Hotpoint Ovn GA2 124 IX

Læs gratis den danske manual til Hotpoint GA2 124 IX (8 sider) i kategorien Ovn. Denne vejledning er vurderet som hjælpsom af 62 personer og har en gennemsnitlig bedømmelse på 4.0 stjerner ud af 31.5 anmeldelser. Har du et spørgsmål om Hotpoint GA2 124 IX, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/8

PRODUCT DESCRIPTION

CONTROL PANEL

1. Control panel

2. Lamp

3. Shelf guides

(the level is indicated on the wall

of the cooking compartment)

4. Door

5. Upper heating element/grill

6. Recess for roasting spit

7. Identification plate

(do not remove)

8. Burner

(not visible)

1. TIMER KNOB

Use to set the timer.

Does not start or stop cooking.

2. ADJUSTMENT KNOB

For switching the oven on,

adjusting the temperature and

selecting the “Grill” function.

Turn to the position to switch

the oven off.

3. GRILL LED

This lights up when the grill is in

use.

4. LIGHT BUTTON

Press to switch the light on (1) or

off (0).

DAILY REFERENCE

GUIDE

Before using the appliance carefully read the Health and Safety guide.

THANK YOU FOR PURCHASING AN

HOTPOINT - ARISTON PRODUCT

To receive more comprehensive help and

support, please register your product at

www.hotpoint.eu/register

WWW

You can download the Safety Instructions

and the Use and Care Guide by visiting our

website docs.hotpoint.eu and following

the instructions on the back of this booklet.

1 2 3 4

ACCESSORIES

Download the Use and Care Guide from

docs.hotpoint.eu for more information

WWW

WIRE SHELF DRIPPING PAN BAKING TRAY ROASTING SPIT

The number of accessories may vary depending on which model is purchased.

Other accessories can be purchased separately from the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER ACCESSORIES

• Insert the wire shelf onto the level you require by

holding it tilted slightly upwards and resting the

raised rear side (pointing upwards) down first. Then

slide it horizontally along the shelf guide as far as

possible.

• The other accessories, such as the baking tray, are

inserted horizontally by sliding them along the shelf

guides.

USING THE ROASTING SPIT

Push the skewer through the centre of the meat

(bound with string if poultry) and slide the meat onto

the skewer until it is positioned firmly on the fork and

cannot move. Push the second fork onto the skewer

and slide it on until it holds the meat firmly in place.

Tighten the fixing screw to secure it in position.

Insert the end into the recess provided in the oven's

cooking compartment and rest the rounded part on

the support (placed on the third level).

To use the roasting spit, start the oven by selecting

the “Grill” function.

To collect the cooking juices, position a dripping pan

below and add 200 ml of drinking water.

To avoid burning yourself when the skewer is hot,

only handle it by the plastic handle (which must

always be removed before cooking).

FITTING THE COVER ON THE BURNER

To fit the cover on the

burner correctly, place it on

the bottom of the cooking

compartment.

Position it so that the words

“AVANTI - FRONT” are facing

the outside and so that the

cover cannot move sideways

once lowered into position.

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Ovn
Model:	GA2 124 IX
Vekselstrømsindgangsspænding:	230 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	595 mm
Dybde:	551 mm
Højde:	595 mm
Vægt:	25000 g
Produktfarve:	Black, Stainless steel
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ingen
Strøm:	13 A
Ledningslængde:	1 m
Placering af apparat:	Indbygget
Indvendig belysning:	Ja
Installationsrum bredde:	- mm
Installationsrum dybde:	- mm
Installationsrum højde:	- mm
Tilsluttet belastning:	2300 W
Energieffektivitetsskala:	A+++ til D
Selvrensende:	Ja
Energieffektivitetsklasse:	A+
Ovn - størrelse:	Medium
Ovntype:	Naturgas
Samlet indvendig ovn kapacitet:	75 L
Antal ovne:	1
Ovn nettokapacitet:	- L
Konventionel madlavning:	Ja
Energiforbrug (konventionel):	1.26 kWh
Energiforbrug (tvungen konvektion):	0 kWh
Energiforbrug (traditionel):	4.54 MJ
Brødfremstilling kapacitet:	Ingen
