Side 1/4

Instruction booklet

TUMBLE DRYER

Important Information

FLUFF FILTER

You must clean the ﬂuff ﬁlter after drying cycle. EVERY

Step 1

Open the door of your dryer

Step 2

Pull out the ﬁlter (using the two

ﬁnger grips)

Step 3

Open the ﬁlter and clean any ﬂuff

deposits from the ﬁlter mesh

Step 4

Reﬁt the ﬁlter, with the curved

side towards you

Step 5

Make sure the ﬁlter is pushed

fully home - run the dryer NEVER

without the ﬁlter in position

Failure to clean the ﬁlter after EVERY drying cycle will affect

the drying performance of your machine.

It will take longer to dry and as a result will use more

electricity during drying.

At least every two or three months you MUST clean ﬂuff build up around the ﬁlter housing and the vent tube.

Check the vent tube and any permanent venting ﬁxture to make sure that there has been no accumulation of ﬂuff or lint.

Remove lint that collects around the ﬁlter and the outlet vents.

PRODUCT DATA... (EU Regulation 392/2012)

Rated capacity of Cotton laundry for the standard programme at full load Energy efﬁciency class 7 kg B

The weighted Annual Energy Consumption (AEc) kWh.472

Consumption per year, based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of

the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used

This household tumble dryer is a Non-Automatic Air-Vented Dryer

Energy consumption: full load Edry

kWh, partial load E4.02 dry1/2 kWh2.14

Power consumption: off-mode (Po) W, left-on mode (Pl) 0.0 N/A

Duration of the ‘left-on mode’ for power management systems - minutesN/A

The ‘standard cotton programme’ suitable for drying normal wet cotton laundry that is the most efﬁcient programme in terms of

energy consumption for cotton used at full and partial load is High Heat

Programme time (minutes) weighted (Tt) full & partial load , full load (T82 dry) , partial load (T109 dry1/2) 62

Airborne acoustical noise emissions dB(A) re 1 pW.69

This data is also available on the website http://www.hotpoint.eu/hotpoint

This symbol reminds you to read this booklet.

TVEM 70

TVFM 70

TVM 570

TVYM 650

WHERE TO PUT YOUR DRYER

If you are going to install the appliance

under a work counter be sure to leave

a 10mm space between the top and any

other objects on or above the machine

and a 15mm space between the sides

and any kitchen units or walls to ensure

proper air circulation.

The dryer must never be installed

behind a lockable door, a sliding door or

a door with a hinge on the opposite side

to that of the dryer door.

VENTILATION

When the dryer is in use there has to be adequate ventilation

to avoid the back ﬂow of gases into the room from appliances

burning other fuels, including open ﬁres.

The vent tube should not exceed 2.4 metres in length.

The tube should be kept clear of the air intake vent and kinks or

‘U’ bends must be avoided as these will obstruct the tube and trap

condensation.

VENTING

Wall mounting

Keep the tube as short and as straight

as possible to prevent condensation

forming in the vent pipe.

The duct in the wall should slope

slightly downwards.

Window mounting

The hole in the window should be as

low down as possible and the tube

should be kept as short as possible.

Depending on how often you use your tumble dryer, it is

essential that areas and are checked periodically to remove A B

lint or debris.

Open window venting

The end of the tube should be

directed downwards, to prevent

warm moist air from condensing in

the room or dryer.

ELECTRICAL CONNECTIONS

The socket must be grounded. The power supply cord should be

checked periodically and, if required, replaced by a cord specially

prepared for this dryer.

LEVELLING YOUR DRYER

The dryer must be installed level for

correct operation. When you have

installed your dryer in its ﬁnal location

check that it is ﬁrst level side to side

and then back to front.

If the dryer is not level use a wooden

block to support it while adjusting the

two front legs up or down until your

dryer is level.

BEFORE YOU START USING YOUR DRYER

Once you have installed your dryer and before you use it clean

the inside of the drum to remove any dust that could have

accumulated during transport.

The HEAT button selects drying temperature.

OUT: LOW IN: HIGH heat heat

15 mm

Dryer Description

Control panel

Installation

Do not discharge exhaust air into a ﬂue which is used for

exhaust fumes from other appliances that burn gas or other

fuels.

Do not discharge exhaust air into an extraction system or any

duct with an extractor fan. This will affect the way the thermal

controls operate and can result in a ﬁre hazard.

Air intake vent

Do not block or obstruct

Caution: Hot! Vent Tube ﬁtted here

100

110

120

130

TIMER

Knob Indicator

HEAT

Button

START

Button
