OWNERS MANUAL
INSTALLATION, OPERATION, & MAINTENANCE INSTRUCTIONS
®
1128 Sherborn Street ▪ Corona, CA 92879 2089 ▪ (951) 281 1830 ▪ - - FAX (951) 281-1879
IHR SERIES
HEAVY DUTY RANGES AND OVEN
All Imperial Mfg. Co. equipment is manufactured for use with the type of gas specied on the rating plate
National Gas Installation Code, C /B149.1 or the Propane Installation code, C /B149.1, as applicable. Copies SA SA
may be obtained from the American Gas Association, 1515 Wilson Blvd, Arlington, VA 22209.
Instructions to be followed in case the user smells gas are to be posted in a prominent location in the
kitchen area. This information shall be obtained by contacting the local gas company or gas supplier.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
IMPORTANT
Safe and satisfactory operation of your equipment depends to a great extent on its proper installation.
Installation must conform to local codes, or in the absence of local codes, with the National Fuel Gas Code ANSI
Z223.1/NFPA 54, the National Gas Installation Code, C /B149.1or the Propane Installation code, C /B149.1, as SA SA
applicable.
Imperial cooking appliances are restaurant grade. Ranges are free standing and available in widths from
two to six feet. A large number of dierent range top arrangements are assembled over one or two ovens or a
cabinet base. Installation is the same for any range top regardless of whether it has an oven below or not; in like
manner, installation is the same for all cooking equipment regardless of the top arrangement. This unit may also be
equipped with a salamander broiler, on a high shelf. A Cheesemelter may be mounted on the high shelf as long as
the Cheesemelter is not wider than the range.
IMPORTANT
Installing, Operating and Service Personnel:
Installation of the equipment should be performed by qualied, certied, licensed and/or authorized
personnel who are familiar with and experienced in state/local installation codes. Operation of the equipment should
be performed by qualied or authorized personnel who have read this manual and are familiar with the function of
the equipment. Service of the equipment should be performed by qualied personnel who are knowledgeable with
Imperial Ranges
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause property
damage, injury or death. Read the installation,
operating and maintenance instructions thoroughly
before installing or servicing this equipment.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS IN THE
VICINITY OF THIS OR ANY OTHER
APPLIANCE.
2
GENERAL
(1) A manual gas shut-o valve must be installed in the gas supply (service) line ahead of the appliance and
gas pressure regulator in the gas stream for safety and ease of future service.
(2) An appropriate gas pressure regulator must be installed on the appliance prior to connecting the equipment
to the gas line. Failure to install a regulator will void the equipment warranty and result in a potentially
hazardous condition.
(3) For proper gas supply and pressure in large battered range line, it may be necessary to have 2 gas inlets. A
“T” gas connection can be installed at appropriate junction. Consult your gas company.
(4) The appliance and its individual shut o valve must be disconnected from the gas supply piping system
during any pressure testing of the system at test pressures in excess of ½ PSI.
(5) The appliance must be isolated from the gas supply piping system by closing its individual manual shut o
valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½
PSI.
(6) Please contact the factory, the factory representative, or a local service company to perform maintenance
and repairs.
RATING PLATE
om the oor). Except The rating plate is located in front of the range below the oven section (7” fr
convection oven base tag is located on rear of oven. Information on this plate includes the model and serial
numbers. When communicating with factory about a unit or requesting special parts or information, this data is
essential for proper identication. Other information on this plate is the BTU/hr input of the burners, operating gas
pressure in inches WC, and whether the unit is oriced for natural or propane gas. Pilot lighting instructions (ovens
only) are also located in the same area. The Salamander broiler or Cheesemelter (if provided) is supplied with its
own rating plate located on the unit.
IMPERIAL COOKING APPLIANCES MUST BE CONNECTED
ONLY TO THE TYPE OF GAS IDENTIFIED ON THE RATING PLATE
CLEARANCES
The appliance area must be kept free and clear of all combustibles. This unit is design-certied for the
following installations only:
The clearances from and construction for ranges and range mounted combustible noncombustible
Salamander broiler or Cheesemelter are as follows:
Combustible Noncombustible
Back 0 4”
Sides 8 ”0
If le gs or casters are not used, the unit must extend 2” beyond the front edge of a noncombustible curb or platform.
SHIPPING DAMAGE CLAIM PROCEDURE
The equipment is inspected & crated carefully by skilled personnel before leaving factory. The transportation company
assumes full responsibility for safe delivery upon acceptance of this equipment. If shipment arrives damaged:
1. Visible loss or damage: Note on freight bill or express delivery and have signed by person making delivery.
2. File claim for damages immediately: Regardless of extent of damages.
3. Concealed loss or damage: If damage is noticed after unpacking, notify transportation company immediately and le
“Concealed Damage” claim with them. This should be done within fifteen (15) days from date delivery is made to
you. Retain container for inspection.
