Side 1/16

DAILY REFERENCE

GUIDE

THANK YOU FOR PURCHASING AN

HOTPOINT-ARISTON PRODUCT

To receive more comprehensive help and

support, please register your product at

www. hotpoint. eu/ register

WWW

You can download the Safety Instructions

and the Use and Care Guide by visiting our

website docs . hotpoint . eu and following

the instructions on the back of this booklet.

Before using the appliance carefully read the Health and Safety guide.

PRODUCT DESCRIPTION

1. Control panel

2. Fan

3. Lamp

4. Shelf guides

(the level is indicated on the wall

of the cooking compartment)

5. Door

6. Upper heating element/grill

7. Identification plate

(do not remove)

embossing for

drinking water

CONTROL PANEL DESCRIPTION

1 32 4 5

1. SELECTION KNOB

For switching the oven on by

selecting a function. Turn to the

position to switch the oven off.

2. LIGHT

With the oven switched on, press

to turn the oven compartment

lamp on or off.

3. SETTING THE TIME

For accessing the cooking time

settings, delayed start and timer.

For displaying the time when the

oven is off.

4. DISPLAY

5. ADJUSTMENT BUTTONS

For changing the cooking time

settings.

6. THERMOSTAT KNOB

Turn to select the temperature you

require when activating manual

functions.

ACCESSORIES

WIRE SHELF DRIP TRAY * BAKING TRAY * SLIDING RUNNERS *

Use to cook food or as a

support for pans, cake tins

and other ovenproof items of

cookware.

Use as an oven tray for

cooking meat, sh,

vegetables, focaccia, etc. or

position underneath the wire

shelf to collect cooking juices.

Use for cooking all bread and

pastry products, but also for

roasts, sh en papillotte, etc.

To facilitate inserting or

removing accessories.

* Availble only on certain models.

The number and the type of accessories may vary depending on which model is purchased.

Other accessories can be purchased separately from the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

. Insert the wire shelf onto the level you require by

holding it tilted slightly upwards and resting the

raised rear side (pointing upwards) down first.

Then slide it horizontally along the runners as far as

possible.

. Other accessories, like the baking tray, are to be

inserted horizontally, letting them slide on the

runners.

REMOVING AND REFITTING THE SHELF GUIDES

. To remove the shelf guides, firmly grip the external

part of the guide, and pull it towards you to extract

the support and the two internal pins from the

lodging.

. To reposition the shelf guides, position them near

the cavity and initially insert the two pins into their

lodgings. Next, position the external part near its

lodging, insert the support, and firmly press towards

the wall of the cavity to make sure the shelf guide is

properly secured.

FITTING THE SLIDING RUNNERS (IF PRESENT)

Remove the shelf guides. Disengage the guide’s

anchoring clips from the shelf guide, starting from

the lower part.

To reinstall the sliding guides, anchor theguide’s

upper clip to the shelf guide, then lower the other

clip into position. To secure the guide, press the

lower portion of the clip firmly against the shelf

guide. Make sure that the runners can move freely.

Reposition the shelf guides.

Please note: The sliding runners can be tted on any level.

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Ovn
Model:	FA4S 544 IX HA
Afrimningsfunktion:	Ingen
Justerbar termostat:	Ja
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	595 mm
Dybde:	551 mm
Højde:	595 mm
Vægt:	26000 g
Produktfarve:	Rustfrit stål
Kontroltype:	Rotary, Touch
Indbygget skærm:	Ja
Skærmtype:	LED
Pakkevægt:	27300 g
Pakkedybde:	650 mm
Pakkebredde:	640 mm
Pakkehøjde:	670 mm
Placering af apparat:	Indbygget
Indvendig belysning:	Ja
Dørhængsel:	Ned
Integreret ur:	Ja
Urtype:	Elektronisk
Installationsrum bredde:	560 mm
Installationsrum dybde:	560 mm
Installationsrum højde:	600 mm
Tilsluttet belastning:	2900 W
Antal madlavningsprogrammer:	8
Grill:	Ja
Damp madlavning:	Ja
Rotisserie:	Ingen
Konvektion madlavning:	Ja
Børnesikring:	Ingen
Døråbningsvinkel:	89 °
Energieffektivitetsskala:	A+++ til D
Selvrensende:	Ingen
LED-indikatorer:	Ingen
Installationsrum højde (min.):	583 mm
Kontrolposition:	Front
Timer type:	Digital
Antal glasdørpaneler:	2
Antal gitre:	1
Varmebeskyttende dør:	Ingen
Ovn - størrelse:	Medium
Ovntype:	Elektrisk ovn
Samlet indvendig ovn kapacitet:	71 L
Strøm for samtlige ovne:	- W
Antal ovne:	1
Ovn nettokapacitet:	71 L
Ovn termostatinterval:	60 - 250 °C
Konventionel madlavning:	Ja
Holde varm funktion:	Ingen
Pizza fremstillingsfunktion:	Ja
Energieffektivitetsindeks (EEI):	106.1
Energiforbrug (konventionel):	0.99 kWh
Energiforbrug (tvungen konvektion):	0.81 kWh
Hurtig varme:	Ingen
Opvarmning i både top og bund:	Ja
Mikroovn madlavning:	Ingen
Blæser grillfunktion:	Ja
Antal bageplader:	2
Strømstiktype:	Intet stik
Alarm klar:	Ingen
Aftaglig ovndør:	Ja
Aftagelig dørglas:	Ja
Dørmateriale:	Glas
Brødfremstilling kapacitet:	Ja
Fuld overflade grill + varmluft (enkelt tilstand):	Ja
Stegetermometer:	Ingen
Indvendig materiale:	Emalje
Sikkerhedsventil:	Ingen
Spildbakke:	Ingen
Ovntilberedningsmetode:	Blæsertvungen
Garantiperiode:	2 År
