Side 1/4

Quick guide

* Available only on certain models

THANK YOU FOR BUYING A HOTPOINT PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

FIRST TIME USE

After installation, wait at least two hours before connecting the

appliance to the power supply. Once connected, it will start working

automatically. The ideal temperature settings are preset from the

factory.

After turning the appliance on, wait 4-6 hours for it to reach the correct

food storage temperature.

CONTROL PANEL

1. On/o

2. Fridge temperature indicator light

3. Fridge temperature setting

4. Super freeze indicator light

5. Super freeze button (rapid freezing)

ON/OFF

The whole product (both fridge and freezer compartments) can be

turned on by pressing this button for 2 seconds. The last set value is

indicated on the interface. Press this button to turn o the device.

FRIDGE TEMPERATURE INDICATOR LIGHT

It shows the temperature of the fridge compartment.

FRIDGE TEMPERATURE SETTING

It allows you to change the fridge temperature value, in a cyclical way;

it also conrms the selected temperature on the interface.

Recommended setting for the refrigerator compartment is +4°C.

SUPER FREEZE INDICATOR LIGHT

Illuminates when the Super freeze button is pressed.

SUPER FREEZE FUNCTION

This function is recommended for freezing fresh food. Fresh food

should be frozen as quickly as possible, for the best possible

preservation and for keeping its nutritional value. Press the Super

freeze button when you need to freeze fresh food; the Super freeze

indicator will come on.

We recommend you press the Super freeze button 24 hours before

putting the food in, in order to prepare the freezer compartment for

the best possible freezing conditions. We recommend you use the

bottom drawer to maximize the freezing capacity.

The Super freeze function is automatically deactivated after 48 hours,

or you can disable it manually by pressing the Super freeze button.

LED LIGHT

This product contains a light source of energy eciency class F.

If the LED light system does not work, please contact the Service to

replace it.

Important: The refrigerator compartment light switches on when

the refrigerator door is opened. If the door is kept open for more than

8 minutes the light will be automatically switched o.

HOW TO STORE FRESH FOOD AND BEVERAGES

a) b)

* The number and type of door balconies depends on the model

Legend

TEMPERATE ZONE

Suggested for storage of tropical fruit, cans, drinks,

eggs, sauces, pickles, butter, jam

COOL ZONE

Suggested for the storage of cheese, milk, daily

food, delicatessen, yogurt

COOLEST AREA

a) Suggested for storage of cold cuts, desserts, meat

and sh

b) Suggested for storage of meat and sh.

The drawer available only on certain model

FRUIT & VEGETABLE DRAWER

FREEZER DRAWERS

(One drawer in models lower than 1,7m)

FREEZING ZONE DRAWER

(Max cool zone)

Suggested to freeze fresh / cooked food

REFRIGERATION COMPARTMENT

Refrigerator compartment defrosting is completely automatic.

Droplets of water on the rear wall inside the refrigerator compartment

indicate that the automatic defrost phase is in progress.

The defrost water is automatically run into a drain hole and collected in

a container, where it evaporates.

Fresh Zone 0°C drawer *

The Fresh Zone 0°C it is a drawer (b) ideal to store meat and sh. By

decreasing/increasing the fridge temperature, you impact the Fresh

Zone 0°C compartment temperature as well. Keep in mind that this

compartment is a mechanical feature operating all the time and it

cannot be switched o.

Humidity Control*

Turn the knob to the left if you are storing vegetables (for which a

more humid environment is recommended), rotate the knob to the

right if you are storing fruit (for which a less humid environment

is recommended), turn the knob to the middle if you are storing a

mixture of fruit and vegetables.

Foldable shelf*

This shelf can be used in three dierent ways:

1. Full-depth, to use the entire surface.

2. Half-depth, to use the rear part and at the same time create space

for taller items (like bottles and jugs) on the shelf below. To adjust

the shelf to half-depth, slightly raise the front part then pull it in.

3. Flipped up if you need to make space for tall or bulky items on

the shelf below. To ip the shelf up, rst adjust it to the halfway

position from half-depth. Flip the shelf down to go back to using it

in half-depth and full-depth.

* Available only on certain models

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Fryser
Model:	H3X 81I W
Bredde:	596 mm
Dybde:	678 mm
Højde:	1912 mm
Vægt:	70000 g
Produktfarve:	Hvid
Indbygget skærm:	Ingen
Strøm:	1 A
Ledningslængde:	1.6 m
Pakkevægt:	73000 g
Pakkedybde:	760 mm
Pakkebredde:	640 mm
Pakkehøjde:	1960 mm
Wi-Fi:	Ja
Årligt energiforbrug:	315 kWh
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Inverter-teknologi:	Ja
Tilsluttet belastning:	160 W
Støjniveau:	40 dB
Børnesikring:	Ingen
Energieffektivitetsskala:	A til G
Støjemissionsklasse:	C
Energieffektivitetsklasse:	F
Vendbare døre:	Ja
Fryser, netto rumindhold:	104 L
Frysekapacitet:	10 kg/24t
Opbevaringstid under strømafbrydelse:	11 t
Klimaklasse:	SN-T
Brugerdefineret panel klar:	Ingen
Køleskab antal hylder/kurve:	4
Antal grøntsagsskuffer:	1
Køleskab, netto rumindhold:	231 L
Total netto kapacitet:	231 L
No Frost (køleskab):	Ja
Stjernebedømmelse:	4*
Fryser position:	Bottom-placeret
Automatisk afrimning (fryser):	Ja
Hylder, materiale:	Glas
Ismaskine:	Ingen
Multi-Airflow-system (køleskab):	Ja
Foldehylde:	Ingen
Multi-Airflow-system (fryser):	Ja
No Frost (fryser):	Ja
Hurtig frys funktion:	Ja
Fryser antal hylder/kurve:	3
Åben dør alarm:	Ja
Oprindelsesland:	Polen
Super Cool funktion:	Ingen
Frisk zone, aflukke:	Ja
Strømstiktype:	Type G
Feriefunktion:	Ingen
Temperaturalarm:	Ja
Antal kompressorer:	1
Justerbare hylder:	Ja
Antal æggebakker:	1
Vandbeholder:	Ingen
Dørflaskeholder:	Ja
Dør flaskehylde:	Ja
Midterste rum:	Ingen
Antibakteriel forsegling:	Ja
