Side 1/211

Operating Instructions

Network Camera

Model No. WV-S2500 Series

WV-S2200 Series

WV-S2100 Series

WV-S1500 Series

WV-S1100 Series

WV-S2136LWV-S2536LN

WV-S1536LN

WV-S1136

• This manual covers the models: WV-S2500 Series (WV-S2536LTN,

WV-S2536LN, WV-S2536L, WV-S2536LT), WV-S2200 Series (WV-S2236L),

WV-S2100 Series (WV-S2136L, WV-S2136), WV-S1500 Series

(WV-S1536LTN, WV-S1536LN, WV-S1536L, WV-S1536LNS, WV-S1536LT),

and WV-S1100 Series (WV-S1136).

• The model number is abbreviated in some descriptions in this manual.

Preface

About the user manuals

There are 3 sets of operating instructions as follows.

• Operating Instructions (this document): Explains how to perform the settings and how to operate this

camera.

• Basic Information: Provides information about “Precautions for use” , “Parts and functions” and “Detail

specifications”.

• Installation Guide: Provides information about “Precautions”, “Precautions for installation” and the

installation method.

The screens used in these operating instructions show the case of WV-S2136L. Depending on the model used,

the screens shown in the explanations may differ to the actual camera screens.

This document provides how to operate and configure the camera using a web browser but it is recommended

to use the i-PRO Configuration Tool to configure the camera. The i-PRO Configuration Tool can configure up

to 1024 cameras at the same time so that the cameras can be configured efficiently.

For information about the i-PRO configuration tool (iCT), refer to our technical information website <Control

No.: C0133>.

Note

• “<Control No.:C****>” used in this document should be used to search for information on our technical

information website

(https://i-pro.com/global/en/surveillance/training-support/support/technical-information) and will guide

you to the right information.

• The captured screens are used based on the guideline by Microsoft Corporation.

• Operations using Google Chrome is described in this document. For information on the operation

verification of the supported web browsers, refer to our technical information website <Control No.:

C0132>

• Covered by one or more claims of the HEVC patents listed at patentlist.accessadvance.com.

• The default settings of some of the stream-related settings vary as follows depending on the language

setting of the browser selected at the time of administrator registration.

Setting items

Language of the browser

Languages other than

Japanese

Transmission priority VBR Frame rate

Image quality 3 Normal

Stream(1)

-Max bit rate (per client)

6144kbps * 3072kbps *

Stream(1)

-Smart VIQS

On(Low) Off

Stream(2)

-Max bit rate (per client)

4096kbps * 2048kbps*

Stream(3)

-Max bit rate (per client)

1536kbps * 768kbps *

Stream(4)

-Max bit rate (per client)

1536kbps * 768kbps *

2 Operating Instructions

Preface

Produkt Specifikationer

Mærke:	I-PRO
Kategori:	Overvågningskamera
Model:	WV-S2236LA
Type:	IP-sikkerhedskamera
Højde:	102.5 mm
Vægt:	570 g
Produktfarve:	Hvid
Kompatible hukommelseskort:	MicroSDHC, MicroSDXC, SD, SDHC, SDXC
Wi-Fi:	Ingen
Bluetooth:	Ingen
Formfaktor:	Kuppel
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Ethernet LAN-porte (RJ-45):	1
Ethernet LAN:	Ja
Webbrowser:	Ja
Understøttede lydformater:	AAC-LC, G.711, G.726
Strømforbrug (typisk):	8.6 W
Driftstemperatur (T-T):	-10 - 50 °C
Maksimal opløsning:	2048 x 1536 pixel
Husmateriale:	Polykarbonat (PC)
Understøttede grafikopløsninger:	320 x 180,1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2048 x 1536 (QXGA)
Forbindelsesteknologi:	Ledningsført
Understøttede netværksprotokoller:	IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, FTP, SFTP, MQTT, LLDP IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, FTP, SFTP, MQTT, LLDP
Strømkilde type:	DC, PoE
Monteringstype:	Loft
Diameter:	129.5 mm
Indbygget kortlæser:	Ja
Indbygget HDD:	Ingen
Understøttet placering:	Indendørs
Antal brugere:	14 bruger(e)
Bæredygtighedscertifikater:	CE, Federal Communications Commission (FCC)
Hvidbalance:	ATW, AWC
Sensortype:	CMOS
Samlet antal megapixels:	2 MP
Optisk zoom:	3.1 x
Autofokus:	Ja
Strømforbrug:	720 mA
IK kode:	IK10
Minimumsbelysning:	0 Lux
Optisk sensorstørrelse:	1/2.8 "
Zoom kapacitet:	Ja
Nattesyn:	Ja
Ethernet-grænsefladetype:	Hurtigt ethernet
DC udgangsspænding:	12
Antal kameraer:	1
Brændviddeområde:	2.9 - 9 mm
Nattesyn, afstand:	70 m
Strømforbrug (Power over Ethernet (PoE)):	8.7 W
Kompensation for baggrundslys:	Ja
Highlight Compensation (HLC):	Ja
Audiosporing:	Ja
Registringsafstand (bred):	24.9 m
Observeringsafstand (bred):	10 m
Genkendt afstand (bred):	5 m
Identifikationsfstand (bred):	2.5 m
Registringsafstand (tele):	118.2 m
Observeringsafstand (tele):	47.3 m
Genkendt afstand (tele):	23.6 m
Identifikationsfstand (tele):	11.8 m
