WASHING MACHINE

Instructions for use

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Care and maintenance, 4

Cutting off the water and electricity supplies

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Precautions and tips, 5

General safety

Disposal

Opening the porthole door manually

Description of the washing machine, 6-7

Control panel

Display

Running a wash cycle, 8

Wash cycles and options, 9

Table of programmes and wash cycles

Wash options

Detergents and laundry, 10

Detergent dispenser drawer

Preparing the laundry

Special wash cycles

Load balancing system

Troubleshooting, 11

Service, 12

FMG 1023

English,1

ΕΛΛΗΝΙΚΑ,13

Installation

! This instruction manual should be kept in a safe

place for future reference. If the washing machine

is sold, transferred or moved, make sure that the

instruction manual remains with the machine so

that the new owner is able to familiarise himself/

herself with its operation and features.

! Read these instructions carefully: they

contain vital information relating to the safe

installation and operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washing machine from its

packaging.

2. Make sure that the washing machine has

not been damaged during the transportation

process. If it has been damaged, contact the

retailer and do not proceed any further with

the installation process.

3. Remove the 4

protective screws

(used during

transportation)

and the rubber

washer with the

corresponding

spacer, located on

the rear part of the

appliance ( ).see figure

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: you will

need them again if the washing machine

needs to be moved to another location.

! Packaging materials should not be used as

toys for children.

Levelling

1. Install the washing machine on a flat sturdy

floor, without resting it up against walls,

furniture cabinets or anything else.

2. If the floor is

not perfectly level,

compensate for

any unevenness

by tightening or

loosening the

adjustable front

feet ( ); the see figure

angle of inclination,

measured in relation

to the worktop, must

not exceed 2°.

Levelling the machine correctly will provide

it with stability, help to avoid vibrations and

excessive noise and prevent it from shifting

while it is operating. If it is placed on carpet or

a rug, adjust the feet in such a way as to allow

a sufficient ventilation space underneath the

washing machine.

Connecting the electricity and

water supplies

Connecting the water inlet hose

1. Connect the inlet

hose by screwing it to

a cold water tap using

a 3/4 gas threaded

connection (see

figure).

Before performing

the connection, allow

the water to run freely

until it is perfectly

clear.

2. Connect the

inlet hose to the

washing machine by

screwing it onto the

corresponding water

inlet of the appliance,

which is situated on

the top right-hand

side of the rear part

of the appliance (see

figure).

3. Make sure that the hose is not folded over

or bent.

! The water pressure at the tap must fall within

the range of values indicated in the Technical

data table (see next page).

! If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Vaskemaskine
Model:	FMG 1023B EU
Bredde:	595 mm
Dybde:	605 mm
Højde:	850 mm
Produktfarve:	Hvid
Indbygget skærm:	Ja
Skærmtype:	LCD
Energieffektivitetsklasse (gammel):	A+++
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Tromlekapacitet:	10 kg
Maksimal centrifugeringshastighed:	1200 rpm
Støjniveau (centrifugering):	- dB
Støjniveau (vask):	- dB
Vaskeprogrammer:	Hygiene/anti-allergy, Black
Børnesikring:	Ja
Energiforbrug ved vask:	- kWh
Spin-tørre klasse:	B
Vandforbrug pr. cyklus:	- L
