Side 1/10

Quick installation guide IB-HUB1418-i3

3.5" Frontpanel

with USB 3.0 Type-C

™

and Type-A hub

Product overview / Produktübersicht

1. 3x USB 3.0 Type-A interface up to 5 Gbit/s

2. 1x USB 3.0 Type-C

™

interface up to 5 Gbit/s

3. USB 3.0 Type-A interface to host computer

4. SATA power connector

1. 2 x USB 3.0 Type-A Anschluss bis zu 5 Gbit/s

2. 2 x USB 3.0 Type-C

™

Anschluss bis zu 5 Gbit/s

3. USB 3.0 Type-A Anschluss zum Hostcomputer

4. SATA Stromanschluss

Safety information

Please read carefully the following information to prevent injuries, damage to

material and device as well as data loss:

Warning levels

Signal words and safety codes indicate the warning level and provide immediate

information in terms of the probability of occurrence as well as the type and severity of the

consequences if the measures to prevent hazards are not complied with.

Warns of a hazardous situation causing directly death or

serious injury.

Warns of a hazardous situation that cause potentially may

death or serious injury.

Warns of a hazardous situation that cause potentially may

minor injury.

Warns of a situation that cause material or potential may

environmental damage and disrupt operative processes.

1. Risk of electrical shock

Contact with parts conducting electricity

Risk of death by electrical shock

• Read the operating instructions prior to use

• Make sure the device has been de-energised prior to working on it

• Do not remove contact protection panels

• Avoid contact with conducting parts

• Do not bring plug contacts in contact with pointed and metal objects

• Use in intended environments only

• Operate the device using a power unit meeting the speciﬁcations of the type plate only!

• Keep the device/power unit away from humidity, liquid, vapour and dust

• Do not modify the device

• Do not connect the device during thunderstorms

• Approach specialist retailers if you require repairs

2. Hazards during assembly (if intended)

Sharp components

Potential injuries to ﬁngers or hands during assembly (if intended)

• Read the operating instructions prior to assembly

• Avoid coming into contact with sharp edges or pointed components

• Do not force components together

• Use suitable tools

• Use potentially enclosed accessories and tools only

3. Hazards caused by a development of heat

Insufﬁcient device/power unit ventilation

Overheating and failure of the device/power unit

• Prevent externally heating up components and ensure an exchange of air

• Do not cover the fan outlet and passive cooling elements

• Avoid direct sunlight on the device/power unit

• Guarantee sufﬁcient ambient air for the device/power unit

• Do not place objects on the device/power unit

DANGER

WARNING

CAUTION

IMPORTANT

WARNING

CAUTION

IMPORTANT

Produkt Specifikationer

Mærke:	Icy Box
Kategori:	USB HUB
Model:	IB-HUB1418-i3
Bredde:	101 mm
Dybde:	137 mm
Højde:	25 mm
Vægt:	143 g
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Pakkevægt:	265 g
Pakkedybde:	31 mm
Pakkebredde:	151 mm
Pakkehøjde:	151 mm
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	3
Husmateriale:	Metal
Hurtig installationsvejledning:	Ja
Pakketype:	Kasse
Udgangsspænding:	5 V
Harmoniseret systemkode (HS):	84719000
Bæredygtighedscertifikater:	CE, Federal Communications Commission (FCC)
Hovedkassen højde (udvendigt):	330 mm
Hovedkassens længde (udvendigt):	340 mm
Hovedkassens bruttovægt (udvendigt):	11400 g
Hovedkassens bredde (udvendigt):	340 mm
Værtsgrænseflade:	USB 3.2 Gen 1 (3.1 Gen 1) Type-A
Oprindelsesland:	Kina
Plug and play:	Ja
Produkter pr. hovedkasse (udvendigt):	40 stk
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-C-porte:	1
Dataoverførselshastighed:	5000 Mbit/s
Porte, antal:	4
Hot-swap:	Ja
Hub-grænseflader:	USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Chipsæt:	GL3520 ASM1543
