Side 1/16
GE Consumer & Industrial
Appliances
Installation Instructions
Built-In Dishwasher
If you have questions, call 800.GE.CARES (800.432.2737) or visit our website at: www.ge.com
IMPORTANT – The dishwasher MUST be
installed to allow for future removal from the
enclosure if service is required.
If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
Optional Accessories – See the Owner’s Manual for
available custom panel kits.
FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS
shown throughout these instructions. While
performing installations described in this booklet,
gloves and safety glasses should be worn.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
IMPORTANT – Observe all governing codes
and ordinances.
• – Be sure to leave these Note to Installer
instructions for the consumer and local inspector’s
use.
• – Keep these instructions with Note to Consumer
your Owner’s Manual for future reference.
• – Installation of this dishwasher requires Skill Level
basic mechanical, electrical and plumbing skills.
Proper installation is the responsibility of
the installer. Product failure due to improper
installation is not covered under the GE
Appliance Warranty. See warranty information.
• . New installations Completion Time – 1 to 3 Hours
require more time than replacement installations.
STOP
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
TOOLS YOU WILL NEED:
Safety glasses
1/4" and 5/16" nutdrivers
Flashlight
Gloves
Adjustable wrench (6”)
Phillips head screwdriver
Measuring tape
Level
Carpenters square
Bucket to catch water when flushing
water line
Tubing cutter
15/16" socket wrench
FOR NEW INSTALLATIONS:
Hole saw set
Drill and appropriate bits
PARTS SUPPLIED IN INSTALLATION
PACKAGE:
Two 8-18 x 5/8" Phillips head wood screws
Junction box cover and #10 hex head
screw
Drain hose (78" long) and hose clamp
Cord protector (Power Cord Models Only)
Conversion leads (Power Cord Models Only)
Literature, product samples, and/or
coupons
MATERIALS YOU WILL NEED:
WX09X70910 power cord if applicable to
your installation
UL Listed wire nuts (3)
Thread seal tape
90° elbow, ferrule and compression nut
– (3/8" NPT external thread on one end
and opposite end sized to fit water supply)
GPF65 Side-mount bracket kit for use with
granite countertops
FOR NEW INSTALLATIONS:
Electrical cable
Water line–3/8" minimum copper tubing
Strain relief for electrical connection
Hand shut-off valve (recommended)
Air gap for drain hose, if required
Waste tee for house plumbing, if
applicable
GPF10S drain hose (10' long), if needed
Screw type hose clamps
Hose Clamp
78" Drain Hose
90° Elbow, Ferrule and
Compression Nut
Thread
Seal Tape
3 Wire Nuts Hot Water Line–3/8"
Minimum Copper
Tubing
Electrical Cable
or WR09X70910
Power Cord
Waste Tee
Optional 10'
Drain Hose
GPF10S
Air
Gap Screw Type
Hose Clamps
Strain Relief
Phillips Head
Screwdriver
Level Carpenters
Square
Measuring Tape
Safety Glasses Flashlight
Gloves
Hole Saw Set
Drill and
Bits
Shut-Off
Valve
1/4" and 5/16" Nutdrivers
Adjustable
Wrench
Tubing
Cutter
GPF65 Side-Mount
Bracket Kit
#8
Phillips Head
Wood Screws
5/8" long
Screw Kit
#10
Hex Head
Junction Box Screw
1/2" long Junction Box Cover
2
Cord Protector
(Power Cord Models Only)
Conversion Leads
(Power Cord Models Only)
15/16
15/16"
Socket Wrench
Bucket
