Side 1/2

Series LED User Guide

Note:The technical data are subject to change without notice.

OYB5

What’s Included

Safety Instructions

1 x OYB5 Light Fixture

1 x Power Adapter

1 x Power Cord

1 x Barn Door

1 x Yoke

1 x Light Bag

1 x Dual Battery Charger

2 x Batteries

1. When using the light, check that the environment is dry and well-ventilated.

2. Do not expose the fixture to rain or moisture.

3. The voltage should not exceed the recommended values.

4. Do not look directly at the light bulbs with naked yes when the light is on.

5. Do not place the light near flammable or volatile solvents such as alcohol or gasoline.

6. Please disconnect the power if the light not used for an extended period of time

7. If the light fixture is not working normally, please contact Ikan. The product should be

only be repaired by a qualified technician.

Please do not dissemble/re-assemble.

Product Information

Overview

Specifications

Thank you for buying the Onyx 5 Bi-Color Aluminum LED Light from Ikan. Please carefully

read the guide before operating the product.

The Onyx Half x 1 Bi-Color Aluminum LED light is fitted with 900 high quality LED lights. The

aviation grade aluminum panel design allows for better heat ventilation. The OYB5 provides a

flicker-free experience when adjusting the brightness (10%-99%) and color temperature

(3200K-5600K). The OYB5 can be controlled remotely with either the included remote control

or DMX via the Ethernet port. Having the option of being powered either by the power adapter

or two Sony “L” style batteries, the OYB5 can meet both your studio or on the field needs.

Ethernet DMX ports

Vents

2.4G Antenna

LED display

Yoke locking knobs

Adjustment knob

Power switch

Yoke

Power socket

DMX/remote

control switch button

Battery location

Channel button

Battery check button

Vents

2.4G Antenna

LED display

Yoke locking knobs

Adjustment knob

Power switch

Power socket

DMX/remote control switch button

Press "DIMMER/COLOR", when the “DIMMER” light is on, the adjustment knob increases or decreases the brightness.

When the “COLOR” light is on, the adjustment knob increases or decreases the color temperature.

RJ45 interface connection, can support the DMX512.

DMX socket

Battery location

Battery check button

Channel button

Press the "CHANNEL" button to toggle the option for the knob adjust the wireless or DMX512 channels.

Press the “Battery” button to view the battery life remaining in batteries. (Only when batteries are in use)

Press the "DIMMER/COLOR" button twice to enter full power under 4400K color temperature model,

the adjustment knob to adjust the brightness 10 ~ 99%.

Full Power Mode

Model OYB5

Output Power 54W

Luminous Flux 6480 LM

LED Quanty 900

Color Temperature 3200K - 5600K

Color Rendering Index ≥ 95

Dimmer 10% - 99%

Remote Control 99 Channels 2.4G Wireless Remote Control

Remote Control Distance 150 feet

DMX512 Yes (Ethernet interface)

Baery Type Sony "L" Style Baeries

DC Power Input DC13-19V

Fixture Size 14.5 x 11 x 1.75 in.

Fixture Weight 4 lbs

When the "DMX" corresponding indicator light is on only DMX controller can be controlled.

When the "2.4G" corresponding indicator light is on either the 2.4 G remote control or manual control can be used.
