Side 1/234

Operating Instructions

Network Camera

Model No. WV-S8574L

WV-S8573L

WV-S8564L

WV-S8563L

WV-S8544L

WV-S8543L

WV-S8544

WV-S8543

WV-S8574L

Before attempting to connect or operate this product, please read these instructions

carefully and save this manual for future use.

The model number is abbreviated in some descriptions in this manual.

Preface

About the user manuals

There are 3 sets of operating instructions as follows.

• Operating Instructions (this document): Explains how to perform the settings and how to operate this

camera.

• Important Information: Provides information about “Precautions for use” and “Detail specifications”.

• Installation Guide: Provides information about “Precautions”, “Precautions for installation” and the

installation method.

The screens used in these operating instructions show the case of WV-S8574L. Depending on the model used,

the screens shown in the explanations may differ to the actual camera screens.

This document provides how to operate and configure the camera using a web browser but it is recommended

to use the iPRO Configuration Tool (iCT) to configure the camera. The iPRO Configuration Tool can configure

up to 1024 cameras at the same time so that the cameras can be configured efficiently. For information about

the i-PRO configuration tool (iCT) refer to our technical information website <Control No.: C0133>.

Note

• “Control No.:C****” used in this document should be used to search for information on our technical

information website below and will guide you to the right information.

https://i-pro.com/global/en/surveillance/training-support/support/technical-information

• The captured screens are used based on the guideline by Microsoft Corporation.

• Operations using Google Chrome is described in this document. For information about operation check

of the supported web browsers, refer to our technical information website <Control No.: C0132>.

• The default settings of some of the stream-related settings vary as follows depending on the language

setting of the browser selected at the time of administrator registration.

Setting items

Language of the browser

Languages other than

Japanese

Transmission priority VBR Frame rate

Image quality 3 Normal

Stream(1)

-Max bit rate (per client)

6144kbps * 3072kbps *

Stream(2)

-Max bit rate (per client)

1536kbps * 768kbps *

About notations

The following notations are used when describing the functions limited for specified models.

The functions without the notations are supported by all models.

S857xL

: The functions with this notation are available when using the model WV-S8574L and WV-S8573L.

S856xL

: The functions with this notation are available when using the model WV-S8564L and WV-S8563L.

S854xL

: The functions with this notation are available when using the model WV-S8544L and WV-S8543L.

S854x

: The functions with this notation are available when using the model WV-S8544 and WV-S8543.

2 Operating Instructions

Preface

Produkt Specifikationer

Mærke:	I-PRO
Kategori:	Overvågningskamera
Model:	WV-S8564L
Kode for international beskyttelse (IP):	IP66, IP67
Type:	IP-sikkerhedskamera
Højde:	90 mm
Vægt:	3300 g
Produktfarve:	Hvid
Kompatible hukommelseskort:	SD, SDHC, SDXC
Wi-Fi:	Ingen
Bluetooth:	Ingen
Formfaktor:	Kuppel
Opbevaringstemperatur (T-T):	-40 - 60 °C
Relativ luftfugtighed ved drift (H-H):	10 - 100 %
Ethernet LAN-porte (RJ-45):	1
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Webbrowser:	Ja
Driftstemperatur (T-T):	-20 - 60 °C
Maksimal opløsning:	3328 x 1872 pixel
Sikkerhedsalgoritmer:	802.1x RADIUS, FIPS 140-2
Husmateriale:	Aluminium, Polycarbonate (PC), Stainless steel
Beskyttelsesfunktioner:	Corrosion resistant, Dust resistant, Shock resistant, Water resistant
Understøttelse af sprog:	CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, POR, RUS
Understøttede grafikopløsninger:	320 x 180,640 x 360,1280 x 720 (HD 720),1920 x 1080 (HD 1080),2560 x 1440
Forbindelsesteknologi:	Ledningsført
Strømforbrug (maks.):	12 W
Netværksstandarder:	IEEE 802.3at
Understøttede netværksprotokoller:	IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, SFTP, MQTT, LLDP IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, SFTP, MQTT, LLDP
Strømkilde type:	DC, PoE
Monteringstype:	Loft
Diameter:	300 mm
Indbygget kortlæser:	Ja
Indbygget HDD:	Ingen
Video komprimeringsformater:	H.264, H.265, M-JPEG
Understøttet placering:	Udendørs
Antal brugere:	24 bruger(e)
Mikrofonindgang:	Ja
Hvidbalance:	ATW, AWC, Natural
Sensortype:	CMOS
Samlet antal megapixels:	25 MP
Støjreduktion:	Ja
Optisk zoom:	1 x
Maksimal størrelse på hukommelseskort:	512 GB
Strømforbrug:	240 mA
Hældningsvinkelområde:	10 - 105 °
Voice codecs:	AAC, G.711, G.726
IK kode:	IK10
Kamerapanorering kontrol:	Ja
Minimumsbelysning:	0 Lux
Panoreringsområde:	-125 - 125 °
Rotationsvinkel:	270 °
Antal sensorer:	4
Optisk sensorstørrelse:	1/2.8 "
Nærmeste fokuseringsafstand:	3 m
Maksimale blænderåbning tal:	1.4
Fast brændvidde:	3.1 mm
Nattesyn:	Ja
LED type:	IR
Billedhastighed:	15 fps
Justering af billedkvalitet:	Lysstyrke
Fortrolighedspolitik maskering:	Ja
Ethernet-grænsefladetype:	Gigabit Ethernet
Bevægelsessensor (video):	Ja
HTTPS -kryptering:	Ja
DC udgangsspænding:	12
DC-udgangsstrøm:	1 A
Antal kameraer:	1
Kameraets lukkerhastighed:	1/10000 - 16/30 sek./side
Nattesyn, afstand:	40 m
Dynamisk interval:	120 dB
Intelligent Video Surveillance (IVS) systemfunktioner:	Face detection, Human detection, Scene change, Vehicle detection
Advarsel notifikationstype:	E-mail, Push notification
Strømforbrug (Power over Ethernet (PoE)):	11.5 W
Lydsystem fuld dupelx:	Ja
Kompensation for baggrundslys:	Ja
Registringsafstand:	48.4 m
Antal sprog:	9
Objektivets synsvinkel, vandret:	108 °
Objektivets synsvinkel, lodret:	56 °
Highlight Compensation (HLC):	Ja
Audiosporing:	Ja
Bitrate kontrol:	Constant Bit Rate (CBR)/Variable Bit Rate (VBR), Variable Bit Rate (VBR)
Alarm indgangskanaler:	3
Observeringsafstand:	19.3 m
Genkendt afstand:	9.7 m
Antal områder med Privacy-maskering:	8
