ENQuick Guide
1
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine’s functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
lled when the SALT REFILL indicator light in the control panel is lit.
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Only the rst time you do this: ll the salt reservoir
with water.
3. Position the funnel (see gure) and ll the salt reservoir
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Whenever you need to add salt, it is mandatory to complete the pro-
cedure before the beginning of the washing cycle to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently prevent-
ing scale buildup on heater, contributing also to better cleaning eciency.
This system regenerates itself with salt, therefore it is required to rell
salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in nal rinse and nishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
A
C
D
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid
dispenser A should be lled when the RINSE AID
REFILL indicator light in the control panel is lit.
NEVER pour the rinse aid directly into the appli-
ance tub.
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce the
detergent into the dry dispenser D only. Place the amount of detergent for
pre-washing directly inside the tub. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the program so
that the best washing and drying results are always achieved.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
CONTROL PANEL
FIRST TIME USE
More information in the Daily Reference Guide on website.
PROGRAMS TABLE
1. On-O / Reset button with indicator light
2. Program selection button with indicator
light
3. Zone Wash button with indicator light /
Keylock
4. Eco program indicator light
5. Keylock indicator light
6. Display
7. Program number and remaining time
indicator
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
THANK YOU FOR BUYING A HOTPOINT ARISTON PRODUCT.
In order to receive a more complete assistance, please register
your appliance on: www.hotpoint.eu/register
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
8. Tablet (Tab)
indicator light
9. Closed water tap
indicator light
10. Rinse Aid rell
indicator light
11. Salt rell indica-
tor light
12. 3D Zone Wash button with indicator light /
Tablet (Tab)
Program
Programs description
Drying
phase
ActiveDry
Available
options
*)
Duration
of wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1.
Eco 50°- Program is suitable to clean normally soiled tableware, that
for this use, it is the most ecient programme in terms of its combined
energy and water consumption, and that it is used to assess compli-
ance with the EU Ecodesign legislation.
3:35 8.7 0.59
2.
Auto Intensive 65° - Automatic program for heavily soiled dishes and
pans (not to be used for delicate items).
2:00 - 3:10 14.0 - 17.0 1.50 - 1.85
3.
Auto Mixed 55° - Automatic program for normally soiled pans and
dishes.
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
4.
Auto Fast Wash 50° - Automatic program for limited quantity of nor-
mally soiled crockery. Ensures optimal cleaning performance in short-
er time.
0:55 - 1:20 11.0 - 14.5 1.15 - 1.25
5.
Delicates 45° - Program for delicate items, which are more sensitive to
high temperatures, for example glasses and cups.
1:40 12.0 1.20
6.
Rapid 30’ 45° - Program to be used for half load of lightly-soiled dishes
with no dried food residues. Without drying.
-
0:30 9.0 0.50
7.
Good Night 50° - Suitable for night-time operation of the appliance.
Ensures optimal cleaning and drying performance with the lowest
noise emission.
3:30 16.0 1.15
8.
Sanitizing 65° - Normally or heavily soiled crockery, with additional
antibacterial wash. Can be used to perform maintenance of the dish-
washer.
-
1.50 12.0 1.30
3
1
2
8
13
14
5
4
6
7 11 12
9
10
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
Quick Guide
EN
2
CARE AND MAINTENANCE
More information in the Daily Reference Guide on website.
OPTIONS AND FUNCTIONS
Please scan the QR code on your product in order to have more detailed information.
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories:
For information on comparative EN testing conditions, please send an email to the following address:
dw_test_support@europeanappliances.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
LOADING THE RACKS
CAPACITY: 10 standard place-settings
UPPER RACK
(loading example for the upper rack)
Load delicate and light dishes:
glasses, cups, saucers, low salad
bowls.
The upper rack has tipup supports
which can beused in a vertical po-
sition when arranging tea/ dessert
saucers or in a lower position to
load bowls and food containers.
FOLDABLE
FLAPS WITH
ADJUSTABLE
POSITION
LOWER RACK
(loading example for the lower rack)
For pots, lids, plates, salad bowls, cut-
lery etc. Large plates and lids should
ideally be placed at the sides to avoid
interferences with the spray arm.
The lower rack has tip-up supports
which can be used in a vertical
position when arranging plates or in
a horizontal position (lower) to load
pans and salad bowls easily.
CUTLERY BASKET
The basket is equipped with
top grilles for improved cut-
lery arrangement. The cutlery
basket should be positioned
only at the front of the lower
rack.
Knives and other utensils with
sharp edges must be placed
in the cutlery basket with
the points facing downwards
or they must be positioned
horizontally in the tip-up com-
partments on the upper rack.
3D ZONE WASH
3D Zone Wash uses
additional water jets
located both: in the lower
and upper part of the
dishwasher (marked with
orange color) to wash
more intensively heavily
soiled items by increas-
ing water coverage on
dishes.
TABLET (Tab) - If you use powder or liquid detergent, this option
should be o.
ActiveDry
- is a convection drying system which automatically opens the
door during/after the drying phase to ensure exceptional drying perfor-
mance every day. The door opens at a temperature that is safe to your kitchen
furniture, thus door will not be opened when the option of SHORT TIME is on.
DELAY -The start of the program may be delayed for a period of time
between 0:30 and 24 hours.
The DELAY function cannot be set once a program has been started.
KEYLOCK - A long press (for 3 seconds) of ZONE WASH button, will acti-
vate the KEYLOCK function. To deactivate the KEYLOCK, long press again.
3D ZONE WASH - Thanks to the additional power jets this option
provides up to 80% more water power, a more intensive and powerful
wash in the lower rack, in the specic bottom area. This option is
recommended for washing pots and casseroles.
ZONE WASH - If there are not many dishes to be washed, a half loading
may be used in order to save water, electricity and detergent.
Bydefault the appliance washes dishes in all racks.
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
A
A
B
C
1 2 3
4
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds
etc.) please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in
aclockwise direction.
The lower spray arm may be
removed by pulling it upwards.
9.
Soak - Use to refresh crockery planned to be washed later.
No detergent to be used with this program.
- -
0:10 4.5 0.01
10.
Self-Clean 65° - Program to be used to perform maintenance of the
dishwasher, to be carried out only when the dishwasher is EMPTY us-
ing specic detergents designed for dishwasher maintenance.
- -
0:50 8.0 0.85
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected
program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
