Indesit I3 D81B UK Manual

Indesit Tørretumbler I3 D81B UK

Læs gratis den danske manual til Indesit I3 D81B UK (4 sider) i kategorien Tørretumbler. Denne vejledning er vurderet som hjælpsom af 42 personer og har en gennemsnitlig bedømmelse på 4.8 stjerner ud af 21.5 anmeldelser. Har du et spørgsmål om Indesit I3 D81B UK, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/4

CARE LABEL

Always check the care labels, especially when placing garments

in the tumble dryer for the  rst time. Below are the most

commonly used symbols:

May be tumble dried.

Do not tumble dry.

Tumble dry – high heat.

Tumble dry – low heat.

THANK YOU FOR BUYING AN INDESIT PRODUCT.

In order to receive a more complete assistance, please

Quick guide

Before using the appliance carefully read the Safety

Instructions.

FIRST TIME USE

Remove all the tapes used to hold items on the machine.

Before you use it, clean the inside of the drum to remove any

dust that could have accumulated during transport. Slight odour

or vapour may be found if you open the door during its rst use,

this is normal and should only last a few minutes.

Make sure that the water tank is correctly inserted. Make sure

that the drain hose on the back of the dryer is properly

connected, either to the dryers's water tank or to your domestic

drainage system.

The dryer must be installed in a room with a temperature

ranging between 5°C and 35°C to ensure proper operation.

DAILY USE

Doing this will keep your machine working at its BEST:

- remember to empty your water tank after each drying cycle.

- remember to clean your condenser unit regularly

(monthly).

- remember to clean your lter after each drying cycle.

Refer to the Care & Maintenance section.

1. Plug the dryer into the power supply socket.

2. Open the door and load garments; always refer to instructions on

clothing labels and the max loads indicated in the programme

section. Empty pockets. Make sure garments do not get caught

between the door and/or the door lter. Do not load items that

are dripping wet. Do not tumble dry large, very bulky items.

3. Close the door.

4. Press the "On/O" button.

5. Select the most suitable programme

for the type of fabric in that

load.

6. Select the options, if necessary.

7. Press the "

Start/Pause"

button to begin drying.

8. At the end of the drying cycle, a buzzer will beep. An indicator on

the control panel signals the end of the cycle. Pull the load out

immediately to prevent the formation of creases on laundry.

9. Turn the machine o by pressing the "On/O" button, open the

door and pull the clothing out. If the machine is not switched o

manually, after about a quarter of an hour from the end of the

cycle , the appliance turns o automatically to save energy.

Note that some programme/option accords with "Crease Care"

system. This means that for some hours, after the end of the

drying cycle, the drum rotates at regular intervals to prevent the

formation of creases.

In case of power failure, it is necessary to press the "Start/Pause"

button to restart the cycle.

OPENING THE DOOR DURING THE CYCLE

Laundry can be checked while the drying cycle runs and any

garments already dry can be removed, while drying continues for

the remaining items. After closing the door, press the "Start/Pause"

button to resume machine operation.

TRANSPORT AND HANDLING

Never lift the dryer by holding on to its top side.

1. Unplug the dryer

2. Remove the water from the water tank completely.

3. Make sure that door and water tank are properly closed.

4. If the drain hose is connected to your drainage system, re-connect

it to the back of the dryer (see "Installation" section in the Safety

Instructions).

PUSH & GO

This function allows you to start an automatic drying cycle with just a

few simple gestures.

It is always necessary to follow points 1, 2, 3 and 4 of the “Daily

Use” section.

Press and hold the “Push & Go” button after turning on the machine,

regardless of the position of the knob. The light on indicates that

the cycle has started. This programme does not allow setting other

options.

This cycle is suitable for cotton and synthetic items, max load 4 kg

(cycle duration 100’).

CONTROL PANEL

1 ON/OFF Button (hold to Reset)

2 Programme Selection Knob

3 Start/Pause

Options Buttons*

4 Push & GO

5 Dryness Level

6 Start Delay

7 Timed Drying

8 Cycle End Signal

9 Light Dry (hold for Key Lock)

10 Crease Care hold to Mute)(

INDICATORS

Dryness Level: Iron Dry - Hanger Dry - Cupboard Dry - Extra Dry

Program Status: ENDDrying - Cool Down - End of Cycle

Empty water tank Clean door lter - - Clean the condenser unit

Refer to troubleshooting section: Call after sales service. Failure:

END

5 6 7

OPTIONS

These buttons allow you to personalise the selected programme

according to personal requirements.

Not all options are available for all programmes. Some options

may be incompatible with ones you have previously set; if so,

you will be alerted by the buzzer and/or blinking indicators.

If the option is available, the option indicator will stay on. The

programme may retain some options selected in previous

drying cycles.

Dryness Level

Press the related button several times to obtain a dierent

level of residual moisture on garments. An indicator signals the

level being selected.

Iron Dry: very delicate drying. Garments will be more

easily ironed immediately after the cycle.

Hanger Dry: a level intended for delicate garments ready

to be hanged.

Cupboard Dry: the garments are ready to be folded and

put away.

Extra Dry: used for garments to be worn at the end of the

cycle.

Start Delay

This option allows you to delay the start of the cycle. Press

the corresponding button several times to obtain the required

delay. After having reached the max settable time, the option is

reset by pressing the button again. An indicator on the control

panel signals the time being selected. After having pressed the

"Start/Pause" button, the machine signals the time remaining to

the start of the cycle. In case of door opening, press the "Start/

Pause" button once the door has been closed.

Timed drying

This option allows to set the drying time. Press the

corresponding button to set the required time for drying. An

indicator on the control panel signals the time being selected.

Cycle End Signal

This option activates a prolonged buzzer at the end of the

cycle. Enable it if you do not think you will hear the normal sound

at the end of the cycle. This option remains in memory if selected

in the previous drying.

Light Dry

Enables a more gentle treatment of the laundry by reducing the

drying temperature.

Key Lock

This option makes all machine controls inaccesible, except the

"On/O" button. When the machine is on:

• to activate the option, keep the button pressed until the

indicator goes on.

• to disable the option, keep the button pressed until the

indicator goes o.

This option remains in memory if selected in the previous drying.

Crease Care

This option adds a crease treatment at the end of the cycle

by means of a periodic rotation of the drum (duration up to 10

hours). It is particularly suitable when it is not possible to remove

the laundry as soon as the drying ends. If this option is used

together with the "Start Delay", the crease treatment is also added

to the "Start Delay" phase. This option remains in memory if

selected in the previous drying.

Mute

This option turns o all sounds of the control panel. Only

warnings remain active. When the machine is on:

• to activate the option, keep the button pressed until the

indicator goes on.

• to disable the option, keep the button pressed until the

indicator goes o.

PROGRAMS

The duration of these programs will depend on the size of the

load, types of textiles, the spin speed used in your washer and

any extra options selected. In machines equipped with display,

the duration of the cycles is shown on the control panel. The

remaining time is constantly checked and adjusted during the

drying cycle to show the best possible estimate.

Option to use - If all your loads on Automatic Cycles are

consistently less dry or more dry than you would like, you may

increase or decrease the dryness level using the specic option.

Eco Cotton Max* kg

This is the most ecient programme in terms of energy

consuption and is suitable for drying normal wet cotton

laundry. The values on the Energy Label are based on this

programme.

NOTE: For optimal energy eciency, select “Cupboard Dry” using

dryness level option. To increase the dryness level, select “Extra

Dry”.

Synthetics 4 kg

For drying synthetic garments.

Mixed 4 kg

This programme is ideal for drying cotton and synthetic

fabrics together.

Delicates 2 kg

For drying delicate laundry requiring a gentle treatment.

Wool 1 kg

Programme for drying wool clothes. It is advisable to turn

the garments inside out before drying. If heavy edges remain

damp, leave them to dry naturally.

Baby 2 kg

A programme intended to dry garments and linen of

new-born babies (cotton and chenille), as well as delicate

garments. Do not dry garments having plastic covering.

Duvet

Programme intended to dry bulky garments, such as a

single duvet.

Sport 4 kg

For drying sports garments made of synthetics or cotton

blends.

Jeans 3 kg

For drying sturdy cotton jeans-wear and garments, like

denim, such as trousers and jackets.

Shirts 3 kg

Programme ideal for cotton or cotton/synthetic blend

shirts.

Smart iron

This cycle allows to stretch the bres of garments thus

making ironing and folding easier. Do not use with

garments that are still wet. Suitable for small loads of cotton

textiles or cotton blends.

45’

Xpress 45' 1 kg

This is a quick timed programme, ideal for drying

garments spun at high speed in the washing machine,

e.g. the shirts used in a working week.

Refresh

A short programme suitable for refreshing bres and

garments through the emission of fresh air. Do not use with

garments that are still wet. It can be used on with any load size

but is more eective with small loads. 20 minutes.It lasts about

Mini synthetics 2 kg

Eco-drying of small laundry loads.

Mini cotton 2 kg

Eco-drying of small laundry loads.

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Tørretumbler
Model:	I3 D81B UK
Bredde:	595 mm
Dybde:	610 mm
Højde:	850 mm
Vægt:	37000 g
Produktfarve:	Blå
Kontroltype:	Dreje
Indbygget skærm:	Ja
Skærmtype:	LED
Strøm:	13 A
Ledningslængde:	1.5 m
Pakkevægt:	38700 g
Pakkedybde:	670 mm
Pakkebredde:	640 mm
Pakkehøjde:	890 mm
Årligt energiforbrug:	560 kWh
Placering af apparat:	Fritstående
Tilsluttet belastning:	2400 W
Støjniveau:	66 dB
Ilægningstype:	Front-læsning
Tromlekapacitet:	8 kg
Forsinket start-timer:	Ja
Near Field Communication (NFC):	Ingen
Tromlemateriale:	Galvaniseret
Tromle volumen:	112 L
Cyklustid:	156 min.
Forsinket start (maks.):	24 t
Tørringsklasse:	B
Wi-Fi kontrolleret:	Ingen
Energieffektivitetsklasse:	B
Tørreprogrammer:	Bomuld
Oprindelsesland:	Storbritannien
Tørresystem:	Kondensering
Antal tørreprogrammer:	15
Anti-krølle funktion:	Ingen
Varmekilde:	Elektrisk
Strømstiktype:	Type G
Anti-allergi funktion:	Ingen
