Quick guide

CONTROL PANEL DESCRIPTION

1. SELECTION KNOB

For switching the oven on by selecting

a function.

Turn to the position to switch the

oven off.

2. LIGHT

With the oven switched on, press to

turn the oven compartment lamp on or

off.

3. SETTING THE TIME

For accessing the cooking time settings,

delayed start and timer. For displaying

the time when the oven is off.

4. DISPLAY

5. ADJUSTMENT BUTTONS

For changing the cooking time settings.

6. THERMOSTAT KNOB

Turn to select the temperature you

require when activating manual

functions. For automatic functions use

0/A.

1 32 4 5 6

FIRST TIME USE

1. SETTING THE TIME

You will need to set the time when you switch on the

appliance for the first time: press icon and until the

the two digits for the hour start flashing on the display.

Use or to set the hour and press to confirm. The two

digits for the minutes will start flashing. Use or to set

the minutes and press to confirm.

Please note: When the icon is flashing, for example following

lengthy power outages, you will need to reset the time.

2. HEAT THE OVEN

A new oven may release odours that have been left behind

during manufacturing: this is completely normal.

Before starting to cook food, we therefore recommend

heating the oven with it empty in order to remove any

possible odours.

Remove any protective cardboard or transparent film from

the oven and remove any accessories from inside it.

Heat the oven to 250 ° C for about one hour. The oven must

be empty during this time.

Please note: It is advisable to air the room after using the appliance

for the first time.

FUNCTIONS & DAILY USE

CONVENTIONAL

For cooking any kind of dish on one shelf only.

CONVECTION BAKE

To cook on a maximum of two shelves at the same time.

It is a good idea to swap the position of the baking trays

halfway through cooking.

GRILL

For grilling steaks, kebabs and sausages, cooking

vegetables au gratin or toasting bread. When grilling meat,

we recommend using a drip tray to collect the cooking juices:

Position the tray on any of the levels below the wire shelf and

add 200 ml of drinking water.

TURBO GRILL

For roasting large joints of meat (legs, roast beef,

chicken). We recommend using a drip tray to collect the

cooking juices: position the pan on any of the levels below

the wire shelf and add 200 ml of drinking water.

ECO CONVECTION BAKE*

For cooking roasts and stuffed roasting joints on a

single shelf. Food is prevented from drying out excessively

by gentle, intermittent air circulation. When this ECO MODE

function is in use, the light will remain switched off during

cooking but can be switched on again by pressing .

BREAD AUTO

This function automatically selects the ideal

temperature and baking time for bread. For best results,

carefully follow the recipe. Activate the function when the

oven is cold.

DESSERTS AUTO

This function automatically selects the ideal

temperature and baking time for cakes. Activate the function

when the oven is cold.

THANK YOU FOR BUYING A HOTPOINT-

ARISTON PRODUCT

In order to receive a more complete

assistance, please register your product on

www . hotpoint . eu/register

Before using the appliance carefully read the Safety

Instruction.

DIAMOND CLEAN

The action of the steam released during this special

low-temperature cleaning cycle allows dirt and food residues

to be removed with ease. Pour 200 ml of drinking water on

the bottom of the oven and only activate the function when

the oven is cold.

* Function used as reference for the energy efficiency declaration in

accordance with Regulation (EU) No.65 / 2014

1. SELECT A FUNCTION

To select a function, turn the to the symbolselection knob

for the function you require: the display will light up and an

audible signal will sound.

2. ACTIVATE A FUNCTION

MANUAL

To start the function you have selected, turn the thermostat knob

to set the temperature you require.

Please note: During cooking you can change the function by

turning the or adjust the temperature by turning the selection knob

thermostat knob.

The function will not start if the thermostat knob is on 0 °C. You can

set the cooking time, cooking end time (only if you set a cooking

time) and a timer.

AUTOMATIC

To start the automatic function you have selected (“Bread”

or “Dessert”), keep the thermostat knob at the position for

automatic functions ( ).

To finish cooking, turn the to position 0.selection knob

Please note: You can set the cooking end time and timer.

3. PREHEATING AND RESIDUAL HEAT

Once the function starts, an audible signal and a flashing

icon on the display indicate that the preheating phase has

been activated.

At the end of this phase, an audible signal and the fixed icon

on the display will indicate that the oven has reached

the set temperature: at this point, place the food inside and

proceed with cooking.

Please note: Placing the food in the oven before preheating has

finished may have an adverse effect on the final cooking result.

After cooking and with the function deactivated, the icon

may continue to remain visible on the display even after the

cooling fan has switched off to indicate that there is residual

heat in the compartment.

Please note: The time after which the icon switches off varies

because it depends on a series of factors such as ambient

temperature and function used. In any case, the product should be

considered to be off when the pointer on the selection knob is at

“0”.

4. PROGRAMMING COOKING

You will need to select a function before you can start

programming cooking.

DURATION

Keep pressing until the icon and “00:00” start flashing

on the display.

Use or to set the cooking time you require, then press

to confirm.

Activate the function by turning the thermostat knob to the

temperature you require: an audible signal will sound and the

display will indicate that cooking is complete.

Notes: To cancel the cooking time you have set, keep pressing

until the icon starts flashing on the display, then use to reset

the cooking time to “00:00”.

This cooking time includes a preheating phase.

PROGRAMMING THE END COOKING TIME/DELAYED

START

After a cooking time has been set, starting the function can

be delayed by programming its end time: press until the

icon and the current time start flashing on the display.

Use or to set the time you want cooking to end and

press to confirm.

Activate the function by turning the thermostat knob to the

temperature you require: the function will remain paused

until it starts automatically after the period of time that has

been calculated in order for cooking to finish at the time you

have set.

Please note: To cancel the setting, switch the oven off by turning

the selection knob to position “ ”.

Please note: Delay to start functionality is not available for Grill and

Turbo Grill functions.

END OOKING OF C

An audible signal will sound and the display will indicate

that the unction as inished. f h f

Turn the selection nob k to elect ifferent unction o s a d f or t

position “ ” to switch the oven off.

Please note: If the timer is active, the display will show “END”

alternately with the remaining time.

5. SETTING THE TIMER

This option does not interrupt or program cooking but

allows you to use the display as a timer, either during while a

function is active or when the oven is off.

Keep pressing until the icon and “00:00” start flashing

on the display.

Use or to set the time you require and press to

confirm.

An audible signal will sound once the timer has finished

counting down the selected time.

Notes: To cancel the timer, keep pressing until the icon starts

flashing, then use to reset the time to “00:00”.
