Instruction booklet
DISHWASHER
Contents
Installation, 2-5
Positioning and levelling
Technical data
Electrical connection
Connecting the water supply
Description of the appliance, 6
Overall view
Control panel
Loading the racks, 7
Lower rack
Cutlery basket
Upper rack
Start-up and use, 8
Starting the dishwasher
Loading the detergent
Washing options
Wash cycles, 9
Wash cycle table
Rinse aid and refined salt, 10
Loading the rinse aid
Loading the refined salt
Care and maintenance, 11
Shutting off the water and electricity supplies
Cleaning the dishwasher
Preventing unpleasant odours
Cleaning the sprayer arms
Cleaning the water inlet filter
Cleaning the filters
Leaving the machine unused for extended periods
Precautions and advice, 12-13
General safety
Disposal
Saving energy and respecting the environment
Troubleshooting, 14
After Sales Service, 15
After Sales Service
Essential Contact Information
Parts and Accessories
Appliance Registration
Hotpoint Guarantee, 16
LFS 114
EN
English, 1
2
EN
Positioning and levelling
1. Remove the appliance from all packaging and
check that it has not been damaged during
transportation.
If it has been damaged, contact the retailer and do not
proceed any further with the installation process.
2. Check the dishwasher by placing it so that its sides
or back panel are in contact with the adjacent
cabinets or even with the wall. This appliance can also
be recessed under a single worktop* (see the
Assembly instruction sheet).
3. Position the dishwasher on a level and sturdy floor. If
the floor is uneven, the front feet of the appliance may
be adjusted until it reaches a horizontal position (the
angle of inclination must not exceed 2 degrees). If the
appliance is levelled correctly, it will be more stable
and much less likely to move or cause vibrations and
noise while it is operating.
4*. Adjust the height of the rear foot from the front of
the appliance* on the central lower part of the
dishwasher, turning a hexagonal spanner (red color)
with an opening of 8 mm in a clockwise direction to
increase the height or in an anticlockwise direction to
decrease the height.
Anti-condensation strip*
After installing the dishwasher, open the door and
stick the adhesive transparent strip under the
wooden shelf in order to protect it from any
condensation that may form.
Keep this instruction manual in a safe place for
future reference. If the appliance is sold, given away
or moved, please ensure the manual is kept with the
machine, so that the new owner may benefit from the
advice contained within it.
Please read this instruction manual carefully: it
contains important information regarding the safe
installation, use and maintenance of the appliance.
If the appliance must be moved at any time,
keep it in an upright position; if absolutely
necessary, it may be tilted onto its back.
Advice regarding the first wash cycle
After the appliance has been installed, immediately
before running the first wash cycle, completely fill
the salt dispenser with water and add only then
approximately 1 kg of salt (see chapter entitled
Rinse aid and refined salt). The water may overflow:
this is normal and is not a cause for concern. Select
the water hardness value (see chapter entitled Rinse
aid and refined salt). - After the salt has been
poured into the machine, the LOW SALT indicator
light* switches off.
If the salt container is not filled, the water
softener and the heating element may be damaged
as a result.
* Only available in selected models.
Installation
Technical data
Dimensions
width 59.5 cm
height 82 cm
depth 57 cm
Capacity 12 standard place-settings
Water supply
pressure
0,05 ÷ 1MPa (0.5 ÷ 10 bar)
4.3 psi – 145 psi
Power supply
voltage See appliance data plate
Total absorbed
power See appliance data plate
Fuse See appliance data plate
This dishwasher conforms to
the following European
Community Directives:
-73/23/EEC dated 19/02/73
(Low Voltage) and subsequent
modifications
-89/336/EEC dated 03/05/89
(Electromagnetic Compatibility)
and subsequent modifications
-97/17/EC (Labelling)
-2002/96/ CE (Waste
Electrical and Electronic
Equipment WEEE)
3
EN
The dishwasher meets the requirements set out
by the regulations in force concerning safety and
electrical equipment.
Any technical checks should be conducted
exclusively by a trained and authorised technician:
Repairs carried out by unaithorised persons will
invalidate the guarantee, as well as posing a
potential hazard to the user.
The manufacturer declines all responsibility for
damage to persons or property resulting from failure
to observe the above precautions, from tampering
with even a single component or from the use of
non-original spare parts.
Electrical Connection
Before inserting the plug into the electrical socket,
make sure that:
the socket is earthed and complies with current
regulations;
the socket can withstand the maximum load of
the appliance, which is indicated on the data
plate located on the inside of the door (see
Description of the appliance);
the power supply voltage falls within the values
indicated on the data plate on the inside of the
door;
the socket is compatible with the plug of the
appliance. If this is not the case, ask an
authorised technician to replace the plug (see
Assistance); do not use extension cables or
multiple sockets.
Once the appliance has been installed, the
power supply cable and the electrical socket should
be easily accessible.
The cable should not be bent or compressed.
If the power supply cable is damaged, it must
be replaced by the manufacturer or its Technical
Assistance Service in order to prevent all potential
hazards. (See Assistance)
This appliance must be earthed.
Fuses:your appliance comes fitted with a plug and a
13A fuse. If you need to replace the fuse, only those
rated at 13A and ASTA approved to BS1362 should
be used. If you lose the fuse cover, a replacement
may be obtained from your local authorised Service
Centre or Electrical company. Correct replacement is
identified by colour coding or the marking on base
of plug.
DO NOT use the plug unless the fuse cover is
fitted.
Changing the Plug
Cut off and dispose of the supplied plug if it
does not fit your socket.
To avoid a shock hazard DO NOT insert the
discarded plug into a socket anywhere else.
Wires in the mains lead are coloured accordance
with the following code:
Green/Yellow - Earth
Blue - Neutral
Brown - Live
If you change the plug, the colour of the wires in the
mains lead may not correspond with the terminal
markings in the plug, which if not coloured, could
be:
EARTH E or
NEUTRAL N
LIVE L
Changing the Mains Lead
A lead can be ordered from Hotpoint Service
UK: 08709 066 066 or
Republic of Ireland: 1850 302 220
- If you have damaged the existing lead or require a
longer one a charge will be made. It is strongly
advised that this work is carried out by a qualified
electrician.
- If the domestic wiring includes a residual current-
operated circuit breaker, ensure that it conforms to
the latest regulations.
The dishwasher must not be connected to the
electricity supply while installation is being carried
out.
- This appliance should only be connected to a 230/
240V AC source, via a properly installed earthed
socket.
- Use the dishwasher solely in a domestic
environment.
- DO NOT stand or place heavy objects on the door
when it is open, this could damage the door or
cause the appliance to tip forward.
The Company shall not be held responsible for
any incidents that occur if these regulations are not
observed.
4
EN Connecting the water supplies
Connection to the water and electricity supplies
should only be performed by a qualified technician.
The dishwasher should not stand on top of the
water hoses or the electricity supply cable.
Connecting the water inlet hose
The water inlet (A) and outlet (B) hoses and the
electricity supply cable may be positioned towards
the right or the left in order to achieve the best
possible installation (see figure).
To a suitable cold water connection point: before
attaching the hose, run the water until it is
perfectly clear so that any impurities that may be
present in the water do not clog the appliance;
after performing this operation, screw the inlet
hose tightly onto a tap with a ¾ gas threaded
connection.
To a suitable hot water connection point: your
dishwasher may be provided with hot water from
the mains supply (if you have a central heating
system with radiators) provided that it does not
exceed a temperature of 60°C.
Screw the hose to the tap as described for
connection to a cold water supply.
If the inlet hose is not long enough, contact a
specialist store or an authorised technician (see
Assistance).
The water pressure must be within the values
indicated in the Technical data table (see
Installation).
The hose should not be bent or compressed.
The appliance must be connected to the water
supply network using new hoses.
Do not use old hoses.
Ensure that the new hose supplied is connected
and the old hose is disposed of safely.
Ensure the fill hose is only fitted to the cold
water supply. DO NOT overtighten the hose
connector, hand tight is sufficient.
Ensure the fill hose is not kinked.
Tap connections*: A range of adaptors are
available to suit your tap.
DO NOT connect the dishwasher to a single
outlet instantaneous water heater or an electric
heater.
Standpipe
Ensure that the hose is not pushed too far down the
standpipe.
If the end of your drain hose is fitted
with retaining flaps*, ensure they are
inserted fully into the standpipe. This
will prevent the pipe from jumping out
during installation and use.
DO NOT position the standpipe near an
electrical outlet.
ENSURE that the drain hose is not kinked and it
is routed as shown in the diagram.
The standpipe should have a bore of at least 38mm
(11/2). It should be installed as shown, have a trap
fitted and must discharge into the same drain
system as your household sink.
It MUST NOT be connected to a surface water
drain.
* Only available in selected models.
5
EN
Anti-flooding protection*
To ensure floods do not occur, the dishwasher:
- is provided with a special system which blocks the
water supply in the event of anomalies or leaks from
inside the appliance.
Some models are also equipped with the
supplementary safety device New Acqua Stop*,
which guarantees anti-flooding protection even in the
event of a supply hose rupture.
* Only available in selected models.
Sink Waste System
For under sink drainage:
before connecting the drain hose, remove any
internal restrictions; this will prevent a build up of
debris which could cause a blockage
remove any restrictions from the waste spigot and
ensure that the sealing bung is removed
the hose should be routed, such that it is raised
to a minimum height of 800mm (31/2).
Ensure the sink outlet pipe has a minimum
diamtere of 32mm.
Untie the end of the GREY drainage hose from
the rear of the appliance.
Reposition the Hooked End Support as required
along the GREY drainage hose.
If fitting an under sink
waste disposal unit, cut
out the membrane, bung
or blanking plug.
Ensure the drain hose is securely attached, to
prevent it coming away while the machine is in
use and causing a flood.
WARNING: HAZARDOUS VOLTAGE!
Under no circumstance should the water inlet hose
be cut as it contains live electrical parts.
The Company shall not be held responsible for
any incidents that occur if these regulations are not
observed.
6
EN
Overall view
1. Upper rack
2. Upper sprayer arm
3. Tip-up compartments
4. Rack height adjuster
5. Lower rack
6. Lower sprayer arm
7. Cutlery basket
8. Washing filter
9. Salt dispenser
10. Detergent and rinse aid dispensers
11. Data plate
12. Control panel***
***Only in completely built-in models.
* Only available in selected models.
Description of the appliance
Control panel
ON/OFF/RESET
button
WASH CYCLE SELECT
knob
Low salt
indicator light*
ON/OFF
indicator light
Start/Pause
button and
indicator light
Washing
indicator light
End
indicator light
Drying
indicator light
8
EN
Start-up and use
Measuring out the detergent
A good wash result also depends on the correct
amount of detergent being used; exceeding the stated
amount does not result in a more effective wash and
increases environmental pollution.
Only use detergent which has been
specifically designed for dishwashers.
DO NOT USE washing up liquid.
Using excessive detergent may result in foam
residue remaining in the machine after the cycle
has ended.
The use of tablets is only recommended for
models which offer the MULTI-FUNCTIONAL
TABLETS option.
To achieve the best results from each washing
and drying cycle, powder detergent, rinse aid
liquid and salt should be used.
Compartment A: Washing detergent
Compartment B: Pre-wash detergent
1. Open cover C by pressing
button D.
2. Pour in the detergent after
consulting the Table of wash
cycles:
For powder detergent use
compartments A and B.
For detergent in tablet form:
when the cycle requires 1 tablet,
place it in compartment A and close the cover; when it
requires 2, place the second tablet at the bottom of the
appliance.
3. Remove detergent residues from the edges of the
compartment and close the cover until it clicks.
* Only available in selected models.
Starting the dishwasher
1. Turn the water tap on.
2. Press the ON/OFF button: all the indicator lights on
the control panel will light up for a few seconds.
3. Open the door and pour in a suitable amount of
detergent (see below).
4. Load the racks (see Loading the racks) and shut the
door.
5. Select the wash cycle by turning the WASH CYCLE
SELECT knob in a clockwise direction: align the notch
on the knob with the number or symbol representing the
desired wash cycle. The START/PAUSE indicator light
will flash.
6. Select the wash options* (see adjacent information).
7. Start the cycle by pressing the START button; the
indicator light will become green and remain lit in a fixed
manner. The indicator light corresponding to the
washing phase will switch on, signalling that the wash
cycle has begun.
8. At the end of the wash cycle the END indicator light
will switch on (fixed green light). Switch off the
appliance by pressing the ON/OFF button, shut off the
water valve and unplug the appliance from the electricity
socket.
9. Wait for a few minutes before removing the crockery,
in order to avoid burns. Unload the racks, beginning with
the lower level.
Modifying a wash cycle in progress
If a mistake was made during the wash cycle selection
process it is possible to change the cycle, provided that
it has only just begun: once the wash cycle has started,
switch off the machine by pressing and holding the ON/
OFF/Reset button. Switch it back on using the same
button and select the desired wash cycle and options.
Adding extra crockery
Press the Start/Pause button (the corresponding
indicator light will flash). Open the door, taking care to
avoid the escaping steam, and place the crockery inside
the appliance. Close the door and press the Start/Pause
button (fixed light): the cycle starts from the point at
which it was interrupted.
If the Start/Pause button is pressed so as to pause the
machine, the wash cycle or the Delayed Start* function
(if selected) is interrupted.
At this stage it is not possible to change the wash cycle.
Accidental interruptions
If the door is opened during the wash cycle, or if there is
a power cut, the cycle stops. It starts again from the point
at which it was interrupted once the door has been shut
or once the electricity supply is restored.
Produkt Specifikationer
| Mærke: | Hotpoint |
| Kategori: | Opvaskemaskine |
| Model: | LFS114B |
Har du brug for hjælp?
Hvis du har brug for hjælp til Hotpoint LFS114B stil et spørgsmål nedenfor, og andre brugere vil svare dig
Opvaskemaskine Hotpoint Manualer
2 August 2025
2 August 2025
1 August 2025
1 August 2025
1 August 2025
1 August 2025
1 August 2025
1 August 2025
1 August 2025
1 August 2025
Opvaskemaskine Manualer
- Respekta
- XD Enjoy
- Unique Appliances
- Danby
- Royal Catering
- Melissa
- High One
- Qilive
- Arthur Martin-Electrolux
- Salora
- Classique
- Sandstrøm
- Rosieres
- Eurotech
- ARC
Nyeste Opvaskemaskine Manualer
15 August 2025
15 August 2025
15 August 2025
14 August 2025
14 August 2025
14 August 2025
14 August 2025
14 August 2025
14 August 2025
14 August 2025
