706414/00 Page 1 of 14 © ifm efector gmbh

RM30xx Profibus

Brief instructions

efector400

706414/00 Page 2 of 14 © ifm efector gmbh

Contents

The description may contain deviations from the user system, because different

manufacturers or software versions may require different installations!

The description was created based on Siemens S7 version V5.4 + SP4.

1 Installation ................................................................................................................................. 3

1.1Software ................................................................................................................................... 3

1.2Hardware ................................................................................................................................. 4

1.2.1Overview ........................................................................................................................... 4

1.2.2Connection ....................................................................................................................... 4

2Setting the encoder function: .................................................................................................. 6

2.1Selection of the correct encoder: ............................................................................................. 6

2.2Multiturn encoder Class2 (standard): ...................................................................................... 7

3Setting of the measuring units (measuring range): ............................................................... 8

3.1Setting examples ..................................................................................................................... 9

3.2Setting examples with high and low word.............................................................................. 10

4Hex parameter setting for multiturn class 2: ........................................................................ 11

5 2List of variables, reset and preset ......................................................................................... 1 

5.1Display variables .................................................................................................................... 12

5.2Reset: ..................................................................................................................................... 13

5.3Preset: .................................................................................................................................... 13

6Other: ........................................................................................................................................ 14

Safety instructions

 Please read the product description prior to set-up of the unit. Ensure that the product is suitable for

your application without any restrictions.

 The unit complies with the relevant regulations and EC directives.

 Improper or non-intended use may lead to malfunctions of the unit or to unwanted effects in your

application.

 That is why installation, electrical connection, set-up, operation and maintenance of the unit must be

carried out by qualified personnel authorised by the machine operator.
