Side 1/4

1 “ON/OFF” button

2 Programme selector

3 “Start/Pause” button

4 “Spin Speed” button

5 “Multi Rinse” button

6 “Cleaning Action” button

7 “Start Delay” button

8 “Energy saver” / “Key lock“

button

9 “Temperature” button

DISPLAY INDICATORS

Door locked

Energy saver activated

Pre-wash activated

Start Delay activated

Key lock activated

Washing phase

Indicates washing phase of the cycle

Failure: Call Service

Refer to Troubleshooting section

Failure: Water lter clogged

Water cannot be drained; water lter

might be blocked

Failure: No water

No or not sucient inlet water.

In the event of any failure, refer to the

“TROUBLESHOOTING” section

THANK YOU FOR BUYING A HOTPOINT PRODUCT.

In order to receive a more complete assistance,

please register your appliance on

www.hotpoint.eu/register

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed. For more detailed

instructions on how to remove them, see the Installation Guide.

CONTROL PANEL

PROGRAMME CHART

Quick guide

PRODUCT DESCRIPTION

1. Worktop

2. Detergent dispenser

3. Control panel

4. Door handle

5. Door

6. Water lter

7. Adjustable feet (4)

DETERGENT DISPENSER

Compartment 1: Pre-wash detergent (powder)

Compartment 2: Washing detergent

(powder or liquid)

Compartment 3: Additives (fabric softeners, etc.)

The fabric softener must not exceed the “MAX” level.

! Use powder detergent for white cotton

garments, for pre-washing, and for washing at

temperatures over 60°C.

! Follow the instructions given on the

detergent packaging.

21 53

For all testing institutes:

2) Long cotton cycle: set cycle 7 at a temperature of 40°C.

3) Long synthetics cycle: set cycle 8 at a temperature of 40°C.

4) The display will show the suggested spin speed as default value.

* By selecting the cycle and excluding the spin cycle, the washing machine will drain only.

** The duration of the wash cycles can be checked on the display.

*** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as

the temperature and pressure of the incoming water, ambient temperature, amount of

detergent, load quantity and type, load balancing and any additional options selected. The

values given for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most efficient

programme in terms of energy and water consumption for washing normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in the

table.

Maximum load 7 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Detergents and Addi-

tives

Recommended

detergent

Residual

dampness % (***)

Energy c

onsumption kWh

Total water l

Laundry

temperature °C

Wash cycle

Temperature Maximum

spin

(r.p.m.)

Maximum

load (kg)

Duration

(h : m)

Pre-

wash Wash Fabric

softener Powder Liquid

Setting Range 1 2 3

1 Anti Stain 40 40 °C - 40 °C 1400 7,0 ** –    – – – – –

2 Anti Stain Quick 40 °C - 40 °C 1200 3,5 ** –   – – – – –

3 White 60 °C - 90 °C 1400 7,0 2:30    (90°) – 52,1 1,36 74,8 55

4 Bed Bath 60 °C - 60 °C 1400 7,0 ** –    – – – – –

40 °C 40°C5Eco 40-60 (1)

1351 7,0 3:25 –     53 0,89 47 35

1351 3,5 2:40 –     53 0,57 45 34

1351 1,75 2:10 –     53 0,52 39 33

6 Mixed 40 °C - 40 °C 1000 7,0 ** –   – – – – –

7 Cotton (2) 40 °C - 60 °C 1400 7,0 3:50 –    – 53 1,0 71 45

8 Synthetics (3) 40 °C - 60 °C 1200 4,0 2:35 –    – 53 0,86 60 43

9 Colours 40 °C - 40 °C 1400 7,0 ** –    – – – – –

10 Rapid 30‘ 30 °C - 30 °C 1200 (4) 3,5 0:30 –   – 73 0,19 31 27

11 Wool 40 °C - 40 °C 800 1,5 ** –   – – – – –

12 20°C 20 °C - 20 °C 1400 7,0 1:50 –   – 52 0,16 64 22

13 Delicates 30 °C - 30 °C 600 (4) 1,0 ** –   – – – – –

14 Duvet 30 °C - 30 °C 1000 3,0 ** –   – – – – –

Rinse & Spin – – 1400 7,0 ** – –  – – – – – –

Spin & Drain * – – 1400 7,0 ** – – – – – – – – –

7Eco Cotton (4) 60 °C 60 °C 1400 7,0 2:55 –     53 0,9 49,2 -

40 °C 40 °C 1400 7,0 –3:50     53 1,0 71 -

  Required dosage Optional dosage

PROGRAMMES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Anti Stain 40

This cycle is suitable to heavily-soiled garments with resistant colours.

It ensures a washing class that is higher than the standard class (A

class). When running the programme, do not mix garments of dierent

colours. We recommend the use of powder detergent. Pre-treatment

with special additives is recommended if there are obstinate stains

Anti Stain Quick

This cycle is ideal for washing daily stains in 45’. It is ideal for mixed

fabrics and coloured garments.

White

For washing normally to heavily soiled towels, underwear, table and

bed linen, etc in resilient cotton and linen. Only when the temperature

is selected at 90°C the cycle is provided with a prewash phase before

main washing phase. In this case it is recommended to add detergent

both, in the prewash and main wash section.

Bed Bath

For washing home linen in a single cycle. It optimises the use of fabric

softener and allows for saving time and electricity. We recommend the

use of powder detergent.

Eco 40-60

For washing normally soiled cotton garments declared to be washable

at 40 °C or 60 °C, together in the same cycle. This is the standard cotton

programme and the most ecient in terms of water and energy

consumption.

Mixed

To wash mixed and coloured items together.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Suitable for washing moderately soiled garments made of synthetic

bres (e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-

cotton bres.

Colours

For washing coloured cotton garments. This programme is optimised

to keep colours bright even after repeated washing.

Rapid 30‘

For washing lightly soiled garments in a short time. Not suitable for

wool, silk and garments to be washed by hand.

Wool - Woolmark Apparel Care - Green:

The Wool wash cycle of this machine has been

approved by The Woolmark Company for the washing

of wool garments labelled as “hand wash” provided

that the products are washed according to the

instructions on the garment label and those issued by the

manufacturer of this washing machine (M1126). The Woolmark logo is a

Certication mark in many countries.

20 °C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Ultradelicates

For washing very delicate garments. It is advisable to turn the garments

inside out before washing them. For best results, use liquid detergent

on delicate garments.

Duvet

Suitable for washing clothing padded with goose down, such as single

duvets (weighing under 3 kg), cushions or down jackets. Duvets should

be loaded into the drum with their edges folded inwards and no more

than ¾ of the total drum volume should be used up. For best results, it

is advisable to use liquid detergent to be poured into the detergent

drawer.

Rinse + Spin

Designed for rinsing and spinning.

Spin + Drain

Designed for spinning and draining the water.

FIRST TIME USE

To remove any manufacturing debris select the programme at a 3

temperature of 90°C. Pour a small quantity of detergent powder into the

main wash compartment of the detergent dispenser (maximum 1/3 of 2

the quantity the detergent manufacturer recommends for lightly soiled

laundry). Start the programme without adding any laundry.

DAILY USE

Prepare your laundry according to the recommendations in the “HINTS

AND TIPS” section. Load the laundry, close the door, open the water

tap and press the “ON/OFF” button to switch the washing machine

on, the “Start/Pause” button ashes. Turn the programme selector

to the desired programme and select any option if needed. The

temperature and spin speed can be changed by pressing the “Temp.”

button or the “Spin Speed” button. Pull out the detergent dispenser and

add the detergent (and additives/softener) now. Observe the dosing

recommendations on the detergent pack. Then close the detergent

dispenser.

STARTING CYCLE

Press the START/PAUSE button.

The machine will lock the door ( symbol on) and the drum will start

to rotate; the door will be unlocked ( symbol OFF) and then locked

again ( symbol on) as preparation phase of each washing cycle. The

“Clicking” noise is part of the door locking mechanism. Water will enter

the drum and start the washing phase once the door is locked.

PAUSE A RUNNING PROGRAMME

To pause the wash cycle, press the “Start/Pause” ; the indicator light

will go o and the remaining time on display ash. To start the wash cycle

from the point at which it was interrupted press the button again.

OPEN THE DOOR, IF REQUIRED

After starting a programme, the “Door locked” indicator lights up to

show that the door can not be opened. As long as a wash programme is

running, the door remains locked. To open the door while a programme

is in progress, press the “Start/Pause” to pause the programme.

Provided the water level and/or temperature is/are not too high, the

“Door locked” indicator light goes o and you can open the door.

For example to add or remove laundry. Press the “Start/Pause” button

again to continue the programme.

PROGRAMME END

The “Door locked” indicator light goes o and the display shows

“End”. To switch o the washing machine after programme ends press the

“ON/OFF” button, the lights goes o. If you do not press “ON/OFF”

button, the washing machine will switch o automatically after about a

10 minutes. Close the water tap, open the door and unload the washing

machine. Leave the door ajar to allow the drum to dry.

OPTIONS

! If the selected option is incompatible with the programme set,

the incompatibility will be signalled by a buzzer (3 beeps) and the

corresponding indicator light will ash.

! If the selected option is incompatible with another previously set

option, only the most recent selection will remain active.

Energy saver

This option saves energy by not heating the water used to wash your

laundry – an advantage both to the environment and to your energy

bill. Instead, intensied wash action and water optimisation ensure

great wash results in the same average time of a standard cycle.

For the best washing results we recommend the usage of a liquid

detergent.

Start Delay

To set the selected programme to start at a later time, press the button

to set the desired delay time. Symbol lights on the display when this

function is enabled. To cancel the delayed start, press the button again

until the value ‚ ‘‘0‘‘ is shown on the display.

Cleaning Action

Option “Cleaning Action” makes it possible to optimise washing based

on the level of soil in the fabrics and on desired wash cycle intensity.

For heavily-soiled garments press “Cleaning Action” button until the

“ ” level is reached. This level ensures a high-performance wash due

to a larger quantity of water used in the initial phase of the cycle and

due to increased drum rotation. It is useful when removing the most

stubborn stains. For lightly-soiled garments or a more delicate treatment

of the fabrics, press “Cleaning Action” button until the “ ” level is

reached. The cycle will reduce drum rotation to ensure washing results

that are perfect for delicate garments.

Multi Rinse

By selecting this option, the eciency of the rinse is increased and

optimal detergent removal is guaranteed. It is particularly useful for

sensitive skin. Press the button once, two or three times to select an

additional 1 , 2 or 3 rinses after the standard cycle rinse and

remove all traces of detergent. Press the button again to go back to the

“Normal rinse” rinse type.

Temperature

Every programme has a predened temperature. If you want to change

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Vaskemaskine
Model:	BI WMHG 71483 UK N
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	545 mm
Højde:	820 mm
Vægt:	66000 g
Produktfarve:	Hvid
Kontroltype:	Rotary,Touch
Indbygget skærm:	Ja
Strøm:	13 A
Ledningslængde:	1.2 m
Placering af apparat:	Indbygget
Dørhængsel:	Venstre
Inverter-teknologi:	Ja
Tilsluttet belastning:	1850 W
Støjniveau:	72 dB
Ilægningstype:	Front-læsning
Tromlekapacitet:	7 kg
Maksimal centrifugeringshastighed:	1400 rpm
Antal vaskeprogrammer:	14
Støjniveau (centrifugering):	- dB
Støjniveau (vask):	- dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Baby care,Bedding,Colour,Cottons 40°C,Cottons 60°C,Delicate/silk,Down wear/duvet,Eco,Mix,Pre-wash,Synthetics,Wool
Børnesikring:	Ja
Justerbare fødder:	Ja
Energiforbrug ved vask:	0.69 kWh
Tromle volumen:	52 L
Dør farve:	Hvid
Balje materiale:	Plast
Balance system:	Ja
Spin-tørre klasse:	B
Cyklustid (maks.):	205 min.
Skum kontrol system:	Ja
Vandforbrug pr. cyklus:	44 L
Energieffektivitetsskala:	A til G
Indikator for resterende tid:	Ja
Støjemissionsklasse:	A
Energieffektivitetsklasse:	D
Energiforbrug pr. 100 cyklusser:	69 kWh
Justerbar centrifugeringshastighed:	Ja
Nem strygning funktion:	Ja
Tænd/sluk-knap:	Ja
