Quick guide

SLIDING RUNNERS AND SHELF GUIDES

Before using the oven remove the protective tape [a] and then

remove the protective foil [b] from the sliding runners.

REMOVING THE SLIDING RUNNERS [c]

Pull the lower part of the sliding runner to uncouple the lower

hooks (1) and pull the the sliding runners upwards, removing

them from the upper hooks (2).

REFITTING THE SLIDING RUNNERS [d]

Hook the upper hooks on the shelf guides (1) then press the

lower part of the sliding runners against the shelf guides, until

the lower hooks are clicking (2).

[c] [d]

REMOVING AND REFITTING THE SHELF GUIDES

1. To remove the shelf guides, rmly grip the external part of the

guide, and pull it towards you to extract the support and the

two internal pins from the lodging.

2. To reposition the shelf guides, position them near the cavity

and initially insert the two pins into their lodgings. Next,

position the external part near its lodging, insert the support,

and rmly press towards the wall of the cavity to make sure the

shelf guide is properly secured.

FIRST TIME USE

1. SETTING THE TIME

You will need to set the time when you switch on the appliance

for the rst time: Press until the icon and the two digits

for the hour start ashing on the display.

Use or to set the hour and press to conrm. The two

digits for the minutes will start ashing. Use o to set the

minutes and press to conrm.

Please note: When the

icon is flashing, for example following

lengthy power outages, you will need to reset the time.

2. SET THE POWER CONSUMPTION

By default the oven is programmed to work at a power higher

than 3 kW (Hi): To operate the oven at a power that is compatible

with a domestic power supply less than 2,9 kW (Lo), you will

need to change the settings.

To go to the change menu, turn the selection knob to , then

turn it back to .

Press and hold and for ve seconds immediately

afterwards.

THANK YOU FOR BUYING A HOTPOINT-

ARISTON PRODUCT

In order to receive a more complete

assistance, please register your product on

ww w . hotpoint . eu/register

Before using the appliance carefully read the Safety

Instruction.

CONTROL PANEL DESCRIPTION

1 32 4 5 6

1. SELECTION KNOB

For switching the oven on by selecting a

function.

Turn to the position to switch the oven

o.

2. LIGHT

With the oven switched on, press to turn

the oven compartment lamp on or o.

3. SETTING THE TIME

For accessing the cooking time settings,

delayed start and timer.

For displaying the time when the oven is

o.

4. DISPLAY

5. ADJUSTMENT BUTTONS

For changing the cooking time settings

6. THERMOSTAT KNOB

Turn to select the temperature you

require when activating manual

functions.

For automatic functions keep on

/A.

Use o to change the setting, then press and hold for at

least two seconds to conrm.

3. HEAT THE OVEN

A new oven may release odors that have been left behind

during manufacturing: this is completely normal. Before starting

to cook food, we therefore recommend heating the oven with it

empty in order to remove any possible odors.

Remove any protective cardboard or transparent lm from the

oven and remove any accessories from inside it.

Heat the oven to 250 °C for about one hour. The oven must be

empty during this time.

Please note: It is advisable to air the room after using the appliance

for the first time.

FUNCTIONS & DAILY USE

CONVENTIONAL

For cooking any kind of dish on one shelf only.

FORCED AIR

For cooking dierent foods that require the same cooking

temperature on several shelves (maximum three) at the same

time. This function can be used to cook dierent foods without

odours being transferred from one food to another.

MAXI COOKING

For cooking large joints of meat (above 2.5 kg). We

recommend turning the meat over during cooking to ensure

that both sides brown evenly. We also recommend basting the

joint every so often to prevent it from drying out excessively.

PIZZA

For baking dierent types and sizes of pizza and bread. It

is a good idea to swap the position of the baking trays halfway

through cooking.

GRILL

For grilling steaks, kebabs and sausages, cooking

vegetables au gratin or toasting bread. When grilling meat, we

recommend using a Baking tray to collect the cooking juices:

position the pan on any of the levels below the wire shelf and

add 500 ml of drinking water.

TURBO GRILL

For roasting large joints of meat (legs, roast beef, chicken).

We recommend using a Baking tray to collect the cooking juices:

position the pan on any of the levels below the wire shelf and

add 500 ml of drinking water.

RISING

For helping sweet or savoury dough to rise eectively. Turn

the thermostat knob to the icon to activate this function.

ECO FORCED AIR

For cooking roasts and stued roasting joints on a single

shelf. Food is prevented from drying out excessively by gentle,

intermittent air circulation. When this ECO function is in use, the

light will remain switched o during cooking but can be switched

on again by pressing .

BREAD AUTO

This function automatically selects the ideal temperature

and baking time for bread. For best results, carefully follow the

recipe. Activate the function when the oven is cold.

PASTRY AUTO

This function automatically selects the ideal temperature

and baking time for cakes. Activate the function when the oven

is cold.

AUTOMATIC OVEN CLEANING - PYRO

For eliminating cooking spatters using a cycle at very high

temperature.

1. SELECT A FUNCTION

To select a function, turn the selection knob to the symbol for

the function you require: the display will light up and an audible

signal will sound.

2. ACTIVATE A FUNCTION

To start the function you have selected, turn the thermostat knob

to set the temperature you require.

To interrupt the function at any time, switch o the oven, turn

the selection knob and the thermostat knob to .

Please note: During cooking you can change the function by

turning the selection knob or adjust the temperature by turning

the thermostat knob.

The function will not start if the thermostat knob is on 0 °C. You can

set the cooking time, cooking end time (only if you set a cooking

time) and a timer.

AUTOMATIC

To start the automatic function you have selected (“Bread”

or “Pastry”), keep the thermostat knob at the position for

automatic functions (

/A).

To nish cooking, turn the selection knob to position .

Please note: You can set the cooking end time and timer.

RISING

To start the “Rising” function, turn the thermostat knob to the

relevant symbol; if the oven is set to a dierent temperature, the

function will not start.

Please note: You can set the cooking time, cooking end time (only

if you set a cooking time) and a timer.

3. PREHEATING AND RESIDUAL HEAT

Once the function starts, an audible signal and a ashing icon

on the display indicate that the preheating phase has been

activated. At the end of this phase, an audible signal and the

xed icon on the display will indicate that the oven has

reached the set temperature: at this point, place the food inside

and proceed with cooking.

Please note: Placing the food in the oven before preheating has

finished may have an adverse effect on the final cooking result.

After cooking and with the function deactivated, the icon

may continue to remain visible on the display even after the

cooling fan has switched o to indicate that there is residual

heat in the compartment.

Please note: The time after which the icon switches off varies

because it depends on a series of factors such as ambient

temperature and function used. In any case, the product should be

considered to be off when the pointer on the selection knob is at

“0”.

4. PROGRAMMING COOKING

You will need to select a function before you can start

programming cooking.

DURATION

Keep pressing

until the icon and “00:00” start ashing

on the display.

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Ovn
Model:	FA5 841 P IX HA
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	595 mm
Dybde:	551 mm
Højde:	595 mm
Vægt:	30000 g
Produktfarve:	Black, Stainless steel
Kontroltype:	Dreje
Indbygget skærm:	Ja
Skærmtype:	LCD
Strøm:	16 A
Pakkevægt:	35000 g
Pakkedybde:	555 mm
Pakkebredde:	600 mm
Pakkehøjde:	560 mm
Placering af apparat:	Indbygget
Installationsrum bredde:	600 mm
Installationsrum dybde:	555 mm
Installationsrum højde:	560 mm
Grill:	2200 W
Konvektion madlavning:	Ja
Antal glasdørpaneler:	3
Ovn - størrelse:	Medium
Ovntype:	Elektrisk ovn
Samlet indvendig ovn kapacitet:	71 L
Strøm for samtlige ovne:	3300 W
Antal ovne:	1
Ovn nettokapacitet:	71 L
Ovn termostatinterval:	250 - 420 °C
Konventionel madlavning:	Ja
Energiforbrug (konventionel):	0.89 kWh
Energiforbrug (tvungen konvektion):	0.69 kWh
Ovn effekt:	3300 W
