Side 1/8
EN -1-
Chart
START/RESUME BUTTON
Push this button to start the selected program: the
indicator lights up and goes off at the end of the program.
When the door is opened during a washing cycle,
the cycle is temporarily paused: the Start indicator
blinks. To resume the cycle close the door and
push Start button again.
PROGRAM SELECTION
BUTTON
Push “P” button (repeatedly)
until the indicator of the
required program lights up
(see “Table of programs”
below).
(see at right for options description)
CANCEL/OFF BUTTON
Push this button to switch off the control panel.
If pressed when a program is running it cancels the
program ongoing draining water for 1 minute
(0:01 is shown into the display).
If pressed when the dishwasher is switched off,
it drains any possible liquids from dishwasher
(1 minute process).
1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional options) and may
vary depending on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the appliance’s automatic
calibration system.
2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the EN/
Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.
Tableau des programmes
Deter-
gent
Consumption
Drying
Phase
Programs
Available
options
Loading instructions
Litres kWh
Minutes
1)
P1
Sensor 40-70°C
Delay
Half load
Recommended program for
routine washes, with dried-
on food (e.g. EN 50242).
X 7-14 1.00-1.60 70-155 Full
P2
Pre-Wash cold
Delay
Crockery to be washed
later.
— 4.0 0.03 14 NO
P3
Fragile 40°C
Delay
Light soiling, for example
glasses and cups.
X 10.0 0.85 100 Light
P4
Rapid 45°C
Delay
Lightly soiled crockery, with
no dried-on food.
X 11.0 0.80 30 NO
P5
Eco
2)
50°C
Delay
Half load
Normally soiled crockery.
Energy-saving program.
X 12.0 1.03 150 Full
P6
Fast Daily 60°C
Delay
Half load
Normally soiled crockery. X 10.0 1.30 80 Full
5019 300 00704
Options and display description
SALT INDICATOR
When lit (at the end of the cycle),
the salt reservoir needs to be
refilled.
HALF LOAD BUTTON
Half load cycle can be used for the upper or lower
rack. Select the required program then press the
“Half Load” button - the light comes on. Turns off at
the end of the program.
The “Half Load” option can be used with the
programs indicated in the table of programs.
DELAYED START BUTTON
Push the button (repeatedly) to delay the
start of the program. Adjustable from
1 to 24 hours. With each press of the
button, the delayed start indicator
increases by one hour and after
24 restarts from 0. Then press the
START button. The dishwasher will start
after the set time.
RINSE AID INDICATOR
When lit (at the end of the cycle),
the rinse aid dispenser needs to
be refilled.
BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ
THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!
THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING ANY
BUTTON EXCEPT CANCEL/OFF BUTTON.
FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES
AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.
TABLET SETTING
This setting allows to optimize
the cycle performances
according the type of
detergent used.
Push the Tablet button for
3 seconds (until the indicator
lights up) if you are using the
combined detergents in tablet
(rinse aid, salt and detergent in
1 dose).
If you are using powder
detergent or liquid detergent,
the Tablet indicator on the
control panel has to be off.
WASH TIME DISPLAY
Indicated the cycle duration and the remaining time (h:min). With “Delayed start” selected it indicates
the time remaining until program start (h.00) - below 1h (0:min).
If “Fx Ey” messages appears on the display, see page 6 - chapter “What to do if...”.
Quick reference guide
