Side 1/3

704492 / 00 10 / 2008

Operating instructions

(Ex protection related part) for inductive sensors according to

EU directive 94/9/EC annex VIII (ATEX) group II, equipment category 3D/3G

Remarks for safe use in hazardous areas

Functions and features

• Use in hazardous areas according to the classification

II 3D

(group II, category 3D, apparatus for dust atmosphere).

The requirements of the standards EN 61241-1 and EN 61241-0 are met.

• Use in hazardous areas according to the classification

II 3G

(group II, category 3G, apparatus for gas atmosphere).

The requirements of the standard EN 60079-15 are met.

• Marking (see unit or technical data sheet)

II 3D Ex tD A22 IP67 T80°C X Ta: 0°C...+60°C

II 3G Ex nA T6 X

• Permissible operating temperature of the application (proper usage):

Ta: 0°C...+60°C

Installation / Set-up

The units must only be installed, connected and set up by qualified staff. The qualified staff

must have knowledge of protection classes, regulations and provisions for apparatus in

hazardous areas.

Check whether the classification (see "Marking" above and marking on the unit) is suitable

for the application.

Installation remarks / Installation

• Adhere to the respective national regulations and provisions as well as the relevant

installation regulations.

• Avoid electrostatic charging on plastic units and cables.

• To avoid electrostatic charging clean the unit with a damp cloth only. Rubbing with non-

conductive materials must be strictly avoided.

• To avoid electrostatic charging steps must be taken to ensure the equalisation of potential

of metal parts (plug housing, fixing elements, protective housing, etc.).

• Do not mount the unit in the dust flow.

• Avoid dust deposits on the units.

• Protect the units and the cables efficiently against damage.

• For the connections and the electrical technical data please see the unit marking or the

technical data sheet.

• To avoid soiling, do not remove the connector cover until attaching the socket.

• Avoid direct radiation with high UV components (sunlight). Mount the unit in a protected

place.

• M12 plugs may only be opened or closed in a sufficiently clean environment.
