Side 1/16



English, 1

Contents

Installation, 2-3-4-5

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the Washer-dryer and

starting a wash cycle, 6-7

Control panel

Indicator lights

Starting a wash cycle

Wash cycles, 8

Table of wash cycles

Personalisation, 9

Setting the temperature

Setting the drying cycle

Functions

Detergents and laundry, 10

Detergent dispenser drawer

Preparing the laundry

Garments requiring special care

Load balancing system

Precautions and tips, 11

General safety

Disposal

Opening the porthole door manually

Care and maintenance, 12

Cutting off the water or electricity supply

Cleaning the Washer-dryer

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 13

Assistance, 14

WDL 520 P/G/A/K

Instructions for use

WASHER-DRYER

Installation

Levelling your appliance correctly will provide it with

stability and avoid any vibrations, noise and shifting

during operation. If it is placed on a fitted or loose

carpet, adjust the feet in such a way as to allow

enough room for ventilation beneath the Washer-

dryer.

Electric and water connections

Connecting the water inlet hose

NOTE: the seal is

included with the fill

hose on UK produced

models. So 1 should

read.

1. Connect the single end

hose connection onto

cold water tap with ¾

bsp thread etc. (see

figure).

Before making the connection, allow the water to

run freely until it is perfectly clear.

2. Connect the double

end hose connection to

the washer dryer. Screw

connections onto both

of the inlet valves

located at the top right-

hand side at the rear of

the appliance making

sure the flexible pipe

section of the "Y" is not

kinked (see figure).

! Although the two pipes are now connected to the

rear of the appliance, the washer dryer will draw

cold water as is required for both wash

programmes and tumble drying as required.

Note: This appliance SHOULD NOT BE

CONNECTED TO A HOT WATER SUPPLY.

3. Make sure there are no kinks or bends in the hose.

!The water pressure at the tap must be within the

values indicated in the Technical details table

(on the next page).

!If the water inlet hose is not long enough, contact

a specialist store or an authorised serviceman.

!Ensure that the supply taps are allowing water

through. Old taps may seize in the closed position

and thus prevent water reaching the machine.

!Keep this instruction manual in a safe place for

future reference. Should the appliance be sold,

transferred or moved, make sure the instruction

manual accompanies the Washer-dryer to inform

the new owner as to its operation and features.

!Read these instructions carefully: they contain

vital information on installation, use and safety.

Unpacking and levelling

U n p a c k i n g

1. Unpack the Washer-dryer.

2. Check whether the Washer-dryer has been

damaged during transport. If this is the case, do

not install it and contact your retailer.

3. Remove the 2

protective screws and

the rubber bush with

the respective spacer,

situated on the rear of

the appliance (see also

the installation leaflet).

NB:The plastic spacers

may fall down inside the

machine once the bolt

has been removed, and will not interfere with the

operation of the machine.

4. Do not remove external bar.

5. Seal the gaps using the plastic plugs provided.

6. Keep all the parts: you will need them again if

the Washer-dryer needs to be moved to another

location.

!Packaging materials are not children's toys.

L e v e l l i n g

Your machine may make a considerable amount of

noise if the two front feet have not been adjusted

correctly.

1. Install the Washer-dryer on a flat sturdy floor,

without resting it up against walls, furniture

cabinets or other.

2. If the floor is not

perfectly level, com-

pensate for any

unevenness by

tightening or loosening

the adjustable front

feet (see figure); the

angle of inclination,

measured according to

the worktop, must not

exceed 2°.

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Tørretumbler
Model:	WDD 960 G
Vekselstrømsindgangsspænding:	50/60 V
Vekselstrømsindgangsfrekvens:	220 - 240 Hz
Bredde:	595 mm
Dybde:	565 mm
Højde:	850 mm
Produktfarve:	Sort, sølv
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Ilægningstype:	Front-læsning
Tromlekapacitet:	5 kg
Maksimal centrifugeringshastighed:	1600 rpm
Forsinket start-timer:	Ja
Døråbningsvinkel:	180 °
Dør farve:	Grå
Vaskeklasse:	A
Vandpåfyldning:	Kold
Brugerdefineret panel klar:	Ingen
Vaske kapacitet:	7 kg
