Side 1/48
Safety Instructions . . . .2–7, 25
Operating Instructions
Aluminum Foil . . . . . . . . .12, 13
Clock and Timer . . . . . . . . . .10
Oven . . . . . . . . . . . . . . . . .10–15
Baking and Roasting . . . . . .12
Broiling . . . . . . . . . . . . . .13, 14
Broiling Guide . . . . . . . . . . .14
Oven Control . . . . . . . . . . . .11
Power Outage . . . . . . . . . . . .11
Preheating . . . . . . . . . . . . . .12
Surface Cooking . . . . . . . . .8, 9
Thermostat Adjustment . . . .15
Care and Cleaning
Air Vents . . . . . . . . . . . . . . . . .21
Broiler Pan and Grid . . . . . . .21
Burner Assemblies . . . . . .16–18
Burner Caps and Heads . . . .18
Burner Grates . . . . . . . . . . . . .17
Control Panel and Knobs . . .21
Cooktop Surface . . . . . . . . . .19
Drip Pans . . . . . . . . . . . . . . . . .16
Lift-Off Oven Door . . . . . . . .20
Lift-Up Cooktop . . . . . . . . . . .19
Oven Bottom . . . . . . . . . . . . .20
Oven Interior . . . . . . . . . .22, 23
Removable Broiler Drawer . .21
Racks . . . . . . . . . . . . . . . . . . . .22
Stainless Steel Surfaces . . . . .19
Installation
Instructions . . . . . . . . . . .24–39
Anti-Tip Device . . . . .28, 38, 39
Connect the Range
to Gas . . . . . . . . . . . . . . . . .29–32
Convert to LP Gas . . . . . . . . .39
Dimensions and
Clearances . . . . . . . . . . . . . . . .27
Electrical Connections . .33, 34
Level the Range . . . . . . . . . . .38
Light the Pilots . . . . . . . . .34–37
Troubleshooting Tips . .40–42
Accessories . . . . . . . . . . . . . . .45
Consumer Support
Consumer
Support . . . . . . . . . .Back Cover
Ownership Registration
for Customers in Canada
only . . . . . . . . . . . . . . . . . .43, 44
Warranty for Customers
in Canada . . . . . . . . . . . . . . . .47
Warranty for Customers
in the U.S.A. . . . . . . . . . . . . . .46
Ranges
183D5580P236 49-85154 01-09 JR
Standard-Clean
Models:
Owner’s Manual
& Installation
Instructions
GEAppliances.com
Write the model and serial
numbers here:
Model # ______________________
Serial # ______________________
You can find them on a label on
the front of the range behind the
kick panel or broiler drawer.
RGB508
RGB524
RGB528
RGB530
RGB533
RGB540
Non-Self-Cleaning Gas
In Canada, contact us at:
www.GEAppliances.ca
Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting TipsConsumer Support
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
—WHAT TO DO IF YOU
SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your
building.
Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
WARNING: If the information
in this manual is not followed exactly,
a fire or explosion may result causing
property damage, personal injury
or death.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or
to prevent property damage, personal injury, or loss of life.
®
To reduce the risk of tipping the range, the range must be
secured by a properly installed anti-tip bracket. See installation
instructions shipped with the bracket for complete details
before attempting to install.
To check if the bracket is installed and engaged properly,
carefully tip the range forward. The bracket should stop the
range within 4 inches. If it does not, the bracket must be
reinstalled. If the range is pulled from the wall for any reason,
always repeat this procedure to verify the range is properly
secured by the anti-tip bracket.
For free-standing or slide-in ranges, never completely remove
the leveling legs or the range will not be secured to the anti-tip
device properly.
If you did not receive an anti-tip bracket with your
purchase, call 1.800.626.8774 to receive one at no
cost (in Canada, call 1.800.561.3344). For installation
instructions of the bracket, visit GEAppliances.com
(in Canada, GEAppliances.ca).
ANTI-TIP DEVICE
