Follow the instructions on the symbols of the garment’s wash
care label. The value indicated in the symbol is the maximum
recommended temperature for washing the garment.
Mixed : Mixed + Steam cycle is ideal for cotton or
synthetic fabrics, as it washes at a temperature of 30°C and a maximum
spin speed of 1200 rpm. Max load 3,5 kg (cycle duration 59’). During the
last phase of the cycle garments will be treated with steam, that will relax
the bres making ironing easier and quicker.
Shirt : Use the special wash cycle to wash shirts in dierent fabrics and
colours to guarantee they receive the best possible care. During the last
phase of the cycle garments will be treated with steam, that will relax the
bres.
ARIEL PODS: A 30°C short cycle designed to wash a mixed load of cotton
and synthetics fabrics, recommended for the use of PODS detergent.
Wool - Wool Care
The wool wash cycle of this machine has been approved by
The Woolmark Company for the washing of machine washable
wool products provided that the products are washed
according to the instructions on the garment label and those
issued by the manufacturer of this washing machine. The
Woolmark symbol is a Certication mark in many countries. (M2227)
20°C: for washing lightly soiled cotton garments, at a temperature of 20 °C.
Cotton: suitable for washing towels, underwear, table cloths, etc. made of
resistant linen and cotton that are moderately to heavily soiled.
Synthetics: specic for synthetic items. If the dirt is dicult to remove,
the temperature can be increased up to 60° and powder detergent can be
used too.
Mixed: for washing lightly to normally soiled resilient garments in cotton,
linen, synthetic bres and mixed bres.
Eco 40-60: for washing normally soiled cotton garments declared to be
washable at 40 °C or 60 °C, together in the same cycle. This is the standard
cotton programme and the most ecient in terms of water and energy
consumption.
! As specied, this wash cycle only runs at 40 °C.
White: suitable for resistant linen and cotton that are heavily soiled.
Rapid 15min: this programme is designed to wash lightly soiled
garments at 20° (excluding wool and silk) with 1.5 kg maximum load in a
short time: it only lasts 15 minutes and allows for saving time and energy.
Rapid 45min Full Load: Suitable for washing a full load of cotton clothes
moderately soiled in 45 minutes.
Wash & Dry 45min: select programme 13 for washing and drying lightly
soiled garments (Cotton and Synthetic) in a short time. This cycle may be
used to wash and dry a laundry load of up to 1 kg in just 45 minutes. To
achieve optimum results, use liquid detergent and pre-treat cus, collars
and stains.
Delicates 30°C: use programme 14 to wash very delicate garments. It is
advisable to turn the garments inside out before washing them. For best
results, use liquid detergent on delicate garments.
When selecting an exclusively time-based drying function, a drying cycle is
performed at the end of the wash cycle that is particularly delicate, thanks
to light handling and appropriate temperature control of the water jet.
The recommended durations are:
1 kg of synthetic garments --> 150 min
1 kg of synthetic and cotton garments --> 180 min
1 kg of cotton garments --> 180 min
The degree of dryness depends on the load and fabric composition.
Rinse + Spin: designed for rinsing and spinning.
Spin + Drain: designed to spin and drain the water.
DISPLAY
The display is useful when programming the machine and provides a lot
of information.
The duration of the available wash cycles and the remaining time of a
running cycle appear in section ; if the Delayed Start option has been A
set, the countdown to the start of the selected cycle will appear.
Pressing the corresponding button allows you to view either the
maximum spin speed, temperature and drying time values attained by
the machine during the set wash cycle, or the values selected most
recently (if compatible with the set wash cycle).
The hourglass ashes while the machine processes the data on the basis
of the selected cycle. After a maximum of 10 minutes, the icon remains
steady lit and the nal time remaining is displayed. The “hourglass” icon
will then switch o approximately 1 minute after the nal time remaining
has been displayed.
phase” of the running cycle appear in section :B
Wash
Rinse
Spin/ Drain
Drying
When lit, the symbol indicates that the set “Delayed Start” value has
appeared on the display.
There are three levels in section relative to the washing options.C
Section includes the icons related to the three dierent drying levels as D
well as the icon , which lights up when a timed drying option is set.
DOOR LOCKED INDICATOR
When lit, the symbol indicates that the door is locked. To prevent any
damage, wait until the symbol turns o before opening the door.
To open the door while a cycle is in progress, press the START/PAUSE
button ; if the symbol is o, the door can be opened.
FIRSTTIME USE
Once the appliance has been installed, and before it is used for the rst
time, run a wash cycle with detergent and no laundry, by setting the
“Auto-Clean” cycle.
DAILY USE
Prepare the laundry by following the suggestions appearing under the
“TIPS AND SUGGESTIONS” section.
Rapid programming
- Press the ON/OFF button ; the START/PAUSE indicator light will
ash slowly green.
- Open the door. Load the laundry while making sure not to exceed the
maximum load quantity indicated in the cycle table.
- Pull out the detergent dispenser drawer and pour the detergent into the
relevant compartments as described in “DETERGENT DISPENSER DRAWER”
section.
- Close the door.
STARTING CYCLE
Press the PUSH & GO button.
The machine will lock the door ( symbol on) and the drum will start to
rotate; the door will be unlocked ( symbol OFF) and then locked again
( symbol on) as preparation phase of each washing cycle. The “Clicking”
noise is part of the door locking mechanism. Water will enter the drum
and start the washing phase once the door is locked.
Traditional programming
- Press the ON/OFF button ; the START/PAUSE indicator light will
ash slowly green.
- Open the door. Load the laundry while making sure not to exceed the
maximum load quantity indicated in the Wash Cycle Table.
- Pull out the detergent dispenser drawer and pour the detergent into the
relevant compartments as described in “DETERGENT DISPENSER DRAWER”
section.
- Close the door.
- Use the WASH CYCLE selector knob to select the desired wash cycle: it
will be associated with a specic temperature and spin speed that can be
modied. The duration of the cycle will appear on the display.
- Modify the temperature and/or spin speed: the machine automatically
displays the maximum temperature and spin speed values set for the
selected cycle, or the most recently-used settings if they are compatible
with the selected cycle. Pressing the button gradually reduces the
temperature down to the cold wash “OFF” setting. Pressing the button
gradually reduces the spin speed until it is completely excluded (“OFF”
setting). Pressing these buttons again restores the maximum values.
- Select the desired options.
STARTING CYCLE
Press the START/PAUSE button.
The machine will lock the door ( symbol on) and the drum will start to
rotate; the door will be unlocked ( symbol OFF) and then locked again
( symbol on) as preparation phase of each washing cycle. The “Clicking”
noise is part of the door locking mechanism. Water will enter the drum
and start the washing phase once the door is locked.
PAUSING A CYCLE
To pause the wash cycle, press the START/PAUSE button again; the
indicator light will ash amber. If the symbol is not lit, the door may be
opened. To start the wash cycle from the point at which it was
interrupted, press the START/PAUSE button again.
OPENING THE DOOR, IF NECESSARY
Once a cycle starts, the symbol turns on to signal that the door cannot
be opened. While a wash cycle is running, the door remains locked. To
open the door while a cycle is under way, for example, to add or remove
garments, press the START/PAUSE button to pause the cycle; the
indicator light will ash amber. If the symbol is not lit, the door may be
opened. Press the START/PAUSE button again to continue the cycle.
CHANGING A RUNNING WASH CYCLE
To change a wash cycle while it is in progress, pause the washer-dryer using
the START/PAUSE button (the relative indicator light will ash amber),
then select the desired cycle and press the START/PAUSE button again.
! To cancel a cycle that has already begun, press and hold the ON/OFF
button. The cycle will be stopped and the machine will switch o.
END OF THE CYCLE
This will be indicated by the word “END” on the display; when the symbol
switches o, the door may be opened. Open the door, unload the laundry
and switch o the machine. If you do not press ON/OFF button, the
washing machine will switch o automatically after about a 10 minutes.
