Infiniti Q60 (2020) Manual (224 Sider)



2020 OWNER’S MANUAL

AND MAINTENANCE INFORMATION

For your safety, read carefully and keep in this vehicle.

CALIFORNIA PROPOSITION 65 WARNING

WARNING

Operating, servicing and maintaining a passenger vehicle or

off-highway motor vehicle can expose you to chemicals

including engine exhaust, carbon monoxide, phthalates, and

lead, whi c h are known to the State of Californ ia to cause

cancer and birth defects or oth er reproductive harm. To

minimize exposure, avoid breath ing exhaust, do not idle the

engine except as necessary, service your vehicl e in a well-

ventilated area and wear gloves or wash your hands

frequently when servicing your vehicle. For more information

go to www.P65Warnings.ca.g ov/p assenger-vehicle.

This man ual was prepa red to help you

underst and the operation and maintenance

of your vehicle so that you may enjoy many

miles (kilometers) of driving pleasure. Please

read through this manual before operating

your vehicle.

A separate Warranty Information Booklet

is included in your Owner’s literature port-

folio. Al ways carry it with you when you

take your vehicle to an INFINITI retailer.

The Wa rranty Inf ormation Booklet con-

te nts provide co m pl ete information about

all warranties co vering this vehi cl e, the

requirement s to k eep the warranties in

effect as well as the INFINITI Roadside

Assistance program.

Ad ditionally, a separate Custo m er Care and

Lemon Law Information Booklet will ex-

plain how to resolve any concerns you ma y

have with your vehicle, as w ell as clarify

your rights under your state’s lemon law.

In addition to factory installed options, your

vehicle may also be equipped with additional

accessories installed by INFINITI or by your

INFINITI retailer prior to delivery. It i s

important that you familiarize yourself with

all disclosures, warnings, cautions and in-

structions concerning proper us e of such

accessories prior to operating the vehicle

and/or accessory. It is recommended you

see an INFINITI retailer for details concern-

ing the particular accessories with which

your vehicle is equipped.

READ FIRST — THEN DRIVE

SAFELY

Before driving your vehicle, read your Own-

er’s Manual caref ully. This will ensure famil-

iarity with controls and maintenance

requirements, assisting you in the safe

operation of your vehicle.

WARNING

IMPORTANT SAFETY INFORMATION

REMINDERS!

Follow these important driving rules to

hel p ensure a saf e and comfortable trip

for you and your passengers!

.NEVER drive under the influence of

alcohol or drug s.

.ALWAYS observe posted speed lim-

its and never drive too fast for

conditions.

.ALWAYS give your full attention to

driving and avoid using vehicle fea-

tures or taking other act ions that

could distract you.

.ALWAYS use your seat belts and

appropriat e child restraint systems.

Pre-teen children should be seated in

the rear seat.

.ALWAYS provide information about

the proper use of vehicle safety

features to all occupants of the

vehicle.

.ALWAYS review this Owner’s Man-

ual for important safety information.

MODIFICATION OF YOUR VEHI -

CLE

This vehicle should not be modified. Mod-

ification coul d affect its performance,

safety or durability, and may even violate

governmental regulations. In addit ion, da-

mage o r perfo rmance problems resulting

from modification will not be covered

under the INFINITI warranties.

WARNING

Installing an aft ermarket On-Bo ard Di-

agnostic (OBD) plug-in device that uses

the port during normal driving, for

example remote insurance company

monitoring, remote vehicle diagnostics,

telematics or en gine reprogramming,

may cause interference or damage to

vehicle systems. We do not recomme nd

Foreword

or endorse t he use of any aftermarket

OBD plug-in devices, unless specifically

approved by INFINITI. The vehicle war-

ranty may not cover damage caused by

any aftermarket plug-in device .

WHEN READING THE MANUAL

This manual includes informati on for all

features and equipme nt available on t his

model. Features and equipment in your

vehicle may vary depending on mode l, trim

level, options selected, order, date of pro-

duction, region or availability. Therefore,

you may find information about features or

equipment that are not included or installed

on your vehicle.

All information, specifications and illustra-

tions in this manual are those in effect at the

time of printing. INFINITI reserves the right

to change specifications, performance, de-

sign or component suppliers without notice

and without obligation. From t ime to time,

INFINITI may update or revise this manual to

provide owners w ith the most accurate

information currently available. Please care-

fully read and retain with this manual all

revision updates sent to you by INFINITI to

ensure you have access to accurate and up-

to-date information regarding your vehicle.

Current versions of vehicle Owner’s Manuals

and any u pdates can also be found in the

owner section of the INFINITI website at

https://owners.infinitiusa.com/owners/na-

vigation /manu alsandGuides. If you have

questions concerning any information in

yo ur Owne r’s Manual , con tact INFINITI

Consumer Affairs. See th e INFINITI CUS-

T OMER CARE PROGRAM page in this

Owner’s Manual for contact information.

IMPORTANT INFORMATION

ABOUT THIS MANUAL

You will see various symbols in this manual.

They are used in the following ways:

WARNING

This is used to indicate the presence of a

hazard that could cause death or serious

personal injury. To avoid or reduce the

risk, the procedures must be followed

precisely.

CAUTION

This is used to indicate the presence of a

hazard that could cause minor or mod-

erate personal injury or da m age to your

vehicle. To avoid or reduce t he risk, the

procedures must be followed c aref ull y.

SIC0697

If you see the symbol above, it means “Do

not do this” “Do not let this happen”or .

If you see a symbol similar to those above in

an illustration, it means the arrow points to

the front of the vehicle.

Arrows in an illustration that are similar t o

those above indicate movement or action.

Arrows in an illustration that are similar t o

those above call atten tion to an item in th e

illustration.

CALIFORNIA PERCHLORATE

ADVISORY

Some vehicle parts, such as lit hium bat-

te ries, may contain perchlorate material.

The following advisory is provide d: “Per-

chlorate Material - special handling may

a p p l y , S e e w w w . d t s c . c a . g o v /

hazardouswaste/perchlorate.”

Manual may be reproduced or stor ed in a

retrieval system, or transmitted in any form,

or by any means, electron ic, mechan ical,

photocopying, recording or otherwise, with-

out the prior written permission of Nissan

Motor Co., Ltd.

INFINITI CUSTOMER CARE PROGRAM

INFIN ITI CARES ...

Both INFINITI and your INFINITI retailer are dedicated to serving all your automotive needs. Your satisfaction with your vehicle and your

INFIN ITI retailer are our primary concerns. Your INFINITI ret ailer is always available to assist you with all your automobile sales and service

needs.

However, if there is something that your

INFINIT I retailer cannot assist you with or

you would like to provide INFINITI directly

with comments or questions, please contact

our (INFINITI’s) Consumer Affairs Depart-

ment using our toll-f ree number:

For U.S. customers

1-800-662-6200

For Canadian c us tomers

1-800-361-4792

The Consumer Affairs Department will ask

f or the following information:

.Your name, address, and telephone num-

ber

.Vehicle identification number (on dash

panel)

.Date of purchase

.Current odometer reading

.Your INFINITI retailer’s name

.Your comments or questions

OR

You can write to INFINITI with the informa-

tion on the left at:

For U.S. customers

INFINITI Division

Nissan North Americ a, Inc.

Consumer Af fairs Department

P.O. Box 685003

Franklin, TN 37068-5003

or via e-mail at:

nnaconsumeraffairs@nissan-usa.com

For Canadian c us tomers

INFINITI Division

Nissan Canada Inc.

5290 Orbitor Drive

Mississauga, Ontario L4W 4Z5

or via e-mail at:

information.centre@nissancanada.

com

If you prefer, visit us at:

www.infinitiUSA.com (for U.S. customer) or

www.infiniti.ca (for Canadian customers)

We appreciate your interest in INFINITI and

thank you for buying a quality INFINITI

vehicle.

Illustrated table of contents 0

Safety — Seats, seat be lts and supplemental restraint

system 1

Instruments and controls

Pre-driving checks and adjustments

Monitor, climate, audio, phone and voice recognition

systems

Starting and driving

In case of emergency

Appearance and care

Do-it-yourself

Mainten ance and schedules

Technical and consumer information

2

3

4

5

6

7

8

9

10

Table of

Contents

11

Index

0 Illustrated table of contents

Seats, seat belts and Supplemental Restraint

System (SRS) ...................................................................... 0-2

Exterior front ..................................................................... 0-3

Exterior rear ....................................................................... 0-4

Passenger compartment ................................................. 0-5

Cockpit ................................................................................. 0-6

Instrument panel .............................................................. 0-8

Meters and gauges .......................................................... 0-9

Engine compartment .................................................... 0-10

VR30DDTT engine ................................................ 0-10

Warning and indicator lights ...................................... 0-11

0-2 Illustrated table of contents

JVC0918X

1. Supplemental front-impact air bags

(P.1-38)

2. Front seat-mounted side-impact su p-

plemental air bags (P.1- 38)

3. Seat belts (P.1- 11)

4. Head restraints (P.1-7)

5. Roof-mounted cu rtain side-impact and

rollover supplemental air bags (P.1-38)

6. Child rest raint anchor points ( f or top

tether strap child restraint) (P.1-23,

P.1-30, P.1-34)

7. Occupant classification sensors

(weight sensors) (P.1-44)

8. Fr ont s eats (P.1-3 )

9. Seat belts with pretensioners (P.1-54)

10. Rear seat walk-in mechanism (P.1-5)

11. Rear seats (P.1-6)

— Child restraints ( P.1-19)

12. LATCH ( Lower Anchors and Tethers

for CHildren ) system (P.1-21)

SEATS, SEAT BELTS AND

SUPPLEMENTAL RESTRAINT

SYSTEM (SRS)

JVC0939X

1. Hood (P.3-22)

2. Windshield wiper and washer

— Switch operation ( P.2-34)

— Window washer fluid (P.8-10)

3. Headlights and t urn s ignal lights

(P.2-38)

— Adaptive Front lighting System

(AFS) (if so equipped) (P.2- 42)

4. Moonroof (if so equipped) (P.2-55)

5. Power windows (P.2-52)

6. Outside mirrors (P.3-31)

— Side turn signal lights (P.2-43)

— Side view camera (if so equipped)

(P.4-11)

7. Front view camera (if so equipped)

(P.4-11)

8. Sonar s ensors (if so equipped)

— Camera aiding sonar function

(P.4-24)

— Sonar system (P.5-133)

9. Fog lights (P.2-44)

10. Tires

— Whe els and tires (P.8-25, P.10-9)

— Flat tire (P.6-3)

— Ti re P ressure Monitori ng System

(TPMS) (P.2-14, P.5-5)

11. Doors

— Keys (P.3-2)

— Door locks (P.3-4)

— Intelligent Key system (P.3-6)

— Remote keyless entry system

(P.3-15)

— Remote engine start (if so equipped)

(P.3-19)

— Courtesy light (P.2-59)

Illustrated t able o f contents 0-3

EXTERIOR FRONT

0-4 Illustrated table of contents

JVC0940X

1. Trunk lid (P.3-22)

— Intelligent Key system (P.3-6)

— Remote keyless entry system

(P.3-15)

2. High-mount ed stop light (P.8-22)

3. Satellite antenna (P.4-42)

4. Rear window defroster (P.2-37)/An -

tenna (P. 4-42)

5. Sonar sensor s (if s o equipped)

— Camera aiding sonar function

(P.4-24)

— Sonar system (P.5-133)

6. Rear view camera

— RearView Monitor (if so equipped)

(P.4-3)

— Around View

®

Monitor (if so

equipped) (P.4-11)

7. Rear combination light (P.8-22)

8. Fuel-filler door (P.3-25)

— Fuel information (P.10-4)

EXTERIOR REAR

JVC0941X

1. Coat hooks (P.2-51)

2. Power window switch (P.2-52)

3. Outside mirror remote control switch

(P.3-31)

4. Automatic dr ive positioner switch (if so

equipped) (P.3-33)

5. Sun visors (P. 3-29)

6. Moonroof switch (if so equipped)

(P.2-55)

7. SOS call switch* (if so equipped)

8. Map light ( P.2-57)

9. Sunglasses h older (P.2-49)

10. Inside mirror (P.3-29)

— HomeLink

®

universal transceiver (if

so equipped) (P.2-59)

— Compass (if so equipped) (P. 2-9)

11. Rear cup holders (P.2-48)

12. Console box (P.2-50)

— Power outlet (P.2-47)

— USB (Universal Serial Bus) connec-

tion ports and AUX (auxiliary) input

jack*

13. Front cup hold ers (P.2-48)

*: Refer to the INF INITI In Touch

TM

Own-

er’s Manual.

Illustrated t able of contents 0-5

PASSENGER COMPARTMENT

0-6 Illustrated table of contents

WAA0093X

1. Side ventilator (P. 4-34)

2. Head light, f og light and turn signal

switch (P.2-38)

3. Steering wheel

— Horn (P.2-44)

— Driver supplemental air bag (P.1-38)

— Heated steering wheel (if so

equipped) (P.2-47)

— Power steering (P.5-124)

4. Windshield wiper and washe r switch

(P.2-34)

5. H azard warning flasher switch (P.6-2)

6. Shift lever (P.5-16)

7. INFINITI control ler*

8. Vehicle Dynamic Contr ol (VDC) OFF

switch (P.2-45, P.5-129)

9. Trunk lid release switch (P.3- 23)

10. Instrument brightness control switch

(P.2-43)

11. TRIP/RESET switch for twin trip od-

ometer (P.2-7)

12. Electric tilting/telescopic steering

wheel switch (if so equipped) (P.3-27)

13. Manual tilting/telescopic steering

wheel lever (if so equipped) (P.3-27)

14. Steer ing-wheel-mounted controls (left

side)

— Audio control s t eering switch*

— Hands-Free Phone System switch*

— Voice recognition system switch*

15. Steering-wheel-mounted controls

(right side)

— Trip computer switches (P.2-29)

— Cruise control switches (if so

equipped) (P.5-66)

— Intelligent Cruise Control (ICC)

switches (if so equipped) (P.5-68)

— Dynamic driver assistance switch (if

so e quipped) (P. 5-25, P.5-45, P.5-89)

16. INFINITI Drive Mode Selector (P.5-21)

COCKPIT

*: Refer to the INFINITI InTouch

TM

Own-

er’s Manual.

Illustrated table of contents 0-7

0-8 Illustrated table of contents

JVC0969X

1. Paddle shifter (if so equipped) ( P.5-18)

2. Meter s and gauges (P.2-6)

— Clock (P.2-31)

3. Push-button ignition switch (P.5-11)

4. Center ventilator (P.4-34)

5. Heater and air conditioner control

(P.4-34)

6. Upper touch screen display* (upper

d isplay) and Navigation system* (if so

equipped)

— RearView Monitor (if so equipped)

(P.4-3)

— Around View

®

Monitor (if so

equipped) (P.4-11)

7. Lower touch screen d ispla y* (lower

display)

8. Rear window and outside mirror

defroster switch (P.2-37)

9. Front passenger supplemental air bag

(P.1-38)

10. Hood release handle (P.3-22)

11. Fuse box cover (P.8- 17)

12. Parking brake (P.5- 20)

13. Storage box (P.2-51) and power out let

(P.2-47)

14. Seat heater switch (if so equipped)

(P.2-45)

15. Audio system*

16. Tr unk release power cancel switch

(P.3-24)

17. Glove box (P.2-50)

*: Refer to the INFINITI InTouch

TM

Own-

er’s Manual.

INSTRUMENT PANEL

JVC0428X

1. Tachometer (P.2-8)

2. Warning and indicator lights (P.2-12)

3. Speedometer (P.2-7)

4. Engine coolant temperature gauge

(P.2-8)

5. Vehicle information d isplay (P.2-20)/

Odometer/twin trip odometer (P.2-7)

6. Fuel gauge (P.2-9)

Illustrated table of contents 0-9

METERS AND GAUGES

0-10 Illustrated table of contents

JVC0968X

VR30DDTT ENGIN E

1. Battery (P.8-11)

2. Eng ine oil dipstick (P.8-6)

3. Engine oil filler cap (P. 8-7)

4. Brake fluid reservoir ( P.8-9)

5. Fuse/fusible link h older (P.8-17)

6. Air cleaner (P.8-15)

7. Engine drive belt location (P.8-13)

8. Radiator filler cap (P.8-3)

9. Intercooler cooling reservoir (P.8-5)

10. Engine coolant reservoir (P. 8-4)

11. Window washer fluid reservoir

(P.8-10)

ENGINE COMPARTMENT

Warning

light Name Page

Anti-lock Braking System

(ABS) warning light 2-12

Brake warning light 2-13

Charge warning light 2-13

Forward Emergency Braking

(FEB) system warning light (if

so equipped)

2-13

Low fuel warning light 2-14

Low tire pressure warning

light 2-14

Master warning light 2-16

Power steering warning light 2-16

Seat belt warning light 2-17

Suppl emental air bag warn-

ing light 2-17

Vehicle Dynamic Control

(VDC) warning light 2-17

Indicator

light Name Page

ECO driv e indicator light 2-18

Exterior light indic ator 2-18

Front fog light indicator light 2-18

Front passenger air bag sta-

tus l ight 2-18

High beam as sist indicator

light (if so equipp ed) 2-18

High beam indicator l ight 2-18

Malfunction Indica tor Light

(MIL) 2-18

Security indicator light 2-19

Turn signal/hazard indicator

lights 2-19

Vehicle Dynamic Control

(VDC) off indicator light 2-19

Illustrated table of contents 0-11

WARNING AND INDICATOR LIGHTS

0-12 Illustrated table of contents

MEMO

1 Safety — Seats, seat belts and supplemental

restraint system

Seats ...................................................................................... 1-2

Front seats ..................................................................... 1-3

Rear seats ....................................................................... 1-6

Head restraints/headrests .............................................. 1-7

Adjustable head

restraint/headrest componen t s ..... ......................... 1-8

Non-adjustable head

restraint/headrest componen t s ..... .......................... 1-9

Remove ........................................................................... 1-9

Install ............................................................................... 1-9

Adjust ........................................................................... 1-10

Seat belts ........................................................................... 1-11

Precautions on seat belt usage ............ .................. 1-11

Pregnant women ....................................................... 1-13

Injured persons ........................................................... 1-13

Pre-crash seat belts with comfort function

(front seats) (if so equipped) . ................... .............. 1-13

Three-point type seat belt ...................................... 1-14

Seat belt extenders ................................................... 1-16

Seat belt maintenance ............................................. 1-17

Child safety ...................................................................... 1-17

Infants .......................................................................... 1-18

Small children ............................................................. 1-18

Larger children ........................................................... 1-18

Child restraints ................................................................ 1-19

Precautions on child restraints .......... .................. 1-19

Lower A nchors and Tethe rs for CHildren

System (LATCH) ...................................................... 1-21

Rear-facing child restraint installation

using LATCH ............................................................ 1-23

Rear-facing child restraint installation using

the seat belts ............................................................ 1-25

Forward-facing child restraint installation

using LATCH ............................................................ 1-28

Forward-facing child restraint installation

using the seat belts ................................................ 1-31

Booster seats ........................................................... 1-35

Supplemental restraint s ystem .. ................... ............. 1-38

Precautions on supplemental

restraint system ....................................................... 1-38

INFINI TI Advanced Air Bag System

(front seats) .............................................................. 1-44

Front seat-mounted side- impact supplement al

air bag and roof-mounted curtain side-impact

and rollover supplemental air bag systems ..... 1-52

Seat belt s with pret ensioners (front seats) ..... 1-54

Supplemental air bag warning labels ................ 1-55

Supplemental air bag warning light ....... ............ 1-55

Repair and replacement procedure .. .............. .... 1-56

1-2 Safety — Seats, seat belts and supplemental restraint system

SSS0133

WARNING

.Do not ride in a moving vehicle when

the seatback is reclined. This can be

dangerous. The shoulder belt will not

be against your body. In an accident,

you co uld be thrown into it and

receive neck or other serious injuries.

You could also slide under the lap belt

and receive serious inte rnal injuries.

.For the most effective protection

when the vehicle is in motion, the

seat should be upright . Alwa ys sit

well back and upright in the sea t with

both feet on the floor and adjust the

seat belt properly. See “Precautions

on seat belt usage ” (P.1-11).

.Do not leave children unattended

inside the vehic le. They could un-

knowingly activate switches or con-

trols. Unattended children could

beco me involved in serious accidents.

.To help avoid risk of injury or death

through unintended operation of the

vehicle and/or its systems, do not

leave children, people who require the

assis ta nce of others or pe ts unat-

tend ed in your vehicle. Additionally,

the temperature inside a closed ve -

hicle on a war m day can quickly

become high enough to cause a sig-

nificant risk o f injury or death t o

people and pets.

.The seatback should not be reclined

further than necessary for comfort.

Seat belts are most effective when

the passenger sits well back a nd

straight up in the s eat. If the seat-

back is reclined, the risk of sliding

und er the lap belt and being injured is

increased.

CAUTION

When adjusting the seat positio ns, be

sure not to contact any moving parts to

avoid possible injuries and/or damages.

SEATS

FRONT SEATS

Fro nt power seat adj ustment

Operating tips:

.The power seat motor has an auto-reset

overload protection circuit. If the motor

stops during operation, wait 30 seconds,

then reactivate the switch.

.Do not operate the power seat switch for

a long period of time whe n the engine is

off. This will discharge the battery.

See “Automatic drive positioner” (P.3-33)

for the seat position memory function.

SSS1051

Forward and backward:

Moving the switch forward or backward

will slide the seat forward or backward to

the desired position.

Reclining:

Move the recline switch backward until

the desired angle is obtained. To bring the

seatback forward again, move the switch

forward.

The reclining feature allows adjustment of

the seatback for occupants of different sizes

for added comfort and to help obtain proper

seat belt fit. (See “Precautions on seat belt

usage” (P.1-11).) Also, the seatback can be

reclined to allow occupants to rest when the

vehicle is parked.

Safety — Seats, seat belts and supplemental restraint system 1-3

1-4 Safety — Seats, seat belts and supplemental restraint system

SSS1052

Seat lifter:

Push the front or rear end of the switch up or

down to adjus t the angle of the front portion

or height of the seat.

SSS1053

Type A (if so equipped)

Lumbar support (for driver’s seat):

The lumbar support feature provides lower

back support to the driver.

Type A ( if so equipped)

Pu sh the front or back e nd of the switch to

adjust the seatback lumbar area.

SSS0836

Type B (if so equipped)

Move the lever up or down t o adjust the

seatback lumbar area.

JVR0186X

Side support (if so equipped):

The side support fea ture allows you to

adjust the torso supports. Push th e switch

inside or outside to adjust the torso

area.

JVR0497X

Walk-in mechanism:

This feature makes it easier to get in and out

of the rear se at. Use the following procedure

when getting in and out of the rear seat.

If the sun visor is used, close it t o the original

position before operating the walk-in fea-

ture.

1. Pull the seatback lever upward to fold

the front seatback down. Make sure that

the front seatback is completely folded

down.

2. To slide the front seat forward, firmly

push the seatback switch . The front

s eat will move forward.

3. Get in or out of the vehicle.

4. T o return the front seat to its original

position, raise the seatback and push the

seatback switch again.

.To stop the seat sliding, push the seat-

back switch again or oper ate the seat

sliding/lifter switches.

.The front passenger seat will stop re-

turning 6.5 in (165.8 mm) from its front-

most position to retain space for the rear

passenger.

.Depending on the seat position, the head

restraint may contact the roof headlining

during the walk-in ope ration. To prevent

possible inter ference, lower the seat

using the seat lifter switch.

Safety — Seats, seat belts and supplementa l restraint system 1-5

1-6 Safety — Seats, seat belts and supplemental restraint system

WARNING

When returning the seat t o its original

pos ition, confirm the seat and seatback

are locked properly.

CAUTION

.Be careful not to pinch your hand or

foot or bump your head when oper-

ating the walk-in seat.

.While operating the walk-in seat, do

not operate the sea tback reclining

switch. The reclining mot or may be

damaged.

.Do not place any objects near the

seatback of the front seats. They may

be pinched and damaged.

The automatic forwarding and reversing will

not work or stop under the following condi-

tions:

.When the vehicle speed is moving (dri-

ver’s seat only).

.When the seat belt is fastened.

.When the shift lever is not in the P (Park)

position (driver’s se at only).

.When the door is closed (automatic

forwarding only).

.While the automatic drive positioner (if

so e quipped) operates.

.When the automatic drive positioner

switches (if so equipped) are pushed.

.When the seatback switch is pushed.

.When the seat position is adjusted.

Note that the seat must be moved to the

front -most position by operating the walk-

in function after the battery is disconnected.

Otherwise, the seat will not move backward

during the walk-in function.

REAR SEATS

Folding

WARNING

.Never allow anyone to ride in the

trunk or on the rear seat when it is in

the fold-dow n position. Use of these

areas by passengers without proper

restraints could result in serious in-

jury in an accident or sudden st op.

.Properly secure all cargo with ropes

or straps to help prevent it from

sliding or shifting. Do not place cargo

higher than the seatback. In a sudden

stop or collisio n, unsecured cargo

could cause personal injury.

.When returning the seatback to the

upright position, be certain they are

completely secured in t he latched

position. If they are not completely

secured, passengers may be injured in

an accident or sudden stop.

.Closely supervise children when they

are around cars to prevent them from

playing and becoming locke d in the

trunk where they could be s eriously

injured. Keep the car locked, with the

rear seatback and trunk lid securely

latched when not in use, and prevent

children’s access to car keys.

JVR0498X

The rear se atback can be folded according to

the following procedu re.

Before folding the s eatback:

Remove drink containers from the rear cup

holder.

To fold the seatback:

1. Open the trunk lid.

2. Pull the strap located on the left side of

the trunk. The rear seat back will be

unlatched.

3. Fold the rear seatback d own.

To return the seatback:

1. Fold up the rear seatback.

2. Securely lock the se atback in position.

WARNING

Head restraint/headrest supplement the

other vehicle safety s yste ms. They may

provide additional protection against

injury in certain rear end collisions.

Adjustable head restraint/headrest

must be adjusted properly, as spe cifie d

in this s ection. Check the a djustment

after someone else uses the seat. Do not

attach anything to the head res traint/

headrest stalks or remove the head

restraint/headrest. Do not use the seat

if the head restraint/headrest has been

removed. If the head restraint/headrest

was r emoved, reinstall and properly

adjust the head restraint/headres t be-

fore an oc cupant uses the sea ting posi-

tion. Failure to follow these instructions

can reduce the effectiveness of the head

restraint/h eadres t. This may increa se

the risk of serious injury or dea th in a

collision.

Saf ety — Seats, seat belts and supplemental restraint system 1-7

HEAD RESTRAINTS/HEADRESTS

1-8 Safety — Seats, seat belts and supplemental restraint system

JVR0388X

The illustration shows the se ating positions

equipped with head restraint/headrest.

Indicates the seating position is

equipped with a head restraint.

Indicates the seating position is

equipped with a headrest.

+ Indicates the seating position is not

equipped with a he ad restraint or headr est.

.Your vehicle is equipped with a head

restraint/headrest that may be inte-

g rated, adjustable or non-adjustable.

.Adjustable head restraints/headrests

have multiple notches along the stalk to

lock them in a desired adjustment posi-

tion.

.The non-adjustable head restraints/

headre sts have a single locking notch to

secure them to the seat frame.

.Proper Adjustment:

— For the adjust able type, align the he ad

restraint/headrest so the center of

your ear is approximately level with

the center of the head re straint/

headrest.

— If your ear position is still higher than

the recommended alignment, place

the head restraint/headrest at the

highest position.

.If the head restraint/headrest has been

removed, ensure that it is reinstalled and

locked in place bef ore riding in that

designated seating position.

SSS0992

ADJUSTABLE HEAD RESTRAINT/

HEADREST COMPONENTS

1. Removable head restraint/headrest

2. Multiple notches

3. Lock knob

4. Stalks

JVR0203X

NON-ADJUSTABLE HEAD RE-

STRAINT/HEADREST COMPO-

NENTS

1. Removable head restraint/headrest

2. Single notch

3. Lock knob

4. Stalks

SSS1037

REMOVE

Use the following procedure to remove the

head restraint/headrest.

1. Pull the head rest raint/headrest up to

the highest position.

2. Push and hold the lock knob.

3. Remove the head restraint/headrest

from the seat.

4. Store the head restraint/headrest prop-

erly in a s ecure place so it is not loose in

the vehicle.

5. Reinstall and properly adjust the head

restraint/headrest before an occupant

uses the seating position.

SSS1038

INSTALL

1. Align t he head restraint/headrest st alks

with the holes in t he seat. Make sure that

the head restraint/headrest is facing the

correct direction. The stalk with the

adjustment n otch must be installed in

the h ole with the lock knob .

2. Push and hold the lock knob and push the

head restraint/headrest down.

3 . Properly adjust the head restraint/head-

rest before an occupant uses t he seating

position.

Safety — Sea ts, seat belts and supplemental restraint system 1-9

1-10 Safety — Seats, seat belts and supplemental restraint system

SSS0997

ADJUST

Adjust the head restraint/headrest so the

center is level with the center of your ears. If

your ear position is still higher than the

recommended alignment, place the head

restraint/headrest at the highest position.

SSS1035

Raise

To raise the head restraint/headrest, pull it

up.

Make sure t he head restraint/headrest is

positioned so the lock knob is engaged in the

notch before riding in that designated seat-

ing position.

SSS1036

Lower

To lower , push and hold the lock knob and

push the head restraint/headrest down.

Make sure t he head restraint/headrest is

positioned so the lock knob is engaged in the

notch before riding in that designated seat-

ing position.

PRECAUTIONS ON SEAT BELT

USAGE

If you are wearing your seat belt properly

adjusted, and you are sitting upright and well

back in your seat with both fee t on the floor,

your chances of being injured or killed in an

accident and/or the severity of injury may be

greatly reduced. I NFINITI strongly en-

courages you and all of your passengers to

buckle up every time you drive, even if your

seating position includes a supplemental air

bag.

Most U.S. sta tes and Canadian provinces or

territories specify that seat belts be worn at

all times when a vehicle is being driven.

SSS0136A

SSS0134A

Safety — Seats, seat belts and supplemental restraint system 1-11

SEAT BELTS

1-12 Safety — Seats, seat belts and supplemental restraint system

SSS0016

SSS0014

WARNING

.Every person who drives or rides in

this vehicle should use a seat belt at

all times. Children s hould be properly

restra ined in the rear sea t and, if

appropriat e, in a child restra int.

.The seat belt should be properly

adjusted to a snug fit. Failure to do

so may reduce the effec tivene ss of

t he entire restraint system and in-

creas e the chance or severity of injury

in an accident. Serious injury or death

can occur if the seat belt is not worn

properly.

.Always route the shoulder belt over

your shoulder and across your c hest .

Never run the belt behind your back,

under your a rm or acros s your neck.

The belt should be away from your

fac e and neck, but not falling off your

shoulder.

.Position the lap belt as low and snug

as possible AROUND THE HIPS, NOT

THE WAIST. A lap belt worn too high

could increase the risk of internal

injuries in an accident.

.Be sure the seat belt tongue is

securely fastened to the proper

buckle.

.Do not wear the seat belt inside out

or twisted. Doing s o may reduce its

effectiveness.

.Do not allow more than one person to

use the same seat belt.

.Never carry more people in the ve-

hicle than there are seat belts.

.If the seat belt warning light glows

continuously while th e ignitio n is

turned ON with all doors closed and

all seat belts fastened, it may indicate

a mal function in the system. Have the

system checked . It is recommended

you visit an INFINITI retailer for this

service.

.No changes should be made to the

seat belt system. For example, do not

modify the seat belt, add material or

install devices that may change the

seat belt routing or tension. Doing so

may aff ect the operation of the seat

belt system. Modifying or tampering

with the seat belt system may result

in s erious personal injury.

.Once a seat belt pretensioner has

activated, it cannot be reused and

must be replaced together with the

retractor. It is recommended you visit

an INFINITI retailer for this service.

.All seat belt assemblies, including

retra ctors and attaching hardware,

should be inspected after any colli-

sion. It is recommended you visit an

INFINITI retailer for thi s service.

INFINITI recommends that all sea t

belt assemblies in use during a colli-

sion be replaced unless the collision

was minor and the belts show no

damage and continue to operate

properly. Seat belt assemblies not in

use during a collisio n should also be

inspected and replaced if either da-

mage or improper o peration is noted.

.All child restraints and attaching

hard ware should be inspected after

any collision. Al ways follow the re-

straint manufacturer’s inspection in-

s t r u c t i o n s a n d r e p l a c e m e n t

recommendations. The child re-

straints should be replaced if they

are damaged.

PREGNANT WOMEN

INFINITI recommends that p regnant women

use seat belts. T he s eat belt should be worn

snug, and always position the lap belt as low

as possible around the hips, not the waist,

and place the shoulder belt over your

shoulder and across your chest. Never run

the lap/shoulder belt over your abdominal

area. Contact your doctor for specific re-

commendations.

INJURED PERSONS

INFINITI recommends that injure d persons

use seat belts, depending on the injury.

Check with your doctor for specific recom-

mendations.

PRE-CRASH SEAT BELTS WITH

COMFORT FUNCTION (front

seats) (if so equ ipped)

The pre-crash s eat belt tightens the seat belt

with a motor to help restrain front seat

occupants. This helps reduce the risk of

injury in a collision.

The motor retracts the s eat belt under the

following emergency conditions:

.During emergency braking.

.During sudden steering maneuvers.

.Activation of the Forward Emergency

Braking (FEB) with pedestrian detection

system. (See “Forward Emergency Brak-

ing (FEB) with pedestrian detection

system” (P.5-100).)

The pre-crash seat bel t will not be active

when:

.The seat belt is not fastened.

.The vehicle speed is under 10 MPH (15

km/h) du ring emergency braking.

.The vehicle speed is under 19 MPH (30

km/h) during su dden steering maneu-

vers.

The pre-crash seat bel t will not be active

w hen the brake pedal is not depressed

ex cept when sudd en steerin g maneuvers

occur or the FEB with pedestrian detection

system activates.

The motor also retracts the seat b elt when

the seat belt is fastened or unfas tene d.

When the s eat belt is fastened, the motor

tightens the seat belt for a snug fit. When

the seat belt is unfastened, the motor

r etracts the seat belt. If the seat belt is not

fully retracted, the motor retracts the seat

belt when the door is opened.

Always wear your seat belt correctly and sit

upright and well back.

If the motor cannot retract the seat belt

when the seat belt is fastened or unf as-

tened, it may indicate the pre-crash s eat belt

system has a malfunction. It is recommended

you have an INFINITI retailer check and

repair the system.

When the seat belt is retracted repeatedly in

a short period of time, the motor may not be

able to retract the seat belt. After a fe w

minutes, the motor normally reactivates and

retracts the seat belt. If the seat be lt still

cannot be retracted by the motor, the pre-

crash seat belt system has a malfunction.

Safet y — Seats, seat belts and supplemental restraint system 1-13

1-14 Safety — Seats, seat belts and supplemental restraint system

Have the system checked and repaired. It is

recommended you visit an INFINITI retailer

for this service.

T HREE-POINT TYPE SEAT BELT

WARNING

.Every person who drives or rides in

this vehicle should use a seat belt at

all times.

.Do not ride in a moving vehicle when

the seatback is reclined. This can be

dangerous. The shoulder belt will not

be against your body. In an accident,

you co uld be thrown into it and

receive neck or other serious injuries.

You could also slide under the lap belt

and receive serious inte rnal injuries.

.For the most effective protection

when the vehicle is in motion, the

seat should be upright . Alwa ys sit

well back and upright in the sea t with

both feet on the floor and adjust the

seat belt properly.

WARNING

Do not allo w children to play with the

seat belts. Most seating positions a re

equipped with Auto matic Locking Re-

tractor (ALR) mode seat belts. If the seat

belt be comes wrapped around a child’s

neck with the ALR mode act ivated, the

child can be seriously injured or killed if

the seat belt retracts and becom es tight.

This can occur even if the vehicle is

parked . Unbuckle the seat belt to relea se

the child.

SSS0292

Fasten ing the seat belts

1. Adjust the seat. (See “Seats” (P.1-2).)

2. Slowly pull the seat belt out of the

retractor and insert the tongue into the

buckle until you hear and feel the latch

engage.

. The retractor is designed to lock

during a sudden stop or on impact.

A slow pulling motion permits the

belt to move, and allows you some

freedom of moveme nt in the seat.

. If the seat belt cannot be pulled from

its fully ret racted position, firmly pull

the belt and release it. Then smoothly

pull the belt out of the ret ractor.

SSS0290

3. Position the lap belt portion low and

snug on the hips as shown.

4. Pull the shoulder belt portion toward the

retractor to take up extra slack. Be sure

the shoulder belt is routed over your

shoulder and across your chest.

The three-point type seat belts have two

modes of operation:

.Emergency Locking Retractor (ELR)

.Automatic Locking Retractor (ALR)

The Emer gency Locking Retractor (ELR)

mode allows the seat belt to extend and

retract to allow t he driver and passengers

some freedom of movement in the seat. The

ELR locks the seat belt when the vehicle

slows down rapidly or during impacts.

The Automatic Locking Retractor (ALR)

mode (child restraint mode) locks the seat

belt for child restraint installation.

When the ALR mode is activated the seat

belt cannot be extended again until the seat

belt t on gue is detached from the buckle and

fully retracted. The seat belt returns to the

ELR mode after the seat belt fully retracts.

For additional information, see “Ch ild re-

straints” (P.1-19).

The ALR mode should be used only for child

rest raint inst allation. During normal seat

belt use by an occupant , the ALR mode

should not be activated. If it is activated, it

may cause uncomfortable se at belt tension.

WARNING

When fastening the seat bel ts, be certain

that seatbacks are compl etely secured in

the latched posi tion. If they are not

completely secured, passengers may be

injured in an accident or sudden stop.

SSS0326

Unfastening the seat belts

To unfasten the seat belt, pu sh the button

on the buckle. The seat belt automatically

retracts.

Checking seat belt operation

Seat bel t retractors are designed to lock seat

belt movement by two separate methods:

.When the belt is pulled quickly from the

retractor.

.When the vehicle slows down rapidly.

To increase your confidence in the seat belts,

check the operation as follows:

.Grasp the shoulder belt and pull forward

quickly. T he retractor should lock and

Safety — Seats, seat belts and supplemental restraint system 1-15

1-16 Safety — Seats, seat belts and supplemental restraint system

restrict further belt movement.

If the retractor does not lock during th is

check, get the system checked. It is recom-

mended you visit an INFINITI retailer for this

service, or to learn more about seat belt

operation.

SSS0588

Shou lder b elt arm (for front seats)

Before fastening the seat belt, pull the

shoulder belt arm f or ward until it clicks at

the lock position. The arm can also be folded

d own for easier access for rear seat passen-

gers.

Pulling t he arm f or ward will allow an easy

access to the belt.

SEAT BELT EXTENDERS

If, because of body size or driving position, it

is not possible to properly fit the lap -

shoulder belt and fasten it, an extender that

is compatible with the installed seat belts is

available that can be purch ased. The ex-

te nder adds approximately 8 in (200 mm) of

length and may be used f or either the driver

or front passenger seating position. It is

recommended you visit an IN FIN ITI re t ailer

for assistance with purchasing an extender if

an extend er is required.

WARNING

.It is recommended only INFINITI seat

belt extenders, made by the same

company which made the original

equipment seat belts, be used with

the INFINITI seat belts.

.Adults and children who can use the

standard seat belt should not use an

ex tender. Such unnecessary use could

result in serious personal injury in the

event of an accident.

.Never use seat belt extenders to

install child restraints. If the child

re straint is not s ecured properly, the

child could be s eriously injured or

killed in a collision or a sudden stop.

SEAT BELT MAINTENANCE

.To clean the seat belt webbing, apply a

mild soap solution or any solution re-

commended for cleaning uphols t ery or

carpets . Then, wipe with a cloth and

allow the seat b elts to dry in the s hade.

Do not allow the seat belts to retract

until they are completely dry.

.If dirt builds up in the shoulder belt guide

of the seat belt anchors, the seat belts

may retract slowly. Wipe the shoulder

belt guide with a clean, dry cloth.

.Periodically check to see that the seat

belt and the metal components such as

buckle s, tongu es, retractors, flexible

wires and anchors work pr op erly. If loose

parts, deterioration, cuts or other da-

mage on th e webbing is found, the en t ire

seat bel t assembly should be replaced.

WARNING

Do not allow childre n to play with the

seat belts. Most seating positions are

equipped with Automatic Locking Re-

tractor (ALR) mode seat belts. If the seat

belt becomes wrapped around a child’s

neck with t he ALR mode activated, the

child can be seriously inj ured or killed if

the seat belt retracts and becomes tight.

This can occur even if the vehicle is

parked. Unbuckle the seat belt to release

the child.

Children need adults to help protect them.

They need to be properly restrained.

In addition to the general information in this

manual, child safety information is available

from many other sources, including d octors,

teachers, government traffic safety offices,

and community organizations. E very child is

different, so be sure to learn the best way to

transport your child.

There are thr ee basic types of child restraint

systems:

.Rear-facing child restraint

.Forward-facing child restraint

.Booster seat

The proper restraint depends on the child’s

size. Generally, infants up to about 1 year

and less than 20 lbs (9 kg) s hould be pl aced

in rear-faci ng child restraints. Forwa rd-

facing child restraints are available for

children who outgrow rear-f acing child re-

s t raints and are at least 1 year old. Booster

seats are used to help position a vehicle lap/

shoulder belt on a child who can no longer

use a forward-facing child restraint.

WARNING

Infants and children nee d special protec-

tion. The vehicle’s seat belts may not fit

them properly. The shoulder be lt may

come too close to the face or neck. The

lap belt may not fit over their smal l hip

b ones. In an accident, an i mproperly

fitting se at belt could c ause serious or

fatal injury. Always use appropriate

child res traints.

All U.S. states and Canadian provinces or

territories require the use of appr oved child

restraints for infants and small children . See

“Child restraints” (P.1-19).

A child restr aint may be secured in the

vehicle by using either the LATCH ( Lower

Anchor and Tethers for CHildren) system or

with the vehicle seat belt. See “Child re-

straints” (P.1-19) for more information.

Safe ty — Seats, seat belts and supplemental rest r aint system 1-17

CHILD SAFETY

JVR0473X

If you answered no to any of these que s-

tions, the child should remain in a booster

seat using a three-point type seat belt.

NOTE:

Laws in some communities may follo w

different guidelines. Check local and state

reg ulatio ns to confirm your child is using the

correct restraint system before traveling.

WARNING

Never let a child stand or kneel on any

seat and do not allow a child in the cargo

area . The child could be seriously injured

or killed in a sudden stop or collision.

SSS0099

SSS0100

PRECAUTIONS ON CHILD RE-

STRAINTS

WARNING

.Failure to follow the warnings and

instructions for proper use and in-

sta llation of child restraints could

result in serious injury or death of a

child or other passengers in a sudden

stop or collision:

— The child restraint must be used

and installed properly. Always

follow all of the child restraint

manufacturer’s instru ctions for

installation and use.

— Infants and children should never

be held on anyone’s lap. Even the

stronges t adult cannot resist the

forces of a coll ision.

— Do not put a seat be lt around

both a child and another passen-

ger.

— INFINITI recommends that all

child restraints be installed in the

rear seat. Studies show that chil-

dren are safer when properly re-

strained in the rear seat than in

the front seat. If you must install a

Safet y — Seats, sea t belts and supplemental restraint system 1-19

CHILD RESTRAINTS

1-20 Safety — Seats, seat belts and supplemental restraint system

forward-facing child restraint in

the front seat, see “Forward-

facing child restraint installation

using the seat belts” (P.1-31).

— Even with the INFINITI Advanced

A ir Bag System , never inst all a

rear-facing child restraint in the

front seat. An inflating air bag

could seriously injure or kill a child.

A rear-facing child res traint must

only be used in the rear seat.

— Be sure to purchase a child re-

st raint that w ill fit the child and

vehicle. Some child restraints may

not fit properly in your vehicle.

— Child restra int anchor points are

designed to withstand loads from

child restraints that are properly

fitted.

— Never use the anchor points for

adult seat belts or harnesses.

— A child restraint with a top tether

strap should not be used in the

front passenger seat.

— Keep seatb acks as upright as

possibl e after fitting the child

restraint.

— Infants and children should al-

ways be placed in an appropriate

child restraint while in the vehicle.

.When the child restraint is not in use,

keep it secured with the LATCH

system or a seat belt. In a sudden

stop or collision, loose objects can

injure occupants or da mage the ve-

hicle.

CAUTION

A child restraint in a c losed vehicle can

become very hot. Check the seating

surface and buckles before placin g a

child in the child restraint.

This vehicle is equipped with a universal child

restraint anchor system, referred to as the

LATCH (Lower Anchors and Tethers for

CHildre n) system. Some child restraints in-

clude rigid or webbing-mounted attach-

ments that can be connected to these

anchors.

For details, see “Lower Anchors and Tethers

for CHildren System (LATCH)” (P.1-21).

If you do not have a LATCH compatible child

restraint, the vehicle s eat belts can be used.

Several manufacturers offe r child restraints

for infants and small children of various

sizes. When selecting any child restraint,

keep the following points in mind:

.Choose only a restraint with a label

certifying that it complies with Federal

Motor Vehicle Safety Standard 213 or

Canadian Motor Vehicle Safety Stan-

dard 213.

.Check the child restraint in your vehicle to

be sure it is compatible with the vehicle’s

seat and seat belt system.

.If the child restraint is compatible with

your vehicle, place your child in the child

restraint and check t he various adjust-

ments to be sure the child restraint is

compatible with your child. Choose a

child restraint that is designed for your

child’s height and weight. Always follow

all recommended procedures.

.If the combined weight of the child and

child restraint is less than 65 lbs (29.5

kg), you may use either the LATCH

anchors or the seat belt to install the

child restraint (not both at the same

time).

.If the combined weight of the child and

child restraint is g reater than 65 lbs (29.5

kg), use the vehicle’s seat belt (not the

lower anchors) t o install the child r e-

straint.

.Be sure to follow the child restraint

manufacturer’s instructions for installa-

tion.

All U.S. states and Canadian provinces or

territories require that infants and small

children be restrained in an approved child

restraint at all time s while the vehicle is

being operated. Canadian law requires the

top tether strap on forward-facing child

restraints be secured to the designated

anchor point on the vehicle.

JVR0499X

Lower Anchors and Tethers for

CHildren System (LATCH)

Your vehicle is equipped with special anchor

points that are used with the LATCH (Lower

Anchors and Tethers for CHildren) system

compatible child restraints. This system may

also be re f erred to as the ISOFIX or ISOFIX

compatible system. With this system, you do

not have t o use a vehicle seat belt to secure

the child restraint unless the combine d

weight of the child and child restraint

exceeds 65 lbs (29.5 kg). If t he combined

weight of th e child and child restraint is

greater than 65 lbs (29.5 kg), use the

vehicle’s seat belt (not the lower anchors)

to install the child re straint. Be sure to follow

the child restraint manufacturer’s instruc-

tions for installation.

LATCH lower anchor

WARNING

F ailure to follow the warnings and

instructions f or proper use and installa-

tion of child restraints could result in

serious injury or death of a child or other

passengers in a sudden stop o r collision:

.Attach LATCH system compatible

child restraints only at the locations

s ho wn in the illustration.

.Do not secure a child restraint in the

rear center position using the LATCH

lower anchors. The child restraint will

not be secured properly.

.Inspect the lower anchors by insert-

ing your fingers into the lower anchor

area. Feel to make sure there are no

obstructions over t he anchors such as

seat belt webbing or seat cushion

material. The child restraint will not

be secured properly if the lower

anchors are obstructed.

Child restraint anchorages are designed

to withstand only those load s imposed

by correctl y fitted child restraints. Under

Saf ety — Seats, seat belts and supplemental restraint system 1-21

1-22 Safety — Seats, seat belts and supplemental restraint system

no circumstances are they to be used to

attach adult seat belts, or o ther items or

equipment to the vehicle. Doing so could

damage the child restraint anchorages.

The child restraint will not be properly

installed using the damaged anchorage,

and a child could be seriously injured or

killed in a collision.

JVR0252X

LATCH lower anchor location

The LATCH lower anchor s are located,

under the covers labelle d I SO FIX, at the

bottom of the rear seat cushions.

To access a LATCH lower anchor, insert

your finger into the cover and pull t he cover

off.

CAUTION

Store the loose LATCH lowe r anchor

covers to avoid losing them and where

they will not get damaged.

SSS0643

LATCH webbing-mounted attachment

Installing chil d restraint LATCH

lower anchor attachments

LATCH compatible ch ild rest raints include

two rigid or webbing-mounted attachments

tha t c an be connected to two anchors

located at certain seating positions in your

vehicle. With this system, you do not have to

use a vehicle se at belt to se cu re the child

rest raint. Check your child restraint for a

l abel stating that it i s compatible with

LATCH. Th is information may also be in

the instructions provided by the child re-

straint manufacturer.

SSS0644

LATCH rigid-mount ed attachment

When installing a child rest raint, carefully

read and follow the instruct ions in this

manual and those supplied with th e child

restraint.

SSS0790

Top tether anchor point locations

Anchor points are located on the rear parcel

shelf.

If you have any questions whe n installing a

top tether strap child restraint on the rear

seat, it is recommended you visit an

INFINITI retailer for this se rvice.

WARNING

Child restra int anchorages a re designe d

to withstand only those loads imposed

by correctly fitted child restra ints. Under

no circumstances are they to be used to

attac h adult seat belts, or other items or

equipment to the vehicle. Doing so could

damage the child restraint anchorages.

The child restraint will not be properly

installed using the damaged anchorage,

and a child could be seriously injured or

killed in a collision.

REAR-FACING CHI LD RE-

STRAINT INSTALLATION USING

LATCH

R efer to all Warnings and Cautions in the

“Child safety” and “Child restraints” sections

before installing a child restraint.

Do not use the lower anchors if the com-

bined weight of the child and the child

restraint exceeds 65 lbs (29. 5 kg). I f the

combined weight of the child and the child

restraint is greater than 65 lbs (29.5 kg), use

the vehicle’s seat belt (not the lower an-

chors) to install the child re straint. Be sure to

follow the child res traint ma nufacturer’s

instructions for installation.

Follow these steps to install a rear-facing

child restraint using the LATCH system:

1. Position the child restraint on the seat.

Always follow the child restraint manu-

facture r’s instructions.

Safety — Seats, seat belts and supplementa l restraint system 1-23

1-24 Safety — Seats, seat belts and supplemental restraint system

SSS0648

Rear-facing web-mounted — step 2

2. Secure the child re straint anchor attach-

m ents to the LATCH lower anchors.

Check to make sure the LATCH attach-

ment is properly attached to the lower

anchors.

SSS0649

Rear-facing rigid-mounted — step 2

SSS0639

Rear-fa cing — step 3

3. For child res t raints that are equipped

with webbing- moun t ed attachments, re-

move any additional slack f rom the

anchor attachments. Press downward

and rearward firmly in the center of the

child restraint with your hand to com-

press the vehicle seat cushion and seat-

back while tightening the webbing of the

anchor attachments.

SSS0650

Rear-facing — s tep 4

4. After attaching the child res t raint, test it

before you place th e child in it. Push it

from side to side while holding the child

restraint near the LATCH attachment

path. The child restraint should not move

more than 1 inch (25 mm), from side to

s ide. Try to t ug it forward and check to

see if the LATCH attachment holds th e

restraint in place. If the restraint is not

secure, tighten the LATCH attachment

as necessary, or put the r estraint in

another seat and test it again. You may

need t o try a differen t child res t raint or

try installing by using the vehicle seat

belt (if applicable). Not all child restraints

fit in all types of vehicles.

5. Check to make sure the child restraint is

properly secured prior to each us e. If the

child restraint is loose, repeat steps 1

through 4.

REAR-FACING CHILD RE-

STRAINT INSTALLATION USING

THE SEAT BELTS

WARNING

The three-point seat belt with Auto -

matic Locking Retractor (ALR) must be

used when installing a c hild restraint.

Failure to use the ALR mode will result in

the child restraint not being properly

secured. The restraint could tip over or

be loose and cause injury to a child in a

sudden stop or collision. Also, it can

change the operation of the front pas-

senger air bag. See “Front passenge r air

bag and status light” (P.1-46).

For additional information, refer to all

Warnings and Cautions in the “Child safety”

(P.1-17) and “Child rest raints” (P.1-19) be-

fore installing a child restraint.

Do not use the l ower anchors if the com-

bined weight of the child and the child

restraint exceeds 65 lbs (29.5 kg). If the

combined weight of the child and t he child

restraint is greater than 65 lbs (29.5 kg), use

the vehicle’s seat belt (not the lower an-

chors) to install the child restraint. B e sure to

follow the child restraint manufacturer’s

Saf ety — Seats, seat belts and supplemental restraint system 1-25

1-26 Safety — Seats, seat belts and supplemental restraint system

instructions for installation.

Follow t hese steps to install a rear-facing

child restraint using the vehicle s eat belts in

the rear s eats:

SSS0100

Rear-fa cing — step 1

1. Child restraints for infants must be used

in the rear-facing direction and there-

fore must not be used in the front seat.

Position the ch ild re straint on the seat.

Always follow the restraint manufac-

turer’s instructions.

SSS0654

Rear-fa cing — step 2

2. Route the seat belt tongue through the

child r estraint and insert it into th e buckle

until you hear and feel the latch engage.

Be sure to follow the child restraint

manufacturer’s instructions for belt

routing.

SSS0655

Rear-facing — step 3

3. Pull the shoulder belt until the belt is fully

extended. At this t ime, the seat belt

retractor is in the Automatic Locking

Retractor (AL R) mode (child re straint

mode). It reverts to the Emergency

Loc king Retractor ( ELR) mode when

the seat belt is fully retracted.

SSS0656

Rear-facing — step 4

4. Allow the seat belt to retract. Pull up on

the shoulder belt to remove any slack in

the belt.

SSS0657

Rear-facing — step 5

5. Remove any additional slack from the

seat belt; press downward and re arward

firmly in the center of the child restraint

to compress the vehicle seat cushion and

se atback while pulling up on the seat

belt.

Safety — Seats, seat belts and supplemental restraint system 1-27

1-28 Safety — Seats, seat belts and supplemental restraint system

SSS0658

Rear-fa cing — step 6

6. After attaching the child restraint, test it

before you place th e child in it. Push it

from side to side while holding the child

restraint near the seat belt path. The

child restraint should not move more

than 1 inch (25 mm), fr om side to side.

Try to tug it forward and check to see if

the belt holds the restraint in place. If the

restraint is not secure, t ighten the seat

belt as necessary, or put the restraint in

another seat and test it again. You may

need to try a different child restraint. Not

all child restraints fit in all types of

vehicles.

7. Check to make sure that the child

restraint is properly secured prior to each

use. If the seat belt is not locked, repeat

steps 1 through 6.

After the child restraint is removed and the

seat belt fully retracted , the ALR mode (child

restraint mode) is canceled.

FORWARD-FACING CHILD RE-

STRAINT INSTALLATION USING

LATCH

Refer to all Warnings and Cautions in the

“Child safety” and “Child rest raints” sections

before installing a child restraint.

Do not use the l ower anchors if the com-

bined weight of the child and the child

restraint excee ds 65 lbs (29.5 kg). If the

combined weight of the child and the child

restraint is gre ater than 65 lbs (29.5 kg), use

t he vehicle’s seat belt (not the lower an-

chors) to install the child restraint. Be sure to

follo w the child restraint man ufacturer’ s

instructions for installation.

Follow these steps to install a forward-

facing child restraint using the LATCH

system:

1. Position the child restraint on the seat.

Always follow the child restraint manu-

facture r’s instructions.

SSS0645

Forward-facing w eb-mounted — step 2

2. Secure the child re straint anchor attach-

m ents to the LATCH lower anchors.

Check to make s ure the LATCH attach-

ment is properly attached to the lower

anchors.

If the child restraint is equipped with a

top tether strap, route the top tether

strap and secure the tether strap to the

tether anchor point. See “In stalling top

t ether strap” (P.1-30 ). Do not install

child restraints that require the use of a

top tether strap in seating positions that

do n ot have a top tether anchor.

SSS0646

Forward-facing rigid-mounted — step 2

3. The back of t he child restraint should b e

secured against the vehicle seatback.

If th e seating position does not h ave an

adjustable head restraint and it is inter-

fering with the proper child restraint fit,

try another seating position or a differ-

e nt child restraint.

SSS0647

Forward-facing — step 4

4. For ch ild restraints th at are equipped

with webbing- moun t ed attachments, re-

move any additional slack f rom the

anchor attachments. Press downward

and rearward firmly in the center of the

child restraint with your knee to com-

press the vehicle seat cushion and seat-

back while tightening the webbing of t he

anchor attachments.

5. Tighten the tether strap according to the

manufacturer’s instructions to remove

any slack.

Safety — Seats, seat belts and supplemental restraint system 1-29

1-30 Safety — Seats, seat belts and supplemental restraint system

SSS0638

Forward - facing — step 6

6. After attaching the child restraint, test it

before you place th e child in it. Push it

f rom side to side while holding the child

restraint near the LATCH attachment

path. The child restraint should not move

more than 1 inch (25 mm), from side to

side. Try to tug it forward and check to

see if the LATCH attachment holds the

restr aint in place. If the restraint is not

secure, tighten the LATCH attachment

as necessary, or put the r estraint in

another seat and test it again. You may

need to try a different child restr aint. Not

all child restraints fit in all types of

vehicles.

7. Check to make s ure the child restraint is

properly secured prior to each use. If the

child restraint is loose, repeat steps 1

through 6.

SSS0790

Installing top tethe r strap

WARNING

Child restraint anchorages are designed

to withstand only those loads imposed

by correc tly fitted child rest raints. Under

no circumstances are they to be used to

attach adult seat belts, or other items or

equipment to the vehicle. Doing so could

damage the child restraint anchorages.

The child restraint will not be properly

installed using the damaged anchorage,

and a child could be seriously injured or

killed in a collision.

T he child restraint top tether strap must b e

used when installing the child restraint with

the LATCH lower anchor attachments.

First, secure the child restraint with the

LATCH lower anchors (rear outboard seat-

ing positions only).

1. Flip up the anchor cover from the anchor

point which is located directly behind the

child restraint.

2. Position the top tether strap over the top

of the seatback.

3. Secure the tet her strap to the tether

anchor point on the rear parcel shelf.

4. Refer to the appropriate ch ild res t raint

installation procedure steps in this sec-

tion before tightening the tether strap.

If you have any questio ns when installing a

top tether strap, it is recommended you

visit an INFINITI retailer for this service.

FORWARD-FACING CHILD RE-

STRAINT INSTALLATION USING

THE SEAT BELTS

WARNING

The three - point sea t belt with Auto -

matic Locking Retractor (ALR) must be

used when inst alling a child restraint.

Failure to use the ALR mo de will result in

the child restraint not being properly

secured. The restraint could tip over or

be loose and cause injury to a child in a

sudden stop or collision. Also, it can

change the operation of the front pas-

senger air bag . See “Front passenger air

bag and status light” (P.1-46).

SSS0640

Forward-facing (front passenger seat) —

step 1

Refer to all Warnings and Cautions in the

“Child safety” and “Child restraints” sections

before installing a child restraint.

D o not use the lower anchors if the com-

bined weight of the child and the child

restraint exceeds 65 lbs (29.5 kg). If the

combined weight of the child and the child

restraint is greater than 65 lbs (29.5 kg), use

the vehicle’s seat bel t (not the lower an-

chors) to install the child restraint. Be sure to

follow the child restraint manufacturer’s

instructions for installation.

Follow these steps to install a forward-

facing child restraint using the vehicle seat

belt i n the rear sea ts or in the front

Safety — Seats, se at belts and suppleme nt al restraint system 1-31

1-32 Safety — Seats, seat belts and supplemental restraint system

passenger seat:

1. If you must install a child restraint in the

front seat, it should be placed in a

forward-facing direction only. Move

the seat to the rearmost position. Child

restraints for inf ants must be used in the

rear-facing direction and, therefore,

must not be used in the front seat.

2. Position the child restraint on the seat.

Always follow the child restraint manu-

facture r’s instructions.

The back of the child restraint should be

secured against the vehicle seatback.

If necessary, adjust or remove the head

restraint or headrest to obtain the

correct child restraint fit. If the head

restraint or headrest is removed, store it

in a secure place. Be sure to reinstall the

head restraint or headrest when the

child restraint is removed. See “Head

restraints/headrests ” (P.1-7) for head

restraint or he adrest adjustment, r e-

moval and installation information.

If the seating position does not have an

adju stable head restraint or headrest

and it is interfering with the prop er child

restraint fit, try another seating position

or a different child restraint.

SSS0360B

Forward- facing — step 3

3. Route the seat belt tongu e through the

child restraint and insert it into the buckle

until you hear and feel the latch engage.

Be sure to foll ow the c hild restraint

manufacturer’s instructions for belt

routing.

If the child restraint is equipped with a

top tether strap, route the top tether

strap and secure the tether strap to the

tether anchor point (r ear seat installation

only). See “Installing top tether strap”

(P. 1-34). Do not install child res t raints

that require the use of a top tether strap

in seating positions that do not have a

top tether anchor.

SSS0651

Forward- facing — step 4

4. Pull the shoulder belt until the belt is fully

extended. At this time, the seat belt

retractor is in the Automatic Locking

Retractor ( ALR) mode (child restraint

mode). It reverts to Emergency Locking

Ret ractor (ELR) mode when the seat belt

is fully retracted.

SSS0652

Forward-facing — step 5

5. Allow the seat belt to retract. Pull up on

the shoulder belt to remove any slack in

the belt.

SSS0653

Forward-facing — step 6

6. Remove any additional slack from the

seat belt; press downward and rearward

firmly in the center of the child restraint

with your knee to compress the vehicle

seat cushion and seatback while pulling

up on t he seat belt.

7. Tighten the tet her strap according to the

manufacturer’s instructions to remove

any slack.

SSS0641

Forward-facing — step 8

8. After attaching the child restraint, test it

befor e you place the child in it. Push it

f rom side to side while holding the child

restraint near the seat b elt path. The

child restraint should not move more

than 1 inch (25 mm), from side to side.

Try to tug it f or ward and check to see if

the belt holds the restraint in place. If th e

restraint is not secure, tighten the seat

belt as necessary, or put the restraint in

another seat and test it again. You may

need to try a different child restraint. Not

all ch ild restraints fit in all types of

vehicles.

9. Check to make sure the child re straint is

properly secure d prior to each use. If the

Safety — Seats, seat belts and supplemental restraint system 1-33

1-34 Safety — Seats, seat belts and supplemental restraint system

seat belt is not locked, repeat steps 2

through 8.

JVR0192X

Forward - facing — step 10

10. If the child restraint is installed in the

front passenger seat, place the ignition

switch in the ON position. The front

passenger air bag status light should

illuminate. If t his light is not illuminated,

see “Front passenger air bag and status

light” (P.1-46). Move the child restraint

to another seating position. Have the

system checked. It is recommended you

visit an INFINITI ret ailer for this service.

After the child restraint is removed and th e

seat belt is fully retracted, the ALR mode

(child restraint mode) is canceled.

SSS0790

Installing top tether strap

WARNING

Child res traint anchorages are designed

to withstand only those loa ds imposed

by correctly fitted child restraints. Under

no circumstances are they to be used to

attach adult seat belts, o r other items or

equipment to the vehicle. Do ing so could

damage the child restraint anchorages.

The child restraint will not be properly

installed using the damaged anchorage,

and a child could be s eriously injured or

killed in a collision.

T he child restraint top tether strap must b e

used when installing the child restraint with

t he seat belts.

First, secure the child restraint with the seat

belt.

1. Flip up the anchor cover from the anchor

point which is l ocated directly behind t he

child restraint.

2. Position the top tether strap over the top

of the seatback.

3. Secure the tet her strap to the tether

anchor point on the rear parcel shelf.

4. Refer to the appropriate ch ild res t raint

installation procedure steps in this sec-

tion before tightening the tether strap.

If you have any questio ns when installing a

top tether strap, it is recommended you

visit an INFINITI retailer for this service.

BOOSTER SEATS

Precau tions on booster seats

WARNING

If a booster seat and seat belt are not

used properly, the risk of a child be ing

injured or killed in a sudden stop or

collision greatly increases:

.Make sure the shoulder portion of

the belt is away from the child’s face

and neck and the lap portion of the

belt does not cross the stomach.

.Make sure the shoulder belt is not

behind the child or under the child ’s

arm.

.A booster seat must only be installed

in a seating position that has a lap/

shoulder belt.

LRS0455

Booster seats of various sizes are offered by

several manufacturers. When selecting any

booster seat, keep the following points in

mind:

.Choose only a booster seat with a label

certifying that it compl ies with Federal

Motor Vehicle Safety Standard 213 or

Canadian Motor Vehicle Safety Stan-

dard 213.

.Check the booster seat in your vehicle to

be sure it is compatible with the vehicle’s

seat and seat belt system.

Safety — Seats, seat belts and supplement al restraint system 1-35

1-36 Safety — Seats, seat belts and supplemental restraint system

LRS0453

.Make sure the child’s head will be

properly supported b y the booster seat

or vehicle seat. The seatback must be at

or above the center of the child’s ears.

For example, if a low back booster seat

is chosen, the vehicle seatback must be

at or above the center of the child’s ears.

If the seatback is lower than the cen t er

of the child’s ears, a high back booster

seat should be used.

LRS0464

.If the booster seat is compatible with

your vehicle, place you r child in the

booster seat and c heck the various

adjus t ments to be sure the booster seat

is compatible with your child. Always

follow all recommended procedures.

All U.S. states and Canadian provinces or

territories require that infants and sm all

children be restrained in an approved child

restraint at all times while the vehicle is

being operated.

The instructions in this section apply to

booster seat installation in the rear seats or

t he front passenger seat.

Booster seat installatio n

CAUTION

To avoid injury to child, do not use the

lap/shoulder belt Automati c Locking

Retractor (ALR) mode when using a

booste r seat with the seat belt s.

Refer to all Warnings and Cautions in the

“Child safety”, “Child restraints” and “Boos-

ter seats” sections earlier in this section

before installing a child restraint.

Follow these steps to install a booster seat in

th e rear seat or in the front passenger seat:

SSS0640

1. If you must install a booster seat in the

front seat, move the seat to the rear-

most position.

2. Position the booster seat on the seat.

Only place it in a f or ward -facing direc-

tion. A lways follow the booster seat

manufacturer’s instr uctions.

LRS0454

Front passenger position

3. The booster seat should be positioned on

the vehicle seat so that it is stable.

If necessary, adjust or remove the h ead

restraint or headrest to obtain the

correct booster seat f it. If the head

restraint or headrest is removed, store

it in a secure place. Be sure to reinstall

the head restraint or headres t when the

booster seat is removed. See “Head

re straint s/headrests” (P.1-7) f o r head

restraint or headrest adjustment, re-

moval and installation information.

If the seating position does not have an

adjustabl e head re strain t or h eadrest

and it is int erfering with the proper

booster seat fit, try another seating

position or a different booster seat.

4. Position the lap portion of the seat belt

low and snug on the child’s hips. Be sure

to follow the booster seat manufac-

turer’s instructions for adjusting the seat

belt routing.

5. Pull the shoulder belt portion of the seat

belt toward the retractor to take up

extra slack. Be sure t he shoulder belt is

positioned across the top, middle portion

of the child’s shoulder. Be sure to follow

t he booster seat manufacture r’s instruc-

tions for adjusting the seat belt routing.

6. Follow th e warnings, cautions and in-

structions for properly fastening a seat

b elt shown in “Seat belts” (P.1-11).

Safety — Seats, seat belts and supplemental restraint system 1-37

1-38 Safety — Seats, seat belts and supplemental restraint system

JVR0192X

7. If the booster seat is installed in the front

passenger seat, place the ignition switch

in the ON position. The front passenger

air bag status light may or may not

illuminate depe nding on the size of the

child and the type of booster seat used.

See “Front passenger air bag and status

light” (P.1-46).

PRECAUTIONS ON SUPPLE-

MENTAL RESTRAINT SYSTEM

T his Supplemental Restraint System (SRS)

section contains important information con-

cerning the following systems:

.Driver and passenger front-impact sup-

plemental air bags (INFINITI Advanced

Air Bag System)

.Front seat-mounted side-impact supple-

mental air bag

.Roof-mounted curtain side-impact and

rollover supplemental air bag

.Seat belt with pretensioner

Supplemental front-impact air bag system:

The INFINITI Advanced Air Bag System can

help cushion the impact force to the head

and chest of the driver and front passenger

in certain frontal collisions.

Front seat-mounted side-impact supple-

mental air bag system: This system can help

cush ion the impact force to the chest and

pelvis area of the driver and f ront passe nger

in certain side impact collisions. The side air

bag is designed to inflate on the side where

the vehicle is impacted.

Roof-mounted curta in side-impact and roll-

over suppl emental air bag system: This

system can help cushion the impact force

to the head of occupants in front and rear

outboard seating positions in certain side

impact or rollover collisions. In a side impact,

the curtain air bags are designed to inflate

on the side where the vehicle is impacted. In

a rollover, curtain air bags on both sides are

designed to inflate and re main inflated for a

short time.

Curtain air bags are also designed to inflate

in certain types of rollover collisions or near

rollovers. As a result, certain vehicle move-

ments may cause the curtain air bags to

inflate.

These supplemental restraint systems are

designed to the crash protectionsupplement

provided by the driver and passenge r seat

belts and are for them. Seatnot a substitute

belts should always be correctly worn and

the occupant seated a suitable d istance

away from the steering wheel, instrument

panel and door finishers. (See “Seat belts”

(P.1-11) for instructions and precautions on

seat belt usage.)

The supplemental air bags operate only

when the ignition switch is in the ON

position.

After placing the ignitio n switch in the ON

position, the supplemental air bag warning

light illuminates. The supplemental air bag

warning light will turn of f after about 7

seconds if the systems are operational.

SUPPLEMENTAL RESTRAINT SYSTEM

SSS0131B

SSS0132B

WARNING

.The front air bags ordinarily will not

inflate in the event of a s ide impact,

rear impact, rollover, or l ower sever-

ity frontal coll ision. Alw ays wear

your se at belts to help red uce the

risk or severity of injury in various

kinds of accidents.

.The front passenger air bag will not

inflate if the passenger air bag status

light is lit. See “Front passenger air

bag and status light” (P.1-46).

.The seat belts and the front air bags

are most effective when you are

sitting wel l back and upright in the

seat with both feet on the floor. The

front air bags inflate with great

force. Even with the INFINITI Ad-

vanced Air Bag System, if you are

unrestrained, leaning forward, sit ting

sideways or out of posit ion in any

way, you are at g reater risk of injury

or death in a crash. Y ou may al so

receive serious or fatal injuries from

the front air bag if you are up against

it when it infl ates. Always sit back

against the seatback and as far-away

as practical from the steering wheel

or instrument panel. Always use the

seat belts.

Safety — Seats, seat belts and supplemental restraint system 1-39

1-40 Safety — Seats, seat belts and supplemental restraint system

.The driver and front passenger seat

belt buckles are equipped wit h s en-

sors that detect if the seat belts are

fastened. The Advanced Air Bag

System monitors the severity of a

collision and seat belt usage then

inflates the air bags as needed. Fail-

ure to properly wear seat belts can

increase the risk or severity of injury

in an accident.

.The front passenger seat is equipped

with occupant c lassifica tion sensors

(weight sensors) that turn the front

passenger air bag OFF under some

conditions. These sensors are only

used in this seat. Failure to b e

properly seated and wearing the seat

belt can increase t he risk or severity

of injury in an accident. See “Front

passenger air bag and status light”

(P.1-46).

.Keep hands on the outside of the

steering wheel. Placing them inside

t he steering wheel rim could increase

the risk of injury if the front air bag

inflates.

SSS0007

SSS0006

SSS0008

SSS0009

SSS0099

SSS0100

WARNING

.Never let children ride unrestrained

or extend their hands or face out of

t he window. Do not attempt to ho ld

them in your lap or arms. Some

examples of dangerous riding pos i-

tions are shown in the illustrations.

.Children may be severely injured or

killed when the front air bags, side air

bags or curtain air bags inflate if they

ar e not properl y restrained. Pre-

teens and children should be properly

restrained in the rear seat, if possible.

.Even with the INFINITI Advanced Air

Bag System , never install a rear-

facing child restraint in the fr ont

se at. An inflating front air bag could

seriously injure or kill your child. See

“Child restraints” (P.1-19) for d etails.

SSS0059A

SSS0188A

Safety — Seats, seat belts and supplemental restraint system 1-41

1-42 Safety — Seats, seat belts and supplemental restraint system

SSS0140

SSS0162

SSS0159

WARNING

Front seat-mounted side-impact supple-

ment al air bags and roof-mounted cur-

t a i n s i d e - i m p a c t a n d r o l l o v e r

supplemental air bags:

.The side air bags ordinarily will not

inflate in the event of a front impact,

rear impact, rollover, or lower sever-

ity side collision. Always wea r your

seat belts to help reduce the risk or

severity of injury in various kinds of

accidents.

.The curtain air bags ordinarily will

not inflate in the event of a front

impact, rear impact, or lower severity

side collision. Always wear your seat

belts to help reduce the risk or

severity of injury in various kinds of

accidents.

.The seat belts, the side air bags and

curtain a ir bags are most effective

when you are sitting well back and

upright in the seat. The side air bag

and curtain air bag infla te with great

force. Do not a llow anyone to plac e

their hand, leg or face near the side

air bag on the side o f the seatback of

the front seat or nea r the side roof

rails. Do not allow anyone sitting in

the front seats or rear o utboard seats

to extend their hand out of the

window or lea n against the door.

Some examples of dangerous rid ing

positions are shown in the previous

illustrations.

.When sitting in the rear seat, do not

hold o nto the seatback of the front

seat. If the supplemental side air bag

inflates, you may be seriously injured.

Be especially careful with children,

who should always be properly re-

strained. Some examples of danger-

ous riding positions are shown in the

illustrations.

.Do not use seat covers on the front

seatbacks. They may interfere with

side air bag inflation.

Safety — Seats, se at belts and supplemental restraint system 1-43

1-44 Safety — Seats, seat belts and supplemental restraint system

JVR0507X

1. Crash zone sens or

2. Supplemental front air bag modu les

(INFINITI Advanced Air Bags)

3. Front seat-mounted side-impact sup-

plemental air bags

4. Roof-moun t ed cur t ain s ide-impact and

rollover supplemental air bags

5. Occupant classification sensors

(weight se nsors)

6. Occupant classification system control

unit

7. Roof-mount ed cur t ain side-impact and

rollover supplemental air bag inflators

8. Pressure s ensors in door

9. Satellite sensors

10. Seat belts with pretensioners

11. Air bag Control Unit (ACU)

12. Lap outer pretensioners

INFI NITI ADVANCED AIR BAG

SYSTEM (front seats)

WARNING

To ensure proper operation of the pas-

senger’s Advanced Air Bag System, ob-

serve the following items.

.Do not allow a passenger in the rear

seat to push or pull on the seatback

pocket.

.Do not place heavy loads heavier

than 9.1 lbs . (4 kg) on the seatback,

head restraint or in the se atback

pocket.

.Make sure that there is nothing

pressing against the rear of the seat-

back, such as a c hild restraint in-

stalled in the rear seat or an object

stored on the floor.

.Make sure that there is no object

placed under the front passenger

seat.

1-46 Safety — Seats, seat belts and supplemental restraint system

Front air bags, along with the use of seat

belts, he lp to cushion the impact force on the

head and chest of the front occupants. They

can help save lives and reduce serio us

injuries. However, an inflating front air bag

may cause facial abrasions or other injuries.

Front air bags do not provide restraint to the

lower body.

Even with INFINITI advanced air bags, seat

b elts should be correctly worn and the driver

and passenger sea ted uprig ht as far as

practical away from the steering wheel or

instrument panel . The f ront air bags inflate

quickly in order to help protect the front

occupants. Because of this, the force of t he

front air bag inflating can increase the risk of

injury if the occupant is too close t o, or is

against, the air bag module during inflation.

The front air bags defl ate quickly after a

collision.

The front air bags operate only when the

ignition switc h is in the ON position.

Af ter placing the ignition switch in the ON

position, the supplemental air bag warning

light illuminates. The supplemental air bag

warning light will turn off after about 7

seconds if the system is operational.

JVR0192X

Front passeng er air bag and status

light

WARNING

The front passenger air bag is designed

to automatically turn OFF under some

conditions. Read this section carefully to

learn ho w it operates. Proper use o f the

seat, seat belt and child restraints is

necessary for most effective protection.

Failure to follow all instructions in this

manual concerning the use of seats, seat

belts and child restraints can increase

the risk or severity of injury in an

accident.

Status light:

The fr ont pass enger seat is equipped with an

occupant classification sensors (weight sen-

sors) that turn the front passenge r air bag on

or off depending on the weight applied to

the front passenger seat. The status of the

fr ont passenger air bag (ON or OFF) is

indicated by the front passenger air bag

status light which is located on the

instrument panel.

After the ignition switch is placed in the ON

position, the front passenger air bag status

light illuminates for about 7 seconds and

then tu rns off or remains illuminated de-

pend ing on the front passenger seat occu-

pied s t atus. The light operates as follows:

CONDITION DESCRIPTION PASSENGER AIR BAG STATUS LIGHT

( ) FRONT PASSENGER AIR BAG STATUS

Empty Empty front passenger seat ON

(illuminated) INHIBITED

Nobody/Somebody Bag or Child or Child Restraint or Small

Adult in the front passenger seat

ON

(illuminated) INHIBITED

Adult Adult in the front passenger seat OFF

(dark) ACTIVATED

Safety — Seats, seat belts and supplemental restraint system 1-47

1-48 Safety — Seats, seat belts and supplemental restraint system

In addition to the above, certain objects

placed on the front passenger seat may also

cause the light to operate as described

above depending on their weight.

For additional information related to the

normal operation and troubleshooting of

this occupant classification sens or system,

please refer to “Normal operation” (P.1-49)

and “Troubleshooting” (P.1-50).

Front passenger air bag:

The fr ont passenger air bag is designed to

automatically turn OFF when the vehicle is

operated under some conditions as de-

scribed below in accordance with U.S.

regulations. If the front passenger air bag

is OFF, it will not inflate in a crash. The driver

air bag and other air bags in your vehicle are

not part of this system.

The purp ose of the regulation is to help

reduce the risk of injury or death from an

inflating air bag to certain f ront passenge r

seat occupants, such as children, by requiring

the air bag to be automatically turned OFF.

Certain sensors are used to meet the

requirements.

The occupant classification sensor in this

vehicle is a weight sensor. It is designed to

detect an occupant and objects on the seat

by weight. For example, if a child is in the

front passenger seat, the Advanced Air Bag

System is designed to turn the passenger air

bag OFF in accordance with the regulations.

Also, if a child restraint of the type specified

in the regulations is on the seat, its weight

and the child’s weight can be detected and

cause the air bag to turn OFF.

F ront passenge r seat adult occupants who

are properly seated and using the seat belt

as outlined in this manual should not cause

the passenger air bag to be automatically

turned OFF. For small adults it may b e

turned OFF, however, if the occupant takes

his/her weight off the seat cush ion (for

example, by not sitting upright, by sitting on

an edge of the seat, or by otherwise being

out of position), this could cause the sensor

to turn the air bag OFF. Always be sure to be

seated and wearing the se at belt properly

for the most effective protection by the seat

belt and supplemental air bag.

INFI NITI recommends that pre-teens and

children be properly restrained in a rear seat.

INFINIT I also recommends that appropriate

child restraints and booster seats be prop-

er ly installed in a rear seat. If this is not

possible, the occupant classification sensor

is designed to ope rate as described above to

turn the front passenger air bag OFF for

specified child restraints as required by t he

regulations. Failing to properly secure child

restraints and to use the ALR mode may

allow th e restraint to tip or move in a

collision or sudden stop. This can also result

in the passenger air bag inflating in a crash

instead of being OFF. For additional infor-

mation, refer to “Child restraints” (P.1-19)

for proper use and installation.

I f the front passenger seat is not occupied,

the passenger air bag is designed not to

inflate in a crash. However, heavy objects

pl aced on the seat could resul t in air bag

inflation, because of the object’s weight

detected by t he occupant c lassification

sens or . Other conditions could also result in

air bag inflation, such as if a child is standing

on the seat, or if two children are on the

seat, contrary to the instructions in this

manual. A lways be sur e that you and all

vehicle occupants are seated and restrained

properly.

Using the front passenger air b ag status

light, you can moni tor when the front

passenger air bag is automatically turned

OFF.

If an adul t occupant is in the seat but the

front passeng er air bag status light i s

illu minated (indicating that the air bag is

OFF), it could be that the person is a small

adult, or is not sitting on the s eat properly or

not using the seat belt properly.

If a child restraint must be used in the front

seat, the front passenger air bag status light

may or may not be illuminated, depending on

th e size of the child and the type of child

restraint be ing used. If the fr ont passenger

air bag status light is not illuminated (in-

dicating that the air bag might inflate in a

crash), it could be that the child restraint or

seat belt is not being used properly. Make

sure that the child restraint is installe d

properly, the seat belt is used properly and

the occupant is positioned proper ly. If the

front passeng er air bag status light is still not

illuminated, reposition t he occupant or child

restraint in a rear seat.

If the front passe nger air bag status light will

not illuminate even though you believe that

t he child restraint, the seat belt s and the

occupant are properly positioned, it is re-

commended that you take your vehicle to an

INFINITI retailer. An INFINITI retailer can

check system status by using a special tool.

However, until you have confirmed with

your retailer that your air bag is working

properly, reposition the occupant or child

restraint in a rear seat.

Th e INF INITI Advanced Air Bag System and

front passenger air bag status light will take

a few seconds to register a change in the

passenger seat status. This is normal system

operation and does not indicate a malfunc-

tion.

I f a malfunction occurs in the front passen-

ger air bag system, the suppl emental air bag

warning light , located in the meter and

gauges area of the instrument panel, will be

illuminated (blinking or steadily lit). Have t he

system checked. It is recommended you visit

an INFINITI retailer for this service.

Normal operation:

In order for the occupant classifica tion

sens or system to classify the front passen-

ger based on weight , plea se follo w the

precautions and steps outlined below:

Precautions

.Make sure that there are no objects

weighing over 9.1 lbs (4 kg) hanging on

the seat or placed in the seatback pocket.

.Make sure that a child restraint or other

object is not pressing against the rear of

the seatback.

.Make sure that a rear passenger is not

pushing or pulling on the back of the

front passenger seat.

.Make sure that the front passenger seat

or seatback is not forced back against an

object on the seat or floor behind it.

.Make sure that there is no object placed

under the front passenger s eat.

.Make sure that the front passenger seat

head restraint does not contact the roof

when adjusting the front passeng er seat.

Steps

1. Adjus t the seat as outlined in “Seats”

(P.1-2). Sit upright, leaning against the

seatback, and centered on the seat

cus hion with your feet comfortably ex-

te nded to the floor.

2. Make sure there are no objects on your

lap.

3. Fasten the seat belt as outlined in “Seat

belts” (P.1-11). Front passenger seat belt

buckle status is monitored by the occu-

pant classification sensor system, and is

u sed as an input to determine occupancy

status. So, it is highly re commende d that

the front passenger f aste ns his/her seat

belt.

4. Remain in this position for 30 seconds

allowing the system to cl ass ify the front

passenger before th e vehicle is put into

motion.

5. Ensure proper classification by checking

the front passenger air bag status light.

NOTE:

This vehicle’s occupant classification sensor

system generally keeps the class ification

locke d during driving, so it is important that

you confirm that the front passenger is

properly classified prior to driving. How-

ever, the occupant classificatio n sensor may

recalculate the weight of the occu pant

under some conditions (both while driving

and when stopped), so the front pa ssenger

seat occupant should continue to remain

seated as out lined above.

Sa fety — Seats, seat belt s and supplemental restraint system 1-49

1-50 Safety — Seats, seat belts and supplemental restraint system

Troubleshooting:

If you think the front passenger air bag

status light is incorrect:

1. If the light is ON with an adult occupying

t he fron t passenger seat:

. Occupant is a small adult - the air bag

status light is functioning as intended.

The front passenger air bag is sup-

pressed.

However, if the occupant is not a s mall

adult, then this may be due to the

following conditions that may be inter-

fering with the weight sensors:

. Occupant is not sitting upright, lean-

ing against the seatback, and cen-

tered on the seat cushion with his/her

feet comfor tably exte nded to the

floor.

. A child restraint or other object press-

ing against the rear of t he seatback.

. A rear passenger pushing or pulling on

the back of the front passenger seat.

. F or cing the front seat or seatback

against an object on the seat or floor

behind it.

. An object placed under the front

passenger seat.

. An object placed between the seat

cushion and center console or be-

tween the seat cushion and the door.

If the vehicle is moving, please come to a

stop when it is safe to do so. Check and

correct any of the above conditions.

Restart the vehicle and wait 1 minute.

NOTE:

A system check will be performed during

which the front passenger air bag status

l ight will re main lit for about 7 seconds

initially.

If the light is still ON after this, the

person should be advised not to ride in

the front passenger seat and the vehicle

sh ould be checked by an IN FIN ITI retailer

as soon as possible.

2. If the light is OFF with a small adult, child

or child restraint occupying the front

passenger seat:

This may be due to the following condi-

tions that may be interfering with t he

weight sensors:

. Small adult or child is not sitting

upright, leaning against the seatback,

and centered on the seat cushion with

his/her f eet comfortably extended to

the floor.

. The child restraint is not properly

installed as outlined in “Chi ld re-

straints” (P.1-19).

. An object weighing over 9.1 lbs (4 kg)

hanging on the s eat or placed in the

seatback pocket.

. A child restraint or other object press-

ing against the rear of t he seatback.

. A rear passenger pushing or pulling on

the back of the front passenger seat.

. F or cing the front seat or seatback

against an object on the seat or floor

behind it.

. An object placed under the front

passenger seat.

. An object placed between the seat

cushion and center console.

. The front passenger seat head re-

straint contacting the roof.

If the vehicle is moving, please come to a

stop when it is safe to do so. Check and

correct any of the above conditions.

Restart the vehicle and wait 1 minute.

NOTE:

A system check will be performed during

which the front passenger air bag status

l ight will re main lit for about 7 seconds

initially.

If the light is still OFF after this, the small

adult, child or child restraint should be

repositioned in the rear seat and the

vehicle should be checked by an INFINITI

retailer as soon as possible.

3. If the light is OFF with no front passen-

ger and no objects on the front passen-

ger seat, the vehicle should be checked

by an INFINITI retailer as soon as

1-52 Safety — Seats, seat belts and supplemental restraint system

.A cracked windshield should be re-

placed immediately by a qual ified

repair facility. A cracked windshield

could affect the function of the

supplemental air bag system.

*The SRS wiring harness connectors are

yel low and orang e for easy identifica-

tion.

When selling your vehicle, we request that

you inform the buyer about the front air bag

system and guide the buyer to the appro-

priate sections in this Owner’s Manual.

SSS0521

FRONT SEAT-MOUNTED SIDE-

IMPACT SUPPLEMENTAL AIR

BAG AND ROOF-MOUNTED

CURTAIN SIDE-IMPACT AND

ROLLOVER SUPPLEMENTAL AIR

BAG SYSTEMS

T he side air bags are located in the outs ide

of the seatback of the front seats. The

curtain air bags are located in the side roof

rails. All of the information, cautions and

warnings in this manual apply and must be

followed. The side air bags and curtain air

bags are designed to inflate in higher

severity side collisions, although th ey may

inf la te if the forc es in anoth er type of

collision are similar to those of a higher

severity impact. They are designed to inflate

on the side where the vehicle is impacted.

They may not inflate in certain side collisions.

Curtain air b ags are also designed to inflate

in certain types of rollover collisions or near

rollovers. As a result, certain vehicle move-

ments may cause the curtain air bags to

inflate.

Vehicle damage ( or lack of it) is not always

an indication of proper supplemental s ide air

bag and curtain side-impact air bag opera-

tion.

When side air bags and curtain air bags

inflate, a fairly loud noise may be heard,

followed by release of smoke. This smoke is

not h armfu l and does not indicate a fire.

Care should be taken not to inhale it, as it

may cause irritation and choking. Those with

a history of a breathing condition shoul d get

fresh air promptly.

Side air bags , along with the use of seat

belts, he lp to cushion the impact force on the

chest of the front occupants. Curtain air

bags help to cushion the impact force to the

head of occupants in the fr on t and rear

outboard seating positions in all rows. They

can h elp save lives and reduce serious

injuries. However, an inflating s ide air bags

and curtain air bags may cause abrasions or

other injuries. Side air bags and curtain air

bags d o not provide restraint to the lower

body.

The seat belts should be correctly worn and

the driver and passenger seated upright as

far as practical away from the side air bag.

Rear seat pass engers should be seated as far

away as practical from the door f inishers

and side roof rails. The side air bags and

curtain air bags inflate quickly in order to

help protect the occupants. Because of this,

the force of the side air bags and curtain air

bags inflating can increase the risk of injury if

the occupant is too close to, or is against,

these air bag modules during inflation. In a

rollover, the curtain air bags on both sides

are de signed to inflate. Under both side-

impact situations, the cur t ain air bags will

remain inflated for a short period of time.

The side air bags and curtain air bags

operate only when the ignition switch is in

the ON positio n.

After placing the ignition switch in the ON

position, the supplementa l air bag warning

light illuminates. The air bag warning light

will turn off after about 7 seconds if the

systems are o perational.

WARNING

.Do not place any objects near the

seatback of the front sea ts. Also, do

not place any objects (an umbrella,

bag, etc.) betwe en the door finisher

and the front seat. Such obje cts may

become dangerous projectiles and

ca use injury if sid e air bag inflates.

.Right after inflation, several side air

bags and curtain air bag s ystem

compone nts will be hot. Do not touch

them; you may severely burn your-

self.

.No unauthorized changes should be

made to any components or wiring o f

side air bag and curtain air bags. This

is to prevent damage to or accidental

inflation of the side air bag and

curtain air bag systems .

.Do not make unauthorized changes

to your vehicle’s electrical system,

suspension system or side panel. This

could affect proper operation of the

side air bag and curtain air bag

systems.

.Tampering with the air bag system

may result in serious personal injury.

For example, do not change the front

seats by placing material near the

seatbac k or by instal ling additional

trim material , such as s eat covers,

around the side air bags.

.It is recommended you visit an

INFINITI retaile r for work on and

around the side air bag and curt ain

air bag. It is also recommended you

visit an INFINITI retailer for installa-

tion of electrical equipment. The

Supplemental Restraint System

(SRS) wiring harnesses* should not

be modified or disconnected. Un-

authorized electrical test equipment

and probing de vices should not be

used on the side-impact air bag

system.

*The SRS wiring harness connectors are

yellow and orange for easy identif ica-

tion.

When selling your vehicle, we request that

you inform the buyer about the side air bag

and curtain air bag systems and guide the

buyer to the appropriate sections in this

Owner’s Manual.

Safet y — Seats, seat belts and supplemental restraint system 1-53

1-54 Safety — Seats, seat belts and supplemental restraint system

SEAT BELTS WITH PRETEN-

SIONERS (front seats)

WARNING

.The pretensioners cannot be reused

after activation. They must be re-

placed together with the retractor

and buckle as a unit.

.If the vehicle becomes involved in a

collision but a pretensioner is not

activated, be sure to have the pre-

tensioner system checked and, if

necessary, replaced. It is recom-

mended you visit an INFINITI retailer

for this s ervice.

.No unauthorized changes should be

made to any compo nents or wiring of

the pretensioners. This is to prevent

damage to or accid ental activation of

the pre tens ioner system. Tampering

with the pretensioner system may

result in serious personal injury.

.It is recommended you visit an

INFINITI retail er for work on and

around the pretensioner system. It is

also recommended you visit an

INFINITI retailer for installation of

electrical equipment. Unauthoriz ed

electrical t est equipment and probing

devices should not be used on the

pretensioner system.

.If you need to dispose of the preten-

sioner or scrap the vehicle, it is

recomm ended you visit an INFINITI

retailer for this service. Correct pre-

tensioner disposal procedures are set

fo rth in the appropriate INFINITI

Service Manual. Incorrect disp osal

procedures could cause personal in-

jury.

.If there is an impact to your vehicle

from any direction, your Occupant

Classification Sensor (OCS) should be

checked. It is recommended an

INFINITI retailer performs this ser-

vice to verify it is still functioning

correctly. The OCS should be checked

even if no air bags deploy as a result

of the impact. Failure to verify proper

OCS function may result in an im-

proper air bag deployment result ing

in injury or dea th.

The pretensioner system may activate with

the supplemental air bag system in certain

types of collisions. Working with the seat

belt retractor, it helps tighten the seat belt

when the vehicle be comes involved in certain

types of collisions, helping to restrain front

seat occupants.

The pretensioner is encased with the seat

belt r etractor. T hese seat belts are used the

same way as conventional s eat belts.

When a pretensioner seat belt activates,

smoke is released and a loud noise may be

heard. The smoke is not harmful, and it does

not indicate a fire. Care should be taken not

to inhale it as it may cause irritation and

choking. Those with a history of a breathing

cond ition should get fres h air promptly.

After pretensioner activation, load limiters

allow the seat be lt to rele ase webbing (if

necessary) to reduce forces against the

chest.

The supplemental air bag warning light

is used to indic ate malfunctions in the

pretensioner system. (See “Su pplemental

air bag warning light” (P.1-55) for more

details.) If the operation of the supplemental

air bag warning light indicates there is a

malfunction, have the syste m checked. It is

recommended you visit an INFINITI retailer

for this service.

When selling your vehicle, we request that

you inform the buyer about the seat belt

pretensioners and guide the buyer to the

appropriate sections in this Owner’s Manual.

SSS1016

SUPPLEMENTAL AIR BAG

WARNING LABELS

Warning labels about the supplemental

front-impact air bag systems are placed in

the vehicle as shown in the illust ration.

SRS ai r bag

The warning labels are located on the

surface of the sun visors.

WARNING

Do not use a rear-facing child restraint

on a sea t protected by an air bag in front

of it. If the air bag de ploys, it may cause

serious injury or dea th.

SPA1097

SUPPLEMENTAL AIR BAG

WARNING LIGHT

Th e supplemental air bag warning light,

displaying in the instrument panel,

monitors the circuits for the air bag systems,

pretensioners and all related wiring.

W hen the ig nition switch is in the ON

position, the supplemental air bag warning

light illuminates for about 7 s econds and

then turns off. This means the SRS air bag

systems are operational.

If any of the following conditions occur, the

air bag and/or pretensioner systems need

servicing:

Safety — Seats, seat belts and supplemental restraint system 1-55

1-56 Safety — Seats, seat belts and supplemental restraint system

.The supplemental air bag warning light

remains on after approximately 7 sec-

onds.

.The supplemental air bag warning light

flashes intermittently.

.The supplemental air bag warning light

does not come on at all.

Under these conditions, the air bag or

pretensioner systems may not operate prop-

erly. They must be checked and repaired. It is

recommended you visit an INFI NITI retailer

for this service.

WARNING

If the supplement al air bag warning light

is on, it could mean that the front air

bag, side air bag, curtain air bag and/or

pretensioner systems will not operate in

an accident. To help avoid injury to

yourself or others, have your ve hicle

checked as soon as pos sible. It is recom-

mended you visit an INFINITI retail er for

this service.

REPAIR AND REPLACEMENT

PROCEDURE

T he front air bags, s ide air bags, curtain air

ba gs and pretensioners are designed to

activate on a one-time-only basis. As a

reminder, unless it is damaged, the supple-

mental air bag warning light will remain

illuminated after inflation has o ccurred.

These systems should be re paired and/or

replaced as soon as possible. It is recom-

mended you visit an INFINITI retailer for this

service.

When maintenance work is required on the

vehicle, the front air bags, side air bags,

curtain air bags, pretensioners and related

parts should b e pointed out to th e person

conducting the maintenance. The ignition

switch should always be in the LOCK

position when working under the hood or

inside th e vehicle.

WARNING

.Once a front air bag, side air bag, or

curtain air bag has inflated, the air

bag module will not function again

and must be replaced. Additionall y,

the activated pretensioner m ust a lso

be replaced. The air bag module and

pretensio ner should be replaced. It is

recomm ended you visit an INFINITI

retailer f or this service. Howe ver, the

air bag module and pretensioner

system cannot be repaired.

.The front air bag, side air bag, curtain

air bag and the pret ensioner system

should be inspected if there is any

damage to the front end or side

portion of the vehicle. It is recom-

mended you visit an INFINITI retailer

for this service.

.If you need to dispose of the supple-

m ental air bag or prete nsioner o r

scrap the vehicle, it is recommended

you visit an INFINIT I retailer. Correc t

supplemental air ba g and seat bel t

pretensioner syste m disposal proce-

dures are set forth in the appropriate

INFINITI Service Manual. Incorrect

disposal procedures could cause per-

sonal injury.

.If there is an impact to your vehicle

from any direction, your Occupant

Classification Sensor (OCS) should be

checked by an INFINIT I re tail er to

verify it is still functioning correctly.

The OCS should be checked even if no

air bags deploy as a res ult of the

impact. Failure to verify proper OCS

function may result in an imprope r air

bag deplo yment result ing in injury or

death.

Safety — Seats, seat belts and supplemental restraint system 1-57

1-58 Safety — Seats, seat belts and supplemental restraint system

MEMO

2 Instruments and controls

Cockpit ................................................................................. 2-3

Instrument panel ............................................................... 2-5

Meters and gauges .......................................................... 2-6

Speedometer and odometer ..................................... 2-7

Tachometer ................................................................... 2-8

Engine coolant temperature gauge ......... .............. 2-8

Fuel gauge ..................................................................... 2-9

Compass (if so equipped) ............................................... 2-9

Zone variation change procedure ......................... 2-11

Warning lights, indicator l ights and audible

reminders ........................................................................... 2-12

Checking lights ........................................................... 2-12

Warning lights ............................................................ 2-12

Indicator lights ........................................................... 2-18

Audible reminders ..................................................... 2-19

Vehicle information display .......................................... 2-20

Indicators for operation .......................................... 2-23

Indicators for maintenance .................................... 2-26

Trip computer ............................................................. 2-29

Clock and outside air temperature ............. .......... 2-31

Security systems ............................................................. 2-32

Vehicle Security System .......................................... 2-32

INFIN ITI Vehicle Immobilizer System .......... ........ 2-33

Wiper and washer switch ............................................ 2-34

Rain-s ensing auto wiper system

(if so equipped) ........................................................ 2-36

Rear window and outside mirror defroster

switch ................................................................................ 2-37

Headlight and turn signal switch .................. ............. 2-38

Headlight switch ..................................................... 2-38

Turn signal switch ................................................... 2-43

Fog light switch ...................................................... 2-44

Horn .................................................................................. 2-44

Vehicle Dynamic Contr ol (VDC) OFF switch ......... 2-45

Heated seats (if so equipped) .... .............. ................... 2-45

Operation with switch ........................................... 2-46

Operation with touch scre en .. ................... .......... 2-46

AUTO mode setting ............................................... 2-46

Heated steering wheel (if so equipped) ............ ....... 2-47

Power outlets .................................................................. 2-47

Storage ............................................................................ 2-48

Cup holders .............................................................. 2-48

Soft bottle holder .................................................... 2-49

Sunglasses holder .................................................... 2-49

Glove box .................................................................. 2-50

Console box ............................................................. 2-50

Card holder ................................................................. 2-51

Storage box ................................................................ 2-51

Coat hooks .................................................................. 2-51

Trunk hooks ................................................................ 2-52

Windows ........................................................................... 2-52

Power windows ......................................................... 2-52

Moonroof (if so equipped) ........................................... 2-55

Power moonroof ....................................................... 2-55

Interior lights .................................................................... 2-57

Map lights ................................................................... 2-57

Console light (if so equipped) ................................ 2-57

Interior light control switch ........ ................... ......... 2- 57

Vanity mirror lights ........................................................ 2-58

Trunk light ........................................................................ 2-59

Courtesy light .................................................................. 2-59

HomeLink

®

Universal Transceiver

(if so equipped) ............................................................... 2-59

Programming HomeLink

®

.................................... 2-60

Programming HomeLink

®

for Canadian

customers and gate openers .................. ............. 2-61

Operating the HomeLink

®

Universal Transceiver ............................................. 2-62

Programming troubleshooting .................. .......... 2-62

Clearing the programmed information ............ . 2-62

Reprogramming a single

HomeLink

®

button .................................................. 2-62

If your vehicle is stolen .......................................... 2-63

WAA0093X

1. Side ventilator (P.4-34)

2. Head light, f og light and turn signal

switch (P.2-38 )

3. Steering wh eel

— Horn (P.2-44)

— Driver supplemental air bag (P.1-38)

— Heated steering wheel (if so

equipped) (P. 2-47)

— Power steering (P.5-124)

4. Windshield wiper and washer switch

(P.2-34)

5. Hazard warning flasher switch (P.6-2)

6. Shift lever (P.5-16)

7. INFINITI control ler*

8. Vehicle Dynamic Contr ol (VDC) OFF

switch (P.2-45, P.5-129)

9. Trunk lid release switch ( P.3-23)

10. Instrument brightness control switch

(P.2-43)

11. TRIP/RE SET switch for twin trip od-

ometer (P.2-7)

12. Electric tilting/telescopic steering

wheel switch (P.3-27)

13. Manual tilting/telescopic steering

wheel lever (P.3-27)

14. Steer ing-wheel-mounted controls (left

side)

— A udio control steering switch*

— Hands-Free Phone System switch*

— Voice recognition system switch*

15. Steering-wheel-mounted controls

(right side)

— Trip computer switch (P.2-29)

— Cruise control switches (if so

equipped) (P. 5-66)

— Intelligent Cruise Control (ICC)

s witches (if so equipped) (P.5-68)

— Dynamic driver assistance switch (if

so equipped) (P. 5-25, P.5-45, P.5-89)

16. INFINITI Drive Mode Selector (P.5-21)

Instruments and controls 2-3

COCKPIT

2-4 Instruments and controls

*: Refer to the INFINITI InTouch

TM

Own-

er’s Manual.

JVC0969X

1. Paddle shifter (if so equipped) (P.5-18)

2. Meter s and gauges (P.2-6)

— Clock (P.2-31)

3. Push-button ignition switch (P.5-11)

4. Center ventilator (P.4-34)

5. Heater and air conditioner control

(P.4-34)

6. Upper touch screen display* (upper

d isplay) and Navigation system* (if so

equipped)

— RearView Monitor (if s o equipped)

(P.4-3)

— Around View

®

Monitor (if so

equipped) (P.4-11)

7. Lower touch screen d ispla y* (lower

display)

8. Rear window and outside mirror

defroster switch (P.2-37)

9. Front passenge r supplemental air bag

(P.1-38)

10. Hood release handle (P.3-22)

11. Fuse box cover (P.8-17)

12. Parking brake (P.5-20)

13. Storage box (P.2-51) and power outlet

(P.2-47)

14. Seat heater switch (if so equipped)

(P.2-45)

15. Audio system*

16. Trunk release power cancel switch

(P.3-24)

17. Glove box (P.2-50)

*: Refer to the INFINITI InTouch

TM

Own-

er’s Manual.

Instruments and controls 2-5

INSTRUMENT PANEL

2-6 Instruments and controls

JVC0428X

1. Tachometer* (P.2-8)

2. Warning and indicator lights (P.2-12)

3. Speedometer* (P.2-7)

4. Engine coolant temperature gauge*

(P.2-8)

5. Vehicle information display (P.2-20)/

Odometer/twin trip odometer (P. 2-7)

6. Fuel gauge* (P.2-9)

*: The needle indicators may move slightly

aft er the ignition swit ch is placed in the

OFF position. This is not a malfunctio n.

CAUTION

.For cleaning, use a soft cloth, dam-

pene d with water. Never use a rough

cloth, alcohol, benzine, thinner or any

kind of solvent or paper towel w ith a

chemica l cleaning agent. They will

scratch or cause discoloration to the

lens.

.Do not spray any liquid such as water

on the meter lens. Spraying liquid

may cause the system to malfunction.

METERS AND GAUGES

JVI0636X

Speedometer

SPEEDOMETER AND OD-

OMETER

Speedometer

The speedometer indicates vehicle speed in

miles per hour ( MPH) and kilometers pe r

hour (km/h).

JVI0637X

Odometer/twin trip odo m eter

Odomete r/twin trip odometer

The odometer and twin trip odometer

are displayed in the vehicle information

display when t he ignition switch is in the

ON position.

The odometer records the total distance t he

vehicle has been driven.

The twin trip odometer records the distance

of individual trips.

Changing the display:

Pushing the TRIP RESET switch under the

combination meter panel changes the dis-

play as follows:

TRIP A TRIP B TRIP A? ?

Resetting the trip odomete r:

Pushing the TRIP RESET switch for more

than 1 second resets the t rip odometer to

zero.

Instruments and controls 2-7

2-8 Instruments and controls

WAC0191X

TACHOMETER

The tachometer indicates engine speed in

revolutions per minute (RPM). Do not rev

the engine into t he red zone .

CAUTION

When engine speed a pproaches the red

zone, shift to a higher gear or reduce

engine speed. Operating the engine in

the red zone may cause serious engine

damage.

JVI0639X

ENGINE COOLANT TEMPERA-

TURE GAUGE

The gauge indicates the engi ne coolant

temperature.

The engine coolant temperature is within the

normal rang e when the gauge ne edle points

within the zone shown in the illustration.

Th e engine coolant t emperature varies with

the outside air tem perat ure and driving

conditions.

CAUTION

If the gauge indicates the engine co olant

temperature is near the hot (H) end of

the normal range, reduce vehicle speed

to decrease the temperature. If the

gauge is over the normal range, stop

the vehicle as soon as safely possible and

let the engine idle. I f the engine is

overheated, continued operation of the

vehicle may seriously damag e the engine.

See “If your vehicle overheats” (P.6-13)

for immediate action required .

JVI0640X

FUEL GAUGE

The gauge indicates the fuelapproximate

level in the tank.

The gauge may move slightly during braking,

turning, acceleration, or going up or down

hills.

The gauge needle re t urns to “0” (Empty)

after the ignition switch is placed in the OFF

position.

Refill the fuel tank before the gauge

registers “0” (Empty).

The low fuel warning light illuminates on

the meter when the fuel level is getting low.

Refuel as soon as it is convenient, preferably

before t he gaug e reaches “0”. There will be a

small reserve of fuel in the tank when the

fuel gauge needle reaches “0”.

The indicates that the fuel-filler door is

located on the right side of the vehicle.

CAUTION

.If the vehicle runs out of fuel, the

malfunction indicator light (MIL) may

come on. Refuel as soon as possible.

After a few driving trips, the

light should turn off. If the light

remains on after a few driving trips,

have the vehicle inspected. It is

recommended you visit an INFINITI

retailer for this se rvice.

.For additional information, see “Mal-

function Indicator Light (MIL)” (P.2-

18).

SIC3181

When the ignition switch is pushed to the

ON position, the compass display will

indicate the direction of the vehicle’s head-

ing.

If the display reads “C”, calibrate the com-

pass by driving the vehicle in 3 complete

circles at less than 5 MPH (8 km/h). You can

also calibrate the compass by d riving your

Instruments and controls 2-9

COMPASS (if so equipped)

2-10 Instruments and controls

vehicle on your everyday route. The compass

will be calibrated once it has tracked 3

complete circles.

To turn on and off the compass manually,

push the switch while the ignition

switch is in the ON position.

SIC0611B

Zone map

ZONE VARIATION CHA NGE

PROCEDURE

The difference between magnetic north and

geographical north is known as variance. In

some areas, this difference can sometimes

be great enough to cause false compass

readings. Follow t hese instructions to set the

variance for your particular l ocation if this

happens:

1. Push the switch for more than 3

seconds. The current zone number will

appear in the display.

2. Find your curre nt location and variance

number on the zone map.

3. Push the switch repeatedly u ntil the

new zone number appears in the display,

then release the switch. After you re-

lease the switch, the display will show a

compass direction within a few seconds .

. If the compass deviates from the

correct indication soon after repeated

adjustment , it is recommended you

have the compa ss checked at an

INFINITI retailer.

. The compass may not indicate the

correct compass point in tunnels or

while driving up or down a steep hill.

(The compass r eturns to th e correct

compass point when the vehicle

moves to an area where the geomag-

netism is stabilized.)

CAUTION

.Do not install a ski rack, antenna,

etc., which are attached to the vehi-

cle by means of a magnet. They affect

t he operation of the compass.

.When cleaning the mirror, use a paper

towel or similar material dampe ned

with glass cleaner. Do not spray glass

cleaner directly on the mirror as it

may cause the liquid cleaner to enter

the mirror housing.

Instruments and controls 2-11

2-12 Instruments and controls

Anti-lock Braking System (ABS) warning

light Power steering warning light High beam assist indicator light (if so

equipped)

Brake war n ing light

Seat belt warning light and chime High beam indicator light

Suppl emental air bag warning light Malfunction Indicator Light (MIL)

Charge warning light Vehicle Dynamic Control (VDC) warning

light Secur ity indicator light

Forward Emergency Braking (FEB) sys-

tem warning light (if so equipped) ECO drive indicator light Turn signal/hazard indicator lights

Low fuel warning light Exterior light indicator Vehicle Dynamic Control (VDC) off in-

dicator light

Low tire pressure warning light Front fog light indicator light

Master warning light Front passenger air bag status light

CHECKING LIGHTS

With all doors closed, apply the parking

br ake, fasten the seat belts and place the

ignition switch in the ON position without

starting the engine. The following lights (if

so equipped) will come on:

, or , , ,

The following lights (if so equipped) will

come on briefly and then go off:

, or , , , ,

If any light does not come on or operates in a

way oth er than described, it may indicate a

burned-out bu lb and/or a system malfunc-

tion. It is recommended you have the system

checked by an INFINITI retailer.

Some indicators and warnings are also

displayed in the vehicle information display

between the speedometer and tachometer.

(See “Vehicle information display” (P.2-20).)

WARNING LIGHTS

or A nti-lock Braking

System (ABS) warning light

When the ignition switch is in the ON

position, the Anti-lock Braking System

(ABS) warning light illuminates and then

turns off. Th is indicates the ABS is opera-

tional.

If the ABS warning light illuminates while the

engine is running, or while driving, it may

indicate the ABS is not functioning properly.

Have th e system ch ecked. It is recommended

WARNING LIGHTS, INDICATOR

LIGHTS AND AUDIBLE REMINDERS

you visit an INFINITI retailer for this service.

If an ABS malfunction occurs , th e anti-lock

function is turned off. Th e brake system then

operates normally, but without an ti-lock

assistance. (See “Brake system” (P.5-126).)

o r Brake warn i ng ligh t

This light functions for both the parking

brake and the foot brake systems.

Parking brake indicator:

When the ignition switch is in the ON

position, the light com es on when the

parking brake is applied.

Low brake fluid warning light:

When the ignition switch is in the ON

position, the light warns of a low brake fluid

l evel. If the light comes on while t he engine is

r unning with the parking brake not applied,

stop the vehicle and perform the fol lowing:

1. Check the brake fluid level. If brake fluid

is ne cessary, add f luid and have the

system checked. It is recommended you

have this service performed by an

INFINITI retailer. (See “Brake fluid”

(P.8-9).)

2. If the b rake fl uid level is correct, have the

warning system checked. It is recom-

mended you have this se rvice performed

by an INFIN ITI retailer.

Anti-lock Braking System (ABS) warning

indicator:

When the parking brake is re leased and the

brake fluid le vel is sufficient, if both th e

brake warning light and the Anti-lock Brak-

ing System (ABS) warning light illuminate, it

may indicate the ABS is not functioning

properly. Have the brake s ystem checked,

and if necessary repaired. It is recommended

you visit an INFINITI retailer for this service.

(See “Anti-lock Braking System (ABS) warn-

ing light” (P.2-12).)

WARNING

.Your brake system may not be work-

ing properly if the warning light is on.

Driving could be dangerous. If you

judge it to be saf e, drive carefully to

the nearest service station for re-

pairs. Otherwise , have your vehicle

towed because driving it could be

dangerous.

.Pressing the brake pedal with the

en gine stopped and/or low brake

fluid level may increase your stopping

distance and braking will requi re

greater pedal effort as well as pedal

travel.

.If the brake fluid level is below the

minimum or MIN mark on the brake

fluid res ervoir, do not drive until the

brake system has been checked. It is

recomm ended you visit an INFINITI

retailer f or this service.

Charge warning light

If the light comes on while the engine is

running, it may indicate the charging system

is not functioning prop erly. Turn the engine

off and check the alternator belt. I f the belt is

loose, broken, missing or if the light remains

on, have your vehicle serviced immediately. It

is recommended you visit an INF INITI re-

tailer for this service.

CAUTION

Do not continue driving if the alternator

bel t is loose, broken or missing.

Forward Emergency Braking

(FEB) system warning light (if so

equipped)

This light comes on when the ignition switch

is placed in the ON position. It turn s off after

the engine is started.

Instruments and controls 2-13

2-14 Instruments and controls

This light illuminates when the FE B with

ped estrian de t ection system is set to OFF on

the lower display.

If the light illuminates when the FEB with

pedestrian detection system is ON, it may

indicate that the system is unavailable. See

“Forward Emergency Braking (FEB) with

pedestrian detection system” (P.5-100) for

more details.

Low fu el warning light

This light illuminates when the fuel in the

tank is getting low. Refuel as soon as it is

convenient, preferably b efore the fuel gauge

reaches the 0 (empty) position.

There will be a small reserve of fuel remain-

ing in the tank whe n the fuel gauge reaches

the 0 position.

Low tire pressure war ning light

Your vehicle is equipped with a Tire Pr essure

Monitoring System (TPMS) that monitors

the tire pressure of al l tires except the spare

tire ( if so equipped).

The low tire pressure warning light warns of

low tire pressure and flat tire (if so equipped)

or indicates that the TPMS is not functioning

properly.

After the ignition switch is placed in the ON

position, this light illuminates for about 1

second and turns off.

Low tire press ure warning:

If the vehicle is being driven with low tire

pressure, the warning light will illuminate.

The “Tire Pressure Low - Add Air” warning

also appears in the vehicle information dis-

play.

When the low tire pressure warning light

illuminates, you should stop and adjust the

tire pressure to the recommended COLD tire

pressure shown on the Tire and Loading

Information label . The low t ire pressure

warning light does not automatically turn

off when the tire pressure is adjusted. After

the tire is inflated to the rec ommended

pressure, the vehicle must be driven at

speeds above 16 MPH (25 km/h) to activate

the TPMS and turn off the low tire pressu re

warning light. Use a tire p ressure gauge to

check the tire pre ssure.

The “Tire Pressure Low - Add Air” warning is

active as long as the low tire pr essure

warning l ight remains illuminated.

For addi tiona l informa tion, see “Vehicle

information display” (P.2-20), “Tire Pressure

Monitoring System (TPMS)” (P.5-5) and

“Tire Pressure Monitoring System (TPMS)”

(P.6-3).

Flat tire warning (if so equipped):

The flat tire warning warns of a flat tire.

If the vehicle is being driven with one or more

flat tires, the low tire pressur e warning light

will illuminate continuously and a chime will

sound for 10 seconds. A “Flat Tire - Visit

dealer” warning also appears in the vehicle

information display.

The chime will o nly so und at the first

indication of a flat tire and the warning light

will illuminate continuously. When the flat

tire warning is activated, have the system

reset and the tire checked, and replaced if

necessary. It is recommended you visit an

INF INITI r etailer for these services. Even if

the tire is inflated to the specified COLD t ire

pressure , the warning light will continue to

illuminate until the system is re set by an

INFINITI retailer.

Y our vehicle can be d riven for a limited time

on a flat tire. See “Run-flat tires” (P.6-4).

TPMS malfunction:

If the TPMS is not functioning properly, the

low tire pressur e warning light will flash for

approximately 1 minute when the ignition

switch is placed in the ON position. Th e light

will remain on after the 1 minute. Have the

system checked. It is recommended you visit

an I NFI NITI retailer for this service. The “Tire

Pressure Low - Add Air” warning does not

appear if the low tire pressure warning light

illuminates to indicate a TPMS malfunction.

For additional information, see “Tire Pres-

sure Monitoring System (TPMS)” (P.5-5).

WARNING

.Radio waves could adversely affect

electric medical equipment. Those

who use a pacemaker should contact

the electric medic al equipment man-

ufacturer for the possible influence s

before use.

.If the light does not illuminate with

the ignition switch pushed ON, have

the vehicle checked as soon as possi-

ble. It is reco mmended you visit an

INFINIT I retailer for this s ervice.

.If the light illuminates while driving,

avoid sudden steering maneuvers or

abrupt braking, reduce vehicle speed,

pull off the road to a safe location

and stop the vehicle as soon as

possible. Driving with under-inflated

tires may permanently damage the

tires and increase t he likelihood of

tire failure. Serious vehicle damage

could occu r and may lead to an

accident and could result in serious

personal injury. Check the tire pres-

sure for all four tires. Adjust the tire

pressure to the recommended COLD

tire pressure shown on the Tire and

Load ing Information label to turn the

low tire pressure warning light OFF.

If the light still illuminates while

driving after adjus ting the tire pres-

sure, a tire may be flat or the TPMS

may be malfunctioning. If you have a

flat tire, replace it with a spare tire (if

so equipped) or repair it with the

emergency t ire puncture repair kit (if

so equipped) as soon as possible. If no

tire is flat and all tires are properly

inflated, it is recomme nded you con-

sult an INFINITI reta il er.

.For models with run-flat tires,

although you can continue driving

with a punctured run-fl at tire, re-

member that vehicle handling stabi-

lity is reduced, w hich could lead to an

accident and perso nal injury. Also,

driving a long dist ance at high speeds

may damage the tires.

— Do not drive at speeds above 50

MPH (80 km/h) and do not drive

more than approximately 93 miles

(150 km) with a punctured run-

flat tire. The actual distance the

ve hicle can be driven on a flat tire

depends on outside temperature,

vehicle load, road cond itions and

other factors.

— If you detect any unusual sounds

or vibrations while d riving with a

punctured run-flat tire, pull of f

the road to a safe location and

stop the vehicle a s soon as possi-

ble. The tire may be seriously

dam aged and ne ed to be replaced.

.Since the spare tire is not equipped

with the TPMS, when a spare tire is

mo unted or a wheel is replaced, the

TPMS will not function and the low

tire pressure warning light will flash

for approximately 1 minute. The light

wil l remain on after the 1 minute.

Have your tires replaced and/or

TPMS sys tem reset as soon as pos-

sible. It is recommended you visit an

INFINITI retailer for these services.

.Replacing tires with those not origin-

al ly specified by INFINITI could affect

the proper operatio n o f the TPMS.

CAUTION

.The TPMS is not a substitute for the

regular tire pressure check. Be sure to

check the tire pres sure reg ularly.

.If the vehicle is being driven at speeds

of less than 16 MPH (25 km/h), the

Instruments and controls 2-15

Infiniti Q60 (2020) Manual

Produkt Specifikationer

Har du brug for hjælp?

var Infiniti Manualer

var Manualer

Nyeste var Manualer
