SAFETY INSTRUCTIONS
IMPORTANT TO BE READ AND OBSERVED
EN
These instructions are valid if the country symbol
appears on the appliance. If the symbol doesn’t appear on
the appliance, it is necessary to refer to the technical
instructions which will provide the necessary instructions
concerning modification of the appliance to the conditions
CAUTION: The use of the gas cooking appliance results
in the production of heat, moisture and products of
combustion in the room in which it is installed. Ensure that
the kitchen is well ventilated especially when the appliance
is in use: keep natural ventilation holes open or install a
mechanical ventilation device (mechanical extractor
hood). Prolonged intensive use of the appliance may call
for additional ventilation, such as opening a window, or
more effective ventilation, for example increasing the level
of mechanical ventilation (if possible).
Failure to follow the information in this manual exactly
may cause a fire or explosion, resulting in property damage
or personal injury.
Before using the appliance, read these safety instructions.
Keep them nearby for future reference.
These instructions and the appliance itself provide
important safety warnings, to be observed at all times. The
manufacturer declines any liability for failure to observe
these safety instructions, for inappropriate use of the
appliance or incorrect setting of controls.
WARNING: If the hob surface is cracked, don’t use the
appliance – risk of electrical shock.
WARNING: Danger of fire: Do not store items on the
cooking surfaces.
CAUTION: The cooking process has to be supervised. A
short cooking process has to be supervised continuously.
WARNING: Unattended cooking on a hob with fat or oil
can be dangerous – risk of fire. NEVER try to extinguish a
fire with water, but switch off the appliance and then cover
flame e.g. with a lid or a fire blanket.
Do not use the hob as a work surface or support. Keep
clothes or other flammable materials away from the
appliance, until all the components have cooled down
completely – risk of fire.
Very young children (0-3 years) should be kept away
from the appliance. Young children (3-8 years) should be
kept away from the appliance unless continuously
supervised. Children from 8 years old and above and
persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge can use
this appliance only if they are supervised or have been
given instructions on safe use and understand the hazards
involved. Children must not play with the appliance.
Cleaning and user maintenance must not be carried out
by children without supervision.
CAUTION: In case of hotplate glass breakage: shut
immediately off all burners and any electrical heating
element and isolate the appliance from the power supply;
do not touch the appliance surface; do not use the
appliance.
The glass lid can break in if it is heated up. Turn off all the
burners and the electric plates before closing the lid. Do
not shout down lid when burner alight.
WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years of
age must be kept away unless continuously supervised.
The food must not be left in or on the product for more
than one hour before or after cooking.
PERMITTED USE
CAUTION: the appliance is not intended to be operated
by means of an external switching device, such as a timer,
or separate remote controlled system.
This appliance is intended to be used in household and
similar applications such as: staff kitchen areas in shops,
offices and other working environments; farm houses; by
clients in hotels, motels, bed & breakfast and other
residential environments.
No other use is permitted (e.g. heating rooms).
This appliance is not for professional use. Do not use
the appliance outdoors.
Use pots and pans with bottoms the same width as
that of the burners or slightly larger (see specific table).
Make sure pots on the grates do not protrude beyond the
edge of the hob.
Improper use of the grids can result in damage to the
hob: do not position the grids upside down or slide them
across the hob.
Do not let the burner flame extend beyond the edge of the pan.
If the hob surface is in glass material, do not use the cast iron griddles, ollar stones,
terracotta pots and pans.
Do not use: heat diffusers such as metal mesh, or any other types; two burners
simultaneously for one receptacle (e.g. Fish kettle).
Should particular local conditions of the delivered gas make the ignition of burner
difficult, it is advisable to repeat the operation with the knob turned to small flame
setting.
In case of installation of a hood above the cooktop, please refer to the hood
instructions for the correct distance.
The protective rubber feet on the grids represent a choking hazard for young
children. After removing the grids, please ensure that all the feet are correctly fitted.
INSTALLATION
The appliance must be handled and installed by two or
more persons - risk of injury. Use protective gloves to
unpack and install - risk of cuts.
The electrical and gas connections must comply with
local regulation.
Installation, including water supply (if any) and electrical
connections, and repairs must be carried out by a qualified
technician. Do not repair or replace any part of the
appliance unless specifically stated in the user manual.
Keep children away from the installation site. After
unpacking the appliance, make sure that it has not been
damaged during transport. In the event of problems,
contact the dealer or your nearest After-sales Service.
Once installed, packaging waste (plastic, styrofoam parts
etc.) must be stored out of reach of children - risk of
suffocation. The appliance must be disconnected from
the power supply before any installation operation - risk of
electrical shock. During installation, make sure the
appliance does not damage the power cable - risk of fire or
electrical shock. Only activate the appliance when the
installation has been completed.
WARNING: Modification of the appliance and its
method of installation are essential in order to use the
appliance safely and correctly in all the additional countries.
Use pressure regulators suitable for the gas pressure
indicated in the instruction.
The room must be equipped with an air extraction
system that expels any combustion fumes.
The room must also allow proper air circulation, as air is
needed for combustion to occur normally. The flow of air
must not be less than 2m
3
/h per kW of installed power.
The air circulation system may take air directly from the
outside by means of a pipe with an inner cross section of
at least 100 cm
2
; the opening must not be vulnerable to
any type of blockages.
The system can also provide the air needed for
combustion indirectly, i.e. from adjacent rooms fitted with
air circulation tubes as described above. However, these
rooms must not be communal rooms, bedrooms or
rooms that may present a fire hazard.
Liquid petroleum gas sinks to the floor as it is heavier
than air. Therefore, rooms containing LPG cylinders must
also be equipped with vents to allow gas to escape in the
event of a leak. As a result LPG cylinders, whether partially
or completely full, must not be installed or stored in rooms
or storage areas that are below ground level (cellars, etc.).
It is advisable to keep only the cylinder being used in the
room, positioned so that it is not subject to heat produced
by external sources (ovens, fireplaces, stoves, etc. ) which
could raise the temperature of the cylinder above 50°C.
Should you experience difficulty in turning the burners knobs, please contact After
Sales Service for replacement of the burner tap if found to be faulty.
The openings used for the ventilation and dispersion of heat must never be covered.
Carry out all cabinet cutting works before fitting the
appliance in the furniture and remove all wood chips and
sawdust.
If the appliance is not installed above an oven, a
separator panel (not included) must be installed in the
compartment under the appliance.
GAS CONNECTION
WARNING: Prior to installation, ensure that the local
distribution conditions (type of gas and gas pressure) and
the adjustment of the appliance are compatible.
Check that the pressure of the gas supply is consistent
with the values indicated in “Burner and nozzle
specifications” table.
WARNING: The configuration conditions for this
appliance are stated on the label (or data plate).
WARNING: This appliance is not connected to a
combustion products evacuation device. It must be
installed and connected in accordance with current
installation regulations. Particular attention must be paid
to the relevant requirements regarding ventilation.
If the appliances is connected to liquid gas, the
regulation screw must be fasted as tightly as possible.
IMPORTANT: When the gas cylinder or gas container is
installed, it must be properly settled (vertical orientation).
WARNING: This operation must be performed by a
qualified technician.
Use only flexible or rigid metal hose for gas connection.
Connection with a rigid pipe (copper or steel)
Connection to the gas system must be carried out in such
a way as not to place any strain of any kind on the appliance.
There is an adjustable L-shaped pipe fitting on the
appliance supply ramp and this is fitted with a seal in order
to prevent leaks. The seal must always be replaced after
rotating the pipe fitting (the seal is provided with the
appliance). The gas supply pipe fitting is a threaded 1/2
gas cylindrical male attachment.
Connecting a flexible jointless stainless steel pipe to a
threaded attachment. The gas supply pipe fitting is a
threaded 1/2 gas cylindrical male attachment. These pipes
must be installed so that they are never longer than 2000
mm when fully extended. Once connection has been
carried out, make sure that the flexible metal pipe does
not touch any moving parts and is not compressed. Only
use pipes and seals that comply with current National
regulations.
IMPORTANT: If a stainless steel hose is used, it must be
installed so as not touch any mobile part of the furniture
(e.g. drawer). It must pass through an area where there are
no obstructions and where it is possible to inspect it on all
its length.
The appliance should be connected to the main gas
supply or to gas cylinder in compliance with the current
national regulations. Before making the connection, make
sure that the appliance is compatible with the gas supply
you wish to use. If this is not the case, follow the instructions
indicated in the paragraph “Adapting to different types of
gas”.
After connection to the gas supply, check for leaks with
soapy water. Light up the burners and turn the knobs
from maximum position 1* to minimum position 2* to
check flame stability.
ADAPTING TO DIFFERENT TYPES OF GAS
(This operation needs to be carried out by a qualified
technician).
In order to adapt the appliance to a type of gas other
than the type for which it was manufactured (indicated on
the rating label), follow the dedicated steps provided after
installation drawings.
ELECTRICAL WARNINGS
IMPORTANT: Information about current and voltage
consumption is provided on the rating plate.
It must be possible to disconnect the appliance from
the power supply by unplugging it if plug is accessible, or
by a multi-pole switch installed upstream of the socket in
accordance with the wiring rules and the appliance must
be earthed in conformity with national electrical safety
standards.

Produkt Specifikationer

Mærke: Hotpoint
Kategori: Komfur
Model: PKD 60G D/IX

Har du brug for hjælp?

Hvis du har brug for hjælp til Hotpoint PKD 60G D/IX stil et spørgsmål nedenfor, og andre brugere vil svare dig


Komfur Hotpoint Manualer

Hotpoint

Hotpoint HTX8017DNF2 Manual

30 Juli 2025
Hotpoint

Hotpoint PKD 60G D/IX Manual

30 Juli 2025
Hotpoint

Hotpoint HTX6014DNF Manual

30 Juli 2025
Hotpoint

Hotpoint HTX8015DNF Manual

30 Juli 2025
Hotpoint

Hotpoint HTX6014DCF Manual

5 Juli 2025
Hotpoint

Hotpoint HEX9024DCFF2 Manual

5 Juli 2025
Hotpoint

Hotpoint HTE5VCB Manual

1 Juli 2025
Hotpoint

Hotpoint H6V5KMX/UK Manual

30 Juni 2025
Hotpoint

Hotpoint HDG5GCX Manual

29 Juni 2025
Hotpoint

Hotpoint HDD6GDC2W Manual

29 Juni 2025

Komfur Manualer

Nyeste Komfur Manualer

ZLine

ZLine CDRZ-WM-36 Manual

30 Juli 2025
SVAN

SVAN SKM4501X Manual

30 Juli 2025
Frigidaire

Frigidaire GCFE3059BF Manual

30 Juli 2025
SVAN

SVAN SKGW5902X Manual

30 Juli 2025
Fisher & Paykel

Fisher & Paykel CI604CTPB2 Manual

30 Juli 2025
SVAN

SVAN SKGW5901PB Manual

30 Juli 2025
Fisher & Paykel

Fisher & Paykel CI604ZCTB2 Manual

30 Juli 2025
Fisher & Paykel

Fisher & Paykel CI905CTPB2 Manual

30 Juli 2025
Fisher & Paykel

Fisher & Paykel CI905ZCTPB2 Manual

30 Juli 2025
Klarstein

Klarstein Full House 3.0 Manual

30 Juli 2025
