For thicker foods requiring longer cooking,For thicker foods requiring longer cooking,For thicker foods requiring longer cooking,

turn the switch to a lower setting after theturn the switch to a lower setting after the

turn the switch to a lower setting after theturn the switch to a lower setting after theturn the switch to a lower setting after the

initial sealing on both sides at 4 or MAXinitial sealing on both sides at 4 or MAX

initial sealing on both sides at 4 or MAX

(depending on Model). The thicker the food,(depending on Model). The thicker the food,

(depending on Model). The thicker the food,

the lower the control should be set.the lower the control should be set.the lower the control should be set.the lower the control should be set.the lower the control should be set.

- DO NOT line the grill pan with aluminiumDO NOT line the grill pan with aluminium

DO NOT line the grill pan with aluminiumDO NOT line the grill pan with aluminium

DO NOT line the grill pan with aluminium

foil, as this increases the amount of fatfoil, as this increases the amount of fatfoil, as this increases the amount of fatfoil, as this increases the amount of fatfoil, as this increases the amount of fat

spitting which can cause a fire.spitting which can cause a fire.spitting which can cause a fire.spitting which can cause a fire.spitting which can cause a fire.

--- After use always return the grill control toAfter use always return the grill control to

After use always return the grill control toAfter use always return the grill control toAfter use always return the grill control to

the OFF (0) position.the OFF (0) position.

the OFF (0) position.the OFF (0) position.the OFF (0) position.

Operation when using

the Top Oven for Grilling

A B C

Grill

Setting

Control

Top Oven

Temperature

Control

Timer

TOP OVEN

PILOT LIGHT

GRILL

PILOT

LIGHT

Step 1 Ensure oven timer is set to manual. Place

the shelf in the correct position (see Grilling

Guide). Place the food/grill pan on the

shelf, positioned centrally under the grill

element. Leave the top oven door fully

open.

Step 2 Turn knob (A), clockwise for FULL grill or

anti-clockwise for HALF grill, to select the

grill setting MIN (1) - MAX (4). NOTE: MIN

(1) = Low, MAX (4) = High.

Grill Controls Example:

or = High Grill Setting (depending on model)

NOTE: Do not grill with

the grill/top oven

door closed.

Step 3 After use, turn the

grill control (A) to

the off position (0).

! The Grill Pilot Light is lit when grill is used.

! Ensure knob (B) is in "0 position". The grill and

the top oven cannot work simultaneously

DO NOT allow young children near to the

appliance when the grill is in use as the surfaces

get extremely hot.

DOOR POSITION

FOR GRILLING

Guide to Grilling



9:;;

:<

 = ;

(depending

on Model)

; 

9:

;;

;>;

;

(depending on

Model)

99:;

;

9;

=;

Toasting of Bread

Products Setting MAX 3 or 2 Setting 4 or MAX 5 - 10 minutes Grill pan and food

support

Small cuts of

meat, Sausage,

Bacon

Setting MAX 3 or 2

Setting 4 or MAX

for 4 minutes

then reduce to

LOWER setting

10 - 25 minutes Grill pan and food

support

Chops etc.

Gammon steaks Setting MAX 2

Setting 4 or MAX

for 6-8 minutes

then reduce to

LOWER setting

20 - 35 minutes Grill pan and food

support

Fish: Whole

Fillets

Fingers

Setting MAX

Setting 4 or MAX

8 - 12 minutes

10 - 15 minutes

10 - 20 minutes

Grill pan and food

support

Pre-cooked

potato products Setting MAX 3 or 2 Setting 3 or

lower setting 15 - 20 minutes Grill pan and food

support

Pizzas Setting MAX 3 or 2 Setting 3 or

lower setting 10 - 20 minutes Grill pan and food

support

Browning of food

eg. Cauliflower

Cheese

Setting MAX 3 or 2 Setting 4 or MAX 10 - 20 minutes

Dish placed

directly on the

shelf

Using the Top Oven as

a Convection Oven

The top oven should be used to cook small

quantities of food. The oven is designed so that the

grill element operates at a reduced heat output, this

is combined with a heating element situated

underneath the floor of the oven. To ensure even

cooking of the food it is important that cooking

utensils are positioned correctly on the oven shelf so

that the element is directly above. As a guide, the

front of the utensil should be approx.100mm (4")

from the front of the shelf.

Note: Charts are a guide only, to suit personal

taste and requirements, it may be necessary to

increase or decrease temperatures by 10°C. It

may also be necessary to increase or decrease

cooking times.

SHELF POSITIONING

ENSURE SHELVES ARE

FITTED CORRECT WAY UP.

DO NOT PLACE FOOD/UTENSILS

DIRECTLY ON THE OVEN FLOOR

There should always be at least 25mm (1 inch)

between the top of the food and the grill element.

WARNING: Items stored in the top oven will get

hot when the main oven is in use.

DO NOT allow young children near to the

appliance when the top oven is in use as the

surfaces get extremely hot.

Operation when using the Top

Oven as a Convection Oven

Step 1 Check that the timer is in manual.

Step 2 Place the shelf in the correct position (see

Oven Temperature Charts).

Step 3 Select the required cooking temperature

(100-220°C or MAX depending on Model)

using control (B) (see Top Oven Tempera-

ture Charts). The pilot light (•) will

immediately come on, and remain on until

the oven reaches the required temperatu-

re. The light will then automatically go off

and on during cooking as the oven

thermostat maintains the correct tempera-

ture.

Step 4 Place the food on the shelf directly below

the element ensuring the oven door is

closed.

NOTE: At the end of your cooking, always return

control (B) to the OFF (O) position.

A B C

Top Oven Temperature Control

Timer

PLATE WARMING

Place the plates/dishes on shelf position 1 from the

base of the top oven, and turn top oven temperature

control (B) to 100°C for 10-15 minutes.

Never use the grill setting control (A) when

warming plates.

TOP OVEN UTENSILS

Do Not use: Meat Pans and Baking Trays larger than

- 225mm x 300mm (9"x12")

DO NOT use the grill pan or main oven meat pan

as a meat pan in the top oven, as the air

circulation will be seriously restricted.

Oven Temperature

Charts - Meat

The most accurate method of testing the readiness of joints of meat or whole poultry is to insert a meat

thermometer into the thickest part of a joint, or the thickest part of poultry thighs, during the cooking period.The

meat thermometer will indicate when the required internal temp has been reached.

Beef - Rare: 60°C 90°CLamb: 80°C Poultry:

Medium: 70°C Pork: 90°C

Well Done: 75°C Veal: 75°C

3 

 /% 34 34&?8+   

Beef/ Lamb

(slow roasting) Yes 170/180 35 mins per 450g (1lb) + 35 mins over.

Runner 1 from

bottom of oven.

Beef/ Lamb

(foil covered) Yes 190/200 35-40 mins per 450g (1lb)

Pork

(slow roasting) Yes 170/180 40 mins per 450g (1lb) + 40 mins over

Pork

(foil covered) Yes 190/200 40 mins per 450g (1lb)

Veal

(slow roasting) Yes 170/180 40-45 mins per 450g (1lb) + 40 mins over

Veal

(foil covered) Yes 190/200 40-45 mins per 450g (1lb)

Poultry/Game

(slow roasting) Yes 170/180 25-30 mins per 450g (1lb) + 25 mins over

Poultry/Game

(foil covered) Yes 190/200 25-30 mins per 450g (1lb)

Casserole

Cooking Yes 150 2-2½ hrs

,@ 4 4@"

8Allow foil to touch sides of oven. )8Cover oven interior with foil. (8Cover shelves with foil.

FanOvenCooking models)(all

Meat Pre-heat Temperature (approx.) Position°C Time inOven

Beef No 160/180 20-25 mins per 450g (1lb) +25 mins extra

Runner 1 from

bottom of oven.

Lamb No 160/180 25 mins per 450g (1lb) +25 mins extra

Pork No 160/180 25 mins per 450g (1lb) +25 mins extra

Veal No 160/170 25-30 mins per 450g (1lb) +25 mins extra

Chicken /

Turkey up to

4kg (8lb)

No 160/180 18-20 mins per 450g (1lb) +20 mins over

Turkey

up to 5.5kg

(12lb)

No 150/160 13-15 mins per 450g (1lb)

e.g. 5kg (11lb) = 143-165 mins

Turkey

over 5.5kg

(12lb)

No 150 12 mins per 450g (1lb)

e.g. 10kg (22lb) = 264 mins

Casserole

Stews No 140-150 1½ - 2 hrs

If aluminium foil,using  never:

1.Allow foil to touch sides of oven. 2.Cover oven interior with foil. 3.Cover shelves with foil.

Using the Main Oven for

Other Functions

FAN ONLY SETTING

DEFROSTING FROZEN MEAT & POULTRY

Joints of meat and whole birds should be defrosted

slowly, preferably in a refrigerator (allowing 5-6 hours

per lb.) or at room temperature (allowing 2-3 hours

per lb.). Frozen meat or poultry must be completely

defrosted before cooking in the oven. However, to

decrease the amount of time required to defrost food

items, a nonheating fan only setting may be

selected for the main oven only.

OPERATION: TO ASSIST IN DEFROSTING:

Place food in the oven and close the oven door.

Turn the Main Oven Temperature and Function

Control (C) clockwise to the setting.

This defrosts by circulating the air around the food,

time to defrost will depend on type and size of the

food.

NOTES: DO NOT defrost meat and poultry by

warming the food through.

Foods ideally suited to defrosting using the fan only

setting are cream/cream cakes, butter cream filled

cakes, gateaux, cheese cakes, iced cakes, quiches,

pastries, biscuits, bread, croissants, fruit and many

delicate frozen foods. If fish, meat and poultry are to

be defrosted using the fan only setting, where

possible it is recommended that the food should be

small and thin.

The items should be placed so that the maximum

amount of surface area is exposed to the circulating

air, and that they are turned regularly to ensure even

defrosting.

Larger cuts of meat and poultry may be defrosted

by using the fan only setting up to a maximum

weight of 2 kg (4lb 8oz).

It is important to wash both meat and poultry and

cooking utensils immediately after defrosting and

before cooking. Food should be cooked immediately

after defrosting.

It is very important to strictly adhere to the

basic principles of food handling and hygiene

to prevent the possibility of bacterial growth.

LIGHT ONLY SETTING

When the Main Oven Temperature & Function

Control (C) is turned clockwise to the setting, the

main oven light only will illuminate.

Care and Cleaning

Warning: Before cleaning, please ensure that the

electricity supply to the appliance is switched off

and the appliance is fully cold.

! Never use steam cleaners or pressure cleaners on

the appliance.

! Clean the glass part of the oven door using a sponge

and a non-abrasive cleaning product, then dry

thoroughly with a soft cloth. Do not use rough abrasive

material or sharp metal scrapers as these could

scratch the surface and cause the glass to crack.

! The accessories can be washed like everyday

crockery (even in your dishwasher).

1. "STAYCLEAN" OVEN LINERS

(Top Oven Sides, Main Oven Sides and

Rear Panel)

MAIN OVEN SIDES AND REAR PANE

TOP OVEN SIDES

(a) How "Stayclean" works.

The surfaces of the "Stayclean" oven liners (Main

Oven rear panel) are treated with a special vitreous

enamel which absorbs cooking soils. At

temperatures of 220°C (425°F) or above, the special

surface enables these soils to be slowly destroyed.

The higher the temperature the more effective it is.

(b) Cleaning.

In most cases normal cooking operations at 220°C

(425°F) will permit this cleaning operation to proceed

during cooking. However if higher cooking

temperatures are not used regularly, it may be

necessary, in order to prevent heavy soiling, to run

the ovens without shelves or meat pan, at a

maximum setting for a couple of hours (Fan Oven

mode only).

It should not normally be necessary to clean the

"Stayclean" panels with water. If the user feels it is

desirable to do so, wipe them over with a clean,

soapy cloth, followed by a wipe with a clean damp

cloth.

DO NOT use biological washing powder, harsh

abrasives or chemical oven cleaners of any kind

as this could damage the "Stayclean" oven liners.

2. CLEANING GRILL, TOP OVEN AND

MAIN OVEN

OVEN

SHELVES

GRILL

PAN

BASE

REAR

MEAT

PAN

MAIN

OVEN

BASE

(a) Base & Rear of Top Oven and Base of Main

Oven.

Wipe out the oven with a damp soapy cloth. For

more stubborn stains on the base of the oven use a

well soaped fine steel wool soap pad.

(b) Grill Pan, Meat Pan & Oven Shelves.

To prevent stains from being burnt on to the grill

pan, food support and rod shelf, always wash

immediately after use in warm soapy water.

Use a well soaped fine steel wool soap pad to

remove stubborn stains from the rod shelves, grill

pan, meat pan and the base of the oven.

DO NOT use aerosol cleaners on this oven as

they could adversely affect the fan motor unit,

and cannot be wiped off the fan blade.

Care and Cleaning

3. OVEN DOORS

CONTROL PANEL

OVEN

DOOR

(a) Control Panel

Regularly wipe with a clean, damp cloth and polish

with a clean, dry cloth.

(b) Inner Door Panels & Glass

Open the door fully. The glass panel may now be

washed. Stubborn stains can be removed by using

a well soaped, fine steel wool soap pad.

Regularly wipe with a clean, damp cloth and polish

with a clean dry cloth.

DO NOT use scouring pads, or abrasive powder,

which will scratch the glass.

4. REPLACEMENT OF THE OVEN LAMP

TOP OVEN LAMP

MAIN OVEN LAMP

Warning: To avoid electric shocks - please ensure

that the electricity supply to the appliance is

switched off and the appliance is fully cold,

before removing the lamp lens.

Open the oven door and remove the oven shelves.

Using a thick cloth, grip the lamp lens, unscrew

anticlockwise and remove the lens.

Carefully unscrew the bulb anti-clockwise.

Fit replacement bulb (25W 300°C SES) and refit lens.

5. HOW TO CLEAN THE LAMP LENS

TOP OVEN LAMP

MAIN OVEN LAMP

Warning: To avoid electric shocks - please ensure

that the electricity supply to the appliance is

switched off and the appliance is fully cold,

before cleaning lamp lens.

Open the oven door and remove the oven shelves.

Using a thick cloth, grip the lamp lens, unscrew

anticlockwise and remove.

Clean with a non-abrasive cleansing cream and refit

lamp lens.

DO NOT use scouring pads, or abrasive powder,

which will scratch the glass lens

Care and Cleaning

CLEANING THE DOORS

Take particular care not to damage the inner

surface of the door inner glass that is coated with

a heat reflective layer. Do not use scouring pads,

or abrasive powder, which will scratch the glass.

Ensure that the glass panel is not subjected to

any sharp mechanical blows.

Stubborn stains can be removed by using a fine

steel wool soap pad. For slight soiling the inner

glass panel may be cleaned, while still warm,

without removing it from the door. After cleaning,

rinse and dry with a soft cloth.

DROP DOWN DOORS

Remove the door inner glass as follows.

1. Open the door fully and remove the extrusion end

caps (This should be done by hand but if it proves

too difficult, simply lift the inner glass to ease the

end caps out of position).

NOTE: If you need to use a tool - be carefulNOTE: If you need to use a tool - be carefulNOTE: If you need to use a tool - be carefulNOTE: If you need to use a tool - be carefulNOTE: If you need to use a tool - be careful

not to damage the extrusion or end cap.not to damage the extrusion or end cap.

not to damage the extrusion or end cap.not to damage the extrusion or end cap.not to damage the extrusion or end cap.

Top filler cap Remove both screws to

remove top filler cap

2. Carefully slide the inner glass towards you and

withdraw it from its locating slots. Ensure that the

door is not allowed to slam shut, due to the

reduction in door weight. Clean the glass as

described above.

3. The inside of the outer door glass can now be

cleaned while still fitted to the cooker.

NEVER OPERATE THE COOKER WITHOUT THE

INNER DOOR GLASS IN POSITION.

Refit the door inner glass as follows.

1. Open the door fully.

2. Locate the inner door glass into its slots. The inner

door glass has a special reflective coating on one

side, in order to minimise surface temperatures

and energy consumption during use, it is important

it is fitted correctly.

3. Carefully slide the glass into its slots as far as it

will go and replace the top filler cap.

Installation

Electrical Requirements

For your own safety, we recommend that your cooker

is installed by a competent person such as one who

is registered with NICEIC (National Inspection

Council for Electrical Installation Contracting). The

cooker should be installed in accordance with the

latest edition of the IEE Regulations.

Warning: This appliance must be earthed.

Electrical Connections

The installer must check that the voltage shown on

the rating plate corresponds with the house

electricity supply. The cooker must be supplied via

a suitable double pole isolating switch, having a

contact separation of at least 3mm in all poles

placed in a readily accessible position adjacent to

the cooker. If the cooker is to be wired into a

connector unit, this may be positioned behind the

cooker providing the following requirements are met:

i) The connector unit must not project from the wall

more than 25mm.

ii) The top of the connector must not be more than

130mm above floor level.

Remove the terminal cover at the rear base of the

cooker. Pass the cable through the cable clamp and

connect to the appropriate terminals provided.

Allow sufficient cable for any future servicing.

Tighten the screws on the cable clamp and replace

the cover. Make main connections in the connector

unit or cooker control unit. This appliance conforms

to B.S. EN 55014 regarding suppression of Radio

and Television reception interference.

A double Pole control switch having a minimum

rating of 32 amps should be used to feed the cooker

using a suitably rated cable. Where a hob is fitted

adjacent to or over the cooker, a 45 amp Double

Pole control switch should be used to feed both

units via separate suitably rated cables.

We recommend a minimum of 4mm2 PVC insulated

twin and earth cable conforming to B.S. 6004 for

connection of each appliance.

In all cases adhere to routing details (see fig. 4).

This appliance must not be installed over any other

appliance that generates heat such as a plinth heater.

Note: Due to many different types of installation, a

mains cable is not supplied with this product. The

installer will fit the correct type and length of cable.

Important

It is essential that the lower cupboard is constructed in

the manner illustrated i.e. having side, back, and roof

panels so joined as to provide no apertures which

could permit access to the oven unit when installed.

1. General

The appliance is designed for mounting at a safe

level into an oven housing which must be secured to

the backing wall.

2. Ventilation

a. The oven housing unit cabinet dimensions must

comply with fig. 4.

b. An air gap of 50mm minimum must be provided at

the rear of any top or bottom cupboards or shelves

(see fig. 1).

c. It is necessary that the cabinets are provided with

unobstructed ventilation, i.e. from adjacent

cabinetry. This can be done by either raising the

base of the cabinets using the adjusting feet (or

spacers) or alternatively by providing a slot in the

cabinet plinth to the dimensions in fig. 1.

d. The air gap at rear allows the warmed air to pass out

of the inner cabinet space. Where it is intended to fit

cupboards above the oven unit to ceiling height, it is

essential that the warmed air is exhausted through

the front of the cabinet (see fig. 1).

e. If an oven unit is installed adjacent to a tall cabinet,

steam escaping from the oven when the door is

opened could condense on and maybe stain the

adjacent surface. To prevent permanent staining, the

adjacent surface should be made of a material that is

heat resisting and easy to clean. Adjacent tall cabinets

should not be deeper than the oven housing cabinet.

3. Final Installation

a. Using a spirit level, check that the housing cabinet

is level from side to side and from front to back in

its installed position.

b. Correct any unevenness by placing spacers under

the bottom of the cabinet. Make sure that the cabinet

rests firmly on the floor without rocking.

c. Before the oven is fitted, the cabinet must be firmly

secured to the backing wall for stability.

d. The oven unit should now be lifted (this is a two

person lift) into the cabinet and pushed fully home.

e. Finally, the oven is secured to the cabinet by means

of the four Phillips C/SK Head screws - two through

each side trim.

f. Remove all packaging material from the grill and

oven interior.

List of loose items:

4 x Phillips C/SK Head No. 6 x 25mm screws.

Tall Cabinet Ventilation

Ventilation Slot required

here if cabinet does not

fit to ceiling - min. area51mm x 457mm

Ventilation Slot

required

here if the cabinet does no

fit to the ceiling

- min. 51mm x 457mm

area

Ventilation Slot

required here

- 51mm x 457mm

min. area

50 mm

Air Gap

50 mm

Air Gap

Fig. 1

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Ovn
Model:	BD32B2
Justerbar termostat:	Ja
Bredde:	597 mm
Højde:	887 mm
Kontroltype:	Dreje
Indvendig belysning:	Ja
Timer type:	Digital
Ovntype:	Elektrisk ovn
Samlet indvendig ovn kapacitet:	65 L
Antal ovne:	2
Pæreeffekt:	40 W
