Side 1/6

2 3

Funciones del display

190.00 mm

130.00 mm

16 15 14 13 12 11

7. Microphone Volume Knob: Use this knob to adjust the microphone volume levels.

8. Microphone Echo Knob: Use this knob to adjust the microphone echo levels.

9. Guitar volume knob: use this knob to adjust the volume of the guitar.

10. external Dc12V Input

11.

Microphone Priority: When the microphone priority is activated,speaking into the

microphone

will automatically lower the other audio signal 20dB.

12. Next Track / Next FM Station (CH+): When using the speaker in USB / TF Card &

Bluetooth mode, press this button to go to the next track.When using the speaker in FM mode,

press this button to go to the next stored FM station.

13. 13.Play/Pause & FM Scan: Press this button to pause the signal from the USB flash drive

TF Card or Bluetooth Inputs. When using the speaker in FM mode, press this button to auto

scan for all available stations. Each station will be stored. Press the CH+ and

CH- to choose a station.

14. Previous Track / Previous FM Station (CH-): When using the speaker in USB / TF Card &

Bluetooth mode, press this button to go to the previous track.When using the speaker in FM

mode, press this button to go to the previous stored FM station

15. Insert the microphone and insert a USB disk or TF card. Press and hold the REC button

on the rear panel for 3-5 seconds to enter the recording. To stop recording, press and hold the

REC button for 3-5 seconds. The recording file is saved in the USB flash drive or TF card.

Recorded files can be deleted on your computer.

16. Mode Selector : Press this button to switch between USB, TF ,FM and Bluetooth Inputs.

TWS:Press TWS button for 3 seconds for bluetooth pairing mode.

17. USB / TF Display Screen: The elapsed time and format will appear on this display screen

for the USB /TF Card inputs.

18. FM Antenna: For best results fully extend the antenna

19. RCA input: connect to CD/DVD, mp3 player, laptop or other audio source deviceThe

input.

20. Insert the guitar into the front panel guitar jack and adjust the guitar volume to the optimal

level.

21. Insert MICPHONE to front panel MIC jack,Adjust MIC VOL and Echo to best level.

22. LED Lights Power Button: Press this button to turn on and off the front LEDs

23. Power Switch: Press this switch turn on and off the speaker. Before powering on the

speaker make sure the volume levels are turned down to prevent damage to the amplifier or

speakers

24. Charging port: plug the power cord into the ac110-240v input port to charge the battery.

3.Main volume knob: use this knob to adjust the volume of USB/TF/BTL/FM music.

4.AUX Input: Connect your smartphone, mp3 player, laptop or other audio device to

this input.

5.Treble Knob: Use this knob to adjust the treble levels.

6.Bass Knob: Use this knob to adjust the bass levels.

1.USB Flash Drive Input: Insert your USB flash drive into this slot. The unit will only read

mp3, .wav, .wma files from the USB flash drive. The maximum storage size of the USB

flash drive cannot exceed 32GB. Do not attempt to connect a computer to the USB input

as the speaker will not be able to connect to a computer.

files from the TFCard flash drive cannot exceed 32GB

TF Input: Insert your TF Card into this slot. The unit will only read .mp3, .wav, .wma

When people sleep, they need a quiet environment.

Please turn off music or turn off the power while sleeping.

Prompt

Thank you for choosing and supporting our Multimedia Speaker Series Products.

Our company' s production management concept:” With talent for development,

with technology for innovation, with management for efficiency,with quality for survival

with service for market”,

Please read this instruction manual for easy operation.

1.SPECIFICATIONS:

K610

Power sup ply:AC110-240V 50/60Hz

Max Power consumption 100W:

Frequency response 45Hz - 22kHz

Signal to n oise ratio: 80dB≥

Speaker diameter:15"x2+1.5"

2. REMOTE CONTROL

TWS Function introduction and operation:

1.TWS is a wireless pairing between two

speakers in bluetooth mode.

2.When both speakers are switched to

bluetooth mode,Long press the TWS

function key on any machine for 3-5

seconds to enter the TWS matching

state.At this point, the two speakers will be

automatically paired and connected.When

hearing a ”dong“ sound of matching

successfully, at the same time LED display

prompt.

3.Then connect the bluetooth of the phone

to the speakers to play music, and the two

speakers will play music at the same time.

4.You must have a speaker with a TWS

function to use it

MANUAL DE USUARIO

USER'S MANUAL

MANUAL DE USUÁRIO

Produkt Specifikationer

Mærke:	Infiniton
Kategori:	Højttaler
Model:	K610
Produktfarve:	Sort
Udgangseffekt (RMS):	600 W
Fjernbetjening inkluderet:	Ingen
Forbindelsesteknologi:	Kabel & trådløs
